Instruction Manual
HI 207 • HI 208
Educational pH /
Temperature Bench Meters
with Built-in Stirrer
Dear Customer,
Thank you for choosing a Hanna Instruments product.
Please read this instruction manual carefully before using these
instruments. This manual will provide you with the necessary
information for correct use of these instruments, as well as a
precise idea of their versatility. If you need additional technical
information, do not hesitate to e-mail us at [email protected]
or view our worldwide contact list at www.hannainst.com.
HI 207 and HI 208 are guaranteed for two years against defects
in workmanship and materials when used for their intended
purpose and maintained according to instructions. The probe is
warranted for a period of six months. This warranty is limited to
repair or replacement free of charge. Damage due to accidents,
misuse, tampering or lack of prescribed maintenance is not
covered. If service is required, contact the dealer from whom you
purchased the instrument. If under warranty, report the model
number, date of purchase, serial number and the nature of the
problem. If the repair is not covered by the warranty, you will
be notified of the charges incurred. If the instrument is to be
returned to Hanna Instruments, first obtain a Returned Goods
Authorization Number from the Technical Service department
and then send it with shipping costs prepaid. When shipping
any instrument, make sure it is properly packed for complete
protection. To validate your warranty, fill out and return the
enclosed warranty card within 14 days from the date of
purchase.
Allrightsarereserved.Reproductioninwholeorinpartisprohibitedwithoutthe
writtenconsentofthecopyrightowner.
WARRANTY
PRELIMINARY EXAMINATION
Remove the instrument from the packing material and examine
it carefully to make sure that no damage has occurred during
shipment. If noticeable damage is evident, notify your dealer.
Each instrument is supplied with:
•HI 1291D pH/Temperature probe with DIN connector and
0.5 m (1.6’) cable
•pH 4.01 & 7.01 buffer solutions (20 mL each)
•Plastic beaker
•Electrode holder
•Rubber O-ring
•Magnetic stir bar (HI 208 only)
•12Vdc power adapter
•Instruction manual
Note:Save all packing material until you are sure that the
instrument functions correctly. All defective items must
be returned in the original packing together with the
supplied accessories.
HI 207 and HI 208 are microprocessor-based pH and temperature
bench meters.
Main features include: extended pH and temperature ranges;
built-in magnetic stirrer (HI 208 only); large dual-line display;
automatic pH calibration at one or two points, with two
memorized buffer sets (standard or NIST); selectable temperature
unit (°C or °F).
The pH electrode has a built-in temperature sensor for simultaneous
pH and temperature readings, and also contains a mini
amplifier to render measurements impervious to noise and
electrical interferences.
GENERAL DESCRIPTION
SPECIFICATIONS
Range (*) -2.00 to 16.00 pH
-5.0 to 105.0 °C / 23.0 to 221.0 °F
Resolution 0.01 pH
0.1 °C / 0.1 °F
Accuracy ±0.02 pH
(@20°C/68°F) ±0.5 °C up to 60 °C; ±1 °C outside
±1 °F up to 140 °F; ±2 °F outside
Typical EMC ±0.02 pH
Deviation ±0.2 °C or ±0.4 °F
Temperature Automatic
Compensation
pH Calibration Automatic, 1 or 2 point
with 2 sets of standardized buffers
(pH 4.01/7.01/10.01 or 4.01/6.86/9.18)
Probe (included) HI 1291D
amplified pH/Temperature probe
with DIN connector and 0.5 m (1.6’) cable
Stirrer (HI 208 only) Built-in magnetic stirrer
at 500 rpm
Power supply 12 Vdc adapter
or 9V alkaline battery
Battery life Approx. 200 hours
without stirrer
Environment 0 to 50 °C (32 to 122 °F);
max RH 95%
Dimensions 192 x 104 x 134 mm (7.6 x 4.1 x 5.3”)
Weight 420 g (14.8 oz.)
(*) The temperature range is limited to 80 °C (176 °F) if using
the HI 1291D probe.
