HART HPAG01 20V User manual

HPAG01 20V
Angle Grinder
Meuleuse d’angle
Amoladora angular
OPERATOR’S MANUAL
General Power Tool Safety Warnings 2-3
 AngleGrinderSafetyWarnings 3-5
Symbols 6
Features 6
 Assembly 7
 Operation 8-9
Maintenance 10
Illustrations 12-13
 Parts/Service
Back Page
MANUEL D’UTILISATION
 Avertissementsdesécuritégénérales 2-3
 relativesauxoutilsélectriques
 Avertissementsdesécuritérelatifs 3-5
 meuleused’angle
Symboles 6
Caractéristiques 6
 Assemblage 7
 Utilisation 8-9
 Entretien 10
Illustrations 12-13
 Commandedepiècesetdépannage
Pagearrière
MANUAL DEL OPERADOR
 Advertenciasdeseguridadpara 2-3
 herramientaseléctrica
 Advertenciasdeseguridadde 3-6
 amoladoraangular
Símbolos 6
Características 6
 Armado 7-8
 Funcionamiento 8-9
 Mantenimiento 9-10
Illustraciones 12-13
 Pedidosdepiezasyservicio 
 Pág.posterior
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
WARNING: To reduce the risk of
injury, the user must read and understand the
operator’s manual before using this product.
CE LIVRET D’INSTRUCTIONS CONTIENT DES
CONSIGNES DE SÉCURITÉ IMPORTANTES.
VEUILLEZ LE LIRE ET LE CONSERVER POUR
TOUTE RÉFÉRENCE FUTURE.
AVERTISSEMENT : Pour
réduire les risques de blessures, l’utilisateur
doit lire et veiller à bien comprendre le manuel
d’utilisation avant d’employer ce produit.
ESTE FOLLETO DE INSTRUCCIONES CONTIENE
INFORMACIÓN DE SEGURIDAD IMPORTANTE.
LÉALO Y CONSÉRVELO PARA REFERENCIA
FUTURA.
ADVERTENCIA: Para reducir
el riesgo de lesiones, el usuario debe leer y
comprender el manual del operador antes de
usar este producto.

2 – English
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failuretofollowallinstructionslistedbelowmayresult
inelectricshock,fireand/orseriousinjury.
Save all warnings and instructions for future reference.
Theterm“powertool”inthewarningsreferstoyourmains-
operated(corded)powertoolorbattery-operated(cordless)
powertool.
WORK AREA SAFETY
Keep work area clean and well lit. Clutteredordark
areasinviteaccidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust.Powertoolscreatesparkswhichmayignitethe
dustorfumes.
Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs with
earthed (grounded) power tools. Unmodifiedplugsand
matchingoutletswillreduceriskofelectricshock.
Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators.
Thereisanincreasedriskofelectricshockifyourbody
isearthedorgrounded.
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
orentangledcordsincreasetheriskofelectricshock.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Useofacord
suitableforoutdoorusereducestheriskofelectricshock.
If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of a GFCI reduces the
risk of electric shock.
Use this product only with batteries and chargers listed
in tool/appliance/battery pack/charger correlation
supplement 995000850.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs,
alcohol or medication.Amomentofinattentionwhile
operatingpowertoolsmayresultinseriouspersonalinjury.
Use personal protective equipment. Always wear eye
protection.Protectiveequipmentsuchasdustmask,non-
skidsafetyshoes,hardhat,orhearingprotectionused
forappropriateconditionswillreducepersonalinjuries.
Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source and/
or battery pack, picking up or carrying the tool. Carrying
powertoolswithyourfingerontheswitchorenergizing
powertools that havethe switchoninvites accidents.
Remove any adjusting key or wrench before turning
the power tool on. Awrenchorakeyleftattachedtoa
rotatingpartofthepowertoolmayresultinpersonalinjury.
Do not overreach. Keep proper footing and balance
at all times. Thisenablesbettercontrolofthepowertool
inunexpectedsituations.
Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts. Looseclothes,jewelryorlonghaircanbecaught
inmovingparts.
If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Useofdustcollection
canreducedust-relatedhazards.
Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool
safety principles. Acarelessactioncan cause severe
injurywithinafractionofasecond.
Do not wear loose clothing or jewelry. Contain long hair.
Looseclothes,jewelry,orlonghaircanbedrawnintoairvents.
Do not use on a ladder or unstable support. Stable
footingonasolidsurfaceenablesbettercontrolofthe
powertoolinunexpectedsituations.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool
for your application. Thecorrectpowertoolwilldothe
jobbetterandsaferattherateforwhichitwasdesigned.
Do not use the power tool if the switch does not turn
it on and off.Anypowertoolthatcannotbecontrolled
withtheswitchisdangerousandmustberepaired.
Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools. Suchpreventive
safetymeasuresreducetheriskofstartingthepowertool
accidentally.
Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
toolsaredangerousinthehandsofuntrainedusers.
Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition that
GENERAL POWER TOOL SAFETY WARNINGS

3 – English
SAFETY WARNINGS COMMON FOR
GRINDING, SANDING AND POLISHING
OPERATIONS
This power tool is intended to function as a grinder,
sander, or polisher. Read all safety warnings, instruc-
tions, illustrations and specifications provided with
this power tool.Failuretofollowallinstructionslisted
belowmayresultinelectricshock,fireand/orserious
injury.
Operations such as cutting-off and wire brushing
are not recommended to be performed with this
power tool. Operationsforwhichthepowertoolwas
notdesignedmaycreateahazardandcausepersonal
injury.
Do not use accessories which are not specifically
designed and recommended by the tool manufac-
turer. Justbecausetheaccessorycanbeattachedto
yourpowertool,itdoesnotassuresafeoperation.
The rated speed of the accessory must be at least
equal to the maximum speed marked on the power
tool. Accessoriesrunningfasterthantheirratedspeed
canbreakandflyapart.
The outside diameter and the thickness of your
accessory must be within the capacity rating of your
power tool. Incorrectly sized accessories cannot be
adequatelyguardedorcontrolled.
Threaded mounting of accessories must match the
grinder spindle thread. For accessories mounted by
flanges, the arbour hole of the accessory must fit the
locating diameter of the flange. Accessoriesthatdo
notmatchthemountinghardwareofthepowertoolwill
runoutofbalance,vibrateexcessivelyandmaycause
loss of control.
Do not use a damaged accessory. Before each use
inspect the accessory such as abrasive wheels for
chips and cracks, and backing pad for cracks, tear or
excess wear. If power tool or accessory is dropped,
inspect for damage or install an undamaged acces-
sory. After inspecting and installing an accessory,
position yourself and bystanders away from the plane
of the rotating accessory and run the power tool at
maximum no-load speed for one minute.Damaged
accessories will normally break apart during this test
time.
GENERAL POWER TOOL SAFETY WARNINGS
ANGLE GRINDER SAFETY WARNINGS
may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many
accidentsarecausedbypoorlymaintainedpowertools.
Keep cutting tools sharp and clean. Properlymaintained
cuttingtoolswithsharpcuttingedgesarelesslikelyto
bindandareeasiertocontrol.
Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Useofthepowertoolforoperationsdifferent
fromthoseintendedcouldresultinahazardoussituation.
Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slipperyhandlesandgrasping
surfacesdonotallowforsafehandlingandcontrolofthe
toolinunexpectedsituations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
ofbatterypackmaycreateariskoffirewhenusedwith
anotherbatterypack.
Use power tools only with specifically designated
battery packs. Useofanyotherbatterypacksmaycreate
ariskofinjuryandfire.
When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquidejectedfromthe
battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictablebehaviorresultinginfire,explosionorrisk
ofinjury.
Do not expose a battery pack or tool to fire or
excessive temperature. Exposuretofireortemperature
above265°Fmaycauseexplosion.
