Case IH MX 210, 230, 255, 285
SmarTrax™ Installation Manual

While every effort has been made to ensure the accuracy of this document,
Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained
herein.
Raven Industries shall not be held responsible or liable for the effects of
atmospheric conditions and sunspot activity on the performance of our products.
Raven Industries cannot guarantee the accuracy, integrity, continuity, or
availability of the GPS signal from the U.S. Department of Defense/NAVSTAR
GPS satellites, the OmniSTAR correction service or the WAAS correction
service.
Raven Industries accepts no responsibility for the use of the signal for other than
the stated purpose. Raven Industries shall not be responsible or liable for
incidental or consequential damages or a loss of anticipated benefits or profits,
work stoppage or loss or impairment of data arising out of the use, or inability to
use, the SmarTrax or any of its components.
Disclaimer

Table of Contents
Manual No. 016-0190-060 i
Chapter 1 Important Safety Information................................................. 1
Important Safety Information .....................................................................................................1
Chapter 2 Introduction............................................................................. 3
Updates .....................................................................................................................................4
Preparing for Installation ...........................................................................................................4
Hydraulic Fittings .......................................................................................................................5
Kit Contents ...............................................................................................................................5
Chapter 3 Mounting the SmarTrax Hydraulic Valve.............................. 9
Mount the SmarTrax Hydraulic Valve ........................................................................................9
Affixing the SmarTrax Tampering Warning Label ....................................................................10
Chapter 4 Hydraulic Connections......................................................... 11
Install the Pressure, Tank, Left, and Right Hoses ...................................................................12
Install the LS-Steer and LS-PV Hoses ....................................................................................14
Install the Pressure Switch ......................................................................................................15
Hydraulic Connection Diagram ...............................................................................................16
Chapter 5 Wiring and Electrical Connections ..................................... 17
Connecting the SmarTrax Hydraulic Valve ..............................................................................17
Connecting the Pressure Override Switch ..............................................................................18
Route the Console Cable Harness ..........................................................................................18
Install the Foot Switch .............................................................................................................18
Mount the SmarTrax Controller ...............................................................................................19
Install the Yaw Sensor .............................................................................................................20
Install the SmarTrax Node .......................................................................................................21
Chapter 6 Start-Up Procedures............................................................. 23
Remove Air from the Hydraulic System ..................................................................................23
Verify the SmarTrax Installation ..............................................................................................24
Chapter 7 System Drawings.................................................................. 25

Table of Contents
ii CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual

CHAPTER
1
Manual No. 016-0190-060 1
C hapt er 1 Important Safety
Information
Important Safety Information
Read this manual and the operation and safety instructions included with your implement and/or controller
carefully before installing the SmarTrax™ system.
•Follow all safety information presented within this manual
•If you require assistance with any portion of the installation or service of your Raven equipment, contact
your local Raven dealer for support.
•Follow all safety labels affixed to the SmarTrax components. Be sure to keep safety labels in condition and
replace any missing or damaged labels. To obtain replacements for missing or damaged safety labels,
contact your local Raven dealer.
When operating the machine after installing SmarTrax, observe the following safety measures:
•Be alert and aware of surroundings.
•Do not operate SmarTrax or any agricultural equipment while under the influence of alcohol or an illegal
substance.
•Remain in the operator’s position in the machine at all times when SmarTrax is engaged.
•Disable SmarTrax when exiting from the operator’s seat and machine.
•Do not drive the machine with SmarTrax enabled on any public thorough-fare or main road.
•Determine and remain a safe working distance from other individuals. The operator is responsible for
disabling SmarTrax when the safe working distance has diminished.
•Ensure SmarTrax is disabled prior to starting any maintenance work on SmarTrax or the machine.
Please review the operation and safety instructions included with your implement and/or controller.
NOTICE

