Harbor Freight Tools 42295 User manual

Pressure Washer
Cart
with 10” Tires
Model 4229542295
4229542295
42295
Assembly & Operating Instructions
Copyright 1999 by Harbor Freight Tools.All Rights Reserved.
No portion of this manual or any artwork contained herein may be reproduced in any
manner, shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
www.HarborFreight.com

Construction: 12 GaugeSheetSteel
Wheels: 10”Diam.x 4” - 30psi
AllTerrainTread
Hub: 4-1/2”Diameterfor 3/4” axle
Axle: 3/4”
Handle: 12”Wx31”H x7/8”Diameter
BaseDimensions: 19-1/8”L x 12-1/4”W
OverallDimensions: 30”Lx 23-1/2”W x 36-1/2”H
NetWeight: 34 Lbs.
MODEL# 42295 PRESSURE WASHER CARTSPECIFICATIONS
PRODUCTFEATURES
1. This cart provides a convenient, movable storage and work unit for pressure washers, air
compressors, tool chests and other items.
2. Hold up to 300 Lbs. recommended weight limit. Do not exceed this weight capacity.
3. Strong steel construction promises long service life.
4. Sturdy pneumatic wheels are inflatable, and have built in brass grease ports.
5. Built in hooks and tool hangers simplify storing and using pressure washer wand, hoses and
other tools.
SAVETHIS MANUAL
You will need this manual for the safety warnings and cautions, assembly instructions, operating
procedures, maintenance procedures, trouble shooting, parts list, and diagram. Keep your invoice
with this manual. Write the invoice number on the inside of the front cover. Keep both this manual
and your invoice in a safe, dry place for future reference.
Page 2 SKU # 42295
NOTICE
The Warnings, Cautions, and Instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by
the operator that common sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS
MANUAL AS A REFERENCE TOOL ONLY: NEITHER THE MANUFACTURER NOR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR
SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT: IN FACT THE MANUFACTURER A
ND/OR DISTRIBUTOR EXPRESSLY STATES THATALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE
BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER
REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

SAFETYWARNING& CAUTIONS
READALLINSTRUCTIONSBEFORE USING THIS TOOL!
1. KEEP WORK AREA CLEAN.Clutteredareasinviteinjuries.Donot use tools in damp, wet,
orpoorlylitlocations.Don’t expose to rain. Keep workareawelllit.
2. KEEPCHILDRENAWAY. Childrenmustneverbeallowedintheworkarea.Donotletthem
handlemachines, tools,or equipment.
3. STOREIDLEEQUIPMENT.Whennotinuse,toolsmustbelockedup in a dry location to
inhibitrust.Always lock uptoolsandkeep out ofreachofchildren.
4. DO NOT FORCE THE TOOL. It willdothe job better and more safely at therateforwhich
itwasintended.Do not use inappropriateattachmentsinanattemptto exceed the tool’s
capacities.
5. USE THE RIGHT TOOL FOR THEJOB.Do not use a tool for apurpose for which it was not
intended.
6. DRESS PROPERLY. Donotwearlooseclothing or jewelry,astheycan be caughtinmoving
parts.Non-skidfootwear isrecommended.Wearrestrictive haircoveringtocontainlong hair.
Alwayswearappropriate workclothing.
7. DO NOT OVERREACH. Keep proper footing and balanceatalltimes.Do not reach over or
acrossrunningmachines.
8. MAINTAINTOOLSWITHCARE.Keeptoolsmaintainedandcleanforbetterandsafer
performance.
SPECIALWARNINGSWHEN USINGTHIS PRESSUREWASHER CART
1. Wearappropriateworkgloves andsafetyshoeswhenhandling thiscartandheavy items.
2. Be careful whenhandlingpressurewashers,air compressors, orothertools.Eachof these
presenttheir ownhazards.Check withthemanufacturer’swarningsandinstructionswhen
usingthesetoolsandmaterials.
3. Keep the weightloadevenlybalancedonthecart. Excessively heavy loads onthetoporone
sideofthe cartmaycreateunstability,with dangerofthecarttoppling overandpossibly
injuringapersonorcausingproperty damage.
4. Do notusesolventsor flammablematerialstocleanthiscart.A milddetergentinwater
willbesufficient.Solventsmaydamagethewheelsorthepaint;andpossiblycreatefirehazard.
5. Be careful toavoidburningyourself on the pressurewashercompressoror air compressor.
Page 3 SKU # 42295 REV01/04
WARNING
Do not overload this cart, recommended weight limit is 300 Lbs.
Do not unbalance the weight load of materials carried on this cart.
When parking this cart, make sure it is on a stable, level surface to prevent rolling.
MAINTENANCE
1. Occasionally lubricatewheelbearings withafew dropsofoil.
2. Keep the tires inflated to the pressure shown onthesideofthetires(30psi).
3. Keep the cart wiped down andclean.Do not expose it to prolonged wetorcorrosive
conditions.
4. Cover the cart andstoreitinadry,protectedenvironment when not in use.

ASSEMBLY
You will need a small adjustable or several small wrenches and a screwdriver to complete assembly
of this Pressure Washer Cart.
1. Find a suitable assembly area, andarrangethepartsandtoolsrequiredtoassembletheCart.
2. Position one Lower Handle Part (#D) onto an inside edge of the rear of the Main Cart (#A)as
showninFigure1.
3. Insert (2) m8 x 40Bolts(#K)throughtheMainCartandtheLowerHandle from the outside
inward,asshown.Fasteninplaceusing(2)m8 FlatWashers (#M) anfd m8 Nuts (#L).
4. Repeat Step3toinstallthe remainingLowerHandlePart.
5. Slide one PneumaticWheel (#B) onto an axle as shown. Slide an m06FlatWasher (#P) onto
theaxle.SecuretheWheelontotheaxleusingaPushNut(#C).SecurethePushNutontothe
axlebytapping itontotheaxle withasoft facedmallet.Donot hammerexcessivelyonthe
pushnut.
6. Install the otherwheelbyrepeating Step 5.
7. If the RubberFeet(#G)arenot already installed, installthemusing(2)m8 x 26 Bolts(#N)
andm8LockNuts(#O).Insert a bolt through the recessed side of a rubber foot, then through
aholedrilledin the bracket welded totheundersideofthemaincart. Secure in place witha
locknut.Repeatthisprocessto install the second rubber foot.
8. Slide the MainHandlewithPlate(#E)over the swaged endsofthelowerhandleparts. Hold
inplacebyinsertingaCarriageBolt(#F)througheachhandlefromtheinsideout,asshownin
thediagram.Besure the square under-head portionofeachboltfitsinto the square holesof
thehandle.Placean m20 FlatWasher (#J) over the threaded end of each carriage bolt, and
securein placewiththe AluminumKnobs(#F).
Page 4 SKU # 42295
PARTS LIST
Part # Description Qty
A Main Cart 1
B Pneumatic Wheel 2
C Push Nut 2
D Lower Handle 2
E Main Handle 1
F Aluminum Knob
w/ Carriage Bolt 2
G Rubber Foot 2
J Flat Washer m20 2
K Bolt m8 x 40 4
L Nut m8 4
M Flat Washer m8 4
N Bolt m8 x 26 2
O Lock Nut m8 2
P Flat Washer m6 2 Figure 1. Parts Diagram