Follow all charging instructions and do not charge the
battery pack or tool outside the temperature range
specified in the instructions. Chargingimproperlyorat
temperaturesoutsidethespecifiedrangemaydamage
thebatteryandincreasetheriskoffire.
SERVICE
Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
willensurethatthesafetyofthepowertoolismaintained.
Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturerorauthorizedserviceproviders.

4 – English
ANGLE GRINDER SAFETY WARNINGS
Wear personal protective equipment. Depending on
application, use face shield, safety goggles or safety
glasses. As appropriate, wear dust mask, hearing
protectors, gloves and workshop apron capable of
stopping small abrasive or workpiece fragments.
Theeyeprotectionmustbecapableofstoppingflying
debrisgeneratedbyvariousoperations.Thedustmask
or respirator must be capable of filtrating particles
generated by your operation. Prolonged exposure to
high intensity noise may cause hearing loss.
Keep bystanders a safe distance away from work area.
Anyone entering the work area must wear personal
protective equipment.Fragmentsofworkpieceorofa
brokenaccessorymayflyawayandcauseinjurybeyond
immediateareaofoperation.
Hold the power tool by insulated gripping surfaces
only, when performing an operation where the cutting
accessory may contact hidden wiring. Contact with a
“live”wiremaymakeexposedmetalpartsofthepower
tool“live”andcouldgivetheoperatoranelectricshock.
Never lay the power tool down until the accessory
has come to a complete stop. Thespinningaccessory
maygrabthesurfaceandpullthepowertooloutofyour
control.
Do not run the power tool while carrying it at your
side. Accidental contact with the spinning accessory
couldsnagyourclothing,pullingtheaccessoryintoyour
body.
Regularly clean the power tool’s air vents.Themotor’s
fanwilldrawthedustinsidethehousingandexcessive
accumulationofpowderedmetalmaycauseelectrical
hazards.
Do not operate the power tool near flammable
materials.Sparkscouldignitethesematerials.
Do not use accessories that require liquid coolants.
Using water or other liquid coolants may result in
electrocution or shock.
KICKBACK AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched or snagged
rotatingwheel,backingpad,brushoranyotheraccessory.
Pinchingorsnaggingcausesrapidstallingoftherotating
accessorywhichinturncausestheuncontrolledpowertool
tobe forced in thedirectionopposite of theaccessory’s
rotationatthepointofthebinding.
Forexample,ifanabrasivewheelissnaggedorpinched
bythe workpiece, theedge of thewheel thatisentering
intothepinchpointcandigintothesurfaceofthematerial
causing the wheel to climb out or kick out. The wheel may
eitherjumptowardorawayfromtheoperator,dependingon
directionofthewheel’smovementatthepointofpinching.
Abrasivewheelsmayalsobreakundertheseconditions.
Kickbackistheresultofpowertoolmisuseand/orincorrect
operatingproceduresorconditionsandcanbeavoidedby
takingproperprecautionsasgivenbelow.
Maintain a firm grip on the power tool and position
your body and arm to allow you to resist kickback
forces. Always use auxiliary handle, if provided, for
maximum control over kickback or torque reaction
during start-up. The operator can control torque
reactionsorkickbackforces,ifproperprecautionsare
taken.
Never place your hand near the rotating accessory.
Accessorymaykickbackoveryourhand.
Do not position your body in the area where power
tool will move if kickback occurs. Kickbackwillpropel
thetoolindirectionoppositetothewheel’smovement
atthepointofsnagging.
Use special care when working corners, sharp edges,
etc. Avoid bouncing and snagging the accessory.
Corners,sharpedgesorbouncinghaveatendencyto
snagtherotatingaccessoryandcauselossofcontrolor
kickback.
Do not attach a saw chain woodcarving blade or
toothed saw blade. Such blades create frequent
kickbackandlossofcontrol.
SAFETY WARNINGS SPECIFIC FOR
GRINDING OPERATIONS
Use only wheel types that are recommended for your
power tool and the specific guard designed for the
selected wheel. Wheelsforwhichthepowertoolwas
not designed cannot be adequately guarded and are
unsafe.
