InstructionManual
HI 208 HI 207
EducationalpH/Temperature
BenchMeters
withBuilt-inStirrer
Dear Customer,
Thank you for choosing a Hanna Instruments
Product.
Please read this instruction manual carefully
before using the instrument. If you need addi-
tional technical information, do not hesitate to
e-mail us at [email protected].
These instruments are in compliance with
the directives.
All Hanna Instruments meters are warranted
for two years against defects in workmanship
and materials when used for their intended pur-
pose and maintained according to instructions. The
probe is warranted for a period of six months.
This warranty is limited to repair or replacement
free of charge. Damage due to accidents, misuse,
tampering or lack of prescribed maintenance are
not covered.
If service is required, contact the dealer from whom
you purchased the instrument. If under warranty,
report the model number, date of purchase, serial
number and the nature of the problem. If the repair
is not covered by the warranty, you will be noti-
fied of the charges incurred. If the instrument is to
be returned to Hanna Instruments, first obtain a
Returned Goods Authorization Number from the
Customer Service department and then send it
with shipment costs prepaid. When shipping any
instrument, make sure it is properly packaged for
complete protection.
All rights are reserved. Reproduction in whole or in
part is prohibited without the written consent of the
copyright owner.
WARRANTY
PRELIMINARY EXAMINATION
Remove the instrument from the packing
material and examine it carefully to make
sure that no damage has occurred during
shipment. If noticeable damage is evident,
notify your dealer.
Each instrument is supplied with:
•HI 1291D pH/Temperature probe with DIN
connector and 0.5 m (1.6’) cable
•pH 4.01 & 7.01 buffer solutions (20 mL each)
• Plastic beaker
• Electrode holder
• Rubber O-ring
•Magnetic stir bar (HI 208 only)
•12Vdc power adapter
•Instruction manual
Note: Save all packing material until you
are sure that the instrument functions
correctly. All defective items must be
returned in the original packing to-
gether with the supplied accessories.
HI 207 and HI 208 are microprocessor-based
pH and temperature bench meters.
Main features include: extended pH and tem-
perature ranges; built-in magnetic stirrer (HI 208
only); large dual-line display; automatic pH cali-
bration at one or two points, with two memo-
rized buffer sets (standard or NIST); selectable
temperature unit (°C or °F).
The pH electrode has a built-in temperature
sensor for simultaneous pH and temperature
readings, and also contains a mini amplifier to
render measurements impervious to noise and
electrical interferences.
GENERAL DESCRIPTION
SPECIFICATIONS
Range (*) -2.00 to 16.00 pH
-5.0 to 105.0 °C / 23.0 to 221.0 °F
Resolution 0.01 pH
0.1 °C / 0.1 °F
Accuracy ±0.02 pH
(@20°C/68°F) ±0.5 °C up to 60 °C; ±1 °C outside
±1 °F up to 140 °F; ±2 °F outside
TypicalEMC ±0.02 pH
Deviation ±0.2 °C or ±0.4 °F
Temperature Automatic
Compensation
pHCalibration Automatic, 1 or 2 point
with 2 sets of standardized buffers
(pH 4.01/7.01/10.01 or 4.01/6.86/9.18)
Probe (included) HI 1291D
amplified pH/Temperature probe
with DIN connector and 0.5 m (1.6’) cable
Stirrer (HI 208 only) Built-in magnetic stirrer
at 500 rpm
Power supply 12 Vdc adapter
or 9V alkaline battery
Battery life Approx. 200 hours
without stirrer
Environment 0 to 50 °C (32 to 122 °F);
max RH 95%
Dimensions 192x 104x134 mm (7.6x4.1 x5.3”)
Weight 420 g (14.8 oz.)
(*) The temperature range is limited to 80 °C (176 °F)
if using the HI 1291D probe.
Hanna Instruments reserves the right to modify
the design, construction and appearance of its
products without advance notice.
LCD DESCRIPTION
1
2
1
3
9
8
7
6
4
5
IST208 05/05
w w w.hannainst.com
FUNCTIONAL DESCRIPTION
STIR
ON/OFF
HOLD
SET
ON/OFF
MODE
HI 208
pH meter
1
2 3 5 64
7
9
10 11
8
Front Panel
1- Liquid Crystal Display (LCD).
