Haussmann TDB342 User manual

1
Operator’s Manual
3.0
HP (Max. Developed)
10 In. Blade
50
00 R.P.M.
TABLE
SAW
Model No.
TDB342
CAUTION:
Before using this Table Saw,
read this manual and follow
all its Safety Rules and
Operating Instructions
●
Safety Instructions
●
Installation
●
Operation
●
Maintenance
●
Parts List

2
TABLE OF CONTENTS
Warranty ………………………………….
2
Know Your Table Saw..….................…..
8
Product Specifi cations …………………..
2
Assembly and Adjustments……………..
9
Power Tool Safety ..……………………...
3
Operation
...........................
……………..
16
Table
Saw Safety......................………...
4
Maintenance..…………………………….
20
Electrical Requirements and Safety……
5
Troubleshooting Guide.......……………..
21
Accessories and Attachments…………..
6
Parts List......................……………….....
22
Tools Needed For Assembly..……….....
6
Push Stick Plan.....………………............
26
Carton Contents ....................................
6
WARNING

!
To avoid electrical hazards, fi re hazards or damage to the tool, use proper circuit protection.
This tool is wired at the factory for 110-120 Volt operation. It must be connected to a 110-120 Volt / 15 Ampere
time delay fuse or circuit breaker. To avoid shock or fi re, replace power cord immediately if it is worn, cut or
damaged in any way.
Before using your tool, it is critical that you read and understand these safety rules. Failure to follow these
rules could result in serious injury to you or damage to the tool.
SECTION PAGE
SECTION PAGE
WARNING

!
Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains
chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
•
Lead from lead-based paints
•
Crystalline silica from bricks, cement and other masonry products
•
Arsenic and chromium from chemically treated lumber
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals, work in a well ventilated area and work with approved safety equipment such as
dust masks that are specially designed to fi lter out microscopic particles.
MOTOR SAW
HP (Maximum developed)……...
3.0 Table Size………………….....
26-7/64 in. x 19-1/2 in.
Type
…………………................... Universal
Table Extensions
……………..
Yes
,
with fences
Amps…………………….............. 15
Extension
Fence Capacity..
…
24 in. Right & Left
Voltage….................................... 120 Blade Size ............................
10 in.
Hz
………………………...............
60 Rip Fence .............................
YES
RPM (no load) ............................ 5000
Miter Gauge .......................... YES
Thermal Overload Protection…... YES Maximum Cut Depth @ 90
º
... 3 in.
Maximum Cut Depth @ 45
º
... 2-1/2 in.
Maximum Dado Cut Width .... 1/2
in.
Net Weight ............................ 64.5 LBS
PRODUCT SPECIFICATIONS
FULL THREE YEAR WARRANTY
This HAUSSMANN product is covered by 3-year warranty against workmanship and mater
ial defects. In case
of any malfunction of your HAUSSMANN tool (failure, missing part, etc.), please contact one of our service
technician at our toll free service line at 1-888-267-7713 from 9 am to 9 pm, Monday to Friday, Eastern time.
WARRANTY

3
POWER TOOL SAFETY
WARNING


!
Before using your table saw, it is critical that you read and understand these safety rules.
WARNING
Before using your table saw, it is critical that you read and understand these safety rules.
WARNING

Before using your table saw, it is critical that you read and understand these safety rules.


!

Before using your table saw, it is critical that you read and understand these safety rules.

!

