Harman AMX JPK-1300 Quick user guide

HARDWARE REFERENCE MANUAL
VERSION: V1.0.0
Jetpack 3x1 Switching, Transport, and Control Solution
UA Version EK Version
AV FOR AN IT WORLD®
JPK-1300

IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. DO NOT install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wider blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE ONLY with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or
moisture, does not operate normally, or has been dropped.
15. DO NOT expose this apparatus to dripping or splashing and ensure that no objects filled with liquids, such as vases, are placed on
the apparatus.
16. To completely disconnect this apparatus from the AC Mains, disconnect the power supply cord plug from the AC receptacle.
17. Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
18. DO NOT overload wall outlets or extension cords beyond their rated capacity as this can cause electric shock or fire.
19. Please use the HDMI cable with magnetic ring.
The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the product.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to persons.
ESD Warning: The icon to the left indicates text regarding potential danger associated with the discharge of static electricity from an
outside source (such as human hands) into an integrated circuit, often resulting in damage to the circuit.
WARNING: To reduce the risk of fire or electrical shock, do not expose this apparatus to rain or moisture.
WARNING: No naked flame sources - such as candles - should be placed on the product.
WARNING: Equipment shall be connected to a MAINS socket outlet with a protective earthing connection.
WARNING: To reduce the risk of electric shock, grounding of the center pin of this plug must be maintained.
COPYRIGHT NOTICE
AMX© 2023, all rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of AMX. Copyright protection claimed extends to AMX hardware
and software and includes all forms and matters copyrightable material and information now allowed by statutory or judicial
law or herein after granted, including
without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks, etc. Reproduction
or disassembly of embodied computer programs or algorithms is expressly prohibited.
LIABILITY NOTICE
No patent liability is assumed with respect to the use of information contained herein. While every precaution has been taken in the preparation of this
publication, AMX assumes no responsibility for error or omissions. No liability is assumed for damages resulting from the use of the information
contained herein.
Further, this publication and features described herein are subject to change without notice.
AMX WARRANTY AND RETURN POLICY
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.

Reference Manual - JPK-1300
3
ESD WARNING
WARNING: This product is intended to be operated ONLY from the voltages listed on the back panel or the recommended,
or included,
power supply of the product. Operation from other voltages other than those indicated may cause irre- versible damage to the
product and void the products warranty. The use of AC Plug Adapters is cautioned because it
can allow the product to be plugged into voltages in which the product was not designed to operate. If the product is equipped
with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are
unsure of the correct operational voltage, please contact your local distributor and/or retailer.
FCC AND CANADA EMC COMPLIANCE INFORMATION:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial
environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Approved under the verification provision of FCC Part 15 as a Class A Digital Device.
Caution
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate this device.
CAN
ICES-3 (B)/NMB-3(B)
EU COMPLIANCE INFORMATION:
Eligible to bear the CE mark; Conforms to European Union Low Voltage Directive 2006/95/EC; European Union EMC Directive 2004/108/EC;
European Union Restriction of Hazardous Substances Recast (RoHS2) Directive 2011/65/EU; European Union WEEE (recast) Directive
2012/19/EU; European Union Radio and Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC
WEEE NOTICE:
To avoid ESD (Electrostatic Discharge) damage to sensitive components, make sure you are properly grounded before
When working with any equipment manufactured with electronic devices, proper ESD grounding procedures must be followed to
make sure people, products, and tools are as free of static charges as possible. Grounding straps, conductive smocks, and conductive
work mats are specifically designed for this purpose. These items should not be manufactured locally, since they are generally
composed of highly resistive conductive materials to safely drain static discharges, with- out increasing an electrocution risk in the
event of an accident.
Anyone performing field maintenance on AMX equipment should use an appropriate ESD field service kit complete with at
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipmentare
hazardous to life. No user-serviceable parts inside. Refer all servicing to
Place the equipment near a main power supply outlet and make sure that you
RISK OF ELECTRIC SHOCK
DO NOT OPEN
C A U T I O N

