Hasbro Ion User manual

QUICK START GUIDE

CONSOLE
TV CONNECTOR CORD
MEASURING STRIP
ACTIVE LEARNING DISC
Next
Open
Stop
Play/Pause
Previous
On/Off
Brightness
Reset
POWER ADAPTOR
(ADS-7515PC)
To start playing with your
ION EDUCATIONAL GAMING
SYSTEM™. follow these
simple steps. See the enclosed
instruction book for more
detailed information and
game instructions.
™
Make sure that the playing
area is brightly lit.
EDUCATIONAL GAMING S YSTEM
EDUCATIONAL GAMING S YSTEM
P
L
A
Y
/
P
A
U
S
E


CAMERA
Make sure that the playing area is brightly lit.
Make sure there is no movement behind the player, as background
motion may hinder game play.
For children of various heights, an adult should tilt the angle of the
camera to adjust it to the child’s height.
Make sure you have enough room to play. Consider the space around
you and clear the area of any obstructions.
For ideal camera performance, your child should wear clothing that
contrasts with the predominant color appearing in the background.
TIPS
ADULT SUPERVISION REQUIRED.
Product works on units with RCA-type audio/video input jacks only.
AGES 4-7
Product and colors may vary. © 2006 Hasbro. All Rights Reserved.
TM & ® denote U.S. Trademarks. The products described herein are
covered by U.S. Patent No. 5,534,917 which has been licensed by
GestureTek, Inc. (“GestureTek “) to Hasbro, Inc. (“Hasbro”). GestureTek
is not affiliated with, nor does GestureTek endorse the operability of, the
products described herein. U.S. Pat. No. 5,534,917. PN 6591690000
™
73085
SETTING UP YOUR ION EDUCATIONAL GAMING SYSTEM™
1. Plug AV jack into “AV Out” port on Console.
POWER
STEREO
TIMER/
STAND BY
- CHANNEL +
- VOLUME +
TV/VIDEO
DEMO
VIDEO
VIDEO 2 INPUT
L AUDIO R
3+ feet
3. Plug Power Adaptor into socket on console.
4. Plug Power Adaptor into wall socket.
5. Place Console with built-in camera on flat surface.
6. Position camera towards child and his/her play space.
7. Always ensure TV is securely placed on lower
furniture or TV stand as per enclosed Consumer
Pro d uct S a fety A lert.
2. Press On button to turn
Console on.
3. Press Open b utton .
2. Plug RCA- t y p e con n ector s into TV.
Match c olors of conn e ctors to t h e
col ors of por ts o n yo u r TV.
GETTING READY TO PLAY
1. Unroll measuring strip 3 feet from base of TV. Make
sure to stand behind the strip while playing. Clear the
play area in front of the TV of any obstructions.
6. Align child with player outline
on the TV screen.
7. As a safety precaution, advise
children to never touch TV.
Always supervise children while
using the system.
3+ feet
4. Insert Act ive Learnin g Disc.
5. Close lid of player.
WARNING Young children can be killed or seriously injured when furniture tips
over. Before installing your ION EDUCATIONAL GAMING SYSTEM,
please read and follow the enclosed Consumer Product Safety Alert.
Questions? Call 1-800-PLAYSKL
Visit us at
playskool.com