Before using your table saw, it is critical that you read and understand these safety rules.
Failure to follow these rules could result in serious injury or damage to the table saw.
Good safety practices are a combination of common
sense, staying alert and understanding how to use your
power tool.To avoid mistakes that could cause serious
injury, do not plug in your power tool until you have read
a
nd underst
ood the following safety rules:
1.
READ
and become familia
r with this entire
Operator’s Manual. LEARN the tool’s applications,
limitations
and p
ossible hazards.
2. Look
for this
2. Look for this 2. Look
symbol that
identifi es important safety precautions. It
m
eans
CAUTION! BECOME ALERT! YOUR
SAFETY IS
INVOLVED
!
3
.
NEV
ER OPERAT
E THIS MACHINE WITHOUT THE
SAFETY GUARD IN PLACE FOR ALL THROUGH-
SAWIN
G OPERATIONS.
4.
DO N
OT US
E IN DANGEROUS ENVIRONMENTS
such as damp or wet locations or exposure to rain.
K
eep work area well lig
hted.
5.
DO NO
T
use power tools in the
presence of
fl ammabl
e liqui
ds or gases.
6.
KEEP WORK AR
EA CLEAN.
Cluttered areas and
be
nches invite acc
idents.
7.
KEEP CH
ILDREN AWAY.
All visitors should be kept
at a safe distance
from the work area.
8.
D
O NOT FORCE TH
E TOOL.
It will do the job better
and safer at t
he rate for which it was designed.
9.
U
SE THE RIGHT T
OOL.
Don’t force the tool or
attachment to d
o a job for which it is not designed.
10.
WEA
R PROPE
R APPAREL.
DO NOT wear loose
clothing, gloves, neckties, rings, bracelets or other
jewelry which may get caught in moving parts. Non-
slip footwear is recommended. Wear protective hair
c
overing to c
ontain long hair.
11.
WEAR A F
ACE
MASK OR DUST MASK.
Sawing,
cutting and sanding operations produce dust.
12.
D
ISC
ONNECT TOOLS
before servicing and when
c
hanging
accessories such as blades, cutters, etc.
13.
REDUC
E T
HE RISK OF UNINTENTIONAL
STARTING.
Make sure the switch is in the OFF
position before plugging into the power supply.
14.
USE ONLY RECOMMENDED ACCESSORIES.
Consult the Operator’s Manual for recommended
accessories. The use of improper accessories may
cau
se injury to you or damage to the tool.
15.
REMOVE
ADJUSTING KEYS AND WRENCHES.
Form the habit of checking to see that keys and
adjusting wrenches are removed from the tool before
turning ON.
16.
NE
VER LEAVE TOOL RUNNING UNATTENDED.
TURN THE POWER “OFF”.
Do not leave the tool
befo
re it comes to a complete stop.
17.
NEVE
R STAND ON TOOL.
Serious injury could
occur if the tool is tipped or if the cutting tool is
uni
ntentionally contacted.
18.
DO NOT
OVERREACH.
Keep proper footing and
b
alance at all times.
19.
MA
INTAIN TOOLS WITH CARE.
Keep tools sharp
and clean for most effi cient and safest performance.
Follow instructions for lubricating and changing
a
ccessories.
20.
CHECK
FOR DAMAGED PARTS.
Before further
use of the tool, a guard or other part that is damaged
should be carefully checked to ensure it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
mounting and any other conditions that may affect its
safe operation. A guard or other part that is damaged
should be properly repaired or replaced.
21.
MA
KE WORKSHOP CHILD PROOF
with padlocks,
m
aster switches or by removing starter keys.
22.
DO N
OT
operate the tool if you are under the
infl uence of any drugs, alcohol or medication that
coul
d impair your ability to use the tool safely.
23.
USE A D
UST COLLECTION SYSTEM
wherever
possible. Dust generated from certain materials can
be hazardous to your health and in some cases, a
fi re hazard. Always operate the power tool in a well-
ventilated area with adequate dust removal.
24.
ALWA
YS WEAR EYE PROTECTION.
Any power
tool can throw foreign objects into your eyes which
could cause permanent eye damage. ALWAYS
wear safety goggles (not glasses) that comply with
ANSI safety standard Z87.1. Everyday glasses have
only impact resistant lenses. They ARE NOT safety
glasses.
NOTE:
Glasses or goggles not in compliance with
ANSI Z87.1 could cause serious injury when they
bre
ak.
25.
DIREC
TION OF FEED.
Feed work into a blade or
cutter against the direction of rotation of the blade or
cutter only.
WARNING
2. Look
WARNING
2. Look

