Super Slicer
SUPER SLICER
1-2019
OPERATOR’S & PARTS
MANUAL

Super Slicer 1

Super Slicer
Thank you for purchasing a Deweze Super Slicer
TO THE OWNER OR OPERATOR:
As with all Harper products, the Super Slicers have been thoroughly tested and built to provide a
sturdy, dependable product. The Super Slicer is equipped with live hydraulics, which allows it to be
used for a wide range of lifting and hauling tasks. This manual is written as an aid to operating and
maintaining the DewEze Super Slicer. Read and understand the manual thoroughly before opera-
tion to avoid damage to the unit or injury to the operator or bystanders.
A Super Slicer can present hazards to an operator who follows unsafe procedures in either the op-
eration or maintenance of the unit. Therefore, SAFETY WARNINGS are present at certain locations
in the text. Harper Industries is not responsible for accidents or injuries that result from the misuse
or lack of maintenance of the Super Slicer.
SYMBOL: SAFETY WARNING!
MEANING: Failure to understand and obey this warning may result in injury to you or others.
Whenever this symbol is used, please pay very close attention to the information presented, and
make sure you fully understand. If you do not, contact your dealer or Harper Industries for clarica-
tion.
151 E. HWY. 160 Harper, KS 67058
[phone] • Fax [phone]
Toll Free 800-835-1042
Email [email protected]
Website www.deweze.com
© 2019 Harper Industries, Inc.
The Harper and DewEze names are registered trademarks of Harper Industries, Inc. All other brand and productnames are trade-
marks or registered trademarks of their respective companies.
1

Super Slicer
Statement of Warranty
Harper Industries warrants to each purchaser of a new DewEze Super Slicer from an au-
thorized dealer or representative, that such equipment is free of manufacturer’s defects
which appear while in normal service for a period of ONE YEAR commencing with deliver
to the original user. The Super Slicer hydraulic system is warranted for a period of one
year.
The obligation of Harper Industries under this warranty is expressly limited, at our op-
tion, to replacement or repair at a service facility designated by Harper Industries or at
the manufacturing plant in Harper, Ks. A part will be replaced after inspection discloses
it to have been defective. This warranty does not apply to defects caused by damage or
unreasonable use (including failure to provide reasonable and necessary maintenance, or
by performing functions without genuine DewEze accessories) while in the possession of
the consumer.
Harper Industries shall not be liable for the consequential damages of any kind, including
but not limited to consequential labor costs or transportation charges in connection with
replacement or repair of defective parts.
Harper Industries makes no warranty with respect to trade accessories. They are subject
to the warranties of their respective manufacturers.
ANY IMPLIED OR STATUTORY WARRANTIES, INCLUDING ANY WARRANTY OR
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXPRESSLY
LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. Harper Industries makes
no other express warranty, nor is anyone authorized to make any on behalf of Harper In-
dustries.
For further information please contact your nearest DewEze dealer.
RECORDS
Date of Purchase ______ / ______ / ______
Dealer’s Name _________________________________
Dealer’s Phone _________________________________
Serial Number Machine __________________________
2 3

Super Slicer
Table of Contents
OPERATOR SECTION
To the Owner or Operator...............................................
Warranty Statement........................................................
Table of Contents............................................................
Specications..................................................................
Safety Guidelines............................................................
Set-Up Instructions.........................................................
Operation
Hydraulic Requirements...................................
Loading Instructions..........................................
Feeding Instructions.........................................
Adjustments
Feed Rate.........................................................
Flow Control Valve Adjustments.......................
Sickle Drive Adjustments..................................
Maintenance Schedule....................................................
PARTS SECTION
Complete Table Assemly...................................
Table Assembly.................................................
Trailer Assembly...............................................
Sickle Drive Assembly.......................................
Sickle Bar Assembly.........................................
Bellcrank Assembly...........................................
Pitman Assembly..............................................
Sideboards & Shields.......................................
Decals...............................................................
Hydraulic Assembly - PTO Option....................
PTO Kit.............................................................
Table Drive Hydraulics Option..........................
Table Drive Hyd. Schematic.............................
3
1
2
3
4
5
6
7
8
8
8
9
9
11
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.1
2.2
2.3
2.4

