Harman JBL Quantum 800 User manual

QUICK START GUIDE
800
HP_JBL_Q800_QSG_PV_V9.indd 1 11/11/2019 2:33:17 PM

Software requirements
Platform: Windows 7 or higher
500MB of free hard drive space for installation
*QuantumSURROUND / QuantumSPHERE 360 and DTS Headphone:X V2.0
available on Windows only. Software installation required.
Download JBL QuantumENGINE to gain full access to features on your JBL Quantum headsets - from
headset calibration to adjusting 3D audio to suit your hearing, from creating customized RGB lighting
effects to determining how the boom microphone side-tone works. jblquantum.com/engine
JBL QuantumENGINE
HP_JBL_Q800_QSG_PV_V9.indd 2 11/11/2019 2:33:17 PM

001 WHAT'S IN THE BOX
JBL quantum800 headset
USB charging
cable
3.5MM AUDIO
CABLE
USB WIRELESS
DONGLE
QSG | WARRANTY CARD |
Safety Sheet
Windshield foam
for microphone
HP_JBL_Q800_QSG_PV_V9.indd 3 11/11/2019 2:33:18 PM

002 Requirements
System compatibility
PC | Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR
PLATFORMS: WINDOWS 7 or Higher
500MB OF FREE HARD DRIVE SPACE FOR INSTALLATION
SOFTWARE REQUIREMENTS
JBL
HP_JBL_Q800_QSG_PV_V9.indd 4 11/11/2019 2:33:18 PM

003 OVERVIEW
03
04
06
13
14
12
16
15
01
07
02
09
05
10
17
18
08
11
01 ANC / TALKTHRU LED
02 ANC / TALKTHRU button
03 Game audio-chat balance dial
04 Volume Control
05 Detachable Windshield foam
06 Notification LED for mic mute / unmute
07 Microphone Mute / unMute
08 CHARGING LED
09 3.5mm Audio Jack
10 USB-C port
11 Voice Focus Boom Microphone
12 Bluetooth pairing button
13 POWER ON / OFF slider
14 POWER / 2.4G / Bluetooth LED
15 RGB-lit JBL logo
16 Flat-fold ear cup
17 2.4G PAIRING BUTTON
18 Volume Control
19 MIC MUTE BUTTON
19
HP_JBL_Q800_QSG_PV_V9.indd 5 11/11/2019 2:33:18 PM

004 POWER ON & CONNECT
OR
power on
>2S
PC | mac | PLAYSTATIONTM
Settings Bluetooth
Bluetooth
DEVICES
JBL Quantum800
Now Discoverable
Connected
ON
01
2.4G Wireless
02
Bluetooth
HP_JBL_Q800_QSG_PV_V9.indd 6 11/11/2019 2:33:18 PM

005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR
*
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK. USB-C PORT FOR CHARGING ONLY.
PC | LAPTOP | MAC
HP_JBL_Q800_QSG_PV_V9.indd 7 11/11/2019 2:33:18 PM

006 BUTTON COMMAND
ANC ON / OFF
>2S
TALKTHROUGH ON / OFF
X1
>2S BT PAIRING MODE
ON OFF
INCREASE CHAT VOLUME
INCREASE GAME VOLUME
INCREASE MASTER VOLUME
DECREASE MASTER VOLUME
ON / OFF
x1
>5S
Microphone Mute / unMute
HP_JBL_Q800_QSG_PV_V9.indd 8 11/11/2019 2:33:18 PM

007 First time setup
JBL Quantum800
Game
JBL Quantum800
Chat
7a Go to Sound Settings
7B UNDER "PLAYBACK" HIGHLIGHT JBL QUANTUM 800 GAME AND SELECT
"SET DEFAULT DEVICE"
7C HIGHLIGHT JBL QUANTUM 800 CHAT AND SELECT "SET DEFAULT
COMMUNICATION DEVICE"
7D UNDER "RECORDING" HIGHLIGHT JBL QUANTUM 800 CHAT AND SELECT
"SET DEFAULT DEVICE"
7E IN YOUR CHAT APPLICATION SELECT JBL QUANTUM 800 CHAT AS THE
DEFAULT AUDIO DEVICE
HP_JBL_Q800_QSG_PV_V9.indd 9 11/11/2019 2:33:18 PM

008 MICROPHONE
Notification LED for mic
mute / unmute
mute unmute
HP_JBL_Q800_QSG_PV_V9.indd 10 11/11/2019 2:33:19 PM

009 CHARGING
2HR
HP_JBL_Q800_QSG_PV_V9.indd 11 11/11/2019 2:33:19 PM

010 LED BEHAVIOURS
LOW BATTERY
CHARGING
FULLY CHARGED
BT CONNECTING
(Blue LED)
BT PAIRING
(Blue LED)
BT CONNECTED
(Blue LED)
ANC/ tt ON
MIC MUTE
MIC UNMUTE
2.4G CONNECTING
2.4G PAIRING
2.4G CONNECTED
2.4G CONNECTING
2.4G PAIRING
2.4G CONNECTED
POWER OFF
POWER ON
HP_JBL_Q800_QSG_PV_V9.indd 12 11/11/2019 2:33:19 PM