2. Look

2. Look
!
2. Look

4
1.
ALWAYS USE SAW BLADE GUARD,
splitter and
anti-kickback pawls for every operation for which they
can be used, including through-sawing. Through-
sawing operations are those in which the blade cuts
completely through the workpiece when ripping or
cross-cutting.
2.
ALWAYS HOLD WORK FIRMLY
against the miter
gauge or rip fence.
3.
USE A PUSH STICK
when required. Always use a
push stick when ripping narrow stock. Refer to ripping
instructions in this Operator’s Manual where the push
stick is covered in detail. A pattern for making your
own push stick is included on page 26.
4.
NEVER PERFORM ANY OPERATION ”FREE
HAND”,
which means using only your hands to
support or guide the workpiece. Always use either
the fence or the miter gauge to position and guide
the work.
WARNING:
FREEHAND CUTTING IS THE MAJOR
CAUSE OF KICK-BACK & FINGER/HAND
AMPUTATIONS.
5.
NEVER STAND
or have any part of your body in line
with the path of the saw blade. Keep your hands out
of the saw blade path.
6.
NEVER REACH
behind or over the cutting tool for
any reason.
7.
NEVER
use a rip fence when cross cutting.
8.
DO NOT USE
a molding head with this saw.
9.
FEED WORK INTO THE BLADE
against the
direction of rotation only.
10.
NEVER
use the rip fence as a cut-off gauge when
cross-cutting.
11.
NEVER ATTEMPT TO FREE A STALLED SAW
BLADE
without fi rst turning the saw OFF. Turn power
switch OFF immediately to prevent motor damage.
12.
PROVIDE ADEQUATE SUPPORT
to the rear
and the sides of the saw table for long or wide
workpieces.
13.
AVOID KICKBACKS
(work thrown back towards
you) by keeping the blade sharp, the rip fence
parallel to the saw blade and by keeping the splitter,
anti-kickback pawls and guards in place, aligned and
functioning. Do not release work before it has passed
all the way past the saw blade. Do not rip work that is
twisted, warped or does not have a straight edge to
guide it along the fence. Do not release work before
it has passed all the way past the saw blade & is off
the table. Do not rip work that is twisted, warped or
does not have a straight edge to guide it along the
fence.
14.
AVOID AWKWARD OPERATIONS
and hand
positions where a sudden slip could cause your hand
to move into the saw blade.
15.
NEVER USE SOLVENTS
to clean plastic parts.
Solvents could possibly dissolve or otherwise
damage the material. Only a soft damp cloth should
be used to clean plastic parts.
16.
MOUNT
your table saw on a bench or stand
before performing any cutting operations. Refer to
ASSEMBLY AND ADJUSTMENTS on page 9.
17.
NEVER CUT METALS
or materials which may make
hazardous dust.
18.
ALWAYS USE IN WELL-VENTILATED AREA.
Remove sawdust frequently. Clean out sawdust
from the interior of the saw to prevent a potential
fi re hazard. Attach a vacuum to the dust port for
additional sawdust removal.
19.
NEVER LEAVE THE SAW
RUNNING
UNATTENDED
. Do not leave the saw until it comes
to a complete stop.
20.For proper operation follow the instructions in
this Operator’s Manual entitled ASSEMBLY AND
ADJUSTMENTS (Page 9). Failure to provide sawdust
fall-through and removal hole will allow sawdust to
build up in the motor area resulting in a fi re hazard
and potential motor damage.
TABLE SAW SAFETY

5
ELECTRICAL REQUIREMENTS AND SAFETY
POWER SUPPLY REQUIREMENTS
To avoid electrical hazards, fi re hazards or damage to
the chop saw, use proper circuit protection. Always use
a separate electrical circuit for your tools. This power
tool is wired at the factory for 120V operation. Connect it
to a 120V, 15 Amp circuit and use a 15 Amp time delay
fuse or circuit breaker. To avoid shock or fi re, replace
the cord immediately i
f it is worn, cut or damaged in any
way.
EXT
ENSION CORD REQUIREMENTS
Any extension cord must be GROUNDED for safe
operation.
MINIMUM GAUGE FOR EXTENSION CORDS
(AWG TYPE / 120 VOLT ONLY)
Ampere Rating
Total length in feet
More Than
Not
More Than
25
50
100
150
0
6
18
16
16
14
6
10
18
16
14
12
10
12
16
16
14
12
12
16
14
12
Not Applicable
WARNING

!
GUIDELINES FOR EXTENSION CORDS
Any extension cord used for power tools MUST be
grounded (3-wire with two fl at prongs and one round
ground prong).
Make sure the extension cord is in good condition.
When using an extension cord, make sure you use one
heavy enough to carry the current the tool will draw.
An undersized cord will cause a drop in line voltage
resulting in loss of power and overheating. The table
above shows the correct size to use according to
extension cord length and nameplate ampere rating. If
in doubt, use the next heavier gauge cord. The smaller
the gauge number the heavier the cord.
NOTE:
The 12 to 16 Amp rating is correct for this tool. It
i
s highlighted in the table above.
Be sur
e your extension cord is properly wired and in
good condition. Always replace a damaged extension
cord or have it repaired by a qualifi ed person before
using it. Protect your extension cords from sharp
o
bjects, excessive heat and damp or wet areas.
Before
connecting the saw to the extension cord, make
sure the saw switch is turned OFF.
GROUNDING INSTRUCTIONS
IN THE EVENT OF A MALFUNCTION OR
BREAKDOWN, grounding provides a path of least
resistance for electric current and reduces the risk of
electric shock. This saw is equipped with an electric
cord that has an equipment grounding conductor and
a grounding plug. The plug MUST be plugged into
a matching receptacle that is properly installed and
grounded in accordance with ALL local codes and
ordinances.
DO NOT MODIFY THE PLUG PROVIDED.
If it will not
fi t the receptacle, have the proper receptacle installed
by a qualifi ed electrician.
IMPROPER CONNECTION
of the equipment grounding
conductor can result in risk of electric shock. The
conductor
(wire) with the green insulation (with or
without yellow stripes) is the equipment grounding
conductor. If repair or replacement of the electric cord
or plug is necessary, DO NOT connect the equipment
grounding conductor to a live terminal.
CHECK
with a qualifi ed electrician or service personnel
if you do not completely understand the grounding
instructions, or if you are not sure the saw is properly
grounded.
Use only 3-wire extension cords that have 3-prong
grounding plugs and 3-pole
grounding
rec
eptacles that
accept the saw’s plug. Repair or replace damaged or
worn cords immediately.
WARNING