The grinding surface of centre depressed wheels
must be mounted below the plane of the guard lip.
Animproperlymountedwheelthatprojectsthroughthe
planeoftheguardlipcannotbeadequatelyprotected.
The guard must be securely attached to the power
tool and positioned for maximum safety, so the least
amount of wheel is exposed towards the operator.
Theguardhelpstoprotectoperatorfrombrokenwheel
fragments,accidentalcontactwithwheelandsparksthat
couldigniteclothing.
Wheels must be used only for recommended
applications. For example: do not grind with the side
of cut-off wheel. Abrasivecut-offwheelsareintendedfor
peripheralgrinding,sideforcesappliedtothesewheels
may cause them to shatter.
Always use undamaged wheel flanges that are of
correct size and shape for your selected wheel.
Properwheelflangessupportthewheelthusreducing
the possibility of wheel breakage. Flanges for cut-off
wheelsmaybedifferentfromgrindingwheelflanges.
Do not use worn down wheels from larger power
tools. Wheelintendedforlargerpowertoolisnotsuitable
forthehigherspeedofasmallertoolandmayburst.

5 – English
ANGLE GRINDER SAFETY WARNINGS
SAFETY WARNINGS SPECIFIC FOR SANDING
OPERATIONS
Do not use excessively oversized sanding disc
paper. Follow manufacturers recommendations,
when selecting sanding paper. Largersandingpaper
extendingbeyondthesandingpadpresentsalaceration
hazardandmaycausesnagging,tearingofthediscor
kickback.
SAFETY WARNINGS SPECIFIC FOR
POLISHING OPERATIONS
Do not allow any loose portion of the polishing bonnet
or its attachment strings to spin freely. Tuck away or
trim any loose attachment strings. Looseandspinning
attachment strings can entangle your fingers or snag on
theworkpiece.
ADDITIONAL SAFETY RULES
Always use proper guard with grinding wheel.Aguard
protectsoperatorfrombrokenwheelfragments.
Know your power tool. Read operator’s manual care-
fully. Learn its applications and limitations, as well
as the specific potential hazards related to this tool.
Followingthisrulewillreducetheriskofelectricshock,
fire,orseriousinjury.
Always wear eye protection with side shields marked
to comply with ANSI Z87.1. Following this rule will
reducetheriskofseriouspersonalinjury.
Protect your lungs. Wear a face or dust mask if the
operation is dusty. Followingthisrulewillreducethe
riskofseriouspersonalinjury.
Protect your hearing. Wear hearing protection during
extended periods of operation. Following this rule will
reducetheriskofseriouspersonalinjury.
Check damaged parts. Before further use of the
tool, a guard or other part that is damaged should
be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other condi-
tions that may affect its operation. A guard or other
part that is damaged should be properly repaired or
replaced by an authorized service center. Following
thisrulewillreducetheriskofshock,fire,orseriousinjury.
Inspect for and remove all nails from lumber before
using this tool. Followingthisrulewillreducetherisk
ofseriouspersonalinjury.
Save these instructions. Refertothemfrequentlyand
usethemtoinstructotherswhomayusethisproduct.If
youloansomeonethisproduct,loanthemtheseinstruc-
tions also.

6 – English
SYMBOLS
FEATURES
PRODUCT SPECIFICATIONS
GrindingWheelCapacity........................................4-1/2in.
RatedSpeed(RPM)............................................7,500/min
SpindleThread .............................................. 5/8x11UNC
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Safety Alert Indicatesapotentialpersonalinjuryhazard.
Read
Operator’s
Manual
Toreducetheriskofinjury,usermustreadandunderstandoperator’smanualbefore
usingthisproduct.
Eye Protection AlwaysweareyeprotectionwithsideshieldsmarkedtocomplywithANSIZ87.1.
Wet
Conditions
Alert
Donotexposetorainoruseindamplocations.
