Harbor Freight Tools Chicago Electric 93432 User manual

Model 93432
ASSEMBLY AND OPERATING INSTRUCTIONS
CORDLESS SCREWDRIVER
3.6 VOLT LITHIUM (LI)
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2005 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 3
ELECTRICAL SAFETY
4. Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs. Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the tools should electrically malfunction or
break down, grounding provides a low resistance path to carry electricity away
from the user.
5. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the
three wire grounded power cord and grounded power supply system.
6. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
7. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools
or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,
sharp edges, or moving parts. Replace damaged Power Cords immediately.
Damaged Power Cords increase the risk of electric shock.
9. When operating a power tool outside, use an outdoor extension cord
marked “W-A” or “W”. These extension cords are rated for outdoor use, and
reduce the risk of electric shock.
PERSONAL SAFETY
10. Stay alert. Watch what you are doing, and use common sense when
operating a power tool. Do not use a power tool while tired or under the
influence of drugs, alcohol, or medication. A moment of inattention while
operating power tools may result in serious personal injury.
11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.
Keep your hair, clothing, and gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught in moving parts.
12. Avoid accidental starting. Be sure the Power Switch is off before plugging
in. Carrying power tools with your finger on the Power Switch, or plugging in
power tools with the Power Switch on, invites accidents.
13. Remove adjusting keys or wrenches before turning the power tool on. A
wrench or a key that is left attached to a rotating part of the power tool may result
in personal injury.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 4
14. Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of the power tool in unexpected
situations.
15. Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
TOOL USE AND CARE
16. Use clamps (not included) or other practical ways to secure and support
the workpiece to a stable platform. Holding the work by hand or against your
body is unstable and may lead to loss of control.
17. Do not force the tool. Use the correct tool for your application. The correct
tool will do the job better and safer at the rate for which it is designed.
18. Do not use the power tool if the Power Switch does not turn it on or off.
Any tool that cannot be controlled with the Power Switch is dangerous and must
be replaced.
19. Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing the tool. Such preventive
safety measures reduce the risk of starting the tool accidentally.
20. Store idle tools out of reach of children and other untrained persons. Tools
are dangerous in the hands of untrained users.
21. Maintain tools with care. Keep cutting tools sharp and clean. Properly
maintained tools with a sharp cutting edge are less likely to bind and are easier
to control. Do not use a damaged tool. Tag damaged tools “Do not use” until
repaired.
22. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool’s operation. If damaged, have
the tool serviced before using. Many accidents are caused by poorly
maintained tools.
23. Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one tool may become hazardous
when used on another tool.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 5
SERVICE
24. Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of injury.
25. When servicing a tool, use only identical replacement parts. Follow
instructions in the “Inspection, Maintenance, And Cleaning” section of this
manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES
1. Maintain labels and nameplates on the Screwdriver. These carry important
information. If unreadable or missing, contact Harbor Freight Tools for a
replacement.
2. Always wear ANSI approved safety impact eye goggles when using
the Screwdriver. Using personal safety devices reduce the risk for injury.
Safety impact eye goggles are available from Harbor Freight Tools.
3. Maintain a safe working environment. Keep the work area well lit. Make sure
there is adequate surrounding workspace. Always keep the work area free of ob-
structions, grease, oil, trash, and other debris. Do not use a power tool in areas
near flammable chemicals, dusts, and vapors. Do not use this product in a damp
or wet location.
4. Avoid unintentional starting. Make sure you are prepared to begin work
before turning on the Screwdriver.
5. Do not force the Screwdriver. This tool will do the work better and safer at
the speed and capacity for which it was designed.
6. Never leave the Screwdriver unattended when it is plugged into an
electrical outlet. Turn off the tool before leaving.
7. IMPORTANT: Carefully inspect the condition of the Screwdriver before use, and
check the tool continually during use. If any damage is noted, stop immediately
and repair or replace the Screwdriver.
8. When using a hand-held power tool, always maintain a firm grip on the tool
with both hands to resist starting torque.
9. The charge time for the Battery (31) is from 3 to 5 hours. Do not charge the
Battery for over 5 hours as damage to the Battery and/or Screwdriver may result.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 6
10. Always recharge the Battery (31) when tool performance begins to
diminish. Never over-discharge a Battery by using the tool even after tool
performance is decreasing. Never attempt to discharge a tool’s Battery by
continuing to pull the tool’s Forward/Reverse Switch (49). When tool performance
begins to diminish, stop the tool, and recharge the Battery for optimal
performance.
11. Battery (31) leakage may occur under extreme usage or temperature
conditions. If Battery fluid comes in contact with skin, wash with soap and water
and rinse with lemon juice and vinegar. If the fluid comes into contact with eyes,
flush with water for several minutes and contact a physician immediately.
12. Never burn a Battery (31), as it can explode in a fire. Contact local
solid waste authorities for instructions on correct disposal of a Battery.
13. Do not attempt to charge a leaking Battery (31).
14. Make sure the Forward/Reverse Switch (49) is in its “PAUSE” (middle)
position prior to performing any inspection, maintenance, or cleaning
procedures.
SAVE THESE INSTRUCTIONS
GROUNDING
WARNING!
Improperly connecting the grounding wire can result in the risk of electric shock.
Check with a qualified electrician if you are in doubt as to whether the outlet is
properly grounded. Do not modify the power cord plug provided with the tool.
Never remove the grounding prong from the plug. Do not use the tool if the power
cord or plug is damaged. If damaged, have it repaired by a service facility before
use. If the plug will not fit the outlet, have a proper outlet installed by a qualified
15. WARNING! People with pacemakers should consult their physician(s) be-
fore using this product. Operation of electrical equipment in close proximity to a
heart pacemaker could cause interference or failure of the pacemaker.
16. WARNING! The warnings and cautions discussed in this manual cannot
cover all possible conditions and situations that may occur. It must be understood
by the operator that common sense and caution are factors which cannot be built
into this product, but must be supplied by the operator.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 7
GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS
1. Tools marked with “Grounding Required” have a three wire cord and three prong
grounding plug. The plug must be connected to a properly grounded outlet. If the
tool should electrically malfunction or break down, grounding provides a low
resistance path to carry electricity away from the user, reducing the risk of
electric shock. (See Figure A.)
2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached
to an electrically “live” terminal. (See Figure A.)
3. Your tool must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like those in the following illustration. (See Figure A.)
3-PRONG
ELECTRICAL
PLUG 120 VOLT,
GROUNDED,
ELECTRICAL OUTLET
FIGURE A
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Tools marked “Double Insulated” do not require grounding. They have a special
double insulation system which satisfies OSHA requirements and complies with
the applicable standards of Underwriters Laboratories, Inc., the Canadian
Standard Association, and the National Electrical Code. (See Figure B.)
5. Double insulated tools may be used in either of the 120 volt outlets shown in the
following illustration. (See Figure B.)
FIGURE B
THE CHARGER (50)
FOR THIS PRODUCT
USES A
2-PRONG PLUG 120 VOLT,
GROUNDED,
ELECTRICAL
OUTLETS