!
3-Prong Plug
3-Prong Plug
Grounding Prong
Grounding Prong
Properly Grounded
Properly Grounded
3-Prong Receptacle
3-Prong Receptacle
Grounding Lug
Make sure this is
Make sure this is
connect
connect
ed to a
known g
known g
round.
2
-Pronged
-Pronged
Receptacle
Receptacle
Adapter

6
ACCESSORIES AND ATTACHMENTS
RECOMMENDED ACCESSORIES
To avoid the risk of personal injury:
●
Do not use adjustable (wobble) type dadoes or
carbide tipped dado blades.
●
Maximum dado width is 1/2”.
●
Do not use a dado with a diameter larger than 6”.
●
Do not use molding head set with this saw.
●
Do not modify this power tool or use accessories not
recommended.
WARNING

!
CARTON CONTENTS
UNPACKING AND CHECKING CONTENTS
Separate all parts from packing materials. Check each
part with the illustration on the next page and the “Table
of Loose Parts” to make certain all items are accounted
for, before discarding any packing material.
If any part is missing or damaged, do not attempt to
assemble the table saw, plug in the power cord, or
turn the switch ON until the missing or damaged part is
obtained and is installed correctly.
WARNING

!
TABLE OF LOOSE PARTS
ITEM
DESCRIPTION
QUANTITY
A
Table saw assembly
1
B
Table extension
2
C
Rear table extension
1
D
Rear table extension tube
2
E
Location seat
5
F
Blade guard and splitter
1
G
Bolt, fl at washer, toothed washer,
Oval washer
1 each
H
Rip fence
1
I
Hand wheels
2
J
Dome nuts
2
K
Dado table insert
1
L
Miter gauge
1
M
Hex keys
1
N
Blade wrenches
2
O
Blade
1
P
Dust chute
1
Q
Dust Bag
1
STAND
R
Top short leg bracket
2
S
Top long leg bracket
2
T
Bottom short bracket
2
U
Bottom long bracket
2
V
Legs
4
W
Stand Mounting Hardware Bag
1
X
Fence Storage Hardware Bag
1
NOTE:
To make assembly easier, keep contents of box
together. Apply a coat of automobile wax to the table.
Wipe all parts thoroughly with a clean dry cloth. This will
reduce friction when pushing the workpiece.
Adjustable Wrench
Flat Blade Screwdriver
Philips Screwdriver
Steel Ruler
Combination Square
TOOLS NEEDED FOR ASSEMBLY
TOOLS NEEDED

7
Sears, Roebuck and Co. MADE IN TAIWAN
SPECIFICATIONS
Heavy Duty Universal Motor
120V, 60Hz, 15Amps, AC
5000RPM (No-load Speed)
Maximum cutting depth:
at 90
0
....................3 inches
at 45
0
..............2-1/2 inches
3.0
MAXIMUM DEVELOPED HP
104920HU
45
o
0
o
15
o
10
o
5o
30
o
25
o
35
o
40
o
20o
TABLE SAW
Consumer Help Line 1-800-843-1682
BLADE
ANGLE
UNPACKING YOUR TABLE SAW
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X

8
KNOW YOUR TABLE SAW
P
U
N
W
D
O
SPECIFICATIONS
Heavy Duty Universal Motor
120V, 60Hz, 15Amps, AC
5000RPM (No-load Speed)
Maximum cutting depth:
at 90
0 ....................3 inches
at 45
0 ..............2-1/2 inches
TABLE SAW
3.0
MAXIMUM DEVELOPED HP
B
lade Guard
T
able Insert
R
ip Fence
S
ide Table
Extension Wing
B
evel Tilting Handwheel
B
lade Bevel Lock Knob
B
lade Elevation Handwheel
E
xtension Wing Locking Lever
B
lade Tilt Pointer & Scale
ON/OFF S
witch with Saftey Key
Overload Reset Switch
Table
M
iter Gauge
R
ear Outfeed Table Extension
D
ust Bag
M
ounting Holes
Stand

