Harbor Freight Tools 57896 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
57896
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 20k
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2020 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 57896
Specifications
LEDs 24 SMD LEDs (lantern)
1 COB LED (fan)
Fan Runtime
4 hr (High)
5 hr (Medium)
12 hr 30 min (Low)
Lantern Runtime
4 hr (High)
7 hr (Medium)
13 hr 30 min (Low)
Fan LED Runtime
9 hr (High)
18 hr (Medium)
35 hr(Low)
Combined Runtime
(Fan and Lantern)
2 hr (High)
4 hr 30 min (Medium)
7 hr (Low)
Battery 3.7V / 4000 mAh
Polymer Li Battery
IMPORTANT SAFETY INFORMATION
Use Precautions
1. This product is not a toy. Do not allow
children to play with or near this item.
2. Use as intended only.
3. Inspect before every use; do not use
if parts are loose or damaged.
4. Do not stare into beam or shine beam into eyes. May
cause temporary or permanent damage to eyes.
5. Do not drop lantern.
6. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
Changing Mode
1. To change lantern intensity, press the “Lantern” switch
to switch between High, Medium, Low, and Off.
2. To change fan LED mode, press the “Lighting” switch
to switch between 100%, 50%, 20%, and Off.
3. To change fan speed, press the “Fan” switch to
switch between Low, Medium, High, and Off.
Figure A: Button Layout

Page 3For technical questions, please call 1-888-866-5797.Item 57896
Micro USB Input and USB Output
1. Move USB port cover. Note: The cover cannot
be completely removed from the item.
2. Use micro USB cable to charge item.
3. Charging indicator will turn red while
charging. Charging indicator will turn
green after the item is fully charged.
4. After the product is fully charged, a mobile device
can be charged via the larger USB Output port.
Figure B: Port Layout
Battery Removal and Disposal
1. To remove the battery, remove the
screws on bottom of the lantern.
2. Remove outer housing for the lantern; the battery
is located in a center compartment of the lantern.
3. Remove the battery from the compartment
and dispose of properly.
Parts List and Diagram
Part Description Qty
1 Fan LED 1
2 Fan Switch 1
3 Lantern Switch 1
4 Fan LED Lighting Switch 1
5 Lantern 1
Part Description Qty
6 Hanger 1
7 Charging LED Indicator 1
8 Micro USB Port 1
9 USB Port 1
10 Fan 1
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175425195 when ordering parts.