011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V / 1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
HP_JBL_Q800_QSG_PV_V9.indd 13 11/11/2019 2:33:19 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
DA DE
HP_JBL_Q800_QSG_PV_V9.indd 14 11/11/2019 2:33:19 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
EL ES
HP_JBL_Q800_QSG_PV_V9.indd 15 11/11/2019 2:33:19 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
FI FR
HP_JBL_Q800_QSG_PV_V9.indd 16 11/11/2019 2:33:19 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
HU IT
HP_JBL_Q800_QSG_PV_V9.indd 17 11/11/2019 2:33:20 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
NL NO
HP_JBL_Q800_QSG_PV_V9.indd 18 11/11/2019 2:33:20 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
PL PT-BR
HP_JBL_Q800_QSG_PV_V9.indd 19 11/11/2019 2:33:20 PM

001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
001 WHAT’S IN THE BOX
JBL quantum800 headset; USB charging cable; 3.5mm Audio Cable;
USB Wireless Dongle; Windshield foam for Mi-crophone; QSG |
Warranty Card | Safety Sheet
002 Requirements
SOFTWARE REQUIREMENTS (PLATFORMS:
WINDOWS 7 or Higher; 500MB OF FREE HARD DRIVE SPACE FOR
INSTALLATION); System compatibility (PC | Xbox™ | PlayStation™
| Nintendo Switch™ | Mobile | MAC | VR
003 OVERVIEW
01 ANC / TALKTHRU LED; 02 ANC / TALKTHRU button; 03 Game audio-
chat balance dial; 04 Volume Control; 05 Detachable Windshield
foam; 06 Notification LED for mic mute / unmute; 07 Microphone
Mute / unMute; 08 CHARGING LED; 09 3.5mm Audio Jack; 10 USB-C
port; 11 Voice Focus Boom Microphone; 12 Bluetooth pairing
button ; 13 POWER ON / OFF slider; 14 POWER / 2.4G / Bluetooth
LED; 15 RGB-lit JBL logo; 16 Flat-fold ear cup; 17 2.4G PAIRING
BUTTON; 18 Volume Control; 19 MIC MUTE BUTTON
004 POWER ON & CONNECT
1. power on; 2. 2.4G Wireless (PC | mac | PLAYSTATION™)
005 SETUP
Xbox™ | PlayStation™ | Nintendo Switch™ | Mobile | MAC | VR;
PC | LAPTOP | MAC
* USB-C TO USB-C CABLE IS NOT INCLUDED BY-PACK.
USB-C PORT FOR CHARGING ONLY.
006 BUTTON COMMAND
ANC on/off; TALKTHROUGH ON/OFF
INCREASE GAME VOLUME; INCREASE CHAT VOLUME
INCREASE MASTER VOLUME; DECREASE MASTER VOLUME
Microphone Mute / unMute; ON/OFF
BT PAIRING MODE
007 First time setup
7a Go to Sound Settings; 7B UNDER “PLAYBACK” HIGHLIGHT JBL
QUANTUM 800 GAME AND SELECT “SET DEFAULT DEVICE”; 7C HIGHLIGHT
JBL QUANTUM 800 CHAT AND SELECT “SET DEFAULT COMMUNICATION
DEVICE”; 7D UNDER “RECORDING” HIGHLIGHT JBL QUANTUM 800 CHAT AND
SELECT “SET DEFAULT DEVICE”; 7E IN YOUR CHAT APPLICATION SELECT
JBL QUANTUM 800 CHAT AS THE DEFAULT AUDIO DEVICE
JBL Quantum600 Game; JBL Quantum600 Chat
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
008 MICROPHONE
Notification LED for mic mute / unmute; mute; unmute
009 CHARGING
010 LED BEHAVIOURS
ANC/ TT ON; MIC MUTE / MIC UNMUTE; LOW BATTERY / CHARGING /
FULLY CHARGED; 2.4G PAIRING / 2.4G CONNECTING / 2.4G CONNECTED; BT
PAIRING (Blue LED) / BT CONNECTING (Blue LED) / BT CONNECTED (Blue
LED); POWER ON / POWER OFF
011 TECH SPEC
Driver size: 50 mm Dynamic drivers
Frequency response: 20 Hz - 20 kHz
Microphone frequency response: 100 Hz -10 kHz
Max input power 30 mW
Sensitivity: 102 dB SPL @1 kHz / 1 mW
Maximum SPL: 97 dB
Microphone sensitivity: -40 dBV @1 kHz / Pa
Impedency: 32 ohm
2.4G Wireless transmitter power: <4 dBm
2.4G Wireless modulation: DQPSK
2.4G Wireless carrier frequency: 2403.35 MHz - 2479.35 MHz
Bluetooth transmitted power: <4 dBm
Bluetooth transmitted modulation: GFSK, π/4 DQPSK, 8DPSK
Bluetooth frequency: 2.402 GHz - 2.480 GHz
Bluetooth prole version: A2DP 1.3, HFP 1.6
Bluetooth version: V5.0
Battery type: Li-ion battery (3.7 V /
1300 mAh)
Power supply: 5 V 2 A
Charging time: 2 hrs
Music play time with RGB
lighting o: 14 hrs
Microphone pickup pattern: Unidirectional
Microphone size: 4 mm x 1.5 mm
Weight: 410 g
SV TR
HP_JBL_Q800_QSG_PV_V9.indd 20 11/11/2019 2:33:20 PM