9
Assemble stand (Fig. A)
1. Unpack all parts and group by type and size (Fig. A).
Refer to parts list for quantities.
2. Attach one long upper support (11, 17) to top of leg (1)
using one square neck bolt (2) and nut (8).
NOTE
:
Do not tighten bolts until stand is properly
aligned (see step #9).
3. Attach other end of long upper support to top of
another leg using one square neck bolt and nut.
4. Attach one long bottom support (3) to center of each
leg using square neck bolts and nuts. This completes
the front frame section.
5.
Assemble rear frame section in exactly the same
way.
6. Join front and rear frame assemblies using two short
upper supports (9) and two short bottom supports
(13), square neck bolts and nuts.
7. Insert large hex head bolt (4) into leg spacer (5) and
insert into bottom of leg. Fasten with washer (6) and
nut (7). Repeat for each leg.
8. Attach the hooks (14) to the frame as desired. The
hooks are used to hold the fence, the blade wrenches
and miter gauge.
9. Place stand on level surface and adjust so all legs
are contacting the fl oor and are at similar angles to
the fl oor. Tighten all bolts.
NOTE
:
Stand should not rock after all bolts are
tightened
.
Assemble table saw to stand (Fig. A, B)
1.
Place protective corrugated cardboard or old blanket
on fl oor to protect the saw table surface.
2.
Place the saw up-side down on the protective
material
(Fig. B).
3. Position the stand up-side down on the saw base.
NOTE:
Make sure front of stand and front of saw are
facing the same direction.
4. Position the dust chute between the stand and saw.
5. Line up four holes in saw base, dust chute and stand.
6. Fasten saw to dust chute and stand using four bolts
(10), washers (11) and nuts (8).
NOTE:
Place washer on each bolt before inserting
into saw base and through the support. Nut must be
fl ush against the bracket (see Fig. A).
7. Tighten all four nuts.
NOTE: DO NOT OVER TIGHTEN NUTS HOLDING
SAW TO STAND. THIS WILL DAMAGE THE SAW
BASE.
8.
Carefully set the saw in its upright position on a clean
level surface.
Fig.B
ASSEMBLY AND ADJUSTMENTS
10
11
9
16
14
15
12
13
2
1
3
17
17
7
6
5
Fig. A

10
BLADE RAISING HANDWHEEL (FIG. E, F)
1. Attach the handwheel (1) to the elevation screw (2)
at the front of the saw.
Make sure the slots (3) in the hub of the handwheel
engage with the pins (4). (Fig. E)
2. Attach and tighten the dome nut (5) at the end of the
shaft (Fig. F).
SAW MOUNTED TO WORK SURFACE (FIG. C)
1. If the leg set will not be used, the saw must be
properly secured to a sturdy workbench using the
four mounting holes at the base of the saw.
2. The surface of the table where the saw is to
be mounted must have a hole large enough to
facilitate sawdust fall-through and removal.
3. Square the saw on the mounting surface and mark
the location of the four 3/8” mounting holes (1).
4. Drill 3/8” hole into the mounting surface.
5. Mark an 11” square (2) centered between the four
mounting holes (1).
6. Cut out and remove the square.
7. This opening will allow sawdust to fall through the
saw base.
8. Place the saw on the work surface, and align
the mounting holes of the saw with those drilled
through the surface.
9. Fasten the saw to the work surface.
WARNING

!
Do not operate this machine on the fl oor. This is very
dangerous and may cause serious injury.
Fig.C
SQUARE
CUTOUT
2
1
Failure to provide the sawdust fall-through hole will
cause sawdust to build up in the motor area, which may
result in fi re or cause motor damage.
KEEPING THE AREA CLEAN (FIG. D)
1. Sawdust and wood chips that fall from under the saw
will accumulate on the fl oor.
2. Make it a practice to pick up and discard this dust
when you have completed cutting.
WARNING

!
WARNING

!
Always keep your work area clean, uncluttered and well
lit.
1. If the dust bag is not used, do not work on fl oor
surfaces that are slippery from sawdust or wax.
2. When using the dust bag some dust will not fall
into the bag but come out through openings in the
housing. Do not cover the motor cooling vents.
INSTALLING THE DUST BAG (FIG. D)
Do not use this saw t
o cut and sand metal.
The hot
WARNING

!
chips or sparks may ignite sawdust or the bag material.
Place the dust bag neck opening around the dust chute
and tie the dust bag with string.
SPECIFICATIONS
HeavyDutyUniversalMotor
120V,60Hz,15Amps,AC
5000RPM(No-loadSpeed)
Maximumcuttingdepth:
at90
0
....................3inches
at45
0
..............2-1/2inches
TABLESAW
3.0
Fig.E
BLADE TILTING HANDWHEEL (FIG. G, F)
1. Attach the other handwheel (6) to the blade tilting
screw on the side of the saw in the same manner as
above.
2. Attach and tighten the handwheel dome nut (5).
Fig.F
3
1
2
4
Fig.
D

11
RIP FENCE (Fig. G)
1. Lift upward on the rip fence handle (1) so that the
holding clamp (2) is fully extended.
2. Place the rip fence on the saw table and engage
the holding clamp (2) to the table rear. Lower the
front end onto the front rail (3).
3. Push down on the fence handle (1) to lock.
Fig. G
INSTALLING AND CHANGING THE BLADE
(FIG. H, I, J)
WARNING