Reference Manual - JPK-1300
4
Table of Contents
Important Safety Instructions................................................................................................... 2
Overview ..........................................................................................................................................6
Features..................................................................................................................................... 6
Package Contents.............................................................................................................................6
Specifications ............................................................................................................................ 7
Keypad Description(UA Version) .............................................................................................9
Wall-plate Transmitter Panel Description(UA Version).................................................. 10
Receiver Panel Description(UA Version)................................................................................11
Pinout Information.................................................................................................................. 12
RS232 .....................................................................................................................................12
RELAY .....................................................................................................................................12
Audio Out...............................................................................................................................13
Installation and Connection.................................................................................................... 14
Basic Operations ............................................................................................................................16
Input Source Switching ........................................................................................................... 17
Auto Switching................................................................................................................. 17
Manual Switching ............................................................................................................ 17
PC Tool Control ....................................................................................................................... 18
Discover..................................................................................................................................18
Control ............................................................................................................................. 19
Schedule.................................................................................................................................20
Settings ............................................................................................................................ 21
Update ............................................................................................................................. 22
Device Online Tree.................................................................................................................22
Web UI Control........................................................................................................................ 23
Video ......................................................................................................................................24
Audio................................................................................................................................ 24
Control ............................................................................................................................. 25
Schedule.................................................................................................................................27
Network ........................................................................................................................... 28
System....................................................................................................................................29
Firmware Upgrade .................................................................................................................. 31
Before Starting ................................................................................................................ 31
Transferring KIT Files ....................................................................................................... 31
Troubleshooting ...................................................................................................................... 33
API Command Set ..........................................................................................................................34
System Commands.................................................................................................................35
Network Commands ..............................................................................................................38
Security Commands ...............................................................................................................40
Video and Audio Commands (Direct Control) .......................................................................41
Control Commands (Direct Control) ............................................................................... 47
Schedule Commands (Direct Control)............................................................................. 54

Reference Manual - JPK-1300
5
Overview
The JPK-1300 is designed for multi-function AV intelligent education system. It consists of a Keypad, a Wall-plate Transmitter and an All-in-one
Receiver. It offers 2 HDMI and USB Type-C video extension, video switching and system control. Uncompressed
video and audio can be
transmitted up to 70m/230ft at 1080P or 40m/131ft at 4K2K@30 (YUV 4:4:4) over a shielded Cat
6/6A/7 cable. The product supports
USB signal pass-through, RS-232 control, Relay, IR (IR pass-through & IR learning), audio
de-embedding, USB-AUDIO, ARC function and CEC control. This design of HDBaseT™ technology allows for full usage of HDMI and controls over
Cat 6/6A/7 cable. The product can be controlled through panel buttons, Web GUI and PC tool.
Keypad contains a volume knob (with MUTE function) and six control keys. It supports two HDMI and one USB-C input selection.
Wall-plate Transmitter contains one USB-C input (without charging function), two HDMI inputs, one USB-B input, an IR learning
window and an input selection button.
Receiver supports MIC input, mixing and 2x25W 4/8 Ohms audio amplifier output, IR output, CEC control, Relay control, RS-232
control, MUTE control, HDMI and USB output.
The same hardware design can meet different specifications and market demands of US/EU/UK only by replacing the front panel of the Wall-
plate (Video Panel).
Features
• HDMI 2.0 and HDCP 2.2 compliant
• Supports video resolution up to 4K2K@50/60Hz 4:2:0, 10.2Gbps video bandwidth
• HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD MA , DSD
• Supports HDR, Dolby Vision and HLG
• HDBT transmits lossless and zero-delay video & audio up to 230ft/70m for 1080P or 131ft/40m for 4K via a Shielded Cat
6/6A/7 cable
• Supports audio de-embedding and ARC function (the audio will be output through the Linear audio output port)
• Supports IR pass-through, RS-232 control and CEC control
• Supports controlling the external devices through IR/CEC/RS-232
• Supports unbalanced and balanced MIC inputs
• Supports mono unbalanced and balanced LINE inputs
• One-way 24V PoC function (Receiver → Wall-plate →Keypad)
• Wall-plate Transmitter supports IR learning
• USB-C port supports DP Alt Mode for audio and video transmission
• USB-C port supports USB 2.0 sound card, which can independently transmit audio to the Receiver
• Control via panel buttons, RS-232, TCP/IP, REST API, Web GUI and PC tool
Package Contents (UA Version)
• 1 x JPK-1300 Wall-plate Transmitter (with Screws)
• 1 x JPK-1300 Keypad (with Screws)
• 1 x JPK-1300 Receiver
• 1 x Phoenix Connector (3.81mm, 2 Pins)
• 4 x Phoenix Connector (3.81mm, 3 Pins)
• 1 x Phoenix Connector (5.08mm, 4 Pins)
• 1 x IR Wideband Emitter Cable (1.5 meters)
• 2 x Mounting Bracket (with Screws)
• 1 x DC 24V/3.75A Power Adapter
• 1 x Power Cord (US&AU for UA version)
• 1 x Quick Start Guide
Package Contents (EK Version)
• 1 x JPK-1300 Wall-plate Transmitter (with Screws)
• 1 x JPK-1300 Keypad (with Screws)
• 1 x JPK-1300 Receiver
• 1 x Phoenix Connector (3.81mm, 2 Pins)
• 4 x Phoenix Connector (3.81mm, 3 Pins)
• 1 x Phoenix Connector (5.08mm, 4 Pins)
• 1 x IR Wideband Emitter Cable (1.5 meters)
• 2 x Mounting Bracket (with Screws)
• 1 x DC 24V/3.75A Power Adapter
• 1 x Power Cord (EU&UK for EK version)
• 1 x Quick Start Guide

