HASEL HSL-KP-02G User manual

WIDE IRONING TABLE
WITHIN BOILER, VACUUM
HSL-KP-02G
HSL-KP-02GK
HSL-KP-02GKI

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 2
CONTENTS
Manufacturer Information:...........................:3
Meaning of Safety Symbols............................:4
Description And Intended Use:......................:5
Technical Specifications:................................:5
Technique Drafting: .......................................:6
Part List:..........................................................:7
Storage:............................................................:7
Transport And Handling:..............................:8
General Safety Precautions: ..........................:9-10
Mounting Instructions:...................................:11
Using Instructions:..........................................:12
Maintenance Instructions: .............................:13
Dismantling And Disposal:.............................:13
Trouble Fixing.................................................:14-15

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 3
MANUFACTURER INFORMATION
Dear Customer,
Firstly, congratulations for your selection. Hasel have been manufactured
industrial type ironing machines since 1985 in Turkey. In production stage
Hasel concerns about high quality, low price with no compensation of
quality and no harm to nature.
This manual contains information about usage of HSL-KP-02G,HSL-KP-
02GK,HSL-KP-02GKI. This information intended to help operator.
Any problems/questions about this manual should be informed to our
head office to obtain necessary information by e-mail or telephone.
MANUFACTURER: HASEL ÜTÜ SAN. ve TİC.LTD. ŞTİ
FACTORY: İkitelli Organize San. Böl. Demirciler San. Sit.B2
Blok No: 71- 72 Başakşehir –İstanbul / TURKEY
Tel: [phone]
Tel:[phone]
Tel:[phone]
Fax:[phone]
WEB: http://www.haselutu.com.tr
E- MAIL:[email protected]
DEAR CUSTOMER,
If you want to get best efficiency from the product please read this
manual thoroughly before operating the product and retain it for
future reference.
SAYIN MÜŞTERİMİZ,
ÜRÜNÜNÜZDEN EN İYİ VERİMİ ELDE ETMEK
İSTİYORSANIZ LÜTFEN KULLANMA KILAVUZUNU
OKUYUNUZ.

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 4
MEANING OF SAFETY SYMBOLS
Read the manual Do not try to repair only
before use Without Qualified Person
Electricity High Temperature
Main Grounding Internal Grounding
Stop the machine
before maintenance

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 5
DESCRIPTION AND INTENDED USE
Product Name: Wide Ironing Table Within Boiler, Vacuum
Model No:
HSL-KP-02G: Narrow Ironing Table With Boiler and Vacuum
HSL-KP-02GK: Narrow Ironing Table With Boiler Vacuum and
Swivel Arm.
HSL-KP-02GKI: Narrow Ironing Table With Boiler Vacuum and
Arm Heating.
These machines are used for ironing all types of clothes.
Models with arm make ironing easier and better for arms of clothes.
Using machine with the exception of above determined condition
eliminates manufacturer’s responsible for damage and injury.
TECHNICAL SPECIFICATIONS
TYPE
HSL-KP-02G
HSL-KP-02GK
HSL-KP-02GKI
Voltage
230/400 V
230/400 V
230/400 V
Frequency
50 Hz
50 Hz
50 Hz
Total Power
8,5 kW
8,5 kW
9 kW
Power of Pump
0,37 kW
0,37 kW
0,37 kW
Vacuum Motor
0,55 kW
0,55 kW
0,55 kW
Power of Resist.
5 kW
5 kW
5 kW
Working Pressure
3,5 bar
3,5 bar
3,5 bar
Water Tank Capa.
20 lt
20 lt
20 lt
Steam Capacity
5 kg/h
5 kg/h
5 kg/h
IP Code
Ip 54
Ip 54
Ip 54
Dimensions
140*80*91 cm
140*90*93 cm
140*90*93 cm
Weight
88 kg
93 kg
93 kg

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 6
TECHNIQUE DRAFTING
HSL-KP-02GKI

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 7
PART LIST
PART NAME
NO
Seat For Iron
1
Thermostat Signal Lamp
2
Water Signal Lamp
3
Hand Iron Switch
4
Main Switch
5
Thermostat
6
Changing Rod For Vacuuming
7
Manometer
8
Vacuum Pedal
9
Water Tank’s Cover
10
Wheels
11
Swivel Arm
12
Arm Heating Switch
13
Solenoid Valve
14
Cable And Hose Holder
15
Feet
16
Water Discharge Valve
17
Link Pipe
18
Steam Discharge Valve
19
Safety Valve
20
Solenoid Valve Socket
21
Hand Iron Socket
22
Power Cable
23

