HAUL MASTER 58119 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference. 22e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. ITEM 58119
Specifications
Capacity 1500 lb combined,
750 lb individually
(Static Conditions)*
Max. Tailgate Height 45"
Dimensions 90" L x 12" W
Important Safety Information
1. Before use:
a. Read and understand manual.
b. Inspect before every use; do not
use if parts loose or damaged.
c. Turn vehicle’s ignition OFF.
d. Set parking brake or chock
wheels. A trailer must be properly
coupled to tow vehicle.
e. Clean dirt, oil and debris off
Ramps and allow Ramps to dry.
f. Set up only on solid,
level, dry surface.
g. Turn Ramps so flange end faces
downward. Position Ramps so
that tongues fully contact tailgate.
h. Properly connect Safety Straps.
2. Load and unload vehicle slowly.
Do not ride vehicle up
or down Ramps.
3. Do not exceed 750 lb capacity per
Ramp or 1500 lb capacity evenly
distributed across two Ramps.
Be aware of dynamic loading!
Sudden load movement may
briefly create excess load
causing product failure.
4. Use as intended only. Do not use:
a. as ladder, bridge, or scaffolding,
b. to load/unload 3-wheeled vehicles,
c. if tailgate on carrying vehicle
is higher than 45", or
d. to load vehicle with wheel
width wider than Ramp.
5. Ground contact. Use your Ramps
on a solid, level, flat, dry surface.
Make sure the Tongue edge fully
contacts the tailgate of the vehicle.
6. Clean Ramps. Prior to each use,
clean dirt, oil, or any debris off Ramps.
7. This product is not a toy. Do not allow
children to play with or near this item.
8. Maintain product labels and
nameplates. These carry
important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
9. All persons not involved in the
loading process must stand
clear of the loading Ramps.
Keep children away. Children must
not be allowed in the work area.
10. Do not exceed weight
capacity of tailgate.

Page 3For technical questions, please call 1-888-866-5797.ITEM 58119
11. Do not work alone. If an accident
happens, an assistant can bring help.
12. Keep work area clean and well lit.
Cluttered and dark areas invite injuries.
13. Store idle equipment. When not in
use, store Ramps in a dry
location to inhibit rust.
14. Dress properly. Do not wear loose
clothing or jewelry. Protective clothes
and nonskid footwear are recommended
when working. Wear restrictive hair
covering to contain long hair.
15. Wear ANSI-approved impact
safety goggles, a safety helmet,
and heavy-duty work gloves
when loading, unloading
or handling Ramps.
16. Keep proper footing and balance
when loading or unloading.
17. Do not cut, drill, weld, or
otherwise modify this product.
18. Stay alert. Watch what you are doing,
use common sense. Do not use
any ramp when you are tired.
19. Check for damaged parts.
Before using any ramp, any part that
appears damaged should be carefully
checked to determine that it will perform
its intended function. Check for any
broken parts or mounting fixtures and
any other condition that may affect
proper operation. Any part that is
damaged should be properly repaired
or replaced by a qualified technician.
20. Replacement parts and accessories.
When servicing, use only identical
replacement parts. Use of any
other parts will void the warranty.
Only use accessories intended
for use with these Ramps.
21. Do not use Ramp if under the
influence of alcohol or drugs.
Read warning labels on prescriptions to
determine if your judgment or reflexes
are impaired while taking drugs. If there
is any doubt, do not use the Ramp.
22. The warnings, cautions, and instructions
discussed in this instruction manual
cannot cover all possible conditions
and situations that may occur. It must
be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
SAVE THESE INSTRUCTIONS.

Page 4 For technical questions, please call 1-888-866-5797. ITEM 58119
Setup and Operation Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY:
Before loading or unloading turn vehicle’s engine off, set its transmission
in gear or park, engage its emergency brake and block its wheels.
Make sure the Ramps are clean and dry before loading or unloading.
Setup
1. The tailgate the Ramps will sit
on and both of the Ramps must
be dry and clean. Check for and
tighten any loose hardware.
2. Sit the Tongue (angled lip) of
the Ramps on the tailgate. The
Tongue edge must face down and
fully contact the truck’s tailgate.
WARNING! TO PREVENT SERIOUS
INJURY: CONNECT SAFETY STRAPS
TO SECURE ATTACHMENT POINTS
ABLE TO WITHSTAND THE PULLING
FORCE OF LOADING. THEY MUST
ALSO BE TAUT ENOUGH TO PREVENT
THE RAMPS FROM COMING OFF
THE VEHICLE BEING LOADED.
3. Connect Safety Strap to truck frame:
a. Verify the Safety Strap is securely
connected to the Ramp.
Ramp
Safety Strap
Hook
Tongue