Chapter 1
2 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
•Always wear appropriate protective equipment when working on hydraulics.
•This machine must remain stationary and switched off with the booms unfolded and supported while
installation or maintenance is conducted.
•Before starting the hydraulic installation, be sure to bleed pressure from the hydraulic system.
•Hydraulic fluid may be hot or under high pressure. When starting the machine for the first time after
installing the SmarTrax system, be sure that all persons stand clear of the machine in case a hose or fitting
has not been completely tightened.
Hydraulic Safety
•Raven Industries recommends that appropriate protective equipment be worn at all times when working on
the hydraulic system.
•Never attempt to open or work on a hydraulic system with the equipment running. Care should always be
taken when first opening a system that has previously been pressurized.
•When disconnecting the hydraulic hoses or purging is required, be aware that the hydraulic oil may be
extremely hot and under high pressure. Caution must be exercised.
•Any work carried out on the hydraulic system must be performed in accordance with the machine
manufacturer's approved maintenance instructions.
•When installing SmarTrax hydraulics or performing diagnostics, maintenance, or routine service, ensure
precautions are taken to prevent any foreign material or contaminants from being introduced in the
machine's hydraulic system. Objects or materials that are able to bypass the machine’s hydraulic filtration
system will adversely reduce performance and possibly damage the SmarTrax hydraulic valves.
Electrical Safety
•Always verify that the power leads are connected to the correct polarity as marked. Reversing the power
leads could cause severe damage to the equipment.
•Ensure that the power cable is the last cable to be connected.
WARNING
CAUTION

CHAPTER
2
Manual No. 016-0190-060 3
C hapt er 2 Introduction
Congratulations on your purchase of the Raven SmarTrax system. This system is designed to provide cutting-
edge, hands-free steering of agricultural equipment via GPS (Global Positioning System) coordinates.
This manual applies to the following machines. For future reference, write your serial number in the space
below.
Make: CaseIH MX 210, 230, 255, and 285
Year: 
Serial Number:
FIGURE 1. CaseIH MX 210
NOTICE
This machine is equipped with Aeroquip STC®
fittings which require two STC Quick release
tools in order to remove the hydraulic fittings.A
flat screwdriver may also be used to remove
fittings, but may make removal difficult. These
tools can be purchased from Aeroquip or Raven
Industries.
Release Tool Aeroquip P/N Raven P/N
STC-06 FF90213-06 333-0012-152
STC-08 FF90213-08 333-0012-153

Chapter 2
4 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
Updates
Updates for Raven manuals as well as software updates for Raven consoles are available at the Applied
Technology Division web site:
http://www.ravenprecision.com/Support/index2.jsp
Sign up for e-mail alerts and we will notify you when updates for your Raven products are available on the
Raven web site.
http://www.ravenprecision.com
Preparing for Installation
Before installing SmarTrax, park the machine where the ground is level, clean, and dry. Be sure to follow
proper safety practices and procedures during the SmarTrax installation procedure. Bleed pressure from the
hydraulic system and leave the machine turned off for the duration of the installation process. Carefully read
and follow the instructions in this manual to properly complete the installation process.
Recommendations
Observe the following recommendations while installing the SmarTrax system:
•Use part numbers to identify parts.
•Do not remove the plastic wrapping from a part until it is necessary for installation.
•Do not remove plastic caps from a part until it is necessary for installation.
Tools Needed
Before beginning the installation process, it is a good idea to gather all the tools that you will need. These tools
include the following items:
•STC Quick release tools
•Screwdrivers of various sizes
•SAE Standard-sized wrenches
•Allen wrenches
•Utility knife
•Drill
•Drill bits
•Side Cutters
•Pliers

2
Manual No. 016-0190-060 5
Introduction
Point of Reference
The instructions in this manual assume that you are standing behind the machine, looking toward the cab.
Hydraulic Fittings
The following fitting types may be referenced in this manual:
FIGURE 2. Hydraulic Fitting Types
Kit Contents
This section contains a list of the kit contents that you should have received with this SmarTrax kit. Before you
begin assembling the kit, compare theitems in your SmarTrax kit with this list. If you have questions about your
kit, contact your local Raven dealer or the Raven Customer Support Center.
In addition to the following kits, a SmarTrax Controller or Node kit is required to complete installation of the
SmarTrax system. Contact your local Raven dealer for available kits and ordering information.
TABLE 1. CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Kit (P/N 117-0195-060)
Picture Item Description Part Number Qty
Not pictures Manual - SmarTrax Installation 016-0190-060 1
Sensor - Yaw 063-0172-684 1
Cable - SmarTrax Console Harness 115-0171-775 1
Plate - Hydraulic Valve Mounting 107-0171-578 1
ORFS Fitting (M)SAE O-Ring Fitting (M)
JIC Fitting (M) STC Fitting (F)