Recycle
Symbol
Thisproductuseslithium-ion(Li-ion)batteries.Local,stateorfederallawsmayprohibit
disposalofbatteriesinordinarytrash.Consultyourlocalwasteauthorityforinformation
regardingavailablerecyclingand/ordisposaloptions.
VVolts Voltage
min Minutes Time
Direct Current Typeoracharacteristicofcurrent
nRated Speed Maximumrotationalspeed
.../min Per Minute Revolutions,strokes,surfacespeed,orbitsetc.,perminute
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER: Indicatesahazardoussituation,which,ifnotavoided,willresultindeathorseriousinjury.
WARNING: Indicatesahazardoussituation,which,ifnotavoided,couldresultindeathorseriousinjury.
CAUTION: Indicatesahazardoussituation,that,ifnotavoided,mayresultinminorormoderateinjury.
NOTICE: (WithoutSafetyAlertSymbol)Indicatesinformationconsideredimportant,butnotrelated
toapotentialinjury(e.g.messagesrelatingtopropertydamage).

7 – English
UNPACKING
Thisproductrequiresassembly.
 Carefullyremovethetoolandanyaccessoriesfromthe
box. All items listed in the Includes section must be
includedatthetimeofpurchase.
WARNING:
Items in this Assembly section are not assembled to
theproductbythemanufacturerandrequirecustomer
installation. Use of a product that may have been
improperlyassembledcouldresultinseriouspersonal
injury.
 If any parts are damaged or missing, please call
1-800-776-5191 for assistance.
WARNING:
Ifanypartsaredamagedormissingdonotoperatethis
productuntilthepartsarereplaced.Useofthisproduct
withdamagedormissingpartscouldresultinserious
personalinjury.
WARNING:
Do not attempt to modify this product or create
accessoriesorattachmentsnotrecommendedforuse
withthisproduct.Anysuchalterationormodificationis
misuseandcouldresultinahazardousconditionleading
topossibleseriouspersonalinjury.
INSTALLING GRINDING WHEEL
See Figure 1, page 12.
DANGER:
UseONLYType27 depressedcenter grindingwheels
(such as the one provided with this product). NEVER
attachaType1 straightor cut-offwheeltothis angle
grinder.Useforanyotherpurposeisnotrecommended
andcreatesahazard,whichwillresultinseriousinjury.
TYPE 27 −OK TO USE TYPE 1 −DO NOT USE
DANGER:
Never attach a wood cutting or carving blade of any
typetothisgrinder.Itisonlydesignedforgrindingand
sanding.Useforanyotherpurposeisnotrecommended
andcreatesahazard,whichwillresultinseriousinjury.
WARNING:
Thoroughly inspect a new grinding wheel before you
installitonthegrinder.
ASSEMBLY
To install:
 Removethebatterypack.
 Inspectthewheel.
• Tap lightly around the wheel using a wooden
hammer.
• Listencarefullytotheresultingsounds.Placeswith
fissuresorcrackswillresultinadifferentsound.
NOTE: Do not use a wheel containing fissures or cracks.
Whenyouinstallanew grinding wheel,carry out ano
load revolution test of approximately one minute with
thegrindingwheelfacingasafedirection,i.e.,awayfrom
peopleorobjects.
Depressthespindlelockbuttonandrotatetheclampnut
untilthespindlelocks.
NOTE: Topreventdamagetothespindleorspindlelock,
alwaysallowmotortocometoacompletestopbefore
engagingspindlelock.
Loosenandremovetheclampnut fromthespindle.Do
notremovethediscflange.
Makesuretheflatsonthebottomofthediscflangeare
engagedwiththeflatsonthespindle.
Placethegrindingwheeloverthespindle.
WARNING:
Alwaysinstallagrindingwheelwiththedepressedcenter
againstthediscflange.Failuretodosowillcausethe
grindingwheeltocrackwhentighteningtheclampnut.
Thiscouldresultinseriouspersonalinjurybecauseof
looseparticlesbreakingoffandbeingthrownfromthe
grinder.Donotovertighten.
 Threadtheclampnut onthespindlewiththeflatsideof
thenutfacingup.