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 8
STORAGE
Store the packed machine in a appropriate place, protected and
not subject to bad weather. For a temporary lack of usage,
clean it carefully and cover it with a cloth. Discharge water
inside the generator if it is not used for long time. Never
subject to bad weather.
TRANSPORT AND HANDLING
To avoid damages to machine, people and environment, take the
maximum attention and care during handling of the machine.
Comply with the precautions necessary and marked on the cards
on the packing and follow chapters carefully.
Unpacking And Handling
Machine is packed in two ways
Wrapped by thick nylon or
Placed in a wooden cage.
If the machine is wrapped by a nylon cover, by putting on
transpalette or lifting up; carry it to where you want to place.
If the machine placed in a wooden cage, remove the straps and
take it out of the wooden structure. By putting on transpalette
or lifting up; carry it to where you want to place.

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 9
GENERAL SAFETY PRECAUTIONS
When using power tools, the following basic safety
measures are to be observed to protect against
electrical shock, personal injury and risk of fire.
Safe operation is enable only if the operation manual is read entirely
before attempting to operate the machine and all the content is
conformed.
Disorder in the working area increases risk of an accident.
Provide good lighting.
During any operation or fixing on the machine please take care
and consider all the precautions which are pointed on warning
signs and labels. All warning labels which are placed on
machine, meanings were pointed above. Please pay attention.
Do not use machine in the vicinity of combustible fluids or
gases.
Do not let people other than those who are sufficiently trained,
to operate the machine.
This machine is in accordance with the relevant safety
regulations. Repairs must be performed only by an electrical
specialist, otherwise accidents can result fort he operator.
Do not work the machine when it is out of its usage limits.
Use the identified spare parts and accessories in order to
improve the security.
If it is necessary change the damaged parts with the original
ones. The manufacturer is not responsible any damage or injury
because of using unoriginal parts.

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 10
GENERAL SAFETY PRECAUTIONS
Fix the machine to contact arm for protection earth. If the
machine is not earthed manufacturer doesn’t bear responsibility
for any damage or injury occurred by lack of grounding.
The power cable must be placed properly in order to prevent
being stepped on or being put anything on it. Check the cable
especially at out going points and connection points. Be careful
not to allow any bending or bowing on the cable.
If the cable is damaged turn off the main switch. Do not allow
the machine to work with damaged cable. Let the authorized
electrician shift the cable.
User should not leave the machine alone while it is working.
When machine Works do not touch base of hand iron.
Before start maintenance turn off main switch.
Do not touch hot places if the covers are removed at the
maintenance. Electric and steam output must be off.
Do not start to work until fix cover.
The machine is under the acceptable noise merit. There is no
vibration and radiation spreading.
The machine can work in a closed area.
The machine can work between +5-40 °C
Do not work machine upper 100 º C.Table cloths can be
burned.
IF THE USERS DO NOT FOLLOW THE CAUTIONS LISTED
ABOVE MANUFACTURER WILL NOT BE RESPONSIBLE OF
ANY ACCIDENT AND INJURIES

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 11
MOUNTING INSTRUCTIONS
1. 1. If the product is three phase: Prepare a panel near to
machine on the wall with 25A an automatic fuse, and
earthed socket suitable for 400 V AC-50 Hz.
If the product is single phase: Prepare a panel near to
machine on the wall with 25A a fuse, and earthed socket
suitable for 230 V AC-50 Hz.
Let a qualified electrician prepare the electric connections of the
Machine. Your cable connection must be as it’s written in the
mounting instruction. Your machine can get trouble by low or high
voltage, and this situation is not in guarantee. You can obviate the
low or high voltage by using an automatic voltage regulator.
2. Water discharge valve (17) will be connected to the
canalization installation by the hose which can resist 100°C
3. Connect the power cable (23) to socket. Do not forget to earth
the machine. Otherwise the manufacturer is not responsible for
any damage or injury occurred by lack of grounding.
4. Mount the end of the iron hose to nipple of solenoid valve (14),
mount the other end of iron hose to nipple of hand iron with hose
clamps.
5. Put the hand iron’s plugs to socket (22). If hand iron doesn’t
work; reverse plug than put to socket again