Chapter 2
6 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
Bracket - Hydraulic Valve Mounting 116-0159-527 1
Switch - SmarTrax Pressure 422-0000-074 1
Valve - SmarTrax Hydraulic 334-0003-066 1
Label - Tampering Warning 041-0159-689 1
Bolt - 5/16” Hex Head 311-0052-104 4
Bolt - 3/8” Hex Head 311-0054-105 4
Nut - 3/8” Hex 312-1001-037 4
Washer - 5/16” Split Lock 313-1000-019 4
Washer - 3/8” Split Lock 313-1000-022 4
Washer - 3/8” Flat 313-2300-013 4
Fitting - 9/16” JIC (M/F) 45° Swivel Elbow 333-0012-027 4
TABLE 1. CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Kit (P/N 117-0195-060)
Picture Item Description Part Number Qty

2
Manual No. 016-0190-060 7
Introduction
Fitting - 9/16” JIC (M/F) 90° Swivel Elbow 333-0012-042 2
Fitting - -8 STC (F/F/F) Tee 333-0012-150 4
Fitting - -6 STC (F) to 11/16” ORFS (F) 45° Elbow 333-0012-151 1
Hose - -8 STC (M) TO -8 STC (M), 5" 214-1000-282 4
Hose - -8 STC (M) 90° To 9/16” JIC (F), 40" 214-1000-283 4
Hose - -6 STC (M) To 9/16” JIC (F), 56" 214-1000-284 1
Hose - 11/16” ORFS (M) To 9/16” JIC (F), 30" 214-1000-285 1
TABLE 1. CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Kit (P/N 117-0195-060)
Picture Item Description Part Number Qty

Chapter 2
8 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual

CHAPTER
3
Manual No. 016-0190-060 9
C hapt er 3 Mounting the
SmarTrax Hydraulic
Valve
Mount the SmarTrax Hydraulic Valve
1. Open the door on the left side of the machine and remove the air cleaner and filter.
FIGURE 1. SmarTrax Valve Mounting Location
2. Mount the valve mounting bracket (P/N 116-0171-527) to the step bracket on the left side of the machine
using the supplied bolts (P/N 311-0054-105), lock washers (P/N 313-1000-022), nuts (P/N 312-1001-037)
and flat washers (P/N 313-2300-013).
NOTICE
The appearance of the SmarTrax hydraulic
valve may vary slightly from the images
contained in this manual. However, the fittings,
hose connections, and cable connections
remain the same.

Chapter 3
10 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
Note: Depending on the year and model of the machine, you may also need to use the supplied
mounting plate (P/N 116-0159-578).
3. Mount the SmarTrax hydraulic valve (P/N 334-0003-066) to the mounting bracket (P/N 116-0159-527) using
the supplied bolts (P/N 311-0052-104) and flat washers (P/N 313-1000-019).
FIGURE 2. SmarTrax Valve Mounting Location
Affixing the SmarTrax Tampering Warning
Label
Raven Industries supplies a tampering warning label (P/N 041-0159-689) with all SmarTrax kits. This label
should be applied on or near the SmarTrax hydraulic valve or mounting bracket and in a location where anyone
working on the machine is able to clearly see and read the label.
1. Thoroughly clean and dry the surface to which the label will be affixed.
2. Remove the protective backing from the tampering warning label (P/N 041-0159-689).
3. Carefully apply the label to the cleaned area and rub with a dry cloth to ensure the label is firmly applied.
SmarTrax Mounting
Bracket (P/N 116-
0159-527)
SmarTrax Hydraulic
Valve (P/N 334-
0003-066)

