Harbor Freight Tools 94723 Quick reference guide

ASSEMBLY & OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web Site at www.harborfreight.com
Copyright©2006 by Harbor Freight Tools®. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
For technical questions and replacement parts please call 1-800-444-3353.
®
94723
Due to continuing improvement, actual product may differ slightly from the product described herein.
UTILITY STOOL
300 LB. MAXIMUM CAPACITY

SKU 94723 For technical questions please call 1-800-444-3353. Page 2
THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please
complete the owner’s record below:
Model______________ SerialNo._____________ PurchaseDate_______________
SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the
entire manual to become familiar with the unit BEFORE you begin assembly.
Technical Specifications
Wood Type: 1/2” compressed wood board
Maximum Weight: 300 Lbs. evenly distributed
Weight: 6.35
Assembled Dimensions: 14-1/4” H X 11-1/4” L X 12”W
Tool Holders: 28 for various sizes
Tool Holder Dimensions: 9-1/4” L X 3” Deep
Support Panels: 9” L X 3-5/8” H X 1/2” W
Frame Legs: 13-3/4” H X 1” X 0.04” Thick
InsideBaseArea: 10-7/8” L X 10-1/4” W
Safety Warnings and Precautions
WARNING:When using product, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this product!
1. Keep work area clean. Cluttered areas invite injuries.
2. Check for damaged parts. Before using any product, any part that appears damaged should
be carefully checked to determine that it will operate properly and perform its intended function.
Check for any broken or damaged parts and any other conditions that may affect its operation.
Replace or repair damaged or worn parts immediately.
3. Replacement parts and accessories. When servicing, use only identical replacement parts.
Use of any other parts will void the warranty.
4. Always check hardware and assembled parts after assembling. All connections should be
tight and hardware tightened.
5. Keep children away. Children must never play on or climb on the Stool.
6. Dress properly. Gloves are recommended when assembling the Utility Stool. Wear restrictive
hair covering to contain long hair.
7. Use eye protection. Always wear ANSI-approved impact safety goggles when assembling
this product.
8. Maintain product with care. Keep the Stool in a dry location.

SKU 94723 For technical questions please call 1-800-444-3353. Page 3
9. Use the right Stool for the situation. There are certain applications for which this Utility
Stool was designed. Do not modify this Stool and do not use this Stool for a purpose
for which it was not intended.
10. Sit on the Stool in a safe fashion. Make certain that weight on the Utility Stool is evenly
distributed.
11. Do not use or assemble the Stool if under the influence of alcohol or drugs. Read
warning labels on prescriptions to determine if your judgement or reflexes are impaired while
taking drugs. If there is any doubt, do not assemble or use the Stool.
12. Do not exceed the Utility Stool’s maximum weight capacity of 300 Lbs. (evenly
distributed).
WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by
the operator that common sense and caution are factors which cannot be built into
this product, but must be supplied by the operator.
Assembly/ Operation
Your Utility Stool will require complete assembly. It is important that you read the entire manual to
become familiar with the product BEFORE you assemble and use the Stool. Before assembling the
Stool be sure that you have all parts described in the Parts List and Assembly Diagram located on
page 5 of this manual.
1. Attach one Leg (4) to each side side of Side Cross Beam (5). Set the Side Cross Beam (5)
against the Leg (4) with bottom holes lined up as shown in Figure 1 and Assembly Diagram.
Secure Leg to Side Cross Beam (5) with two sets of Nuts and Bolts (10). Repeat for second
Side Cross Beam (5) and two Legs (4).
2. Attach one Main Cross Beam (6) to each of the sections assembled in Step 1. Secure the
one Main Cross Beam (6) to the Legs using four sets of Nuts and Bolts (10) -see Figure 1
and Assembly Diagram. Please note: Although the Side Cross Beams (5) and Main Cross
Beams (6) may look identical, the Side Cross Beams (5) are approximately 3/8” shorter.
3. Slide the Bottom Shelf (2) onto the bottom lips of the Main Cross Beam (6) and Side Cross
Beams (5) as assembled in Steps 1 and 2. Make certain that the Bottom Shelf (2) slides in
place under the ends of the Nuts and Bolts (10) as in Figure 1.
Leg (4)
Side Cross Beam (5) Main Cross
Beam (6)
Bottom Shelf (2)
Nuts & Bolts (10)
Figure 1
Foot (7)

SKU 94723 For technical questions please call 1-800-444-3353. Page 4
4. Attach remainsing Main Cross Beam (6) to Legs (4). Secure with Nuts and Bolts (10).
5. Attach Angle Braces (8) to the StoolTop (1) making certain that outside end of Angle
Braces (8) line up with the outside of the Stool Top (1). Screw into place with Screws (9)-
see Figure 2.
6. Use Nylon Nuts and Bolts (10) to attach each Leg (4) to the Angle Braces (8) mounted to the
StoolTop (1)-see Figure 2.
7. Attach theTool Holder (3) to the front of the Utility Stool. Line upTool Holder (3) with the
holes midway up the Legs (4). Secure in place using Nylon Nut and Bolt (11) on each side.
Screw (9)
Nylon Nut and Bolt (11)
StoolTop (1)
Figure 2
Part # Description Quantity Part # Description Quantity
1 StoolTop 1 6 Main Cross Beam 2
2 Bottom Shelf 1 7 Feet 4
3 Tool Holder 1 8 Angle Brace 4
4 Legs 4 9 Screws 4
5 Side Cross Beam 2 10 Nuts & Bolts 16
11 Nylon Nuts & Bolts 6
8. Attach one Foot (7) to the bottom of each Leg (4).
Parts List
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE
TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY
KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT,THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED
TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER
REPAIRSTOTHE ORIGINAL PRODUCT OR REPLACEMENT PARTSTHERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Angle Brace (8)

SKU 94723 For technical questions please call 1-800-444-3353. Page 5
