HI99161
Waterproof pH / Temperature
Meter for Food and Dairy
Products
INSTRUCTION MANUAL

All rights are reserved. Reproduction in whole or in part is
prohibited without the written consent of the copyright owner, Hanna
Instruments Inc., Woonsocket, Rhode Island, 02895, USA.
Thank you for choosing a Hanna Instruments product.
Please read this instruction manual carefully before
using this meter.
This manual will provide you with the necessary
information for correct use of this meter, as well as
a precise idea of its versatility.
If you need additional technical information, do not
hesitate to e‑mail us at [email protected] or view
our worldwide contact list at www.hannainst.com.
Dear
Customer,

3
TABLE OF CONTENTS
Table of Contents......................................................
Preliminary Examination ...........................................
General Description and Intended Use........................
Main Features..........................................................
Specifications...........................................................
Display Description...................................................
Operational Guide ....................................................
Meter Setup.............................................................
Battery Replacement.................................................
Accessories...............................................................
Electrode Maintenance..............................................
Certification..............................................................
Recommendations for Users ......................................
Warranty .................................................................
4
5
7
9
15
6
8
16
14
3
17
18
19
19

4
PRELIMINARY EXAMINATION
Remove the meter from the packing material and examine
it carefully to make sure that no damage has occurred
during shipment. If noticeable damage is evident, contact
your local Hanna Instruments Office.
Each meter is supplied complete with:
• FC2023 preamplified pH/temperature probe with DIN
connector and 1 m (3.3’) cable, conical tip
• pH 4.01 & 7.01 Buffer sachet
• HI700601 Electrode cleaning solution (2 sachets)
• 100 mL beaker (1 pc.)
• Alkaline batteries: 1.5V AAA (3 pcs.)
• Rugged carrying case
• Calibration certificate of meter
• Calibration certificate of probe
• Instruction manual
Note: Save all packing material until you are sure that
the meter functions correctly. All defective items must
be returned in the original packing together with the
supplied accessories.

5
GENERAL DESCRIPTION and INTENDED USE
The HI99161 is a portable, lightweight meter with two
button operation that is simple to use. It is designed
specifically for use in the food sector. Features include a
waterproof and compact casing, large dual‑line display,
low battery detection, automatic pH calibration at one or
two points and selectable temperature unit (°C or °F).
The meter is supplied with a pH electrode specially designed
for use in the food sector.
The FC2023 pH electrode has a built‑in temperature sensor
for simultaneous temperature compensated pH and tem‑
perature readings, and also contains an integral preamplifier
to provide measurements impervious to noise and electrical
interferences.
TheFC2023 isapenetrationstyle pH electrode with aconical
sensing tip and features an easy to clean, PVDF body and
double junction gel filled reference with a free diffusion
sleeve style reference junction. The electrode is ideal for
measurements in semisolid foods such as processed meats,
soft cheeses, soups, sauces, condiments, jams, jellies,
dough, ice cream, sushi and rice.

6
MAIN FEATURES
Main features:
• Simultaneous pH and temperature measurements on a
large dual‑line LCD display
• Automatic pH calibration at one or two points within
two memorized buffer sets (standard or NIST)
• Selectable temperature unit (°C or °F)
• Electrode condition indicator
• mV of pH measurement for electrode check
• FC2023 dedicated pH with integral temperature sensor
• Probe quick connect system
• Battery life indication and low battery detection
• Keystroke confirmation tone
• Auto‑off function
• Waterproof casing IP67
pH meter

7
Range*
‑2.00 to 16.00 pH / ‑2.0 to 16.0 pH
±825 mV (pH‑mV)
‑5.0 to 105.0 °C/23.0 to 221.0 °F
Resolution
0.01 pH / 0.1 pH
1 mV
0.1 °C/0.1 °F
Accuracy
@ 20 °C / 68 °F
±0.02 pH / ±0.1 pH
±1 mV (pH‑mV)
±0.5 °C up to 60 °C; ±1.0 °C outside
±1.0 °F up to 140 °F; ±2.0 °F outside
Temperature
compensation
Automatic
‑5.0 to 105.0 °C/23.0 to 221.0 °F
pH Calibration
Automatic, 1 or 2 point selectable buffer
set Standard: 4.01;7.01;10.01 or
NIST: 4.01;6.86;9.18
Probe (included)
FC2023 preamplified pH/temperature
probe with DIN connector and 1 m
(3.3’) cable
Battery type / life 1.5V AAA (3 pcs.)
approx. 1400 hours of continuous use
Auto‑Off user selectable: after 8 min, 60 min or
disabled
Environment 0 to 50 °C (32 to 122 °F)
RH max. 100%
Meter Dimensions 154 x 63 x 30 mm (6.1 x 2.5 x 1.2”)
Meter Mass
(with batteries) 196 g (6.91 oz.)
Case Ingress
Protection Rating IP67
SPECIFICATIONS
* the FC2023 is limited to be used from 0 to 12 pH and from 0 to
50 °C temperature (32 to 122 °F).