Specifications
Reference Manual - JPK-1300
6
Technical
HDMI Compliance HDMI 2.0
HDCP Compliance HDCP 2.2
Video Bandwidth 297MHz/10.2Gbps
Video Network
Bandwidth
10G
Video Resolution 480i ~1080p50/60Hz, 4Kx2K@24/30Hz, 4k2k@50Hz/60Hz 4:2:0
Color Depth
8/10/12-bit (1080P60Hz)
8-bit (4K30Hz 4:4:4)
Color Space RGB, YCbCr 4:4:4 / 4:2:2. YUV 4:2:0
HDR HDR, Dolby Vision, HLG
IR Level 12Vp-p
IR Frequency Wideband 20 k - 60 KHZ
Audio Formats
• HDMI: LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-ES,DTS-96/24, DTS High Res, DTS-HD MA, DSD
• Linear audio out: PCM 2.0
Control Method
• Front panel buttons
• PC tool
• Web UI
• RS-232 control (API Commands)
PC Requirements
• Memory: 8GB
• Graphic: Intel HD graphics 4000 or above
• OS Compatibility: Windows 7 (64-bit), Windows 10, Windows 11
Mac OS 10.12 or newer
• Storage: >= 300MB
Connections
Keypad
INPUT: 1 × CONTROL (RJ45)
1 × MICRO USB (Update port)
Wall-plate Transmitter
INPUT: 2 × HDMI IN (Type A, 19-pin port)
1 × USB-C IN (24-pin port)
1 × USB HOST (USB Type B)
1 × IR Receive Window
1 × MICRO USB (Update port)
OUTPUT: 1 × AV LINK (RJ45)
1 × CONTROL (RJ45)
Receiver
INPUT: 1 × AV LINK (RJ45)
1 × LAN 10/100 (RJ45)
1 × REMOTE MUTE (2pin-3.81mm Phoenix Connector)
1 ×
MIC/LINE IN (3pin-3.81mm Phoenix Connector)
1 × DC 24V
1 × MICRO USB (Update port)
OUTPUT: 1 × HDMI OUT (Type A, 19-pin port)
1 × IR OUT (3.5mm Stereo Mini-jack)
1 × USB DEVICE (USB Type A)
1 × RS-232 (3pin-3.81mm Phoenix Connector) 1 ×
RELAY (3pin-3.81mm Phoenix Connector)
1 × AUDIO OUT(3pin-3.81mm Phoenix Connector) 1 ×
AMP OUT (4pin-5.08mm Phoenix Connector)

