Titan Attachments SS6DOZER72 User manual

6 WAY DOZER BLADE
SS6DOZER72, SS6DOZER84
191606, 191607
Operator’s Manual
Read the Operator’s Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

2
NOTES FROM TITAN
•Please read the product manual completely before assembly
•Check against the parts list to make sure all parts are received
•Wear proper safety goggles or other protective gears while in assembly
TO OPERATE THIS IMPLEMENT,
USER MUST FIRST CONNECT TO EXTERNAL 12V POWER SOURCE.
GENERAL COMMENTS
Congratulations for having this dozer blade! Your concrete mixer was carefullydesigned and
manufactured to give you years of dependable service. Your concrete mixer will require some minor
maintenance (such as cleaning and lubricating) to keep it in top working condition. Be sure to observe
all safety precautions and maintenance procedures as described in this manual.
ABOUT THIS MANUAL
This manual has been designed to help you do a better and safer job. Read this manual carefully and
become familiar with its contents. Remember, never let anyone operate this unit without reading the
"Safety Precautions" and "Operation Instructions" sections of this manual. Unless noted otherwise, right,
and left sides are determined from the position of the skid steer operator sitting in the seat facing forward.
SERVICE
When service your dozer blade, pls. remember to use only manufacturer replacement parts. Substitute
parts may not meet the standards required for safe, dependable operation. To facilitate parts ordering, pls.
record the model No. and serial No. of the metal plate on your unit.
SAFETY PRECAUTIONS
The dozer blade is designed to be easy to use and maintain. They are operated by the skid steer auxiliary
hydraulics. The dozer blade mount to the toolbar or quick attach mechanism for easy mounting.
BEFORE OPERATION
1. The operator must read the operation manual carefully before installation, operation or
maintenance. Improper operation will cause the machine damaged or the operator dead.
2. Read all the safe signs and safe declarations. Obey all the professional safe terms, local laws, or
the professional directions.
3. Familiar with the dozer blade about functions, specs, and operation. Replace the to-be-damaged
parts in time. Make sure all the hydraulic installations and couplings connect firmly, and all the safe
signs stick on the suitable positions clearly.

3
TO THE OPERATOR
1. Warning! Protect Against Flying Debris –Always wear proper safety glasses, goggles, or a face
shield when driving pins in or out, or when any operation causes dust, flying debris, or any other
hazardous material.
2. Don’t modify the dozer blade casually.
3. Should keep the machine on the flat ground when repair, far away from the transportation and
other dangerous places.
4. Should use the right tools to repair.
5. Don’t operate the machine, unless you are professional, have certificates, and familiar with its
functions, specs and safe operation rules.
6. Must not leave the machine when the machine is running. Must stop the engine at first and then
remove the key if want to leave.
IMPORTANT SAFETY INFORMATION
THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE
PRODUCTS DESCRIBED IN THIS MANUAL.
SAFETY AT ALL TIMES
Thoroughly read and understand the instructions given in this manual before operation. Refer
to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to
operate this equipment who has not thoroughly read and comprehended this manual. Do not
allow anyone who has not adequately trained in the safe operation of the equipment.
•The operator must not used drugs or alcohol as they can change the alertness or
coordination of that person while operating, equipment. The operator should if taking
over the counter drugs, seek medical advice on whether he/she can safely operate the
equipment
•The operator should be familiar with all functions of the unit.
•Operate implement from the driver’s seat only.
•Make sure all guards and shields are in place and secured before operating the tool.
•Do not leave a tractor or implement unattended with the engine running.
•Dismounting from a moving tractor could cause severe injury or death.
•Do not allow anyone to stand between tractor and implement while backing up to
implement.
•Keep hands, feet, and clothing away from power-driven parts.
•Wear snug-fitting clothing to avoid entanglement with moving parts.
•Watch out for wires, trees, etc., when raising implements. Make sure all persons are clear
of the working area.
•Turning the tractor too tight may cause implement to ride upon wheels. This activity could
result in injury or equipment damage.
•Do not carry passengers on the tool at any time.
•Detach and store implement where children do not play often. Secure implements by
using blocks and supports.