2- ON/OFF/MODE key, to turn the instrument
ON or OFF, to quit calibration/freezing
mode or to set parameters in SETUP.
3- HOLD/SET key, to freeze the display, to select
the temperature unit or the calibration buffer
set, or to reset to the default calibration.
4- Stirrer status LED indicator (HI 208 only).
5- STIR ON/OFF key (HI 208 only), to start/
stop the stirrer.
6- Electrode holder.
Rear Panel
7- Plastic beaker.
8- Beaker holder.
9- Magnetic stir bar (HI 208 only).
10- DIN connector for probe.
11- Socket for power adapter.
1. Automatic Temperature Compensation
indicator
2. Stability indicator
3. Battery percentage
4. pH calibration indicator
5. Battery indicator
6. Selectable temperature unit
7. Secondary display
8. Primary display
9. pH measurement unit
www.tools.in.th
www.neonics.co.th

To connect the probe
With the instrument OFF, connect the HI 1291D
probe to the DIN connector on the rear panel of
the instrument by aligning the pins and pushing it
in the plug. Tighten the nut to ensure a good con-
nection.Removethe protectivecapfromtheprobe
before taking any measurements.
To turn the meter ON
Plug the 12 Vdc adapter into the appropriate
socket or use a 9V alkaline battery to power on
the instrument.
Press the ON/OFF/MODE key until the display
lights up. At start up, all the LCD segments are
displayed for one second, then the percentage
of the remaining battery life is shown for an-
other second (e.g. % 98 BATT). The instrument
then enters normal measurement mode.
Note: If the display needs to be checked, keep
the ON key pressed while turning the
meter on. The meter will display all seg-
ments as long as the key is pressed.
Note: If using a battery and its percentage is
under 15%, the stirrer will not work.
To freeze the display
While in measurement mode, press the HOLD/
SET key. The "HOLD" message will appear on
the secondary display and the reading will be fro-
zen on the LCD (e.g. pH 5.73 HOLD). Press any
key to return to normal measurement mode.
To turn the meter OFF
While in normal measurement mode, press the
ON/OFF/MODEkey.The"OFF"messagewillap-
pear on the secondary display. Release the key.
Note: The instrument is provided with an
acoustic signal feature, which is heard
every time a key is pressed.
Note: When the instrument detects the absence
oftheprobe,the"ATC"tagturnsoffandthe
secondary display shows a default tem-
perature value of 25 °C (77 °F) blinking.
Whenthe probe isconnected,the instrument
automatically returns to the Automatic Tem-
peratureCompensation mode,the"ATC"tag
turns on, and the measured temperature is
shown on the secondary display.
INSTRUMENT SETUP
The SETUP mode allows the selection of the
temperature unit and the pH buffer set.
To enter SETUP mode, press and hold the ON/
OFF/MODE key until "CAL" message on the
secondary display is replaced by "TEMP" and
the current temperature unit (e.g. TEMP °C).
Then:
•for°C/°Fselection,usetheHOLD/SETkey.After
the temperature unit has been selected, press
the ON/OFF/MODE key to enter the buffer set
selection mode; press ON/OFF/MODE twice to
return to normal measurement mode.
•to change the calibration buffer set, after setting
the temperature unit, the instrument will show the
current buffer set: "pH 7.01 BUFF" (for 4.01/7.01/
10.01) or "pH 6.86 BUFF" (for 4.01/6.86/9.18).
ChangethesetwiththeHOLD/SETkey,thenpress
ON/OFF/MODE to return to normal mode.
• Make sure the instrument has been calibrated
before use.
• If the probe is dry, soak it in HI 70300 storage
solution for one hour to reactivate it.
• Make sure that the stirrer LED is off or press the
STIRON/OFFkeytostopthestirrer(HI208only).
• Place the beaker with the solution to be tested
into the beaker holder and attach the electrode
holder.
• Insert the probe in the electrode holder and use
the supplied rubber O-ring for probe in order to
immersetheprobetipapproximately4cm(1½")
into the sample to be measured.
• Press STIR ON/OFF to start the stirrer (HI 208
only) and wait until the stability indicator turns off.
