Harman JBL CLUB WS1000 User manual

THANKYOU for choosing an JBL Club
WS1000 or Club WS1200 subwoofer. These
Club subwoofers are designed to suit a
broad range of car audio applications and
can be used in a wide variety of enclosure
types to produce extended, powerful bass
in a limited amount of vehicle space . To
get the most performance from your new
subwoofer, it is strongly recommended
that you have a qualified professional
install your WS1000 or WS1200
subwoofer. Although this manual does
provide general instructions about
installing these Club Series subwoofers, it
does not include enclosure construction
details or exact installation methods for
any particular vehicle .If you do not feel
that you have the necessary experience,
do not attempt the installation yourself,
but instead ask your authorized JBL dealer
about professional installation options.
Remember to keep your sales receipt in a
safe place , along with this manual, so
that both are available for future Club.
BOX CONTENTS
(1) WSlOOO or WS1200 subwoofer
(1) Owner's manual
(1) Technical data sheet
WARNING
Playing loud music in a vehicle can hinder
your ability to hear traffic and
permanently damage your hearing. The
maximum volume levels achievable by JBL
speakers when combined with high-power
amplification may exceed safe levels for
extended listening. Using low volume
levels is recommended when driving. JBL
Systems accepts no liability for hearing
loss, bodily injury, or property damage as
a result of use or misuse of this product.
REPRODUCING
BASS
IN VEHICLES
Depending on the size of your vehicle's
interior listening space, reproduced bass
frequencies below 80Hz will be boosted
by nearly 12dB per octave as frequency
decreases. This phenomenon, known as
the vehicle's transfer function (or cabin
gain), plays an important role in shaping
the subwoofer's frequency response in
your vehicle. The enclosed technical data
sheet includes frequency response graphs
that show both the subwoofer's "in-car"
response (which factors in this vehicle
transfer function) and its "out-of - car"
response (which does not).
SUBWOOFER
ENCLOSURE TYPES
Club WS1000 and WS1200 subwoofers are
designed to perform best in moderately
sized sealed enclosures , vented
enclosures and prefabricated band-pass
enclosures. Infinite-baffle mounting is
possible, but the subwoofer's mechanical
power handling will be reduced because
there will be no volume of air to stiffen
the subwoofer's suspension and prevent
overexcursion .If you choose infinite-baf-
fle mounting, consider the RMS and peak
power-handling ratings to be half of what
is listed in the specifications in this
manual.
You should choose an enclosure type
based on the amount of cargo space you
can devote to the enclosure, the amount
of power you will use to drive your
subwoofer(s), and your listening habits.
SEALED ENCLOSURES
The air trapped inside a sealed enclosure
is compressed when the subwoofer moves
rearward and is rarefied when the
subwoofer moves forward. In both cases,
the air inside and outside the box will
seek equilibrium by pushing and pulling on
the subwoofer cone. The result is a
stiffer suspension when compared to the
subwoofer operating in free air. This
means that the subwoofer's cone will be
harder to move at low frequencies, a
condition which protects the subwoofer
from physical overexcursion, but
requires more power than other designs
to achieve a given acoustic output.
See accompanying data sheet for specific
enclosure dimension requirements.
SEALED-ENCLOSURE PERFORMANCE
ADVANTAGES
·The in-vehicle performance will have
the flattest overall frequency response.
·The In-vehicle response will have the
widest bandwidth. (Usable low-frequency
response inside the vehicle will be
below 20Hz.)
• An optimum sealed enclosure will always
be smaller than an optimum enclosure of
another type.
SEALED-ENCLOSURE PERFORMANCE
TRADE-OFFS
• An optimum sealed enclosure will have
lower overall efficiency than an
optimum enclosure of another type.
•A Club WS1000 or WS1200 subwoofer in
an optimum sealed enclosure will require
more amplifier power to achieve a given
acoustic output than in an optimum
enclosure of another type.
