HARDWARE RESOURCES 1523SC User manual

STEP 1
Determine the Mounting Height
32-5/8”
1523 = 25-1/2” - 35”
1532 = 33” - 48”
COMPRESSED LENGTH
Following the diagram, determine the best height for
your application.
IMPORTANT:
Before you begin, make sure you familiarize yourself with all the
parts and fully read the instructions.
CUSTOMER SERVICE:
Toll-free customer help line available weekdays between
7:00am and 6:00pm Central Time at 800-463-0660.
TOOLS NECESSARY:
Screw gun or Phillips screwdriver and tape measure. NOTE: If
screw gun has a clutch, set to lowest setting so as not to over
tighten and/or strip screws.
PARTS IDENTIFICATION:
A #3 x 3/8” Pan Head Screw 1X
B #8 x 1/2” Flat Head Phillips Wood Screw 12X
C #8 x 1” Flat Head Phillips Wood Screw 2X
D #8 x 1-3/8”Flat Head Allen Machine Screws 2X
EMounting Bracket 2X
F Left Hand (LH) Lift Arm 1X
G Right Hand (RH) Lift Arm 1X
H Side Bracket 2X
I Adjustable Rail 1X
J Adjustable Pole with Handle 1X
KAllen Wrench 1X
Soft-Close Wardrobe Lift
Installation Instructions for the 1523SC & 1532SC
LOOSEN TIGHTEN
A
C
C
D
K
J
I
G
H
H
F
E
E
B
WARNING
THIS PRODUCT IS UNDER EXTREME PRESSURE AND COULD
CAUSE SEVERE HARM IF NOT INSTALLED CORRECTLY!

STEP 2 - Install Mounting Brackets STEP 3 - Install Lift Arms
Install Mounting Brackets at desired height with twelve (12) #8 x 1/2”Flat Head Phillips Wood Screws
provided.
NOTE: If using a pre-drilled 32mm system, the front of the bracket can be mounted using 5mm Euro screws.
Install RH and LH Lift Arms by sliding into the brackets as shown. NOTE: Depending on the room
available, it may be necessary to fold down the Lift Arm before install. (PROCEED WITH CAUTION.
Lift Arm is under extreme pressure). Once fully seated in the Mounting Bracket, install one (1) #8 x 1”
Flat Head Phillips Wood Screw in the rear top hole of each Lift Arm to secure it in place.
STEP 2 - Install Rail and Pole STEP 3 - Install Handle and Final Adjustments
LOOSEN TIGHTEN
A
A
B
C
J
I
H
F
G
E
D
LOOSEN TIGHTEN
A
B
C
KH
F
G
E
D
Attach the Side Brackets to the Adjustable Rail with the two (2) #8 x 1-3/8” Flat Head Allen Machine
Screws provided. With Lift Arms in the down position, adjust the Adjustable Rail so that the Side
Brackets slide onto the ends of the Lift Arms as shown and tighten Side Brackets with Allen Wrench
provided. Slip the Adjustable Pole into the T-Bracket and fasten using one (1) #3 x 3/8” Pan Head
Screw.
Operate the lift by gently pushing upward on the handle. Check clearance of Adjustable Rail from
side to side and adjust accordingly. Center the T-Bracket on the Adjustable Rail and slide the rubber
O-rings tight against both sides of the T-Bracket to hold it in place. Adjust Handle Pole to desired
length as shown.
15xxSC12/15 v.1
#8 x 1”Flat Head
Phillips Wood Screw
#8 x 1/2”Flat Head
Phillips Wood Screws