LCD DESCRIPTION
1
2
1
3
9
8
7
6
4
5
www.hannainst.com
FUNCTIONAL DESCRIPTION
STIR
ON/OFF
HOLD
SET
ON/OFF
MODE
HI 208
pH meter
1
2 3 5 64
7
9
10 11
8
FRONT PANEL
1. Liquid Crystal Display (LCD).
2. ON/OFF/MODE key, to turn the instrument ON or OFF, to
quit calibration/freezing mode or to set parameters in
SETUP.
3.HOLD/SET key, to freeze the display, to select the
temperature unit or the calibration buffer set, or to reset to
the default calibration.
4. Stirrer status LED indicator (HI 208 only).
5. STIR ON/OFF key (HI 208 only), to start/stop the stirrer.
6. Electrode holder.
REAR PANEL
7. Plastic beaker.
8. Beaker holder.
9. Magnetic stir bar (HI 208 only).
10. DIN connector for probe.
11. Socket for power adapter.
1. Automatic Temperature Compensation indicator
2. Stability indicator
3. Battery percentage
4. pH calibration indicator
5. Battery indicator
6. Selectable temperature unit
7. Secondary display
8. Primary display
9. pH measurement unit
Hanna Instruments reserves the right to modify the design, construction or
appearance of its products without advance notice.
IST208 02/13

To connect the probe
With the instrument OFF, connect the HI 1291D probe to the DIN
connector on the rear panel of the instrument by aligning the pins
and pushing it in the plug. Tighten the nut to ensure a good
connection. Remove the protective cap from the probe before taking
any measurements.
To turn the meter ON
Plug the 12 Vdc adapter into the appropriate socket or use a
9V alkaline battery to power on the instrument.
Press the ON/OFF/MODE key until the display lights up. At start
up, all the LCD segments are displayed for one second, then the
percentage of the remaining battery life is shown for another
second (e.g. ”% 98 BATT”). The instrument then enters normal
measurement mode.
Note:If the display needs to be checked, keep the ON key pressed
while turning the meter on. The meter will display all
segments as long as the key is pressed.
Note:If using a battery and its percentage is under 15%, the
stirrer will not work.
To freeze the display
While in measurement mode, press the HOLD/SET key. The ”HOLD”
message will appear on the secondary display and the reading will
be frozen on the LCD (e.g. ”pH 5.73 HOLD”). Press any key to
return to normal measurement mode.
To turn the meter OFF
While in normal measurement mode, press the ON/OFF/MODE
key. The ”OFF” message will appear on the secondary display.
Release the key.
Note:The instrument is provided with an acoustic signal feature,
which is heard every time a key is pressed.
Note:When the instrument detects the absence of the probe, the
”ATC” tag turns off and the secondary display shows a
default temperature value of 25 °C (77 °F) blinking. When
the probe is connected, the instrument automatically
returns to the Automatic Temperature Compensation mode,
the ”ATC” tag turns on, and the measured temperature is
shown on the secondary display.
INSTRUMENT SETUP
The SETUP mode allows the selection of the temperature unit and
the pH buffer set.
To enter SETUP mode, press and hold the ON/OFF/MODE key
until ”CAL” message on the secondary display is replaced by
”TEMP” and the current temperature unit (e.g. ”TEMP °C”).
Then:
• for °C/°F selection , use the HOLD/SET key. After the temperature
unit has been selected, press the ON/OFF/MODE key to enter
the buffer set selection mode; press ON/OFF/MODE twice to
return to normal measurement mode.
• to change the calibration buffer set , after setting the temperature
unit, the instrument will show the current buffer set: ”pH 7.01
BUFF” (for 4.01/7.01/10.01) or ”pH 6.86 BUFF” (for 4.01/
6.86/9.18). Change the set with the HOLD/SET key, then
press ON/OFF/MODE to return to normal mode.
•Make sure the instrument has been calibrated before use.
•If the probe is dry, soak it in HI 70300 storage solution for one
hour to reactivate it.
•Make sure that the stirrer LED is off or press the STIR ON/OFF
key to stop the stirrer (HI 208 only).
•Place the beaker with the solution to be tested into the beaker
holder and attach the electrode holder.
•Insert the probe in the electrode holder and use the supplied
rubber O-ring for probe in order to immerse the probe tip
approximately 4 cm (1½") into the sample to be measured.