SKU 93432 For technical questions, please call 1-800-444-3353. Page 8
EXTENSION CORDS
1. Grounded tools require a three wire extension cord. Double Insulated tools
can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a
serious drop in voltage, resulting in loss of power and possible tool damage.
(See Figure C.)
3. The smaller the gauge number of the wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure C.)
4. When using more than one extension cord to make up the total length, make
sure each cord contains at least the minimum wire size required.
(See Figure C.)
5. If you are using one extension cord for more than one tool, add the nameplate
amperes and use the sum to determine the required minimum cord size.
(See Figure C.)
6. If you are using an extension cord outdoors, make sure it is marked with the suf-
fix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.
7. Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified elec-
trician before using it.
8. Protect your extension cords from sharp objects, excessive heat, and damp or
wet areas.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 9
SYMBOLOGY
Double Insulated
Canadian Standards
Association
Underwriters
Laboratories, Inc.
Volts Alternating Current
Amperes
No Load Revolutions
per Minute (RPM)
no xxxx/min.
A
V ~
FIGURE D
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 13
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
ASSEMBLY AND OPERATING INSTRUCTIONS
NOTE:
For additional information regarding the parts listed in the
following pages, refer to the Assembly Diagram on page 13.
1. CAUTION! Always make sure the Forward/Reverse Switch (49) of the
Screwdriver is in its “PAUSE” (middle) position and the tool is disconnected from
its Charger (50) prior to assembling the tool, adding any accessories, or making
adjustments to the tool.
Charging and Re-Charging The Battery:
1. The Battery (31) for the Screwdriver must be fully charged before using the tool.
(See Figure E, next page.)
2. When charging for the first time, the charge time is 5 hours. Thereafter,
subsequent charge times are from 3 to 5 hours. Never charge the Battery (31)
for longer than 5 hours, as damage to the Battery and/or tool will occur.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 10
CHARGER
(50)
DC PLUG
(33)
PLUG ONLY INTO A
120 VOLT, GROUNDED
ELECTRICAL OUTLET
FIGURE E
3. To charge the Battery (31), insert the Charger’s (50) cable into the DC Plug (33)
located at the top of the Screwdriver body. (See Figure E.)
4. Plug the Charger (50) into a 120 volt, grounded, electrical outlet.
(See Figure E.)
5. Once the Battery is fully charged (within 3 to 5 hours) the Charger will
automatically shut off.
6. Once the Battery is fully charged, unplug the Charger (50) from its electrical
outlet. Then, remove the Charger’s cable from the DC Plug (33) of the
Screwdriver. (See Figure E.)
7. NOTE: While charging the Battery (31), the Charger (50) may feel warm to the
touch which is normal during the charging process. (See Figure E.)
Lithium Battery Charging Safety
Do not leave unattended while charging.1.
Battery charging should be done by adults only.2.
Charge on non-flammable surface and keep away from flammable items.3.
Turn charger off when battery is charged, and unplug charger from battery-pow-4.
ered device.
Disconnect AC wall chargers from outlets while not in use.5.
If battery-powered device has been damaged, immediately stop use, unplug, and6.
safely move away from flammable materials.
Follow instructions for charging battery. Do NOT charge longer than recommended.7.
REV 08c