Specifications
Reference Manual - JPK-1300
7
General
Operating
Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity
20% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/±4kV (Contact discharge)
Power Supply
Input: AC100 - 240V 50/60Hz
Output: DC 24V/3.75A (US/EU standards, CE/FCC/UL certified)
Power Consumption
(Max) 80W (TX + RX + Keypad)
Device Dimension
(W x H x D)
UA Version:
• Keypad:
Front panel: 70mm x 114mm x 22.2mm / 2.76” x 4.49” x 0.87”
Rear case: 69.4mm x 48.4mm x 17.2mm / 2.73” x 1.91” x 0.68”
• Wall-plate Transmitter:
Front panel: 116mm x 114mm x 39.2mm / 4.57” x 4.49” x 1.54” Rear
case: 85.8mm x 52.6mm x 34.2mm / 3.38” x 2.07” x 1.35”
• Receiver: 250mm x 30mm x 104mm / 9.84” x 1.18” x 4.09”
EK Version:
• Keypad:
Front panel: 146mm x 85mm x 22.2mm / 5.75” x 3.35” x 0.87”
Rear case: 69.4mm x 48.4mm x 17.2mm / 2.73” x 1.91” x 0.68”
• Wall-plate Transmitter:
Front panel: 146mm x 85mm x 39.2mm / 5.75” x 3.35” x 1.54”
Rear case: 85.8mm x 52.6mm x 34.2mm / 3.38” x 2.07” x 1.35”
• Receiver: 250mm x 30mm x 104mm / 9.84” x 1.18” x 4.09”
Product Weight
UA Version:
• Keypad: 0.19kg/0.42lb
• Wall-plate Transmitter: 0.35kg/0.77lb
• Receiver: 0.81kg/1.79lb
EK Version:
• Keypad: 0.23kg/0.51lb
• Wall-plate Transmitter: 0.33kg/0.73lb
• Receiver: 0.81kg/1.79lb
Certification
CE, FCC, ETL, PSE, RCM
Transmission Distance
Note: Straight-through category cable wired to T568B standard is recommended.
Cable Type Range Supported Video
Shielded Cat 6/6A/7
70m/230ft 1080P
40m/131ft 4K2K@30 (YUV 4:4:4)
HDMI
Input: 12m/39ft
Output: 12m/39ft
1080P@60Hz
Input: 10m/33ft
Output: 10m/33ft
4K@60Hz 4:2:0
USB
Input: 1.5m/4.9ft
4K@60Hz 4:2:0

Keypad Description (UA Version)
Reference Manual - JPK-1300
8
No. Name Description
1
Volume Knob and
Volume Level
Indicator
Use the volume knob to adjust the audio output volume of the amplifier, the corresponding volume
level indicator will be on.
▪ Rotating clockwise will increase the audio volume;
▪ Rotating counterclockwise will decrease the audio volume.
2
DISPLAY ON
Button Press this button to turn on display devices. For details, please refer to the System Control setting
instructions in
the Control page of Web UI Control.
3
HDMI 1 Button
Press this button to select the HDMI IN 1 port of TX as the signal input channel.
4
USB-C Button
Press this button to select the USB-C port of TX as the signal input channel.
5
DISPLAY OFF
Button
Press this button to turn off display devices. For details, please refer to the System Control setting
instructions in the Control page of Web UI Control.
6
HDMI 2 Button
Press this button to select the HDMI IN 2 port of TX as the signal input channel.
7
SYSTEM ON/
OFF Button
Press and hold this button for three seconds to turn on/off the system.
8
CONTROL port
Connect to the CONTROL port of TX via a Cat 6/6A/7 cable.
9
MICRO USB
port Used for Software upgrade.