!
To avoid injury from an accidental start, make sure
the switch is in the OFF position and the plug is not
connected to the power source outlet.
1. Remove the table insert (1) by unscrewing the
two screws (2, 3).Be careful not to lose the rubber
washer that is on the back screw (3) beneath the
table insert. (Fig. H)
Fig.H
2. Raise the blade arbor (4) (Fig. I) to the maximum
height by turning the blade raising handwheel
counterclockwise.
3. Remove the arbor nut (5) and fl ange (6), remove
blade.
4. Install the saw blade onto the arbor with the blade
teeth pointing toward the front of the saw.
5. Install the fl ange (6) against the blade and thread the
arbor nut (5) as far as possible by hand. Ensure that
the blade is fl ush against the inner side of the blade
fl ange.
WARNING

!
To avoid possible injury and damage to the workpiece
be sure to install the blade with the teeth pointing toward
the front of table in the direction of the rotation arrow on
the blade guard.
Fig.I
6. To tighten the arbor nut (5) place the open-end
wrench jaws on the fl ats of the saw arbor to keep the
arbor from turning. (Fig. J)
7. Place the box-end wrench (8) on the arbor nut (5),
and turn clockwise (to the rear of the saw table).
8. Replace the blade insert in the table recess, insert
the screws through the front and rear holes and
tighten.
Fig. J
WARNING

!
To avoid injury from a thrown workpiece, blade parts, or
blade contact, never operate saw without the proper
insert in place. Use the saw blade insert when sawing.
Use the dado head insert when using a dado.
1
3
2
1
3
2
4
5
6
8
7
5

12
7
8
Anti-kickback Pawl
Straight Edge
Straight Edge
9
3
Improper splitter alignment can cause “kickback” and
serious injury.
BLADE GUARD ASSEMBLY (FIG. K, L, M)
1. Set the blade to maximum height and the tilt to zero
degrees on the bevel scale with the hand wheels.
Lock the blade lock knob.
2. Place the external toothed lock washer (1) and a
steel fl at washer (2) onto the long hex head bolt (3).
Insert the bolt into the splitter bracket (4) as shown.
(Fig. K)
Fig. K
3. Place the oval washer (5) on the pivot rod (6). (Fig. L)
4. Install the bracket assembly (4) at the rear of the saw
table and snugly – do not tighten. Thread the bolt (3)
into the internally threaded pivot rod.
NOTE:
The splitter is removed from the illustration
for clarity.
Fig. L
5. Position the blade guard arm (7) to the rear of the
table. (Fig. M)
6. Using a straight edge, check to see if the blade guard
splitter (8) is aligned with the saw blade (9).
7. If straightening adjustment is necessary, loosen the
bolt (3) and shift the splitter assembly to right or left,
or rotate.
8. When the splitter is properly aligned with the saw
blade, tighten the bolt, very tight.
9. If height adjustment is necessary, loosen the knob
(11) and raise the splitter assembly to the desired
height and tighten the knob. (Fig. K)
NOTE
: The splitter must always be correctly aligned
so that the cut workpiece will pass on either side
without binding or twisting to the side.
WARNING

!
INSTALLING TABLE SIDE EXTENSIONS (FIG. N)
1. Identify the right hand table extension.
NOTE:
For illustration purposes the view in Fig. N looks
“through” the saw table to the under side of the table.
The right hand table extension is the one with the
measuring scale (1) visible from the front of the saw
when it is installed to the right hand side of the saw
table (Fig. N).
2. Open both front and rear cam locking levers (2) on
the right hand side of the saw base by pulling them
out from the cam locking assemblies (4).
3. Insert the table extension mounting tubes (3) into the
two matching holes in the cam lever assemblies.
NOTE:
Make sure the front mounting tube has the
measuring scale visible from the front of the saw.
4. Slide the table extension toward the table until it rests
against the saw table.
5. Lock both cam locking levers by pushing them in
toward the cam locking lever assemblies.
F
ig. N
4
11
1
2
3
5
6
2
1
Fig.M