SKU 93432 For technical questions, please call 1-800-444-3353. Page 11
To Install A Screwdriver Bit:
1. The chuck of the Screwdriver is a self-locking type. When a screwdriver bit (not
included) is inserted, the chuck will grip it automatically. If the bit is not long
enough for the chuck to securely grip, connect a magnetic extension rod (not
included) to the bit. To remove a bit, with a gloved hand, firmly pull the bit from
the Chuck. (See Figure F.)
FIGURE F
SCREWDRIVER BIT
(NOT INCLUDED)
CHUCK
The Forward/Reverse Switch:
1. For a clockwise rotation of the Screwdriver, squeeze the TOP portion of the
Forward/Reverse Switch (49). For a counterclockwise rotation, squeeze the
BOTTOM portion of the Forward/Reverse Switch. When the tool is not in use,
make sure the Forward/Reverse Switch is in its “PAUSE” (middle) position.
(See Figure G.)
FORWARD/REVERSE SWITCH
(49)
FIGURE G
CLUTCH CAP
(7)

SKU 93432 For technical questions, please call 1-800-444-3353. Page 12
To Adjust The Torque:
1. The Screwdriver is designed with 22 adjustable torque positions. To adjust the
torque, turn off the Screwdriver and wait until the screwdriver bit stops
rotating. Then, turn the Clutch Cap (7) to the desired setting. (See Figure G.)
Operating Tips:
1. When driving screws into wood or plastics, drill a pilot hole first in the workpiece.
Make sure the length and diameter of the hole is slightly less than that of the
actual screw. When driving screws into metal, drill a pilot hole slightly more than
that of the actual screw.
2. When finished using the Screwdriver, always remove the screwdriver bit and
store the tool in a clean, dry, safe location out of reach of children and other
unauthorized people.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 13
2. Before each use, inspect the general condition of the Screwdriver and its
Charger (50). Check for loose screws, misalignment or binding of moving parts,
cracked or broken parts, damaged electrical wiring, and any other condition
that may affect safe operation. If abnormal noise or vibration occurs, have the
problem corrected before further use. Do not use damaged equipment.
3. To clean the Screwdriver, use only a clean cloth and mild detergent. Do not use
solvents. Do not immerse any part of the tool in liquids.
4. When storing, make sure to store the tool in a clean, dry, safe location out of
reach of children and other unauthorized people.
5. CAUTION! All maintenance, service, or repairs not mentioned in this
manual must only be performed by a qualified service technician.
TROUBLESHOOTING
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND
NOT BY THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF HIS OR
HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
INSPECTION, MAINTENANCE, AND CLEANING
1. WARNING! Make sure the Forward/Reverse Switch (49) of the Screwdriver
is in its “PAUSE” (middle) position and the tool is disconnected from its Charger
(50) prior to performing any inspection, maintenance, or cleaning procedures.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 14
PARTS LIST AND ASSEMBLY DIAGRAM
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
1
2
4
5
3
6
7 8 9
101112 13
14
15
16
17
1819 20 21 22 23 24 25 26
27
28
29
30
31
3233
34
35
40
41, 42
37
45, 46
43, 44
47, 48
39
38
36
49
50: CHARGER NOT SHOWN.

SKU 93432 For technical questions, please call 1-800-444-3353. Page 15
LIMITED 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high
quality and durability standards, and warrants to the original purchaser that this prod-
uct is free from defects in materials and workmanship for the period of 90 days from
the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities,
criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental,
contingent, special or consequential damages arising from the use of our product. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESS-
LY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us
with transportation charges prepaid. Proof of purchase date and an explanation of the
complaint must accompany the merchandise. If our inspection verifies the defect, we
will either repair or replace the product at our election or we may elect to refund the
purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that
the defect resulted from causes not within the scope of our warranty, then you must bear
the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
