LUX LIGHT METER
MODEL 91194
OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http//www.harborfreight.com
Copyright 2004 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor FreightTools.
For technical questions, please call 1-800-444-3353.
®
©

Item Description
Electrical Requirements One 9-Volt Battery (Not Included)
Display 3-1/2 Digit with a Maximum Display Reading of 1999
Measuring Range 1 ~ 2,000, 20,000, 50,000 Lux
Repeatability ±2%
Overrange Display The Highest Display Digit “1”
Accuracy ±4% Reading ±0.5% Full-Scale
±4% Reading ±5 digit (10,000 -50,000 Lux)
±5% Reading ±10 digit (50,000+ Lux)
Measuring Rate 2.0 times/sec.
Photo Detector One Silicon Photo Diode
Temperature Characteristic ±0.1%/°C
Accessories Carrying Case
Weight 0.7 Pounds
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures, parts list and assembly
diagram. Keep your invoice with this manual. Write the invoice number on the inside of
the front cover. Keep this manual and invoice in a safe and dry place for future refer-
ence.
UNPACKING
When unpacking, check to make sure all the parts shown in this manual and the
carrying case are included. If any parts are missing or broken, please call Harbor Freight
Tools at the number shown on the cover of this manual as soon as possible.
SKU 91194 PAGE 2
GENERAL SAFETY WARNINGS AND PRECAUTIONS
1. Check for damaged parts. Before using this product, carefully check that it will
operate properly and perform its intended function. Check for damaged parts and
any other conditions that may affect the operation of this product.
NOTE: Individual replacement parts are not available for this product.
2. Maintain this product with care. Keepthisproductclean and drywhen in use and
during storage for better product performance. Service and maintenance should
be performed regularly by a qualified technician. When in use, the Photo Detector
(5) (white sphere) must be kept clean.

SKU 91194 PAGE 3
3. Use the right product for the job. There are certain applications for which this
product was designed. Do not modify this product, and do not use this product for
a purpose for which it was not intended.
4. Maintain labels and nameplates on this product. These carry important infor-
mation. If unreadable or missing, contact Harbor Freight Tools for a replacement.
5. Do not use this product in excessive heat and humidity conditions.
6. Do not allow children to handle this product. This product is constructed with
small parts that may pose a serious choking hazard if swallowed.
7. WARNING! The warnings, precautions, and instructions discussed in this manual
cannot cover all possible conditions and situations that may occur. The operator
must understand that common sense and caution are factors, which cannot be built
into this product, but must be supplied by the operator.
OPERATING INSTRUCTIONS
NOTE: For additional references to the parts listed in the following pages refer to
Figure A, below.
POWER SWITCH (2)
LCD DISPLAY (1)
RANGE SELECTION SWITCH (3)
DATA HOLD SWITCH (4)
PHOTO DETECTOR (5)
FIGURE A
1. Press the Power Switch (2) to turn the Light Meter “ON”. Press the Power Switch
again to turn the Light Meter “OFF”. (See Figure A.)
2. Press the Range Selection Switch (3) to select between the ranges of 1 ~ 2,000/
20,000/50,000(200,000) Lux. At the same time, the LCD Display (1) will indicate
the value by which to multiply to receive the correct value.(See Figure A.)

SKU 91194 PAGE 4
3. Face the Photo Detector (5) in a horizontal position toward the light source.
(See Figure A, previous page.)
4. Read the number on the LCD Display (1). If the LCD Display only shows “1”, the
input signal is too strong and a higher measuring range should be selected.
(See Figure A.)
5. Press the Data Hold Switch (4) and “H” will illuminate on the LCD Display (1). The
most recent value will continue to show on the LCD until the Power Switch (2) is
pressed or the Data Hold Switch is pressed again. (See Figure A.)
6. After completing the measurement, make sure the Light Meter is turned “OFF” and
the Photo Detector (5) is covered. Then, store the unit in its Carrying Case.
(See Figure A.)
TO REPLACE THE BATTERY
When the 9 volt Battery (not included) becomes low, the letters “BT”
will illuminate on the LCD Display (1). To replace the Battery, remove the
Screw on theBattery Compartment Door located on the back of the Light
Meter. Then remove the Battery Compartment Door by sliding it down. Re-
move the old Battery. Install a new 9 volt Battery. Then, replace the Battery
Compartment Door and the Screw. (See Figure B.)
BATTERY
COMPARTMENT
DOOR
FIGURE B
REAR VIEW
SCREW

SKU 91194 PAGE 5
SPECTRAL SENSITIVITY
Please Note:
While the manufacturer has made every effort to ensure this is a
reliable and accurate tool, neither Harbor Freight Tools nor the manu-
facturer can be held responsible for any errors in lighting placement/
adjustment; the costs of any wasted film, time, etc.; or any other costs
incidental to any errors in measurement.
SPECTRAL SENSITIVITY CHARACTERISTICS
RELATIVE
SENSITIVITY
(%)
100
80
60
40
20
0400 500 600 700
LIGHT
METER
-V(r)
FIGURE C
INSPECTION, MAINTENANCE, AND CLEANING
1. Before each use, inspect the general condition of the Light Meter. Check for bro-
ken, loose or missing parts; low Battery; any condition that may affect the proper
operation of the product. If a problem occurs, have the problem corrected before
further use. Do not use damaged equipment.
2. Do not use abrasives or solvents to clean this product.
NOTE: No individual replacement parts are available for this product.
WAVELENGTH (nm)