4
LOOK FOR THE SAFETY ALERT SYMBOL
The SAFETY ALERT SYMBOL indicates a potential hazard to personal safety, and individuals must
take safety precautions. When you see this symbol, be alert and carefully read the message that
follows it. In addition to the design and configuration of equipment, hazard control and accident
prevention depend on the awareness, concern, prudence, and proper training of personnel involved
in the operation, transport, maintenance, and storage.
BE AWARE OF SAFETY ALERT WORDS
DANGER: Indicates imminently hazardous practices. A situation that, if not avoided, will result in
death or severe injury. The signal word is limited to the most extreme situation, typically for
machine components that, for functional purposes, cannot be guarded.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death or
severe injury, and includes hazards that are exposed when guards remove. Use warnings to alert
against unsafe practices.
CAUTION: Indicates a potentially hazardous situation that may result in minor or moderate injury if
not avoided. It may also be used to alert against unsafe practices.
FOR YOUR PROTECTION
Thoroughly read and understand the “Safety Label” section, read all instructions noted on them.
AVOID UNDERGROUND UTILIITES
•Always contact your local utility companies (electrical, telephone, gas, water, sewer, and
others) before digging so that they may mark the location of any.
•Be sure to ask how close you can work to the marks they positioned.
SHUTDOWN AND STORAGE
•Lower lift arms and put attachment flat on the ground.
•Turn off engine and engage parking brake.
•If included, raise seat bar and move controls until both locks.
•Remove key to prevent unauthorized starting.
•Use steps, grab handles and anti-slip surfaces when getting on and off the loader.
USE SAFETY LIGHTS AND DEVICES
•Slow-moving tractors, self-propelled equipment, and towed implements can create a hazard
when driven on public roads. They are challenging to see, especially at night.
•Flashing warning lights and we recommend turn signals whenever driving on the public road.
PRACTICE SAFE MAINTENANCE
•Understand procedure before doing work. Use proper tools and equipment, refer to
Operator’s manual for additional information.
•Work in a clean dry area.

5
•Lower attached implement to the ground and follow all shutdown procedures before leaving
the operators seat to perform maintenance.
•Allow implement to cool completely before working on it
•Disconnect battery ground cable (-) before servicing or adjusting electrical systems or before
welding on implement.
•Do not grease or oil implement while it is in operation.
•Inspect all parts. Make sure parts are in good condition & installed properly.
•Remove buildup of grease, oil, or debris.
•Remove all tools and unused parts from implement before operation.
TRANSPORT MACHINERY SAFELY
•Comply with state and local laws
•The maximum transport speed for implement is 20 mph, DO NOT EXCEED. Never travel at a
rate that does not allow adequate control of steering and stopping. Some rough terrain
requires a slower speed.
•Sudden braking can cause a towed load to swerve and upset. Reduce speed if the towed load
is not equipped with brakes.
•Use the following maximum speed –tow load weight ratios as a guideline:
•20 mph when weight is less than or equal to the weight of the tractor.
•10 mph when weight is double the weight of the tractor.
IMPORTANT: Do not tow a load that is more than double the weight of the tractor.
KEEP RIDERS OFF MACHINERY
•Riders obstruct the operator’s view; they could be struck by foreign objects or thrown from
the machine.
•Never allow children to operate equipment.
•Practice Safe Maintenance
•Understand procedure before doing work. Use proper tools and equipment; refer to
Operator’s Manual for additional information.
•Work in a clean, dry area
•Lower the implement to the ground, put the tractor in park, turn off the engine, and remove
the key before maintenance.
•Allow implement to cool completely.
•Do not grease or oil implement while it is in operation.
•Inspect all parts. Make sure details are in good condition and installed correctly.
•Remove the buildup of grease, oil, or debris.
•Remove all tools and unused parts from implementation before operation.
PREPARE FOR EMERGENCIES
•Be prepared if a fire starts.
•Keep a first aid kit and fire extinguisher handy
•Keep emergency numbers for doctor, ambulance, hospital, and fire department near the
phone.
WEAR PROTECTIVE EQUIPMENT

6
•Wear protective clothing and equipment appropriate for the job. Avoid loose-fitting clothing.
•Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear
suitable hearing protection such as earmuffs or earplugs.
•Operating equipment safety requires the full attention of the operator. Avoid wearing radio
headphones while operating machinery.
AVOID HIGH-PRESSURE FLUIDS HAZARD
•Escaping fluid under pressure can penetrate the skin causing severe injury.
•Avoid the hazard by relieving pressure before disconnecting hydraulic lines or performing
work on the system.
•Ensure all hydraulic fluid connections are tight and all hydraulic hoses and lines are in good
condition before applying pressure to the system.
•Use a piece of paper or cardboard, NOT BODY PARTS, to check for suspected leaks.
•Wear protective gloves and safety glasses or goggles when working with hydraulic systems.
•If an accident occurs, see a doctor immediately. Remember, any fluid injected into the skin
must be treated within a few hours, or gangrene may result.
USE SEAT BELT AND ROPS
•Operate only skid steers equipped with a Roll-Overprotective Structure (ROPS) and seat belt.
•Fasten seat belt snugly and securely to help protect against serious injury or death from
falling and skid steer overturn.
•Wearing protective equipment such as safety shoes, safety glasses, hard hat, and ear plugs is
highly recommended.
TIRE SAFETY
•Tire changing can be dangerous, and trained personnel should be the only ones using correct
tools and equipment.
•When inflating tires, use a clip-on chuck and extension hose long enough to allow you to
stand to one side and NOT in front of or over the tire assembly. Use a safety cage if available.
•When removing and installing wheels, use wheel handling equipment adequate for the
•weight involved.