8
DISPLAY DESCRIPTION
1 Automatic Temperature Compensation indicator
2 Stability indicator
3 Battery percentage
4 Electrode condition indicator
5 Low battery indicator
6 Measurement unit
7 Primary LCD
8 Temperature unit
9 Secondary LCD
10 Meter modes indicator
11 pH calibration buffer(s) used

9
OPERATIONAL GUIDE
Each meter is supplied with batteries. Before using the
meter for the first time, open the battery compartment
and insert batteries, observing the polarity (see “Battery
Replacement“).
TO CONNECT THE ELECTRODE
With the meter turned off, connect the FC2023 probe to the
DIN socket on the bottom of the meter by aligning the pins
and pushing in the plug firmly. Remove the protective cap
from the probe before taking any measurements.
TO TURN THE METER ON
To turn the meter ON, press the button on the front of the
meter. If it does not turn on, make sure that the batteries are
properly installed in their place. The meter is provided with
an active acoustic signal when a key is pressed. At start‑up
the meter displays all LCD segments for a few seconds, fol‑
lowed by the percentage indication of the remaining battery
life, displaying “WAIT“ until electrode check is in process
then the meter enters the normal measurement mode.
Note: The meter detects the presence and the type of
the probe at its input.
- If the probe is not connected the message “NO”
”PROBE“ appears alternatively on the secondary LCD
with “---“ blinking on the first LCD line.
- If the probe is not compatible “WRONG” ”PROBE“
message appears alternatively on the secondary LCD
with “---“ blinking on the first LCD line.
- If the readings are out of range, the nearest range limits
are displayed blinking (E.g. -2.00 pH -5.0 °C).
Battery life
Measurement
mode
LCD
check up
→ →
→
Electrode
check

10
OPERATIONAL GUIDE
pH MEASUREMENT & CALIBRATION
Make sure the meter has been calibrated before use.
If the probe is dry, soak it in HI70300 storage solution for
30 minutes to reactivate it. If fouled, clean the electrode
by soaking in cleaning solution for 20 minutes, then rinse
the tip and soak in storage solution at least 30 minutes
before use.
Rinse the electrode off well and shake off excess droplets.
Recalibrate before using.
Submerge the probe in the sample to
be tested while stirring it gently. Wait
until the tag on the LCD disappears.
→
TO SELECT THE MEASUREMENT RANGE
While in measurement mode, press the SET button to select
pH or pH‑mV measurement on the first LCD line.
TO FREEZE THE MEASUREMENT VALUES
While in measurement mode, press and hold the SET
button until “HOLD“ appears on the secondary LCD. The
“HOLD“ remains for 1 second and reading of pH, mV
and temperature will be frozen on the LCD with“H” blinking.
Press any button to resume active measurements.
TO ENTER CALIBRATION MODE
Press and hold the button until ”POWER” and tag
is replaced by “STD“ and tag. Release the button.
TO ENTER SETUP MODE
Press and hold button until “STD“ and tag is
replaced by “SETUP“ and tag. Release the button.
TO TURN THE METER OFF
Whileinmeasurementmode,pressthe button.”POWER”
and tag will appear. Release the button.

11
OPERATIONAL GUIDE
The LCD displays the pH value (auto‑
matically compensated for tempera‑
ture) on the primary LCD, while the
secondary LCD displays the sample
temperature. If measurements are
taken in different samples successively, rinse the probe tip
thoroughly†to eliminate cross‑contamination.
For better accuracy, frequent calibration of the pH sensor
with the meter is recommended. In addition, the meter
must be recalibrated whenever:
a) The pH electrode is replaced.
b) After testing aggressive chemicals.
c) Where high accuracy is required.
d) At least once a month.
e) After cleaning the sensor.
†The probe tip should be rinsed with purified water (reverse
osmosis, distilled, or deionized) before and after placing in
any solution (buffer, storage or sample).
pH calibration
Enter calibration mode while in pH measurement mode.
Place the sensor into the first calibration buffer. If perform‑
ing a two‑point calibration, use pH 7.01 (pH 6.86 for NIST)
buffer first. The meter will enter the calibration mode,
displaying “pH 7.01 USE” and tag blinking (or
“pH 6.86 USE” for NIST).
Follow directions for single and two‑point calibration below:
Single-point calibration
1. Place the probe in any buffer from the selected buffer set.
The meter will automatically recognize the buffer value.
2. If the buffer is not recognized or the calibration offset is
out of the accepted range “---- WRONG“ is displayed.
3. If the buffer is recognized “REC“ is displayed then
“WAIT“ until the calibration is accepted.
If using pH 7.01 (or pH 6.86 for NIST), after acceptance
of the buffer press any key to exit. The ”SAVE” message is
displayed and the meter returns to pH measurement mode.