Super Slicer
Specications
4 5
Power Hydraulic or PTO powered
Dimensions 91.63” H x 148” L x 119” W (in eld position)
Weight 2750 lbs. w/ trailer
Cutting Device 81” Sickle Bar - 27 individual sickle sections (knives)
NOTE: Following publication of this manual, certain changes in standard equipment and options may have occurred which would
not be included in these pages. Your Harper dealer is the best source for up-to-date information.

Super Slicer
Safety Guidelines
• Use genuine factory parts or parts
with equivalent characteristics, includ-
ing type, strength and material. Fail-
ure to do so may result in product mal-
function and possible injury to the op-
erator and/or others.
• If hardware is not secure, or if some of
the hardware is over-tightened, equip-
ment failure may result, posing poss-
ible safety hazards.
• To prevent possible eye injury, always
wear SAFETY GLASSES while oper-
ating equipment.
• Replace locknuts and locking screws if
you can tighten them without feeling
considerable resistance for several
turns before they are completely tight.
Replace them with factory authorized
parts or their equivalent.
Guards & Shields
• Keep all safety devices in place.
• Replace all worn, damaged, unusable,
missing or lost safety shields and
guards before operating the equip-
ment.
• Keep the equipment in good operating
condition.
Safety Decals
• If safety related or instructional decals
become illegible or are removed, re-
place them immediately. New decals
may be obtained from your local Harp-
er Dealer.
• If you replace parts that have such
decals attached to them, make sure
the decals are replaced with current
versions, and are on the replacement
parts before the machine is operated
again.
Hydraulics
To prevent serious injury or death:
• Relieve pressure on system before
repairing, adjusting or disconnecting
any hydraulic hose or tting.
• Wear proper hand and eye protection
when searching for leaks.
• Use wood or cardboard instead of
hands when looking for leaks.
• Keep all hoses, ttings and compo-
nents in good operating condition.
• Do not use any type of heat or ame
(welding, soldering, cutting torch, etc.)
near pressurized hydraulic lines.
SAFETY WARNING!
HIGH-PRESSURE FLUID HAZARD!
Escaping uid under pressure can pene-
trate skin causing serious injury or death.
5

Super Slicer
Set-Up Instructions
Your SUPER SLICER is shipped from
the factory in a “knockeddown” position to
make it easier to transport. If it is necessary
for you to transport your Super Slicer you will
again need to “knock it down” in order to get
within the legal limits of most public roads. If
transport is necessary or if you have received
your machine in the “knocked-down” position
follow the instructions below to set it up
correctly.
1. Raise the backboard (1) into an up-
right position and secure loosely with
two 1/2” bolts (5) provided on each
end. (See Fig. 1)
2. Set sides (2) in place and fasten down
with ve 5/16” bolts (3) located on the
table sides.
3. Tighten top hold-down brackets (4).
(See Fig. 1).
4. Tighten four 1/2” bolts described in
instruction 1 above.
5. Slide the table into the feeding position
(away from the loading arm) and
secure with bolts (1) provided, one at
each end. (See Fig. 2)
SAFETY WARNING!
OPERATING THE SUPER SLICER LIFT-
ING ARM WITH THE TABLE IN THE ROAD/
TRANSPORT POSITION WILL DO DAMAGE
TO THE LIFT ARM LINKAGE!
Figure 2
6 7