While the stirrer is on, the stirrer LED also is on.
• The LCD shows the pH value automatically
compensated for temperature variations and
the temperature of the solution.
• If measurements are taken in different samples
successively, rinse the probe tip thoroughly to
eliminate cross-contamination. After cleaning,
rinse the probe tip with some of the sample to
be measured.
pH calibration
For better accuracy, frequent calibration of the
instrument is recommended. In addition, the
instrument must be recalibrated whenever:
a) The pH electrode is replaced.
b) After testing aggressive chemicals.
c) Where high accuracy is required.
d) At least once a week.
• From normal mode press and hold the ON/OFF/
MODE key until "OFF" message on the second-
ary display is replaced by "CAL". Release the key.
• The LCD enters the calibration mode, displaying
"pH7.01USE"(or"pH6.86USE"iftheNISTbuffer
set was selected) and "CAL" tag blinking. After 1
second the instrument activates the automatic
buffer recognition feature. If a valid buffer is de-
tected, then its value is shown on the primary dis-
play, and "REC" message appears on the sec-
ondary display. If no valid buffer is detected, the
instrument keeps the "USE" message active for
12 seconds, and then replaces it with "WRNG", to
indicate an invalid buffer.
HI 1291D pH/Temperature probe with DIN
connectorand 0.5 m(1.6’)cable
HI 7004 pH 4.01 buffer solution, 500 mL
HI 7006 pH 6.86 buffer solution, 500 mL
HI 7007 pH 7.01 buffer solution, 500 mL
HI 7009 pH 9.18 buffer solution, 500 mL
HI 7010 pH 10.01 buffer solution, 500 mL
HI 70300L Storage solution, 500 mL
HI 7061L Cleaning solution, 500 mL
ACCESSORIES
BATTERY REPLACEMENT
Battery replacement must only take place in a
non-hazardous area and using the battery type
specified in this instruction manual.
Simply rotate the battery cover from the bottom of
the instrument as shown in the figure, and replace
the battery while paying attention to the correct po-
larity. Replace the cover.
O
P
E
N
C
L
O
S
E
OPERATIONAL GUIDE pH MEASUREMENT & CALIBRATION • For a single-point calibration with pH 4.01, 9.18
or 10.01 buffer, the meter automatically accepts
the calibration when the reading is stable; the
meterwill showtheaccepted buffer,with the "OK
1" message, and an audible signal is produced.
After 1 second the meter automatically returns to
normal measurement mode.
If a single-point calibration with pH 7.01 or 6.86
buffer is desired, then after the calibration point
has been accepted, the ON/OFF/MODE key
must be pressed in order to return to normal
measurement mode. After the key is pressed,
theinstrument shows"7.01"(or "6.86") -"OK1",
and an audible signal is produced. After 1 second,
the instrument automatically returns to normal
measurement mode.
Note: For better accuracy it is always recom-
mended to carry out a two-point calibration.
• For a two-point calibration, place the probe in
pH 7.01 (or pH 6.86) buffer. After the calibration
point has been accepted, the pH 4.01 "USE"
message appears. The message is held for
12 seconds, unless a valid buffer is recognized.
Ifnovalidbufferisrecognized,thenthe"WRNG"
message is displayed. If a valid buffer (pH 4.01,
pH 10.01 or pH 9.18) is detected, then the in-
strument completes the calibration procedure.
When the buffer is accepted, the LCD shows its
value with the "OK 2" message. The instrument
then returns to normal measurement mode.
Note: Whenthecalibrationprocedureiscompleted,
the "CAL" tag turns on.
To quit calibration and to reset to the default
values
• After entering the calibration mode and before the
first point is accepted, it is possible to quit the
procedureand return tothelastcalibrationdata by
pressingthe ON/OFF/MODEkey. Thesecondary
display shows "ESC" message for 1 second and
the instrument returns to normal mode.
• To reset to the default values and clear a previ-
ous calibration, press the HOLD/SET key after
entering calibration mode and before the first
point is accepted.
The secondary display shows "CLR" message
for 1 second, the instrument resets to the de-
fault calibration and the "CAL" tag turns off.
www.tools.in.th
www.neonics.co.th
