VABCHES JY9947BS01 User manual

As this item contains many parts, please read the installation
instruction carefully before installation . Please use tools
properly and carefully. If you have any questions about the
product and installation, please contact us.
[email protected]
Our professional after-sales team will serve you online all
day.
JY9947BS01
1-44
WhatsApp community↑
[email protected]

Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing, please
pay attention to slow down and stop when screw is tight. Failure to do so
may result in stripping the screw.（Assembly speed can be increased
by using electric screwdriver）
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with an R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- If there is a back panel in the package, please install it to make sure your unit is complete
and sturdy.
-Please fix all the screws provided for the back panel which can enhance product stability. If
it is difficult to fix it when tightening, it can be fixed with the help of a hammer and then
tightened.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Before You Start
Helpful Hints
PEOPLE NEEDED FOR ASSEMBLY:1-2
2-44

A B
G
C
Board Identification
Not actual size
3-44
D E F
H I
BACK SLAT
Qty:1 LOWER BACK SLAT Qty:1 LEFT FRONT SLAT Qty:1
MIDDLE PANEL
Qty:1 FIXED SHELF
Qty:1 UPPER LEFT SIDE PANEL Qty:1

J K L
M N O
P Q R
Board Identification
Not actual size
4-44
UPPER RIGHT SIDE PANEL
Qty:1 UPPER LEFT MIDDLE PANEL
Qty:1 UPPER RIGHT MIDDLE LANEL
Qty:1
FIXED SHELF
Qty:4 HUTCH FIXED SHELF Qty:1 HUTCH SIDE PANEL Qty:2
HUTCH SIDE PANEL
Qty:2 HUTCH FIXED SHELF Qty:1 DESK BACK PANEL Qty:1

S T U
V W X
Y Z
AA
Board Identification
Not actual size
5-44
DESK BACK PANEL
Qty:1 DESK BACK PANEL Qty:1 DESK BACK PANEL Qty:1
DRAWER LEFT SIDE
Qty:2 DRAWER RIGHT SIDE Qty:2 DRAWER BACK PANEL Qty:2
DRAWER BOTTOM
Qty:2 LEFT DRAWER FRONT Qty:1 RIGHT DRAWER FRONT Qty:1

BB CC DD
EE FF
Board Identification
Not actual size
6-44
DRESSING MIRROR
Qty:1 STOOL SIDE PANEL
Qty:2 STOOL APRON
Qty:2
STOOL LOWER SLAT
Qty:1 SPONGE CUSHION
Qty:1

350mm 350mm 350mm 350mm
Part List
1
CAM LOCK
spare:3
X46 2
CAM BOLT
spare:3
X46 4X24
3X17
10
SCREW
spare:2
X27
14
SCREW
spare:1
X4
11
SCREW
spare:3
X40
9CL
LEFT CABINET MEMBER
X2
POWER STRIP
X1
HANDLE
X2 X2
13
7 8
Ø15X9.5mm Ø6.5X35mm
WOOD DOWEL
spare:2
WOOD DOWEL
spare:1
Ø6X30mm Ø8X30mm
Ø4X35mm
Ø3X12mm
Ø3.5X14mm
9CR
RIGHT CABINET MEMBER
X2 9DL
LEFT DRAWER RUNNER
X2 9DR
RIGHT DRAWER RUNNER
X2
M4X19mm
14" 14" 14" 14"
7-44
5
SCREW
spare:2
X22
Ø6X50mm
X1
HAIR DRYER RACK
109*99*38.5mm
16
HEX KEY
X1
64X65mm
12
SCREW
spare:3
X34
Ø3X14mm
Ø25X20mm
SCREW
spare:1
SCREW
spare:1
X2
Ø4X14mm
17
15
POWER PLUG
X1

Cam Lock
Fastening
System
12
34
The opening must point toward the
edge of the board
Insert the cam bolt into the
hole first, then insert the cam
lock and lock it.
Part List
8-44
18 X1 19 X12 21 X2 20 X2
22 X42 X1set
23
PERFECT STICKER
spare:3 HIPPING RESTRAINT
HARDWARE KIT
HOOKING PULLEY PULLEY THREAD CLASP
21X7.2X5.3mm Ø15X20mm 58X31X15mm 58X31X15mm
Ø21mm

Board Identification
Not actual size
9-44
S
R
T
U
I
KL
J
M
M
H
Q
N
P
BB
O
P
OA
B V
C
D
G
EF
Y
Y
X
XW
W
V
Z
AA
FF
CC CC
DD DD
EE

10-44
Flip
RIGHT CABINET MEMBER
9CR
UP
UP
11
11
11
UP
11
11
11
UP
LEFT CABINET MEMBER
9CR
STEP1
350mm 350mm
9CL X1 9CR X1
14" 14"
11 X6
Ø3.5X14mm
G
G

11-44
STEP2
5X2
Ø6X50mm X1
64X65mm
D
G
33X1
Ø8X30mm
3
5

12-44
10 X1
Ø4X35mm
D
G
F
STEP3
10

RIGHT CABINET MEMBER
9CR
LEFT CABINET MEMBER
9CL
13-44
C
B
UP
UP
350mm 350mm
9CL X1 9CR X1
14" 14"
11 X6
Ø3.5X14mm
UP
11
11
11
11
11
11
STEP4
UP

5X6
Ø6X50mm X1
64X65mm 22 X6
Ø21mm
22
5
D
G
E
B
STEP5
14-44

BE
D
G
C
5X6
Ø6X50mm X1
64X65mm 22 X6
Ø21mm
STEP6
15-44
5
22

16-44
3X8
Ø8X30mm
B
3
C
STEP7

17-44
A
2
2X10
Ø6.5X35mm
STEP8

P
18-44
4X8
Ø6X30mm
4
O
X2
X2
4
STEP9

19-44
10
PO
P
O
A
10 X8
Ø4X35mm
STEP10

20-44
1
B
C
A
P
PO
O
Proper orientation of CAM LOCK
UNLOCK
LOCK
Insert the cam bolt into
the hole first, then insert
the cam lock and lock it.
1X6
Ø15X9.5mm
STEP11