13
5
3
6
Sears, Roebuck and Co. MADE IN TAIWAN
SPECIFICATIONS
Heavy Duty Universal Motor
120V, 60Hz, 15Amps, AC
5000RPM (No-load Speed)
Maximum cutting depth:
at 90
0
....................3 inches
at 45
0
..............2-1/2 inches
3.0
MAXIMUM DEVELOPED HP
137.248880
104920HU
5
1
3
2
4
INSTALLING TABLE SIDE EXTENSIONS- cont’d
(FIG. O)
6. Snap one location seat (5) over the end of the rear
table extension tube (3). Make sure the locating pin
(6) in the location seat fi ts into the matching hole in
the extension tube (Fig. O).
7. Install the left hand table extension in a similar way.
NOTE:
Install location seat on front table extension tube.
NOTE:
For illustration purposes the view in Fig. O looks “through”
the saw table to the under side of the table.
Fig. O
INSTALLING REAR TABLE EXTENSION (FIG. P)
1. Place the rear table extension onto the two rear table
extension tubes (1).
2. Snap two location seats (4) over the two rear table
extension tubes (1).Make sure the locating pin in
the location seat fi ts into the matching hole (5) in the
extension tube.
3. Insert rear table extension tubes (1) into the two
holes in the rear of the saw table (3) and into
extension tube brackets under the table.
Position rear table support so instruction labels
are up.
4. Snap one location seat (4) over the end of the left
rear table extension tube (1). Make sure the
locating pin in the location seat fi ts into the
matching hole in the extension tube.
Fig. P
4
3
5
1
ADJUSTING REAR TABLE EXTENSION
1. Rear table extension should be positioned as close
as possible to the rear of the table when ripping short
work pieces.
2. Rear table extension should be pulled out fully until
the location seat prevents it from moving outward
when ripping long work pieces that require extra
support as you are completing the cut.
RIP FENCE ADJUSTMENT (FIG. Q)
1. The fence (1) is moved by lifting up on the handle (2)
and sliding the fence to the desired location. Pushing
down on the handle locks the fence in position.
2. Position the fence on the right side of the table, and
along one edge of the miter gauge grooves.
3. Lock the fence handle. The fence should be parallel
with the miter gauge groove.
4. If adjustment is needed to make the fence parallel to
the groove, do the following:
●
Loosen the two screws (3) and lift up on the
handle (2).
●
Hold the fence bracket (4) fi rmly against the front
of the saw table. Move the far end of the fence
until it is parallel with the miter gauge groove.
●
Tighten both screws and push the handle to lock.
5. If fence is loose when the handle is in the locked
(downward) position, do the following:
●
Move the handle (2) upward and turn the adjusting
nut (5) clockwise until the rear clamp is snug. Do
not turn the adjusting screw more than 1/4 turn at
a time.
●
Over-tightening the adjusting screw will cause the
fence to come out of alignment.
Failure to properly align fence can cause “kickback” and
serious injury.
Fig.
Q
WARNING

!

14
RIP FENCE INDICATOR ADJUSTMENT (FIG. Q)
1. The rip fence indicator (6) points to the measurement
scale (8). The scale shows the distance from the side
of the fence to nearest side of the blade.
2. Measure the actual distance with a rule. If there is a
difference between the measurement and the indicator,
adjust the indicator (6).
3. Loosen the screw (7) and slide the indicator to the
correct measurement on the scale. Tighten the screw
and remeasure with the rule.
To avoid injury from an accidental start, make sure
the switch is in the OFF position and the plug is not
connected to the power source outlet.
WARNING

!
ADJUSTING THE 90° AND 45° POSITIVE STOPS
(FIG.Q-1, Q-2, Q-3)
Your saw has positive stops that will quickly position the
saw blade at 90° to the table. Make adjustments only if
necessary.
90° Stop
1. Disconnect the saw from the power source.
2. Turn the blade elevation handwheel and raise the
blade to the maximum elevation.
3. Loosen the blade bevel lock handle (2) and move the
blade to the maximum vertical position. Tighten the
lock handle (2).
4. Place a combination square on the table and against
the blade (1) to determine if the blade is 90° to the
table. (Fig. Q-2)
5. If the blade is not 90° to the table, loosen the two set
screws (4), located on the bottom of the table saw,
(Fig. Q-3) with the hex key, and back off the collar..
6. Loosen the bevel lock knob. Turn the blade tilting
handwheel to move the blade until it is 90° to the
table.
7. Adjust the collar (5) so it contacts the bracket (3)
when the blade is 90° to the table. Tighten the two
set screws (4).
Fig. Q-1
Fig. Q-2
45° Stop
1. With the blade in the upright 90° position, loosen
the bevel lock knob and move the blade to the 45°
position as far as it will go.
2. Place the combination square on the table as shown
in (Fig.Q-2) to check if the blade is 45° to the table.
3. If the blade is not 45° to the table, adjust the screw (4)
(Fig. Q-3) with a screw driver until the blade is 45° to
the table.
4. Tighten the bevel lock handle.
5. Tighten the screw (4) until resistance is felt. Do not
overtighten.
BLADE TILT POINTER
1. When the blade is positioned at 90°, adjust the blade
tilt pointer to read 0° on the scale.
2. Loosen the holding screw, position pointer over 0°
and tighten the screw.
NOTE:
Make a trial cut on scrap wood before making
critical cuts. Measure for exactness.
Fig. Q-3
1
3
90
°
45
°
4
5
3
3
4
5
2

15
BLADE PARALLEL TO THE MITER GAUGE GROOVE
(FIG. R,S)
This adjustment was made at the factory, but it should
be rechecked and adjusted if necessary.
WARNING

