HARDWARE RESOURCES RSR Series User manual

STEP 1
Disassemble both the top and bottom mounting slides as
illustrated above.
STEP 2 - Top Installation
15”
2-3/8”
30”
15”15”
Using the tape measure and square layout and install top
mounting slide according to the dimensions shown above
using three (3)-#8 x 5/8”at head Philips wood screws
provided.
IMPORTANT:
Before you begin, make sure you familiarize yourself with all the
parts and fully read the instructions.
CUSTOMER SERVICE:
Toll free customer help line available weekdays between 7:00am
and 6:00pm Central Time at 800-463-0660.
TOOLS NECESSARY:
Screw gun, Phillips screwdriver, tape measure, and square. You
will also need an 8mm and 13mm open end wrench to fully
assemble this unit. NOTE: If screw gun has a clutch, set to lowest
setting so as not to over tighten and/or strip screws.
A Shelves RSR-12:12 pcs
RSR-08: 8 pcs
RSR-04: 4 pcs
B Top Slide 1 pcs
C Bottom Slide 1 pcs
D Control Arm 2 pcs
E Plastic Corner Connectors - Includeds #4 x 5/6
Washer Head Phillips Machine Screws
4 pcs
F Bearing Pin 2 pcs
G Connecting Pin 2 pcs
H Frame Crossbar 2 pcs
I Frame Upright 2 pcs
J 8 mm Nut 4 pcs
KMetal Washer 4 pcs
L 13 mm Cap Nut 2 pcs
M #4 x 5/16 Washer Head Phillips Machine Screw RSR-12: 48 pcs
RSR-08: 32 pcs
RSR-04: 16 pcs
N1/2” Silicone Washer 4 pcs
O1-3/8” Silicone Washer 2 pcs
P #8 x 5/8 Flat Head Phillips Wood Screw 7 pcs
DIMENSIONS:
Cabinet minimum opening: 30” wide x 15” deep x
12 Shelves 8 Shelves 4 Shelves
72” high 50” high 27-1/2”” high
PARTS IDENTIFICATION:
Rotating Shoe Rack
Installation Instructions
for the RSR Series

STEP 3 - Bottom Installation
15”
2-1/4”
30”
15”15”
Using the tape measure and square, layout and install bottom
mounting slide according to the dimensions shown above
using four (4)-#8 x 5/8”at head Philips wood screws provided.
STEP 4
Adjustment notch
E
Adjustment screw
H
I
Assemble the shoe rack frame as shown above by installing
the frame uprights and crossbars into the plastic corner
connectors. Make sure the adjustment notch of the
connector slides onto the uprights as shown. Attach
connectors using three (3)-#4 x 5/16”washer head Phillips
machine screws provided. Hand tighten adjustment screws
at this time.
STEP 5
N
K
J
L
O
N
K
J
N
K
J
L
O
J
K
N
G
G
Re-assemble the top and bottom mounting slides and then mount the main frame to the slides. See Diagram. Position the frame to
the desired height and tighten the four (4) adjustment screws as shown.
STEP 6
M
Using the #4 x 5/16”washer head Phillips machine
screws provided, attach the shelves to the frame as
shown.
RSR08/15 v.1