12
OPERATIONAL GUIDE
If using pH 4.01 or 10.01 (or pH 9.18 for NIST) buffer
the ”SAVE” message is displayed and meter returns to pH
measurement mode.
Two-point calibration
Proceed with steps 1 through 3 under single point calibra‑
tion using 7.01 (pH 6.86 for NIST) pH buffer first. Then
follow steps below:
The ”pH 4.01 USE” message is then displayed.
Place the probe in the second calibration buffer (pH 4.01
or 10.01, or, if using NIST, pH 4.01 or 9.18). When the
second buffer is accepted, the LCD will display “SAVE”
for 1 second and the meter will return to the normal
measurement mode.
If the buffer is not recognized or the slope is out of accepted
range ”--- WRONG” is displayed. Change the buffer, clean
the electrode or press any key to exit calibration.
It is always recommended to carry out a two‑point calibra‑
tion for better accuracy.
When the calibration procedure is completed, the tag
is turned on together with the calibrated points.
To exit calibration and reset default values
After entering the calibration mode and before the first point
is accepted, it is possible to quit the procedure and return
to the last calibration data by pressing the button. The
LCD displays “ESC“ for 1 second and the meter returns to
normal mode.
To reset the default values and clear a previous calibration,
press the SET button after entering the calibration mode
and before the first point is accepted.
The LCD displays “CLEAR“ for 1 second, the meter resets to
the default calibration and the tag with the calibrated
points on the LCD disappears.

13
ELECTRODE CONDITION
The display is provided with a probe icon (unless the fea‑
ture is disabled from setup) which indicates the electrode
status after calibration. The “condition” remains active for
12 hours (unless the batteries are removed).
The electrode condition is evaluated only if the current
calibration has two points.
5 bars: excellent condition
4 bars: very good condition
3 bars: good condition
2 bars: fair condition
1 bar: poor condition
1 bar blinking: very poor condition
With 1 bar it is recommended to clean the electrode and
recalibrate. If there is still only 1 bar or 1 bar blinking
replace the probe.
Sensor Check
Setting the meter to pH‑mV range the user can check the
sensor status at any time. The offset value is the reading
in pH 7.01 buffer (@ 25 °C/77 °F). If this reading is
outside the range ±30 mV, the electrode is considered
“very poor”. The slope value of the sensor is the difference
between readings in pH 7.01 and in pH 4.01 buffers. When
the slope reaches the value of about 150 mV, the electrode
is considered “very poor“. When “poor“ or “very poor“, it
is recommended to replace it with a new one.
Note: To ensure reliable readings, the electrode must
be cleaned with cleaning solution and then hydrated in
storage solution for a minimum of 30 minutes before
calibrating the probe.
OPERATIONAL GUIDE

14
METER SETUP
Setup mode allows the selection of the Temperature unit,
Auto‑off, Beep, the type of pH buffer set, the Resolution and
Information. To enter Setup mode press and hold button
until “STD“ and tag is replaced by “SETUP“ and
tag. Release the button.
• “TEMP“ is displayed on the second‑
ary LCD with the current temperature
unit (E.g. “TEMP °C“), for °C/°F
selection, use the SET button. After
the temperature unit has been selected,
press to confirm and to enter the
“A-OFF“ selection.
• Use the SET button, to cycle through
the auto‑off choices: 8 minutes (“8”,
default value), 60 minutes (“60”) or
disabled (“---”). Press to confirm
and to enter the “BEEP“ selection.
• To switch ON or OFF the beep tone,
press the SET button; press to
confirm and to enter the calibration
buffer selection “pH 7.01 BUFF“.
• To change the type of calibration buf‑
fer set, the meter will show the current
buffer set: “pH 7.01 BUFF” (for stan‑
dard buffer set: 4.01/7.01/ 10.01)
or “pH 6.86 BUFF” (for NIST buffer
set: 4.01/6.86/ 9.18). Change the set
with the SET button. Press to con‑
firm and to enter pH resolution selection
“RESOL“.
• To change the pH measurement reso‑
lution between “0.1“ and “0.01“ use
the SET button; then press to con‑
firm and to enter electrode calibra‑
tion information “INFO“ selection .
• To switch ON or OFF the electrode
condition indicator on the LCD, press
the SET button; press to exit setup
options; Change the set with the SET
button, then press to confirm and
to return to normal mode.

15
Replace the three 1.5V AAA alkaline batteries located in
the battery compartment, observing the indicated polarity.
BATTERY REPLACEMENT
When the remaining battery life is less
than 10% the battery tag blinks on the
display to warn the user.
Battery Error Prevention System (BEPS)
If the battery is too weak (“0%”) the display shows
“bAtt“, “DEAD“ for few seconds then the meter power off.
Immediately replace the batteries with new ones.
The batteries are accessed by opening the battery cover
on the back of the instrument. Remove protective boot
if present.
BATTERY REPLACEMENT
Replace the battery cover making sure that the gasket is
in place.