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 12
USING INSTRUCTIONS
1. Fill the water tank with purified water. Not allow to
overflow. If no water in the tank the machine does not
work.
2. Turn off water discharge valve (17).
3. Turn on main switch (5).
4. When the manometer (8) reach to 3,7 bars you can start
to work..
If the steam pressure gets over 5 bars turn off the main switch at
your electric panel and main switches at your machine, than call
a service
If the pump gets air during filling up water, rip out the screw onto the
pump than tighten up the screw until water comes. Dry operating of
pump will able to damage it after about 5 minutes.
5. When the main switch is opened, turn the heater
thermostat (6) on. Adjust the working temperature by
using the table heater thermostat between 60-90°C.Do
not forget if machine works upper 100°C long time,
table cloth can be burned.
6. For vacuuming just pres the vacuum pedal (9), as long as
you pres pedal, you can get vacuuming.
Do not forget vacuuming continuously. This situation causes
to get upper table wet by cooling and break motor down by
warming extremely.
7. Pull at changing rod (7) for arm vacuuming, than pres
the vacuum pedal (9).
8. For type of HSL-KP-02GKI, open the arm heating
switch (13) if you want heating arm.

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 13
USING INSTRUCTIONS
1. Turn on hand iron switch (4).
2. Adjust hand iron thermostat (B) to your
temperature reference.
3. Let steam go out by pressing hand iron
switch (A).During you are pressing the switch it will continue.
MAINTANENCE INSTRUCTIONS
Before reparation, turn the main switches absolutely off. If you take
away the protective parts during the maintenance, you have to be
careful hot places.
End of work; turn off the main switches. Turn on
discharge valve for evacuating steam.
Bimonthly, fill the water tank with water and adequate
lime preventive than turn on the machine. Allow the
machine to idle 1 hour. After that turn on discharge valve
(17) for evacuating dissolution lime.
DISMANTLING AND DISPOSAL
The usage life of the steam tube in the machine is 10 years. (By 8
hours working per day).When machine is gotten out of run, all its
spare parts can be waste away to a junk yard. No parts contain any
harmful material for environment.

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 14
TROUBLE FIXING
PROBLEM
CAUSE
CHECKS
THE STEAM
GENERATOR
DOES NOT WORK
**No electricity on
the boiler
*Be sure the cable(23)
connect the wall fuse
correctly.
*Main switch(5) may
be broken.
*Call the service
*Water tank may be
empty.
* Check water level in the
water tank.
*Water control relay
may be broken.
* Call the service
THE STEAM
PRESSURE
DOES NOT GET
HIGH
*Pressure switch may
be out of order.
*Boiler resistance
may be out of order.
*Main switch may be
out of order
*Water control relay
may be broken.
* Call the service
*Water tank may be
empty.
* Check water level in the
water tank.
THE STEAM
PRESSURE
GETS OVER 5
BARS
*Pressure switch may
be out of order.
*On the electricity
panel which starts up
boiler resistance may
be out of order.
*Call the service
THE UPPER
PLATE IS NOT
GETTING HOT
*Table surface
heating element may
be broken.
*Thermostat (6) may
be broken
*Call the service
* Thermostat (6) may
be switch off
*Control thermostat
adjustment

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 15
TROUBLE FIXING
PROBLEM
CAUSE
CHECKS
THE PUMP
DOES NOT
PUMP WATER
INTO THE
BOILER
* Water pump may be
out of order.
*Call the service
* Water solenoid valve
may be out of
order.(white color, near
the pump)
*Non-returns valves
maybe out of
order(yellow color, near
the pump,2units)
*Air may enter into the
pump
*Disconnect the pump air
taking screw (yellow), fill it
up with water, connect the
screw again and let star
work the machine.
*Water tank may be
empty
*Check water level in the
water tank. If there is not
enough water complete it.
HAND IRON DOES
NOT WORK
*Hand iron may be
broken.
*Change new one or
repaired.
*Hand iron plug may be
connect counter.
*Turn the plug counter
direction and connect
again.
HAND IRON
HEATING BUT
DOES NOT
SEND STEAM
*Soloneid valve
(14)maybe broken
* Call the service
*Hand iron base may be
clogged.
*Clean the hand iron base
with suitable material.
*Steam hose may be
craked.
*Change new one.

HASEL ÜTÜ SAN.TİC.LTD.ŞTİ. 16