 Fit theraised, smalldiameter portionof theclamp nut
intotheholeinthewheelandfingertighten.
Depress the spindle lock button and rotate the wheel
clockwiseuntilthespindlelocksinposition.
Tightentheclampnut securelywiththewrenchprovided.
Donotovertighten.
INSTALLING THE SIDE HANDLE
See Figure 2, page 12.
WARNING:
Thesidehandlemustalwaysbeusedtohelpprevent
lossofcontrolandpossibleseriousinjury.
Thesidehandlecanbeinstalledonthetop,left,orrightside
ofthegrinder,dependingonoperatorpreference.
To install:
 Removethebatterypack.
 Insertthesidehandleintothedesiredoperatingposition.
 Turnthesidehandleclockwisetosecurelytighten.

8 – English
OPERATION
WARNING:
Donotallowfamiliaritywiththisproducttomakeyou
careless.Rememberthatacarelessfractionofasecond
issufficienttoinflictseriousinjury.
WARNING:
Always remove battery pack from the tool when you
are assembling parts, making adjustments, cleaning,
orwhennotinuse.Removingbatterypackwillprevent
accidental starting that could cause serious personal
injury.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1.Failuretodosocouldresultin
objectsbeingthrownintoyoureyesandotherpossible
seriousinjuries.
WARNING:
Do not use any attachments or accessories not
recommendedbythemanufacturerofthisproduct.The
useof attachmentsor accessories notrecommended
canresultinseriouspersonalinjury.
APPLICATIONS
Youmayusethisproductforthepurposeslistedbelow:
 Grindingmetals
 Sandingwoodormetalsurfaces
INSTALLING/REMOVING BATTERY PACK
See Figure 3, page 12.
Insertthebatterypackintothebatteryportasshown.
Makesurethelatchonthebatterypacksnapsintoplace
andthe batterypack issecured inthe product before
beginningoperation.
Depress the latch and pull to release and remove the
batterypack.
For complete charging instructions, see the operator’s
manualsforyourbatterypackandcharger.
WARNING:
Battery tools are always in operating condition. Lock
the switch when not in use or carrying at your side,
wheninstallingorremovingthebatterypack,andwhen
installingorgrindingwheelsoraccessories.
SWITCH TRIGGER
See Figure 4, page 13.
ToturnthegrinderON,depressandholdlock-offbutton,
thendepresstheswitchtrigger.ToturnitOFF, release the
switch trigger.
LOCK-OFF BUTTON
See Figure 4, page 13.
The lock-off button is located on the handle behind the
switch trigger. You must depress the lock-off button in
ordertopulltheswitchtrigger.Thelockresetseachtime
thetriggerisreleased.
POSITIONING THE GUARD
See Figures 5 - 6, page 13.
The guard on the grinder should be correctly positioned
dependingonwhichsidethehandleismounted.Neveruse
thegrinderwithouttheguardcorrectlyinplace.
WARNING:
Neverplacetheguardsothatitisinfrontofthegrinder.
Thiscouldresultinseriousinjurybecausesparksand
looseparticlesthrownfromthegrindingwheelwouldbe
directedtowardtheoperator.Alwaysplacetheguardin
the correct location as shown.
To reposition the guard:
 Removethebatterypack.
 Unlocktheguardclaspbypullingtheclaspout,away
fromthegrinder.
 Rotatetheguardtoitscorrectpositionasshown.
 Locktheguardclaspbypushingtheclaspin.
NOTE: Besuretheraisedridgeontheguardisseated
inthegrooveonthebearingcap.Neverusethegrinder
withouttheguardinplaceandproperlyadjusted.
OPERATING THE GRINDER
See Figure 7, page 13.
Always carefully select and use grinding wheels that are
recommended for the material to be ground. Make sure
thattheminimumoperatingspeedofanyaccessorywheel
selectedis7,500/minormore.Thegrindingwheelprovided
with the grinder is suitable for grinding welds, preparing
surfacestobewelded,grindingstructuralsteel,andgrinding
stainless steel.