Super Slicer
Operation
NOTE: BEFORE OPERTATING YOUR
NEW SUPER SLICER MAKE A COMPLETE
INSPECTION OF ALL COMPONENTS TO
INSURE THAT ALL THE NUTS AND BOLTS
ARE TIGHT AND THAT NO DAMAGE HAS
OCCURRED DURING SHIPPING.
HYDRAULIC REQUIREMENTS
Your new DEWEZE SUPER SLICER is de-
signed to be used as a mobile feeding unit
mounted on a trailer or as a stationary unit
in a permanent installation. Regardless of
the type of use the SUPER SLICER WILL
REQUIRE 15 GPM (gallons per minute) of
hydraulic oil ow and a minimum of 1800 PSI
(pounds per square inch) hydraulic pressure
to operate properly. Be sure that the hydrau-
lic system you intend to use is functioning
properly and that the oil is clean and of good
quality.
Two hydraulic remotes are required to oper-
ate the trailer mounted Super Slicer. One is to
control the lift arm for loading the bales and
the other is to operate the slicer table. Each
remote must be capable of reversible ow.
You may want to mark the remotes to make
sure that you hook up the hydraulics the
same way each time you use the machine.
NOTE: When using a hydraulically driven
Super Slicer II continuously (for more than
3 bales in 10 minutes) the following adjust-
ments must be made to tractors equipped
with a high ow, pressure compensated load
sense hydraulic system.
1. Flow (speed) must be controlled on
the tractor remote outlet. To set this
speed rst set the Slicer ow as
outlined in the manual. Secondly,
turn the ow control toward the “turtle”
on the tractor selective control outlet
until the speed begins to decrease.
Stop turning as soon as you can notice
a decrease in speed. Failure to follow
these procedures may result in the
overheating of the tractor hydraulic
system, as the system will be at
maximum ow and pressure. (Load is
sensed at the tractor selective control
valve and if this valve is wide open the
system is at constant maximum
pressure / ow.
2. The alternative to the above is to buy a
“ow limiter valve” and attach it
between the quick disconnect and the
hose on the pressure side.
3. On PTO model Super Slicer II, ow
must also be regulated at the selective
control outlet for the slat motor.
NOTE: If the above instructions are not fol-
lowed, the following symptoms may develop:
Rapid heating of the tractor hydraulic
oil, this will show up as a loss of speed
on the hydraulic motor speed. These
 motorsloseefciencyrapidlywhenoil
over heats.
7

Super Slicer
LOADING INSTRUCTIONS
(Trailer Mounted Unit Only)
Approach the bale on its right side with the
lift arm lowered to the ground. If your trac-
tor is equipped with dual rear wheels, you
may have to reposition the tongue to allow
the tractor to pass the bale. (See the instruc-
tions above). Cradle the bale in the lift fork
by moving forward so that the bale is against
the back of the fork. Lift the bale all the way
up so that the bale rolls onto the table slats.
Move the bale toward the sickle by activating
the feeder and stop as the bale reaches the
sickle. To load and carry a second bale, re-
peat the above process and raise the second
bale until it rests snuggly against the rst.
NOTE: Be sure to raise the lift arm to the
upright position and latch the safety chain
whenever you transport your super slicer on
the road!
FEEDING INSTRUCTIONS
To engage the feeding operation of the Su-
per Slicer, idle the tractor engine, engage the
slicer table hydraulics and increase the en-
gine speed to 2100 RPM. This is the optimum
speed for processing for most tractors and
will process an average bale in approximately
four minutes at the minimum feeder setting.
SAFETY WARNING!
Stay clear of the table and cutter bar when
the machine is in operation!
If the system stalls, reverse the slats and try
again. If stalling continues, increase the RPMs
of the tractor about 10 percent.
NOTE: Always wait until the rst bale has
been processed completely and the table
slats have stopped before loading the second
bale onto the table.
SAFETY WARNING!
Excessive sickle speed may cause table vi-
bration and damage to the hydraulic motor
and/or the sickle!
FEEDING RATE
The feeding rate may be adjusted by chang-
ing the speed of the feeder chain, or by
adjusting the distance between the sickle and
the table slats. To change this distance, use
the following procedure.
SAFETY WARNING!
Turn off tractor and disconnect the hydrau-
lic hoses before making any adjustments
to the sickle! Failure to do so could result
in serious personal injury!
1. Loosen the two 5/8” hex bolts (1) and
two 5/8” carriage bolts (2) that hold the
sickle bar in place. (See Fig. 3)
2. Screw the 3/4” all thread adjustment
bolts (3) in or out at each end of the
sickle. Make sure that each end is
adjusted so that the sickle is parallel
with the table slats. Use a tape
measure to gauge each end.
Adjustments
8 9