SEALED-ENCLOSURE CONSTRUCTION
Sealed-enclosure construction is straight·
forward and forgiving of errors in volume
calculation, but air leaks should be
avoided. Use medium-density fiberboard
(MDF), glue and screws to construct the
enclosure, and seal all joints with silicone
caulk.
THE JBL RECOMMENDATION
Club WS1000 and WS1200 subwoofers in
sealed enclosures are recommended for
enthusiasts who prefer accurate music
reproduc-tion and flat frequency
response, for those who have a smaller
space to devote to a subwoofer
enclosure, and for those who have plenty
of amplifier power devoted to driving the
subwoofer. The sealed-enclosure design
indicated on the technical data sheet
accompanying this manual represents the
best compromise between low-frequency
extension and flat response .

VENTED ENCLOSURES
A vented enclosure acts like a sealed
enclosure at frequencies above its tuned
(resonance) frequency. At resonance
(which is defined by the vent), the vent
produces the majority of sound- the
subwoofer cone is nearly stationary while
the air inside the vent vibrates. This
provides greater mechanical power
handling at and above resonance, but
reduced mechanical power handling below
resonance. Since the subwoofer cone and
voice coil don't move much at resonance,
airflow across the voice coil is minimized
and thermal power handling is reduced
slightly at resonance.
Vented enclosures provide better
efficiency in the 40Hz- 60Hz range, at
the expense of sound output in the lowest
octave (below 40Hz). The use of an
infrasonic filter is recommended with
vented enclosures. An optimum vented
enclosure for a Club Series subwoofer is
larger than an optimum sealed enclosure.
See accompanying data sheet for specific
enclosure dimension requirements.
VENTED-ENCLOSURE PERFORMANCE
ADVANTAGES
• An optimum vented enclosure has
greater efficiency and higher output in
the 40Hz- 60Hz range than an optimum
sealed enclosure.
• An optimum vented enclosure provides a
greater sensation of bass than an
optimum sealed enclosure.
·A Club WS1000 or WS1200 subwoofer in
an optimum vented enclosure will
require less amplifier power to achieve
a given acoustic output (down to the
enclosure's resonance frequency) than
in an optimum sealed enclosure.
VENTED-ENCLOSURE PERFORMANCE
TRADE-OFFS
• Reduced output in the lowest octave
(below 40Hz).
• Reduced mechanical power handling
below the enclosure's resonance
frequency. The use of an electronic
infrasonic filter is strongly recommend·
ed, to reduce the chance of overdriving
the subwoofer below the enclosure's
resonance frequency,
• An optimum vented enclosure will
always be larger than an optimum
sealed enclosure.
VENTED-ENCLOSURE CONSTRUCTION
Vented-enclosure construction is more
difficult than the construction of a sealed
enclosure. The enclosure volume and port
dimensions have a specific relationship
with the physical and electromechanical
characteristics of the subwoofer ,
requiring that the recommended
enclosure volume and port characteris-
tics be strictly observed. As with sealed
enclosures, use medium-density
fiberboard (MDF), glue and screws to
construct the enclosure, and seal all
joints with silicone caulk.
THE JBL RECOMMENDATION
Club WS1000 and WS1200 subwoofers in
vented enclosures are recommended for
enthusiasts who prefer accentuated bass
response, for those who have plenty of
cargo space to devote to a subwoofer
enclosure and for those who will use a
less powerful amplifier to drive their
subwoofer. The volume and port
dimensions indicated on the included
technical data sheet must be followed
precisely to ensure optimum
performance.
BAND· PASS ENCLOSURES
Band-pass enclosures can provide the
most output from any amplifier and
subwoofer combination over a limited
band of frequencies, but that additional
output comes at the expense of sonic
accuracy. Band-pass enclosures combine
a sealed or vented enclosure that houses
the subwoofer along with a vented
chamber into which the subwoofer
outputs its sound. The vented chamber
acts as an acoustic low-pass filter which
attenuates high frequencies in the
subwoofer's output. That attenuation of
high frequencies can make it very
difficult to hear amplifier and speaker
distortion; consequently, you may not be
able to determine when the subwoofer is
in danger of being damaged.