Wall-plate Transmitter Panel Description (UA Version)
Reference Manual - JPK-1300
9
No. Name Description
1
POWER LED
(Green)
On: JPK-1300 TX is powered on.
Off: JPK-1300 TX is powered off or in standby.
2
LINK LED
(Green)
LED indicates the connection status of the TX and RX. On: JPK-
1300 TX and RX are linked.
Blinking: Link error.
Off: No link.
3
HDCP LED
(Green)
On: Signal is being transmitted with HDCP.
Off: Signal is being transmitted without HDCP or no signal is being transmitted.
4
HDMI 1 LED
(Green)
On: The HDMI IN 1 port is selected as the signal input channel.
Off: The HDMI IN 1 port is not selected as the signal input channel.
5
HDMI 2 LED
(Green)
On: The HDMI IN 2 port is selected as the signal input channel.
Off: The HDMI IN 2 port is not selected as the signal input channel.
6
USB-C LED
(Green)
On: The USB-C port is selected as the signal input channel.
Off: The USB-C port is not selected as the signal input channel.
7
USB-C IN Port
USB-C signal input port. Connect to the USB-C source device (such as PC) with USB-C cable.
8
HDMI IN 1/2
Port
HDMI signal input port. Connect to the HDMI source device (such as DVD player or PC) with HDMI
cable.
9
USB HOST
Connect to the PC or Notebook with USB cable.
10
SOURCE
Button
Press this button to circularly select the signal input channel, and the corresponding HDMI 1/HDMI 2/ USB-
C LED will be on.
11
IR Window
Used for IR pass-through or IR learning.
12
AV LINK Port
HDBaseT output port. Connect to the AV LINK port of RX with Cat 6/6A/7 cable.
13
CONTROL Port
Connect to the CONTROL port of Keypad with Cat 6/6A/7 cable.
14
MICRO USB
Port Used for Software upgrade.

Receiver Panel Description (UA Version)
Reference Manual - JPK-1300
10
No. Name Description
1
POWER LED
(Green)
On: JPK-1300 RX is powered on.
Off: JPK-1300 RX is powered off or in standby.
2
STATUS LED
(Green)
On:
JPK-1300 RX is working properly.
Blinking: JPK-1300 RX is not working properly.
3
LINK LED
(Green)
LED indicates the connection status of the TX and RX. On: JPK-
1300 TX and RX are linked.
Blinking: Link error.
Off: No link.
4
HDCP LED
(Green)
On: Signal is being transmitted with HDCP.
Off: Signal is being transmitted without HDCP or no signal is being transmitted.
5 MICRO USB Port Used for Software upgrade.
6 LAN 10/100 Connect to PC for Web UI control.
7 RESET
When JPK-1300 RX is powered on, use a pointed stylus to hold down the RESET button for five
seconds, and then release it, it will reboot and restore to its factory defaults.
8 AV LINK Port HDBaseT input port. Connect to the AV LINK port of TX with Cat 6/6A/7 cable.
9 HDMI OUT Port HDMI signal output port. Connect to the HDMI display device (such as TV or Projector).
10 IR OUT Port IR signal output port. Connect with IR Blaster cable.
11
USB DEVICE
Port USB Type A port. Connect to USB devices such as electronic whiteboard, USB camera, mouse or
keyboard.
12 RS-232 Port RS-232 control port. Used to control devices with RS-232 port, such as Projector.
13
REMOTE MUTE
Port
Fire alarm trigger port. Used to mute the audio output function when there is a fire.
14 RELAY Port RELAY control port. Used to control projection screen rise and fall.
15 AUDIO OUT Port Linear audio output port. Connect to amplifier or other audio LINE IN input devices.
16
MIC/LINE
Selection
Switch
When selecting “MIC” with the switch, connect the MIC/LINE IN port to a dynamic microphone; When
selecting
“LINE” with the switch, connect the MIC/LINE IN port to a wire-level audio source or wireless microphone.
There are two connection methods:
1. Unbalanced connection: Connect “+” to MIC signal, and connect “ ╧ ” to the ground.
2. Balanced connection: Connect “+” to the positive signal of the microphone balance, and connect “-” to
the negative signal of the microphone balance.
17 MIC/LINE IN port Connect a dynamic microphone or a wireless microphone compatible with linear audio.
18 AMP OUT Port 4pin Phoenix Connector. Connect to speakers for audio mixing output.
19
DC 24V Port
DC 24V power input port.