7
OPERATION INSTRUCTIONS
1. Manifold Block
2. Solenoid Valve
3. Deflection Cylinder
4. Kingpin
5. Cylinder Pin
6. Push Shovel
7. Cutting Blade
8. Bottom Blade
9. Steering Cylinder
10. Hitch Frame
1. Know this dozer blade’s loading capacity, working pressure of hold should be ≤20MPa.
2. The SS6DOZER is manufactured standard with exposed wiring for power source
connection. Operator will need to wire this to a 12V power source for proper
function of the provided controller.
3. Start host, connect attachment hitch frame with host frame, pressed the positioning lock
pin handle.
4. Lifting host working arm. Before working, please in situ opeation lever control dozer
blade for all kinds of actions, in order to familiar with the opeation of dozer blade, and
check dozer blade’s all origin parts in normal condition.
MAINTENANCE INSTRUCTIONS
Regular Maintenance is the key to keep machine work long life and safety, the following
description of maintenance is more important.
a. Check whether there is loose phenomenon, tighten loose parts immediately.
b. Check attachment hydraulic system to see whether there is a leaking phenomenon, it
should change leaking tuber connectors or tubers in time.
c. Check equipment parts for damage and solder joint for cracks, repair it when necessary
d. During maintenance, be sure to close the attachment engine, Hang up “maintenance”
warning sign on obvious position of attachment, to prevent others closing.
e. For replacement parts, user can only choose manufacturer approved parts for

8
replacement.
STORAGE INSTRUCTIONS
a. After working, remove all piece, dirt, and grease on attachment.
b. Attachment should be stored in a dry and non-corrosive environment to avoid
attachment surface from rust.
c. When stock dozer blade, it needs fix-frame, it will be easy to connect host with
attachment during next operation.
SPECIFICATIONS
MODEL
030960
030972
030987
TOTAL HEIGHT (MM)
700
700
700
TOTAL LENGTH (MM)
965
965
965
TOTAL WIDTH (MM)
1530
1830
2130
WIDTH AT TURNING 30° (MM)
1270
1519
1845
MAX TURING ANGLE (°)
+/-30
+/-30
+/-30
MAX TILT ANGLE (°)
+/-10
+/-10
+/-10
MAX PRESSURE (MPA)
16-21
16-21
16-21
WEIGHT (KG)
510
560
610

9
PARTS DIAGRAM / EXPLODED VIEW

10
KEY
PART
NUMBER
DESCRIPTION
QTY
NOTE
1
030960-1
BLADE
1
2
030960-2
PUSH SHOVEL
1
3
030960-3
DEFLECTION CYLINDER
1
4
030960-4
PIN
4
5
030960-5
BLADE
1
6
030960-6
ADJUST WASHER
2
7
030960-7
PRESSING PLATE
2
8
030960-8
CONNECTION PART
1
9
030960-9
DEFLECTION PIN
1
10
030960-10
VALVE COVER
1
11
030960-11
ADJUST WASHER RING
2
12
030960-12
PIN
2
13
030960-13
PRESSING COVER
1
14
030960-14
STEERING CYLINDER
2
15
030960-15
HITCH FRAME
1
16
GB2673
M16X45 COUNTERSUNK
HEAD BOLT
12
17
GB97.1
FLAT WASHER
12
18
GB93
SPRING WASHER
12
19
GB5783
M8X25 BOLT
4
20
GB5783
M10X30 BOLT
1
21
BR05
SELF-LUBRICATING BEARING
2
22
GB5781
M20X45 BOLT
6
23
BR05
SELF-LUBRICATING BEARING
1
24
GB91
D6 COTTER PIN
2
25
GB5783
M8X30 BOLT
8
26
SWH-G02-
C2-D12-20
ELECTROMAGNETIC
DIRECTIONAL VALVE
2
27
GB5783
M20X45 BOLT
1

11
ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY
The use of any equipment, including this one, involves the potential risk of injury. Apart from any
warranty claim that might be presented for a claimed defect in material or workmanship of the product,
you accept and assume full responsibility for any and all injuries, damages (both economic and non-
economic), and losses of any type, which may occur, and you fully and forever release and discharge
Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,
demands, damages, rights of action, or causes of action, present or future, whether the same be known
or unknown, anticipated, or unanticipated, resulting from or arising out of the use of said equipment.
This equipment must be used with care by capable and competent individuals under supervision, if
necessary.
TITAN LIMITED WARRANTY: TERMS, EXCLUSIONS AND LIMITATIONS OF REMEDIES
This product comes with a one (1) year limited warranty that can be found at
www.palletforks.com/warranty.html. Please review the same for all details regarding the Titan Limited
Warranty.
THE TITAN LIMITED WARRANTY FOUND AT WWW.PALLETFORKS.COM/WARRANTY.HTML IS
EXCLUSIVE AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE, EACH
OF WHICH IS HEREBY DISCLAIMED.

12
NEED HELP? CONTACT US FIRST.
1-800-605-7595
[email protected]
www.palletforks.com
© 2023 Titan Brands