See accompanying data sheet for specific
enclosure dimension requirements.
BAND-PASS-ENCLOSURE PERFORMANCE
ADVANTAGES
• An optimum band-pass enclosure
provides higher output over a limited
bandwidth than an optimum enclosure of
any other type.
BAND-PASS-ENCLOSURE PERFORMANCE
TRADE-OFFS
• Band-pass enclosures achieve high
output at the expense of sonic
accuracy.
• An optimum band-pass enclosure has a
more limited bandwidth than an
optimum enclosure of any other type.
• The enclosure's low-pass filter
characteristics can make it difficult to
hear if the subwoofer is in danger of
being damaged.
• An optimum band-pass enclosure is
usually larger than an optimum vented
enclosure .
BAND-PASS-ENCLOSURE CONSTRUCTION
Band-pass-enclosure construction is more
difficult than vented-box construction
and, as with vented enclosures, the
design parameters for the vented section
must be followed carefully. (The sealed
section is more forgiving of small design
and construction variations.) Fortunately,
there are many prefabricated band-pass
enclosures that are designed to extract
the most output possible from nearly any
subwoofer. Prefabricated band-pass
enclosures are strongly recommended if
you must have a band-pass enclosure. If
you choose to build your own band· pass
enclosure, use medium-density fiberboard
(MDF), glue and screws to construct the
enclosure,and be sure to seal all joints
with silicone caulk.
THE JBL RECOMMENDATION
Band-pass enclosures are recommended
only for enthusiasts who want high
sound-pressure levels (SPL) without
regard for sonic accuracy. If high SPL
AND great-sounding bass are your goals,
choosing a vented enclosure is
recommended instead,

MOUNTING
THE
SUBWOOFER
The
Club
WS1000
and
WS1200
subwoofers
can
be
mounted
from
the
outside
of
the
enclosure
or
from
the
inside
of
the
enclosure.
Which
-
ever
way
you
mount
the
subwoofer,
use
the
included
foam
mounting
gasket
to
ensure
a
leak
-
free
seal
between
the
subwoofer
frame
and
the
enclosure.
CONNECTING
THE
SUBWOOFER
SETTING
THE
IMPEDANCE
The
Club
WS1000
and
WS1200
subwoofers
both
feature
the
Selectable
Smart
Impedance
m
(SSI)
switch.
This
exclusive
feature
lets
you
set
the
subwoofer's
impedance
to
either
2
ohms
or
4
ohms
with
the
flip
of
a
switch
(
see
illustrations
to
the
right).
This
allows
you
to
extract
the
most
from
your
subwoofer
amplifier
in
any
si
tuation.
The
SSI
2-ohm
setting
increases
the
subwoofer's
output
over
the
4-ohm
setting
by
up
to
3dB,
depending
on
the
amplifier.
Performance
is
identical
in
all
SPECIFICATIONS
g
=
0
I
P-4
~
=
ll
~
20
~
0
m
IMPEDANCE
2-0hm
Setting
20
~n
ITJ
IMPEDANCE
4-Dhm
Setting
Club
WS1000
10"
(250mm)
Power
Handling
(RMS
):
·
Power
Handling
(Peak)
:
Sensitivity
@
2.83V
/1m
:
Frequency
Response
:
Impedance
:
Voice-Coil
Diameter:
Mounting
Depth:
Overall
Diameter
:
Cutout
Diameter:
Low-profile
SSI
Automotive
Subwoofer
200W
BOOW
89dB
35Hz-
175Hz
2
or
4
ohms
(
selectable
)
2"
(50mm)
3-5/16"
(
83mm)
1
0-9/16"
(
268mm)
9-1/2"
(240mm)
A
valid
serial
number
is
required
for
warranty
coverage
.
Features,
specifications
and
appearance
are
subject
to
change
without
notice.
"'-""
-~
?
-
~
~
?
~
other
respects.