Super Slicer
NOTE: The backboard will slide up or down
in relation to the sideboards without loosen-
ing any other bolts.
3. Retighten the four 5/8” bolts loosened
in step one on previous page.
4. Adjust the Pitman rod assembly as
follows to set the sickle register.
(Fig. 4)
A. Loosen two 3/8” socket head
screws (1) on turnbuckle.
B. Rotate Pitman arm turnbuckle
(2) 1-1/2 times for every one inch
that the thickness was changed
(Step two above).
SHORTEN THE ARM when reducing
the thickness of cut
LENGTHEN THE ARM when
increasing the thickness of cut.
C. Loosen two 3/8” socket head
screws loosened in Step A.
NOTE: Improper sickle register causes
machine vibration and shear bolt breakage in
PTO models..
FLOW CONTROL VALVE ADJUSTMENT
The ow control valve on the right controls
the speed of the sickle; the valves loosen the
knob on the adjustment lever and move the
lever to higher number to increase speed,
and to lower the number to decrease speed.
After moving the lever, tighten the knob to
hold the lever in place.
For initial setting of the valves, set each
adjusting lever on “5”. Fine tune the speed of
the sickle and slats by adjusting the valves
individually to get the proper cutting for the
type of hay you are processing.
SICKLE DRIVE ADJUSTMENT
The sickle and drive are pre-set at the factory.
If the drive needs to be set because of loose
bolts, sickle change, etc., use the following
procedure:
SAFETY WARNING!
Turn off and depressurize the hydraulic
power source before working on the sickle
in any way by activating the controls both
ways with the system off.
1. Disconnect the chain coupler (1) of the
drive motor. (Fig 5)
9

Super Slicer
2. Loosen 4 bolts (1) on Bell Crank (2).
(See Fig. 6). Position the Bell Crank
so that the Bell Crank arm connected
to the sickle head (3) is perpendicu-
lar to the Pitman rod (4). Use a
square as shown to set the center line
of the arm perpendicular. The center
of the sickle sections (5) should be
midway between the points of the stub
guards (6). If not, adjust the tie rod
end
on the sickle head to center the sickle
sections.
3. Adjust the Bell Crank so there is no
more than 1/16”clearance between
sickle bar (7) and back of stub guard.
Tighten 4 mounting bolts.
4. Keeping Bell Crank in perpendicular
position, loosen the 3/8” socket
head screws (8), and adjust the
Pitman Arm Turnbuckle (9) until the
Pitman Arm mounting bolt (10) is
either TOP DEAD CENTER or
BOTTOM DEAD CENTER. Tighten
socket head screws.
5. Be sure that all guards and shields are
back in place before operating the
machine.
10 11

Super Slicer
TRAILER MAINTENANCE
MONTHLY (Or every 100 bales)
Grease the linkage of the lift arm to avoid binding and rust.
ANNUALLY
Clean and repack the wheel bearings.
TABLE MAINTENANCE
MONTHLY (Or every 100 bales)
Grease the Pitman drive bearings, one grease tting per bearing.
Grease knuckle joints on Pitman arm (two ttings)
Check the conveyor chain for tightness. The chain should not swag more than 6” from the
bottom of the table at the center. Adjust the make-up roller equally at each end for
maximum chain life.
Lubricate the system drive chains with chain oil.
DRIVE SHAFT MAINTENANCE
MONTHLY (Or every 100 bales)
Grease all grease zerks on the drive shaft.
(Zerks located at each end and one in the middle of the shaft.)
Inspect and replace any broken or missing safety shields.
Check for loose bolts on drive shaft.
Maintenance
11

