Harmopool ZBZX2074 User manual

Assemble it on U shape frame pool cover reel
X 1 X 2
Step 1 Step 2
E E
A
C
D
A
BB
E
F
Electric Pool Cover Reel Instruction
NOTE：The electric machine should be assembled on the other side of the handle wheel.
Step 3: Take part G and insert it
into the hole on the top of
electric machine. And then
connect part H（solar panel）
with the other end of part G.
Step 4: Connect the line of part H
with the line on electric
machine, and then fix the
waterproof cap tightly.
Step 5: Fix part C and the tube with
Part I
Step 1: Take part A and inset it into the hole of Part B.
Take part E and secure the automatic machine
on frame (part B) with four M5metal screws(part F).
Step 2: Take Part C and connect it with part A , Secure
the assembly with the metal screw D (M6 screw).
X 4 X 3X 1
X 1 X 1 X 1
F D I
CG H
SPARE PARTS LIST
Step 3
Step 4 Step 5
GG
G
H
H
I
I
I
H
C
A
B
C
A
B
A
B
C

POWER
Manual
Auto
FORWARD
REVERSE
PAUSE / SETTING
How to set the working time.
1. Turning on the power.
2. Pressing and holding the "Setting" button for three seconds.
3. When the power indicator start blinking, then it enters the setting mode.
4. Pressing the "forward" or "reverse" button for time keeping until you finish rolling the pool cover .
5. Then press the “Setting” botton again.
Assemble it on T shape frame pool cover reel
How to use your automatic cover reel.
1. Use it without time setting.
Step1 :Turning on the power.
Step 2:Pressing the "forward" or "reverse" button
Step 3:Pressing the “Pause” button when you finish rolling the pool cover.
2. Use it after you setting the time
Step 1:Turning on the power.
Step 2: Pressing the "forward" or "reverse" button.
PAUSE
FORWARD
REVERSE
PAUSE
A
Step 1 Step 2
Step 3 Step 4 Step 5
A
A
A
A
B
BB B
B
C
C
CC
E
E
E
EE
F
GG
G
H
H
H
II
I
D
NOTE: If you want to set time again, repeat these steps. The Forward time and reverse time will
be the same after setting the time.
The roller will stop automatically after finishing rolling the cover, you don’t need to wait and
press the “Pause” button.
NOTE：Use within 50 meters.
Step 1: Take part A and inset it into the hole of Part B.
Take part E and secure the automatic machine
on frame (part B) with four M5metal screws(part F).
Step 3: Take part G and insert it
into the hole on the top of
electric machine. And then
connect part H（solar panel）
with the other end of part G.
Step 4: Connect the line of part H
with the line on electric
machine, and then fix the
waterproof cap tightly.
Step 5: Fix part C and the tube with
Part I
Step 2: Take Part C and connect it with part A , Secure
the assembly with the metal screw D (M6 screw).
How to assemble the electric machine
on your manual pool cover reel
Solar energy or
direct power charging port
Manual mode and Electric
mode adjustment knob