If
the
connected
amplifier
is
rated
for
2-ohm
operation
and
its
2-ohm
power
ratings
are
within
the
subwoofer
's
power-handling
specifications,
setting
the
SSI
switch
in
the
2-ohm
position
will
achieve
maximum
output.
IMPORTANT:
Make
sure
the
subwoofer
amplifier
is
turned
OFF
before
setting
the
SSI
switch.
Do
not
change
the
switch
position
while
the
subwoofer
amplifier
is
operating.
Doing
so
could
damage
the
amplifier.
CONNECTING
THE
AMPLIFIER
The
Club
WS1
000
and
WS1200
subwoofer
connectors
are
compatible
with
quick-
disconnect
(not
supplied)
or
soldered
connections.
The
recommended
wire
gauge
is
between
14AWG
and
BAWG,
depending
on
the
length
of
the
wire
run
between
the
amplifier
and
woofer.
Heavier
gauge
wire
is
preferred
for
runs
over
6'
(
2m
).
Club
WS1200
12"
(300mm)
Low-profile
SSI
Automotive
Subwoofer
250W
1000W
92dB
27Hz
-
175Hz
2
or
4
ohms
(
selectable)
2"(
50mm
)
3-5/16
"(
83mm)
12
-
1/4"
(
310
m
m)
11-1
/
8"
(282mm
)
These
products
are
designed
for
mobile
applications
and
are
not
intended
for
connection
to
the
mains.
~
HARMAN
~
HARM
AN
In
te
rn
ational
Indu
stries,I
nc.
8500
Bal
boa
Bo
ul
ev
ar
d,
Nort
h
rid
ge,
CA
91
329
USA
www.j
bl
.c
om
©2015
HARM
AN
lnt
er
nation
allndus
tri
es,
ln
cor
por
at
ed
.
All
rig
ht
sr
es
er
ved.
JBL
isa
tradem
ar
k
of
HA
RMAN
In
te
rnatio
n
al
Indu
str
ie
s,
In
c
orpo
ra
t
ed
re
gi
s
ter
ed
in
th
e
United
Sta
tesand/or
ot
her
countrie
s.
The
wider
terminal
is
the
positive
and
the
narrower
is
negative
(
also
indicated
on
the
terminal
cover).
NOTE:
If
using
untinned
bare
wire,
be
sure
that
no
stray
"+"
and
"-"
strands
touch
each
other.
Touching
strands
can
cause
a
short
circuit,
which
can
damage
your
amplifier.
-

THIELE-SMALL PARAMETERS
VotcE-COIL DC RESISTANCE:
VOICE-COIL INDUCTANCE@ 1KHz:
DRIVER RADIATING AREA:
MoTOR FoRCE FACTOR:
COMPLIANCE VOLUME:
SusPENSION CoMPLIANcE:
MoviNG MAss, AIR LoAo:
FREE-AIR RESONANCE:
MECHANICAL Q:
ELECTRICAL Q:
Tom Q:
MAGNETIC-GAP HEIGHT:
VOICE-COIL HEIGHT:
MAXIMUM ExcuRsioN:
20 40
REvc (OHMS) •••••••••• 1 .84, ,,,,,,,,,, 4.16
LEVC (MH) ' ' ' ' ' ' ' '' ' ' 0.65' ' ' ' ' ' ' ' ' ' ' 0.71
So (tN2) ............ 77.92 .... ...... 77.92
So (cM2) .......... 502.73 .. ...... • 502.73
BL(TM) .., .......... 9.02 .......... 12.87
VAS (FT3), ,,,,,,,,,,, 3.44, ,,,,,,,,,, 3.45
VAs(LITERS) .•...••. • 97.43 •• • ••••••• 97.56
CMs (1-JM/N) ••••••• , 274.00, ,,,,,,,, 275.00
MMs (GRAMS) ........ 177.46 .., ...... 177.02