Pinout Information
Reference Manual - JPK-1300
11
The following figures show the pinouts of the Phoenix Connectors.
RS232
Connects to an RS232-enabled device with the 3-pole, 3.81mm captive screw connectors. Wire as shown below:
RELAY
Connects to a projector screen with the 3-pole, 3.81mm captive screw connectors. Wire as shown below:

Reference Manual - JPK-1300
12
Audio Out
Connect to an audio device with the 3-pole, 3.81mm captive screw connector. Wire as shown below:

Reference Manual - JPK-1300
13
Installation and Connection
Cable Requirements
1. CONTROL port connection distance is up to 164ft/50m via a Shielded Cat 6/6A/7 cable. The CONTROL cable must be pre- run from the
Wall-plate Transmitter backbox to the Keypad backbox.
2. AV LINK port connection distance is up to 230ft/70m for 1080P video or 131ft/40m for 4K video via a Shielded Cat 6/6A/7 cable.
The AV LINK cable must be pre-run from the Receiver installation location to the Wall-plate Transmitter backbox.
Install Jetpack Receiver
1. Position and install the mounting brackets of JPK-1300 RX with the 4 mounting screws provided, as shown below.
JPK-1300 RX
2. Mount and secure the JPK-1300 to a surface or a suitable location using appropriate mounting screws.
Connect Jetpack Receiver
1. Connect the pre-run AV LINK cable to the AV LINK port on the JPK-1300 RX.
2. Connect the power adapter provided to the JPK-1300 RX.
3. Connect HDMI OUT
Connect an HDMI display device (such as a projector) to the HDMI OUT port of the JPK-1300 RX.
4. Connect USB DEVICE
Connect an USB device (such as a Smart Board) to the USB DEVICE port of the JPK-1300 RX.
5. Connect MICROPHONE or OTHER ROOM AUDIO SOURCE
Connect an audio source (such as a microphone) to the MIC/LINE IN port of the JPK-1300 RX. (Make sure the MIC/LINE
switch is
turned to MIC when connecting a microphone to the MIC/LINE IN port.).
6. Connect AUDIO OUT
Connect the AUDIO OUT port to an amplifier or powered speakers and/or connect the AMP OUT port to 4/8 Ohm speakers
using appropriate speaker cables.
7. Connections for additional control options:
• LAN control (Web UI/PC tool/Telnet/SSH): Connect the JPK-1300 RX to the same network of the PC or control system
via the LAN.
• RS-232/IR/RELAY control: Connect the RS-232 or IR OUT port of the JPK-1300 RX to the display device such as a projector via an
RS-232 cable or the IR emitter cable provided, and connect the RELAY port (1-2) to the electric lifting projection screen.
• Remote mute control: Connect the REMOTE MUTE port of the JPK-1300 RX to the contact closure of the fire alarm
system.
Note: Please refer to the Instruction manual for the configuration of RS-232/IR/RELAY control and the REMOTE MUTE.
Connect Jetpack Devices
1. Connect one end of the pre-run CONTROL cable to the CONTROL port on the JPK-1300 Wall-plate TX and the other end to the
CONTROL port on the JPK-1300 keypad.
2. Connect the free end of the pre-run AV LINK cable to the AV LINK port on the JPK-1300 Wall-plate TX.

