Haneco STAX-S Series User manual

Thanks for choosing our STAX LED Floodlight.
We strongly recommend that you read this manual carefully before installation.
Product Parameter
STAX-S
HANECO LED FLOODLIGHT INSTALLATION GUIDE
For more information
www.haneco.com.au
1300 001 LED
Product Dimension
PRODUCT CODE POWER VOLTAGE/
FREQUENCY PF OPERATING TEMPERATURE Net Weight
STAX10WB5K-S 10W
220 - 240V
50Hz - 60Hz
>0.8 -20° - 40° 0.34kg
STAX20WB5K-S 20W >0.9 -20° - 40° 0.49kg
STAX30WB5K-S 30W >0.9 -20° - 40° 0.67kg
STAX50WB5K-S 50W >0.9 -20° - 40° 0.99kg
10W 20W 30W 50W
L1 8mm 8mm 8mm 20mm
L2 30mm 40mm 55mm 35mm
L3 6.5mm 6.5mm 6.5mm 10.5mm
L4 6.5mm 6.5mm 6.5mm 6.5mm
L5 68mm 88mm 118mm 90mm
L6 85mm 85mm 85mm 110mm
L7 12mm 18mm 18mm 25mm
W103mm 133mm 163mm 178mm
10W 20W 30W 50W
L182mm 211mm 237mm 256mm
W113mm 143mm 173mm 183mm
D55mm 55mm 55mm 60mm
D
L6
L6
L7
L5

The luminaire must be installed by professional electrician.
Switch power o when wiring the luminaire.
Ensure input voltage conforms to the voltage range of product.
Ensure wires are securely connected.
Before switching on, ensure that all the wiring is correct.
The warranty is void if product is not installed according to the instructions.
WARNING Product Code: STAX10WB5K-S
STAX20WB5K-S
STAX30WB5K-S
STAX50WB5K-S
For more information
www.haneco.com.au
1300 001 LED
1. Ensure mains supply is switched o before commencing installation.
2. Mark wall with appropriate xing position and install the bracket.
Installation
3. Adjust luminaire to the desired angle.
5. Sensor function regulation.4. Connect the luminaire to the main supply using suitable IP rated enclosure.
Brown: L
Blue: N
Yellow & Green:
ART05062019
AMBIENT LIGHT 10-2000 lux
TIME DELAY 10 ± 3 seconds to
7 ± 2minutes
DETECTION DISTANCE 2 to 8m
DETECTION RANGE 120°
INSTALLATION HEIGHT 1.8m to 2.5m
1. To activate MANUAL MODE, switching OFF/ON momentary action at switch unit
once within 2 seconds. In MANUAL MODE, the unit will remain ON and it will not be
aected by the TIME and LUX controls.
2. To deactivate MANUAL MODE, switching OFF at the switch unit for 10 seconds
then switch ON. The PIR motion sensor will reset to warm-up period for 30 seconds
and returns to AUTO MODE.
Manual Override