To operate the grinder:
Secureallworkinaviseorclamptoaworkbench.
DANGER:
Never use the grinder with the guard removed. It has
been designed for use only with the guard installed.
Attemptingtousegrinderwithguardremovedwillresult
in loose particles being thrown against the operator
resultinginseriouspersonalinjury.

9 – English
OPERATION
 Holdthegrinderinfrontandawayfromyouwithboth
hands,keepingthegrindingwheelclearoftheworkpiece.
 Turnonthegrinderandletthemotorandgrindingwheel
builduptofullspeed.
 Lower the grinder gradually until the grinding wheel
contactstheworkpiece.
WARNING:
Topreventlossofcontrolandpossibleseriouspersonal
injury, always operate the grinder with both hands,
keepingonehandonthesidehandle.
 Keepthegrindertiltedatananglefrom5°to15°and
continuouslymovingatasteady,consistentpace.
NOTICE:
Ifthegrinderisheldinonespottoolong,itwillgouge
andcutgroovesintheworkpiece.Ifthe grinderisheld
attoosharpanangle,itwillalso gougetheworkpiece
because of concentration of pressureonasmallarea.
 Use just enough pressure to keep the grinder from
chattering or bouncing.
NOTE:Heavypressurewilldecreasethegrinder’sspeedand
putastrainonthemotor.Normallytheweightofthetool
aloneisadequateformostgrindingjobs.Uselightpressure
whengrindingjaggededgesorlooseboltswherethereis
thepotentialforthegrindertosnagonthemetaledge.
 Liftthegrinderawayfromtheworkpiecebeforeturning
offthegrinder.

10 – English
NOTE: ILLUSTRATIONS START ON PAGE 11
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.
WARNING:
When servicing, use only identical replacement parts.
Useofanyother part couldcreateahazardorcause
productdamage.
WARNING:
Alwaysweareyeprotectionwithsideshieldsmarkedto
complywithANSIZ87.1,alongwithhearingprotection.
Failuretodosocouldresultinobjectsbeingthrowninto
youreyesandotherpossibleseriousinjuries.
WARNING:
To avoid serious personal injury, always remove the
battery pack from the tool when cleaning, performing
any maintenance, or when storing the tool.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plasticsaresusceptibletodamagefromvarioustypesof
commercialsolventsandcanbedamagedbytheiruse.Use
cleanclothstoremovedirt,dust,oil,grease,etc.
WARNING:
Donotatanytimeletbrakefluids,gasoline,petroleum-
basedproducts,penetratingoils,etc.,comeincontact
withplasticparts.Chemicalscandamage,weakenor
destroy plastic which could result in serious personal
injury.
REPLACING THE GUARD
See Figure 1, page 12.
WARNING:
Donotchangeorloosenguardscrew.Failuretoheedthis
warningmaycausetheguardtobecomelooseduring
operationresultinginseriouspersonalinjury.
Afterextendeduse,theguardmaywearandneedreplacing.
Ifyoudropthegrinderanddamagetheguarditmayalso
benecessaryforyoutoreplaceit.
To replace the guard:
Removethebatterypackfromthegrinder.
 Depressspindlelockandrotateclampnutuntilspindle
locks.
Loosen and remove clamp nut from spindle using the
wrenchprovided.
Removegrindingwheelanddiscflange.
 Unlocktheguard claspby pullingtheclasp out, away
fromthegrinder.
 Openclasp fullyandtwistguardtoreleaseitfromthe
lockinggrooveinthetoolhousing.
 Removeguard.
Placethenewguardontheshoulderofthebearingcap.
Rotateguardtothecorrectposition.RefertoPositioning
the Guard earlier in this manual.
NOTE:Besuretheraisedridgeontheguardisseatedin
thegrooveonthebearingcap.
  Reassemblediscflange,grindingwheel,andclampnut.
Refer to Installing Grinding Wheel earlier in this manual.
  Tightentheclampnutsecurelywiththewrenchprovided.
MAINTENANCE