Fs (Hz) ,,,,,,, ,,,,, 22.80 ..,..•.•.• 22.82
QMs ••••••••.••••••• 6.24. •••••••••• 3.57
QEs •••••••••••••••• 0.57. , ••.•.• ,•, 0.64
QTs •••••••••• ,•••.• 0.53 .....•.. , •. 0.54
HAG (iN) ' '.' •.. ...... 0.31 .....•..... 0.31
HAG (MM) •• ' ' ' ' •' '' ' ' 8.00 ' ' ' ' ' •' ' ' ' . 8.00
Hvc (iN), ,,,,,,,,,,,, 0.92 ..,,.• ,,,.. 0.92
Hvc (MM) .•••.••••• , 23.30 •••••••••• 23.30
XMAX (iN) ' ' ' ' ' ' ' ' '' ' ' 0.30 ' ' ' ' ' ' ' ' ' .. 0.30
XMAX (MM) .... ' •••• ' •7.65''. ' .•• ' '' ' 7.65
SEALED· Box VoLUME (INcLuDEs DRIVER DisPLACEMENT)
Club WS1200
(side view)
V
80
x= 0.75 fP (21 .241iters)
VENTED-Box VoLUME (INcLuDEs DRIVER/PoRT DisPLACEMENTs)
~~ ~ !! !§JF
l
length = 10"
Port
Club WS1200
['""
fo =33Hz
(s ide view)
--
I I
V oox= 1.75 fP (49.56 liters)
diameter = 4"
102mm
BAND-PAss- Box VoLUME (INcLuDEs DRIVER/PoRT DisPLAcEMENTs)
Club WS1200
(s ide view)
V REAR= 1.00 ft
3
(28.31 liters)
2 Ports
fo= 53Hz
1~1
102mm
i
length =
7-1 /2"
190.5mm
~
VFRONT= 1.75 ffl (49.551iters)
SPECIFICATIONS
DIAMETER:
SENSITIVITY (2.83V @ 1M):
POWER HANDLING:
FREQUENCY RESPONSE:
NOMINAL IMPEOACE:
VotcE-COIL DIAMETER:
DIMENSIONS:
12" (305MM)
92dB
250W RMS (1 000W PEAK)
27Hz -175Hz
2 OR 4 OHMS
2" (51 MM)
SEALED ENCLOSURE (FREQUENCY RESPONSE@ 2.83V)
1
115
110
105
100
95
20 90
l:
75
70
65
dBSPL
In - Car
"\.
r--- ;2 dB LP I@ Blllz
..
! ~
r:-
~
....
1-- ..
.. ··r
~Out - of - Car
20 Hz 30 40 50 60 70 80 90100
"'-
--
-----
'\
""
"'
""1m
200 300
VENTED ENCLOSURE (FREQUENCY RESPONSE @ 2.83V)
1
:::
105
100
95
20 90
l: 70
65
D!SPL
~-
.......
r "
12dBLP @ 8111 z
....
-- -r--
~
..
.. .......
..... ~~
"'-
....
Out ·of -Car
2 0H z 30 40 50 60 70 80 90100
-
-----
'
""-
"
~
20 0
300
BAND-PASS ENCLOSURE (FREQUENCY RESPONSE @ 2.83V)
1
115
110
105
100
95
20 90
l
85
80
75
70
65
d !SP L
~
......
'
12d8LP @ 8111 z
"'
....
--
.. ':
~
.,. ..
....
~
~o- .. "'
Out·o f ·C ar
"~--
"'\:' ........
'\...
.... ~-- .......
"""""-
" "' ~
20 Hz 30 40
50 60 70 80 90100 2 00 3 00
~ HARMAN International In du stries, In c. ©
20 16 H AR MAN International I nd ust ri es, Incorporated. A ll rig ht s reserved.
112l
107
102
97
02
87 40
~J
72
67
62
112l
10 7
10 2
97
92
87 40
~J
62
11 2 l
10 7
10 2
97
92
87 40
~J
72
67
62
HARMAN 8500 Bal bo a Boulev ar d, Northridge, CA 91 329 USA
www ..bl. co m
JBL is a trademark of HARMAN International I nd ust ri es, I nco r po rated registered in th e U n~ed States an d/o r o th er co u nt ries.