Reference Manual - JPK-1300
14
Installing Jetpack Wall-plate Transmitter and Keypad
To install the UA version JPK-1300 Wall-plate TX and Keypad:
1. Place the wall-plate TX and keypad into US standard back box.
2. Secure the wall-plate TX and keypad with the white screws provided, as shown below.
JPK-1300-UA TX JPK-1300-UA Keypad
To install the EK version JPK-1300 Wall-plate TX and Keypad:
1. Remove the white screws on the cover of the wall-plate TX and keypad and remove the cover.
2. Place the wall-plate TX and keypad into an EU standard back box, and secure with the screws provided, as shown below.
JPK-1300-EK TX
JPK-1300-EK Keypad
Note: Use the two screw holes on the left and right ends to install the EK version wall-plate TX and keypad into UK standard back boxes.
3. Secure the cover back to the wall-plate TX and keypad with the white screws provided, as shown below.
JPK-1300-EK TX JPK-1300-EK Keypad
Connecting Jetpack TX to Source Equipment
1. Connect HDMI / USB-C IN
Connect the HDMI and/or USB-C video sources to the HDMI IN 1, 2, or USB-C port of the JPK-1300 TX.
2. Connect USB HOST
If using an HDMI input, connect the USB HOST port on the JPK-1300 TX wall-plate to the USB port of the PC.

Reference Manual - JPK-1300
15
Basic Operations
1. Power on all the attached devices: When all are powered on, check all LED indicators on the JPK-1300 TX and RX to ensure the
installation is successful.
2. Use the SYSTEM ON/OFF button on the JPK-1300 Keypad to turn on/off the system.
• When the system is off, press to turn on the system.
• When the system is on, press and hold for 3 seconds to turn off the system.
3. When the system is on, press DISPLAY ON or DISPLAY OFF button on the JPK-1300 Keypad to turn the display device on or
off by RS-232/IR/CEC and raise or lower the projection screen by relays.
4. When the system is on, press the HDMI IN 1, HDMI IN 2, or USB-C buttons on the JPK-1300 Keypad or the SOURCE button on the JPK-
1300 TX to switch the video source. Press and hold the currently selected video source button for three seconds to mute the video
output, press again to unmute. Check the video output on the display device.
5. Connect MICROPHONE or OTHER ROOM AUDIO SOURCE to MIC/LINE IN port
• Set MIC/LINE select switch to appropriate setting for the connected source.
6. Connect AMP OUT port to 4/8 Ohm speakers using appropriate speaker cables.
• The correct speaker impedance loading must be observed. By default, the amplifier is configured for use with 8 Ohm speakers. The Web
UI or Telnet/SSH commands can be used to configure the amplifier for 4 Ohm loads if 4 Ohm speakers are required.
7. When the system is on, turn the knob on the JPK-1300 Keypad to adjust the volume, or press the knob to mute and unmute the volume.
Typical Connection Diagram

Reference Manual - JPK-1300
16
HDMI IN 1
USB-C IN
SOURCE
HDMI IN 2
USB HOST
IR
Input Source Switching
The JPK-1300 Kit supports Auto and Manual Switching between the HDMI and USB-C inputs.
Auto Switching
1. When multiple sources are inserted, and power is ON for all devices, the input will be switched to the last selected input port of the last
operation.
2. When a new source is inserted, the input will be switched to it automatically, following the Last-In-First-Out rule.
3. When the currently selected source is removed, the input will first be switched to the most recently selected port.
Note:
• The Auto Switching function is enabled by default once all devices are powered on.
• Auto Switching can be set to Enabled or Disabled through PC tool and Web UI control.
Manual Switching
JPK-1300-UA TX JPK-1300-UA Keypad
The JPK-1300 Kit supports Manual Switching between the HDMI and USB-C inputs in four methods.
Method 1: Through the JPK-1300 Keypad
Press the HDMI 1/HDMI 2/USB-C button on the JPK-1300 Keypad to directly select the HDMI 1/HDMI 2/USB-C input source. Method 2:
Through the SOURCE button of JPK-1300 TX
Press the SOURCE button on the front panel of JPK-1300 TX to circularly select the HDMI 1/HDMI 2/USB-C input source.
Method 3: Through the PC tool control
For details, please refer to the Control setting of “PC Tool Control”.
Method 4: Through the Web UI control
For details, please refer to the Video Switching operation in the Video setting of “Web UI Control”.
Note:
• The Manual Switching function is enabled by default once all devices are powered on.
• Auto and Manual Switching functions exist simultaneously.

