HART HPSV01 Quick setup guide

REPAIR SHEET
BRAND
HART
DESCRIPTION
20 Volt Stick Vac
MODEL NO.
HPSV01
HART CONSUMER PRODUCTS, INC.
P.O. Box 1348, Anderson, SC 29622 1-800-776-5191 www.HARTtools.com 8-10-22 (Rev:03)
The model number and manufacturing location will be found on a label attached to the product. Always mention this information in all communications regarding this product and when ordering parts.

2
HPSV01
PARTS LIST
KEY NO. PART NO. DESCRIPTION QTY.
1-CN 206310002 Console Assembly 1
1-VN 206310003 Console Assembly 1
2 204310002 Dust Tank Assembly 1
3 204310003 Filter Assembly 1
4 903623004 Dirt Cup Filter 1
5 317035001 Crevice Tool 1
6 317036001 Dust Brush 1
7 317212001 Mirco Crevice Tool 1
8 317211001 Upholstery Tool 1
9 317073001 Extension Wand Assembly 1
10-CN 316852005 Beater Bar Assembly 1
10-VN 316852006 Beater Bar Assembly 1
11 317323001
or 317323002 Wall Mount 1
12 318170001 Brushroll 1
13 542221001 Brushroll End Cap 1
14-CN 941123300 Data/Battery Statement Label 1
14-VN 941123828 Data/Battery Statement Label 1
15 941120765 Caution Statements/Icons Label 1
Not Shown:
998000180 Operator’s Manual (961153504)
13
12 10
9
11
15
1
14
2
3
4
5
6
7
8
If a key number has multiple part numbers, please order the part that corresponds with the date code shown on the product’s data label. CN = China VN = Vietnam
