HARTINGTON FLORENCE Series User manual

Important
Please read these instructions before using the product. Retain instructions for future use.
HHGL Limited, MK9 1BA; HHGL (ROI) Limited, D02 X576
FLORENCE COLLECTION
Gazebo with
Rattan Panels
Powder-coated steel frame
Includes 1 x gazebo and panels
H260 x W300 x D300cm

ATTENTION: To avoid damage, disassemble the gazebo during bad weather, e.g. during high wind or heavy rain.
This product is intended to be used as a temporary shelter and is not designed to be used as a permanent structure.
2
Please read these instructions fully before starting assembly.
Check you have all the components and tools listed on pages 3 and 4.
Remove all fittings from the plastic bags and separate them into their groups.
Keep children and animals away from the work area; small parts could choke if swallowed.
Make sure you have enough space to lay out the parts before starting.
Do not stand or put weight on the component parts and product, as this could cause damage.
Assemble the item as close to its final position as possible.
Assemble on a soft, level surface to avoid damaging the unit or your floor.
Parts of the assembly will be easier with two people.
We do not recommend the use of power drills/drivers for inserting screws, as this could
damage the unit. Only use hand screwdrivers.
Dispose of all packaging carefully and responsibly.
Only clean using a damp cloth and mild detergent; do not use bleach or abrasive cleaners.
From time to time, check that there are no loose screws on this unit.
This product should not be discarded with household waste.Take to your local authority waste disposal centre.
Domestic use only.