Reference Manual - JPK-1300
17
PC Tool Control
Controlling the JPK-1300 through the PC tool.
Download the “AMX Jetpack Manager” from amx.com and install this application tool on the PC. Before
launching this tool, connect all the JPK-1300 kits and the PC into the same network.
The default IP mode of JPK-1300 is DHCP. If there is no DHCP server in the network, the default IP of JPK-1300 is 192.168.1.2. The IP
addresses of
all the kits in the same network can be discovered by the PC tool.
Launch AMX Jetpack Manager and select “DISCOVER” in the menu on the top.
Discover
The Discover page is used to discover devices and set device PIN code.
The PIN code is a string of 8 digits. (The default PIN code is 00000000.)
New PIN code can be applied on each device. To discover devices with multiple PIN codes, please separate multiple PIN codes with
spaces (for example: 00000000 00000001 00000002…).
1. Discovering devices
There are two methods to discover devices:
Method 1: Auto Discover
Click DISCOVER, and then enter the PIN code in the Discovery PIN Code box, click the “Discover” button to start searching for devices. The
discovered devices will be displayed in the Discovered list and shown in the DEVICE LIST. Finally, click the “Stop” button to stop searching.
Method 2: Discover by IP
Enter the PIN code in the Discovery PIN Code box, select “Limit IP Range” and enter the IP address range with “Start Address” and “End
Address”. Click the “Discover” button to start searching. The discovered devices will be displayed in the Discovered list and shown in the
DEVICE LIST. Finally, click the “Stop” button to stop searching.
Note: “Start Address” and “End Address” must be in the same Network segment. (The subnet mask is 255.255.255.0.)

Reference Manual - JPK-1300
18
2. Set device PIN code in batches
Click the checkbox at the DEVICE LIST to select at least one device, for which the PIN code is to be set. Then click “Change PIN” to pop up the
“Change PIN“ window, as shown in the figure below. Enter an 8-digit PIN code in “New PIN Code”. Finally click “Set New PIN
Code” to
complete setting, and click “Done” to close the window.
Control
1. Control devices
Click the device to be set at the DEVICE LIST, and the background of the selected device will turn gray. The information and Schedule list of the
current device will be displayed. Then click the corresponding function on the right to set the Auto Switching, Volume, Audio
Mute, Source
Inputs, Microphone/Line Gain, Display, System function.
2. Web Console
Click the icon in the upper right corner to open the Preference window. Enter the Username and Password in Device Auto-login. Finally
click
Web Console to open the Web of the current selected device.
Note: Make sure that the password can pass verification no matter how you set the Username and Password, otherwise, it will not login
automatically.
Schedule
1. Get device Schedule information

Reference Manual - JPK-1300
19
Click the checkbox to select the device at the DEVICE LIST, the corresponding Schedule information will be displayed on the right.
2. Add Schedule in batches
Please follow the steps below to add Schedule in batches:
Step 1, Click the checkbox at the DEVICE LIST to select the device.
Step 2, Click to set Auto Switching, Volume, Audio Mute, Source Inputs, Microphone/Line Gain, Display and System. Please note that
the
value of Volume and Microphone/Line Gain must be larger then 0.
Step 3, Set the repeat start time in “Start Time”.
Step 4, Click to select the repeat mode. Please note that you must select at least one day when you select Weekly.
Step 5, Set the start date in “Range of Repeat”.
Step 6, Set the end date in “Range of Repeat”.
Step 7, Enter the “Action Name”.
Step 8, Click “Save” to complete adding.

Reference Manual - JPK-1300
20
3. Remove Schedule
Click the “Remove” button in the Current Schedule list, and then click “Yes” to complete remove.
Settings
1. Export Configuration Files
Click the checkbox at the DEVICE LIST to select the device. Please note that, you can only choose one device at one time. Then click
“Save Config”, select the file path, and click “Confirm” to save the file and complete exporting.
2. Import Configuration Files in batches
Click the checkbox at the DEVICE LIST to select at least one device, then click “Load Config” to select the configuration file to be
imported.
Finally, click “Confirm” to complete batch importing.