16
Code and serial
number on the
other side
Quick connector with
Rubber protection, and
1 meter cable
FC2023
Preamplified pH/temperature probe
with DIN connector and 1 m (3.3’)
cable, conical tip
HI7004L pH 4.01 buffer solution, 500 mL
HI7006L pH 6.86 buffer solution, 500 mL
HI7007L pH 7.01 buffer solution, 500 mL
HI7009L pH 9.18 buffer solution, 500 mL
HI7010L pH 10.01 buffer solution, 500 mL
HI70300L pH electrode storage solution, 500 mL
HI7061L pH electrode cleaning solution, 500 mL
HI710029 Silicon rubber boot blue color
HI76405 Electrode holder
HI77400P Calibration kit (pH 4 & 7, 20 mL,
5 pcs. each)
ACCESSORIES
Reference junction
Temperature sensor
pH bulb

17
ELECTRODE MAINTENANCE
PREPARATION
• Remove the protective cap. DO NOT BE ALARMED IF
ANY SALT DEPOSITS ARE PRESENT. Rinse with water.
• Shake the electrode down as you would do with a
clinical thermometer to eliminate any air bubbles inside
the glass bulb.
• If the bulb and/or junction are dry, soak the electrode in
HI70300 Storage Solution for a minimum of 30 minutes.
• Rinse with water.
• Calibrate before using.
STORAGE
• To ensure a quick response, the glass bulb and the junction
should be kept moist and not allowed to dry.
• Replace protective cap with a few drops of HI70300
Storage Solution. Follow PREPARATION above before
taking measurements.
Note: NEVER STORE THE ELECTRODE IN DISTILLED WATER.
PERIODIC MAINTENANCE
• Inspect the electrode for any scratches or cracks. If any
present, replace the electrode.
• Rinse off any salt deposits with water.
• Follow the STORAGE procedure above.
CLEANING PROCEDURE
• Soak in Hanna HI7061 General Cleaning Solution for
20 minutes. Rinse well and calibrate before using.
IMPORTANT: After performing any of the cleaning
procedures rinse the electrode thoroughly with distilled
water. Soak the electrode in HI70300 Storage Solution
for a minimum of 30 minutes. Rinse with water. Calibrate
before using.
TROUBLESHOOTING
• pH Meter: Follow the meter’s operating and calibration
procedures.
• Electrode: Evaluate your electrode performance based on
the SENSOR CHECK procedure on page 13.

18
All Hanna Instruments conform to the CE European
Directives.
Disposal of Electrical & Electronic Equipment. The
product should not be treated as household waste. Instead
hand it over to the appropriate collection point for the
recycling of electrical and electronic equipment which will
conserve natural resources.
Disposal of waste batteries. This product contains
batteries, do not dispose of them with other household
waste. Hand them over to the appropriate collection point
for recycling.
Ensuring proper product and battery disposal prevents
potential negative consequences for the environment and
human health. For more information, contact your city,
your local household waste disposal service, the place of
purchase or go to www.hannainst.com.
RoHS
compliant
CERTIFICATION
MAN99161 04/18

19
HI99161 is warranted for two years against
defects in workmanship and materials when
used for its intended purpose and maintained
according to instructions. This warranty is
limited to repair or replacement free of
charge. Damage due to accidents, misuse,
tampering or lack of prescribed maintenance
is not covered.
If service is required, contact your local Hanna
Instruments Office. If under warranty, report
the model number, date of purchase, serial
number (see engraved in the back of the
meter) and the nature of the problem. If the
repair is not covered by the warranty, you will
be notified of the charges incurred. If the meter
is to be returned to Hanna Instruments, first
obtain a Returned Goods Authorization number
from the Technical Service department and
then send it with shipping costs prepaid. When
shipping any meter, make sure it is properly
packed for complete protection.
Warranty
Hanna Instruments reserves the right to modify the design,
construction or appearance of its products without advance notice.
Before using this product, make
sure it is entirely suitable for your
specific application and for the en‑
vironment in which it is used. Any
variation introduced by the user
to the supplied equipment may
degrade the meters’ performance.
For yours and the meter’s safety
do not use or store the meter in
hazardous environments.
Recommendations
for Users

Printed in ROMANIA
World
Headquarters
Hanna Instruments Inc.
Highland Industrial Park
584 Park East Drive
Woonsocket, RI 02895 USA
www.hannainst.com
MAN99161
Local Office
Hanna Instruments Inc.
270 George Washington Highway
Smithfield, RI 02917
Phone: [phone]
Fax: [phone]
e‑mail: [email protected]