Super Slicer

Super Slicer
PARTS SECTION

Super Slicer

Super Slicer
Table of Contents
PARTS SECTION
Complete Table Assemly...................................
Table Assembly.................................................
Trailer Assembly...............................................
Sickle Drive Assembly.......................................
Sickle Bar Assembly.........................................
Bellcrank Assembly...........................................
Pitman Assembly..............................................
Sideboards & Shields.......................................
Decals...............................................................
Hydraulic Assembly - PTO Option....................
PTO Kit.............................................................
Table Drive Hydraulics Option..........................
Table Drive Hyd. Schematic.............................
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.1
2.2
2.3
2.4

Super Slicer

Super Slicer
Parts List
ITEM QTY PART #DESCRIPTION
1 20 110054 Bolt, 7/16-14 X 2.5 in Carriage
2 2 110391 Bolt, 5/8-11 X 2 in Carriage 3 6 110400 BOLT, 3/8-16 X 2.0 4 4 110402 Bolt, 3/8-16 X 1.25 in Carriage 53 110407 BOLT, 5/8-11 X 5.0
6 2 110410 BOLT, 1/4-20 X 2.5 74 110419 BOLT, 1/2-13 X 1.75
84110420 BOLT, 3/8-16 X 1.0
9 20 110425 BOLT, 3/8-16 X 1.25
10 8 110429 BOLT, 1/2-13 X 1.5 11 6 110437 BOLT, 3/8-16 X 0.75, WIZ FLANGE 12 2 110513 BOLT, 5/8-11 X 2.5
13 6 110535 BOLT, 7/16-14 X 1.5
14 126 110561 BOLT, 1/4-20 X .75
15 4 110588 NUT, 1/2-13 WIZ FLANGE 16 1 110596 NUT, 3/4-10 17 7 110597 NUT, 5/8-11 HEX 18 1 110599 NUT, 5/8-11, CASTLE 19 2 110609 NUT, 1/4-20
20 10 110610 NUT, 1/2-13
21 4110615 NUT, 1/2-13, UNITORQUE LOCK
22 126 110630 NUT, 1/4-20 LOCK (NYLON INSERT)
23 26 110641 NUT, 7/16-14
24 1 110645 NUT, 3/8-16 WIZ FLANGE 25 3 110650 WASHER, 5/8" FLAT STANDARD
26 7 110655 WASHER, 5/8" LOCK
27 6 110658 WASHER, 1/2" FLAT STANDARD
28 1 110660 WASHER, 1/2 FLAT SPECIAL 1.5 OD
29 4 110666 WASHER, 1/2" LOCK
30 2 110667 WASHER, 1/4" LOCK
31 26 110671 WASHER, 7/16" LOCK 32 34 110672 WASHER, 3/8" LOCK 33 38 110676 WASHER, 3/8" FLAT STANDARD 34 28 110826 NUT, 3/8-16 GR 5 35 4 111148 Bolt, 1/2-13 X 2.5 in Carriage
Parts List
ITEM QTY PART # DESCRIPTION
36 4 120115 Adapter, 10mb-8fp
37 1 120200 ADAPTER, 8MP-8FPX90
38 1 120203 Adapter, 8mp-8fpx-8fpx 39 1 120414 Adapter, 10mb-8fp90
40 2 200010 DANGER DECAL 41 1 340007 Sprocket, 6030 X 1.25 42 2 400008 Decal, Strobe Super Slicer