•Press STIR ON/OFF to start the stirrer (HI 208 only) and wait
until the stability indicator turns off. While the stirrer is on, the
stirrer LED also is on.
•The LCD shows the pH value automatically compensated for
temperature variations and the temperature of the solution.
•If measurements are taken in different samples successively,
rinse the probe tip thoroughly to eliminate cross-contamination.
After cleaning, rinse the probe tip with some of the sample to be
measured.
pH calibration
For better accuracy, frequent calibration of the instrument is
recommended. In addition, the instrument must be recalibrated
whenever:
a) The pH electrode is replaced.
b) After testing aggressive chemicals.
c) Where high accuracy is required.
d) At least once a week.
•From normal mode press and hold the ON/OFF/MODE key
until ”OFF” message on the secondary display is replaced by
”CAL”. Release the key.
•The LCD enters the calibration mode, displaying ”pH 7.01
USE” (or ”pH 6.86 USE” if the NIST buffer set was selected)
and ”CAL” tag blinking. After 1 second the instrument activates
the automatic buffer recognition feature. If a valid buffer is
detected, then its value is shown on the primary display, and
”REC” message appears on the secondary display. If no valid
buffer is detected, the instrument keeps the ”USE” message
active for 12 seconds, and then replaces it with ”WRNG”, to
indicate an invalid buffer.
HI 1291D pH/Temperature probe with DIN connector and
0.5 m (1.6’) cable
HI 7004 pH 4.01 buffer solution, 500 mL
HI 7006 pH 6.86 buffer solution, 500 mL
HI 7007 pH 7.01 buffer solution, 500 mL
HI 7009 pH 9.18 buffer solution, 500 mL
HI 7010 pH 10.01 buffer solution, 500 mL
HI 70300L Storage solution, 500 mL
HI 7061L Cleaning solution, 500 mL
ACCESSORIES
BATTERY REPLACEMENT
Battery replacement must only take place in a non-hazardous
area and using the battery type specified in this instruction manual.
Simply rotate the battery cover from the bottom of the instrument
as shown in the figure, and replace the battery while paying
attention to the correct polarity. Replace the cover.
O
P
E
N
C
L
O
S
E
OPERATIONAL GUIDE pH MEASUREMENT & CALIBRATION
•For a single-point calibration with pH 4.01, 9.18 or 10.01
buffer, the meter automatically accepts the calibration when
the reading is stable; the meter will show the accepted buffer,
with the ”OK 1” message, and an audible signal is produced.
After 1 second the meter automatically returns to normal
measurement mode.
If a single-point calibration with pH 7.01 or 6.86 buffer is
desired, then after the calibration point has been accepted, the
ON/OFF/MODE key must be pressed in order to return to
normal measurement mode. After the key is pressed, the instrument
shows ”7.01” (or ”6.86”) - ”OK 1”, and an audible signal is
produced. After 1 second, the instrument automatically returns
to normal measurement mode.
Note:For better accuracy it is always recommended to carry out a
two-point calibration.
•For a two-point calibration , place the probe in pH 7.01 (or pH
6.86) buffer. After the calibration point has been accepted, the
pH 4.01 ”USE” message appears. The message is held for
12 seconds, unless a valid buffer is recognized. If no valid buffer
is recognized, then the ”WRNG” message is displayed. If a
valid buffer (pH 4.01, pH 10.01 or pH 9.18) is detected, then
the instrument completes the calibration procedure. When the
buffer is accepted, the LCD shows its value with the ”OK 2”
message. The instrument then returns to normal measurement
mode.
Note:When the calibration procedure is completed, the ”CAL”
tag turns on.
To quit calibration and to reset to the default values
•After entering the calibration mode and before the first point is
accepted, it is possible to quit the procedure and return to the
last calibration data by pressing the ON/OFF/MODE key. The
secondary display shows ”ESC” message for 1 second and the
instrument returns to normal mode.
•To reset to the default values and clear a previous calibration,
press the HOLD/SET key after entering calibration mode and
before the first point is accepted.
The secondary display shows ”CLR” message for 1 second, the
instrument resets to the default calibration and the ”CAL” tag
turns off.