CHAPTER
4
Manual No. 016-0190-060 11
C hapt er 4 Hydraulic
Connections
WARNING
Hydraulics may be under pressure. Never
attempt to open or work on a hydraulic system
with the equipment running. Care should
always be taken when working on a system that
has previously been pressurized. When
disconnecting or purging hydraulic connections,
be aware that hydraulic oil within the system
may be extremely hot and under high pressure.
CAUTION
Ensure precautions are taken to prevent any
foreign material or contaminants from being
introduced into the machine’s hydraulic system.
Objects or materials that are able to bypass the
machine’s hydraulic filtration system will
adversely reduce performance and possibly
damage the SmarTrax hydraulic valves.
CAUTION
Before beginning the SmarTrax hydraulic
installation procedure, turn off the machine and
relieve hydraulic pressure by turning the wheel
left and right.

Chapter 4
12 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
Install the Pressure, Tank, Left, and Right
Hoses
1. Locate the steering orbitrol underneath the front of the cab.
2. Using an STC fitting removal tool or flat screwdriver, disconnect the original pressure, tank, left, and right
lines from the steering orbitrol.
Note: When disconnecting the hoses from the machine, label the hoses in order to avoid any confusion
when reconnecting the hoses.
FIGURE 1. Machine’s Steering Orbitrol
NOTICE
This machine is equipped with Aeroquip STC®
fittings which require two STC Quick release
tools in order to remove the hydraulic fittings.A
flat screwdriver may also be used to remove
fittings, but may make removal difficult. These
tools can be purchased from Aeroquip or Raven
Industries.
Release Tool Aeroquip P/N Raven P/N
STC-06 FF90213-06 333-0012-152
STC-08 FF90213-08 333-0012-153

4
Manual No. 016-0190-060 13
Hydraulic Connections
3. Install the provided extension hoses (P/N 214-1000-282) onto the steering orbitrol’s P, T, L, and R ports.
4. Install the supplied run tees (P/N 333-0012-150) onto the ends of the extension hoses and reconnect the
original hoses to their corresponding tee fittings.
FIGURE 2. Supplied Hoses Installed on the Machine’s Steering Orbitrol
5. Connect the supplied hoses (P/N 214-1000-283) to the remaining branch of the tee fitting.
6. Route the hoses under the air cleaner and in between the side panel and frame rail to the SmarTrax
hydraulic valve using a supplied 45° elbow (P/N 333-0012-027) or 90° elbow (P/N 333-0012-042) if
necessary.
7. Refer to the following table to connect the hoses to the appropriate ports of the SmarTrax hydraulic valve.
FIGURE 3. Hoses Connected to SmarTrax Hydraulic Valve
Hose SmarTrax Hydraulic Valve
Pressure P
Tank T
Left Steer A
Right Steer B

Chapter 4
14 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
Install the LS-Steer and LS-PV Hoses
1. Disconnect the original load sense hose from the steering orbitrol.
FIGURE 4. Machine’s Steering Orbitrol
2. Connect the original load sense hose to the extension hose (P/N 214-1000-285) using the supplied 45 °
elbow (P/N 333-0012-151).
3. Route the hose to the ‘LS-PV’ port on the SmarTrax hydraulic valve.
4. Connect the supplied ‘LS-Steer’ hose (P/N 333-0012-284) to the ‘LS-Steer’ port on the SmarTrax hydraulic
valve.
5. Route and connect the other end of the hose to the steering orbitrol.
FIGURE 5. SmarTrax Hydraulic Valve

4
Manual No. 016-0190-060 15
Hydraulic Connections
Install the Pressure Switch
1. Attach the pressure switch (P/N 422-0000-074) directly to the ‘PS’ port on the SmarTrax hydraulic valve.
FIGURE 6. Pressure Switch connected to SmarTrax Hydraulic Valve
‘PS’ Port

Chapter 4
16 CaseIH MX 210, 230, 255, and 285 SmarTrax Installation Manual
Hydraulic Connection Diagram