43 3 400009 DECAL, DEWEZE BLACK OUTLINE
44 2 400011 Decal, Super Slicer
45 4 400012 Decal, Danger Moving Sickle
46 2 400014 DECAL, SHIELD REMOVED
47 22 400031 Stub Guard, Super Slicer II
48 1 400051 STUB GUARD, MODIFIED
II,laceD560004294
50 1 410075 SIDE, LEFT/FRONT
51 1 410076 SIDE, RIGHT/BACK 52 2 410121 PAD, BELLCRANK MOUNT
53 2 410135 RETAINER, SIDEBOARD 54 1 410145 PITMAN ARM BRACKET ASSEMBLY 55 1 410148 Shield, Sickle Drive 56 1 410150 Shield, Sickle Assembly 57 1 410182 Pitman Assembly 58 1 410186 Tie Rod End, ES2082R
59 1 410191 Sickle Assembly, Service Part
60 1 410196 BACKBOARD ASSEMBLY
61 1 410198 BELLCRANK ASSEMBLY
62 5410232 Bearing Insert, 2.83, 1.25" ec Lk
63 8 410233 Flange, 2 Hole 64 4 410238 Key, 1/4 X 1/4 X 2.25
65 3 410243 BEARING, 2fng Sd 1.375
66 1 410244 WELDMENT, PITMAN DRIVE SHAFT
67 1 410261 COTTER PIN, 1/8 X 1.75
68 2 410281 ADJUSTMENT BRACKET ASSY
69 1 410282 Weldment, Adjustment Screw, Long 70 1 410321 Key, 1/4 X 1 Woodruff
Parts List
ITEM QTYPART # DESCRIPTION
71 1 410365 MOTOR ADJ. PLATE
72 1 410370 Shield, Slat Motor
73 2 410371 Shield, Sickle Motor
74 1 410375 SPROCKET, 60b10 X 1.0
75 1 410384 SICKLE MOUNT WELDMENT 76 1 410389 KEY 5/16" X 5/16" X 1 1/4"
77 1 410393 Shield, Pitman Arm
78 1 410394 SPACER, SICKLEBAR
79 1 410441 Connecting Link, Half-offset #60 80 1 410442 Connecting Link, #60 Chain
81 10 410710 PLATE, STUB GUARD ADJ.
82 10 410711 SHIM, STUB GUARD
83 3 411117 Chain, Feeder
TALS5311140148
85 1 411137 SHAFT, SLAT DRIVE
86 1 411140 Shield, Drive Sprocket 87 1 411168 Weldment, Table, Super Slicer II
88 3 411170 Half Link, Offset, 2060h
89 1 411171 WELDMENT, SLAT ROLLER, SSII
90 1 411176 SPACER, PITTMAN BRACKET
91 2 411294 CENTER BEARING MOUNT
92 1 411524 SICKLE MOUNT SHIM
93 11 415003 Toothed Slat
94 1 420001 Hose .50 X 135.39 8mp/8mpx
95 1 420005 COUPLER, PIONEER MALE
96 1 420027 Hose .50 X 20.00 8mp/8mp
97 1 420031 Hose .50 X 24.00 8mp/8mp
98 1 420048 VALVE, FLOW CONTROL, -10 SAE 99 1 420128 Motor, Eaton 101-1014 (14.1 CI)
100 1 440034 Chain, Slat Drive 101 3 440070 Sprocket,2062b13x1.25k2ss,time
102 1 500036 DECAL, DO NOT STAND
103 2 500038 Decal, Danger Keep Covers In Place
104 20 510161 SetScrew, 3/8-16 X 0.5
1/15/2019
Complete Table Assembly
1.1

Super Slicer
1.2
22
17
25
15
13
25
15
25
15
21
8
24
11
1
3
11
10
12
14
13
2
9
6
26
16
4
1
11
11
18
14
13
10
12
23
20
7
7
5
19.2
19.3
19.1
19
Table Assembly
26
16
4
16
2
2/24/2017