Page 5For technical questions, please call 1-888-866-5797.ITEM 58119
b. Connect the Hook of the Safety Strap
to the anchor point on the truck’s
frame closest to the Ramp.
Hook
Hook
Tongue
c. Pull the Safety Strap tight so
that the loading Ramp cannot
be pulled backwards.
4. Repeat the previous three
connection steps for the second
Safety Strap on the other Ramp.
5. After Safety Strap adjustment, the
entire Tongue portion of the Ramps
must fit securely onto the tailgate
and not be able to slide backwards.
If either Ramp can still slide,
adjust both Safety Straps.
4- Wheel ATV Loading and Unloading
• These Ramps are for use with 2-wheeled dirt bikes and 4-wheeled ATV’s only.
Do not use these Ramps to load/unload 3-wheeled vehicles.
• Do not use these Ramps to load or unload any vehicle that weighs more than 1500 lb.
• Do not use these Ramps to load or unload any vehicle that is wider than the Ramp.
• Do not use these Ramps to load or unload any vehicle that is carrying gear on its racks.
• Do not use these Ramps if the tailgate on the vehicle being
loaded or unloaded is higher than half each Ramp’s length (45").
WARNING! TO PREVENT SERIOUS INJURY: Riding an ATV while
loading or unloading is dangerous and should not be attempted.
WARNING! TO PREVENT SERIOUS INJURY: Be aware of dynamic loading!
Sudden load movement may briefly create excess load causing the Ramps to fail.
WARNING! TO PREVENT SERIOUS INJURY: All persons not involved in the
process must stand clear of the Ramps and truck. Make sure no pets are nearby.

Page 6 For technical questions, please call 1-888-866-5797. ITEM 58119
Loading Using a Winch (not included)
WARNING! TO PREVENT SERIOUS
INJURY: Riding an ATV while loading is
dangerous and should not be attempted.
WARNING! TO PREVENT SERIOUS
INJURY: Follow all winch operating
instructions and safety measures.
1. The winch and mounting/
connection points must all have
appropriate capacity to pull the
ATV up the Ramps safely.
2. ATV Mounted Winch Setup: Unwind
cable from the winch and attach it to a
secure mounting location on the truck,
at the same height as the winch will
be after the ATV has been loaded.
3. Truck Mounted Winch Setup:
Attach the cable to the bottom
front part of the frame.
4. While operating the winch,
stand back and to the side of the
ATV, with the vehicle between
you and the winch cable.
5. Operate the winch to slowly load
the ATV onto the vehicle.
Unloading
WARNING! TO PREVENT SERIOUS
INJURY: Riding an ATV while unloading is
dangerous and should not be attempted.
1. Have an assistant monitor the Ramp
Tongues for slippage on the tailgate.
2. Set up the Ramps on the truck
bed as explained under operation.
Remove all tie down straps and
securing equipment from the ATV.
WARNING! TO PREVENT SERIOUS
INJURY: Be sure the 4-wheel
ATV is centered on Ramps.
3. While staying off the ATV,
start the engine, disengage the parking
brake, put the transmission into
reverse, and make sure the wheels
are in a straight line with the Ramps.
While holding the brake, position
yourself in front of the ATV.
4. Release the brake and push on the ATV
to get it started down the Ramps. Allow
the ATV to roll down naturally, do not
attempt to steer it or apply the brakes.
If it stops while on the Ramps, gently
give it throttle to back it off the Ramps.

Page 7For technical questions, please call 1-888-866-5797.ITEM 58119
2-Wheel Bike Loading
1. Do not attempt to load any dirt bike
or other 2-wheel motor bike alone.
Have a qualified adult assist.
2. Line up the 2-wheel bike
with one of the Ramps.
3. With one person pushing the bike
slowly up the Ramp, a helper should be
in the bed of the hauling vehicle both
to guide and to apply the brake if it is
necessary to stop the bike while it is
on the Ramp. Have one person with a
hand on the bike hand brake for safety.
4. Once the person inside the truck bed
has hold of the handle bars, apply
the brake and steady the bike while
the other person moves behind the
bike (but off to one side) and pushes
it all the way into the truck bed.
NOTE: While most dirt bikes are light
enough to safely load with two people, a third
person can make the job easier and safer.
5. Once the bike is safely loaded, secure it
with four tie down straps (not included),
one on each side of the front, and one
on each side at the rear of the bike.
2-Wheel Bike Unloading
1. Position the Ramp against the
truck tailgate behind the rear
tire of the bike and attach the
Safety Strap to the truck bed.
2. Remove the tie-down
straps (not included).
3. With assistance, slowly and carefully
push the bike backwards until the back
tire is at the top of the Ramp. With
one person on the ground behind and
to the side of the Ramp, slowly push
the bike onto the Ramp. Someone
must always hold the hand brake.
4. Slowly work the bike down the
Ramp and onto the ground.

Page 8 For technical questions, please call 1-888-866-5797. ITEM 58119
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY:
Remove the Ramps from the vehicle before performing any maintenance or service.
Do not use damaged equipment.
If Ramps are damaged, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE,
inspect the general condition
of the Ramps. Check for:
• loose hardware
• misalignment or binding of parts
• cracked or broken parts
• any other condition that may
affect its safe operation.
2. Clean the Ramps after each use.
Make sure any dirt, oil, grease, or
debris are not on the Ramps.

Page 9For technical questions, please call 1-888-866-5797.ITEM 58119
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175432575 when ordering parts.

Page 10 For technical questions, please call 1-888-866-5797. ITEM 58119
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS
LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL
ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT
HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN
FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT
ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY
CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO
THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 11For technical questions, please call 1-888-866-5797.ITEM 58119
Parts List and Diagram
Part Description Qty.
1 Ramp 2
2 Safety Strap 2
3 Lock Nut, M6 2
Part Description Qty.
4 Washer, #6 Extra Large 4
5Hex Socket Button
Head Bolt, M6 x 16 2
1
2
Bottom View
3
45
Top View

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
