Hatteras Hammocks HHDCA1-K User manual

DINING CHAIR W/ARMS
INSTRUCTIONS
• CHAIR BACK/BACK LEGS
• CHAIR SEAT
• LEFT LEG ASSEMBLY
• RIGHT LEG ASSEMBLY
• NAMEPLATE
• LOWER FRAME
• RUBBER MALLET
• PHILLIPS HEAD SCREWDRIVER
• DRILL
HHDCA1: Hardware Pack Weight: 6.5 oz.
(12) BARREL NUTS
(12) 2” BARREL BOLTS
(4) 2” SCREWS
(2) 3” SCREWS
(1) ALLEN WRENCH
(1) SQUARE-HEAD BIT
HARDWARE PACK
CHAIR PARTS
SUGGESTED TOOLS
STEP 1. Attach chair seat to left and right front legs using (4) barrel
bolts and barrel nuts.
Note: Name plate hidden to show assembly.
ASSEMBLY
LEFTLEFT
FRONTFRONT
LEGLEG
BARRELBARREL
NUTNUT
RIGHTRIGHT
FRONTFRONT
LEGLEG
CHAIR SEATCHAIR SEAT

Congratulations on purchasing this Dining Chair w/Arms. QUESTIONS REGARDING THIS PRODUCT? Call our customer service team, 252-758-0641.
RESIDENTIAL WARRANTY - This quality product includes a FULL LIFETIME WARRANTY for RESIDENTIAL CUSTOMERS. In the unlikely event any splintering, rotting, cracking, peeling,
chipping, insect infestation or other damage should ever occur, The Hammock Source will replace this furniture, at no charge to you. Note that an original sales receipt must accompany any
returned product, along with a Return Authorization Number from Hammock Source customer service; call toll-free at 252-758-0641.
CONTRACTOR WARRANTY - CONTRACTORS receive a FULL 7-YEAR WARRANTY. Follow the same steps outlined above.
MAINTENANCE - Thoroughly inspect product before each use. Periodically check bolts after assembly and re-tighten when necessary.
ASSEMBLY
3” SCREW
#6109A
STEP 2. Use (2) 3” screws to attach
name plate to chair front legs.
STEP 4. Use (4) 2” screws to attach
lower frame to front and back chair
legs. The screws on the front of
the lower frame should be oset
towards the top side.
STEP 5. Use (2) 2” barrel bolts and
barrel nuts to attach chair arms to
chair back.
STEP 3. Use (6) 2” bolts and barrel
nuts to attach chair back to chair
seat.
NAME PLATE
2” BOLT
CHAIR
BACK
BARREL
NUT
2”
BARREL
BOLT
LOWER FRAME
2” SCREW
CHAIR
ARM
*6109A*