!
WARNING

!
To prevent personal injury:
●
Always disconnect plug from the power source
when making any adjustments.
●
This adjustment must be correct or kickback could
result in a serious injury and accurate cuts can not
be made.
1. Remove the yellow switch key and unplug the saw.
2. Move the blade guard out of the way.
3. Raise the blade to the highest position and set at the
0° angle (90° straight up).
4. Select and mark, with a felt tip marker, a blade tooth
having a “right set”.
5. Place the combination square base (1) into the right
side miter gauge groove (2). (Fig. R)
6. Adjust the rule so it touches the front marked tooth
and lock ruler so it holds its position in the square
assembly.
7. Rotate the blade bringing the marked tooth to the
rear and about 1/2 inch above the blade.
8. Carefully slide the combination square to the rear
until the ruler touches the marked tooth.
9. If the ruler touches the marked tooth at the front and
rear position, no adjustment is needed at this time. If
not, perform adjustment procedure described in next
section.
Fig. R
2
1
Additional blade adjustments (Fig. S)
The adjusting mechanism is located on top of blade
height adjusting hand wheel under the tabletop. If the
front and rear measurements are not the same, adjust
the alignment by the mechanism as follows:
If the blade is partial to right side:
1. Loosen the two nuts (1) and the right side screw ,
then adjust the left side screw .
2. Tighten the nuts (1) and the right screw and
remeasure, as described in steps 4 to 9 in the
prior section.
If the blade is partial to left side:
3. Loosen the two nuts (1) and the left side screw ,
then adjust the right screw .
4. Tighten the nuts (1) and the left screw and
remeasure, as described in steps 4 to 9 in the
prior section.
5. Recheck blade clearance making sure that the
blade does not hit the table insert or other parts
when at the 90° and 45° settings.
Fig. S
1

16
P
off
o
n
U
N
W
D
O
OPERATION
BASIC SAW OPERATIONS
RAISE THE BLADE (FIG. T)
To raise or lower the blade, turn the blade elevation
handwheel (1) to the desired blade height, and then
tighten lock handle (2) to maintain the desired blade
angle.
Fig. T
1
2
3
TILTING THE BLADE (FIG. T)
1. To tilt the saw blade for bevel cutting, loosen the
lock knob (2) and turn the tilting handwheel (3).
2. Tighten the lock knobs (2) to secure.
ON/OFF SWITCH (FIG. U)
The ON / OFF switch has a removal key. With the key
removed from the switch, unauthorized and hazardous
use by children and others is minimized.
1. To turn the saw ON, insert key (1) into the slot in
the switch (2). Move the switch upward to the ON
position.
2. To turn the saw OFF, move the switch downward.
3. To lock the switch in the OFF position, grasp the end
(or yellow part) of the switch toggle (1), and pull it
out.
4. With the switch key removed, the switch will not
operate.
5. If the switch key is removed while the saw is running,
it can be turned OFF but cannot be restarted without
inserting the switch key (1).
Fig. U
3
2
1
OVERLOAD PROTECTION (FIG. U)
This saw has an overload relay button (3) that resets
the motor after it shuts off due to overloading or low
voltage. If the motor stops during operation, turn the
ON / OFF switch to the OFF position. Wait about fi ve
minutes for the motor to cool. Push in on the reset
button (3) and turn the switch to the ON position.
WARNING

!
To avoid injury, the ON / OFF switch should be in the
OFF position and the plug removed from the power
source while the cool down takes place, to prevent
accidental starting when the reset button is pushed.
Overheating may be caused by misaligned parts or a
dull blade. Inspect your saw for proper setup before
using it again.
USING THE TABLE EXTENSION (FIG. V, V-1)
If the table extension is not parallel with the table.
Remove the bolts (1) and position the parallel washers
(2) between the table extension and tube until it is
parallel with the table, then tighten the bolts.
NOTE: Paeallel washer (2) see page 6 for table of loose
parts ITEM: W-2
Fig. V
NOTE:
Move and lock the fence to the 15” left or right
side scale. The fence is now clear of the table.
1. Release the extension lock handles.
2. Slide the extension out until the correct measurement
is displayed on the tube scale. The user sights the
scale off the edge of the table.
3. Tighten all extension lock handles.
Sears,RoebuckandCo.MADEINTAIWAN
SPECIFICATIONS
HeavyDutyUniversalMotor
120V,60Hz,15Amps,AC
5000RPM(No-loadSpeed)
Maximumcuttingdepth:
at90
0
....................3inches
at45
0
..............2-1/2inches
3.0
MAXIMUMDEVELOPEDHP
137.248880
104920HU
14 15 16
141516
Fig. V-1
1
2

17
RIPPING (FIG. W, X)
WARNING

!
To prevent serious injury:
●
Never use the miter gauge when ripping.
●
Never use more than one rip fence during a single
cut.
●
Do not allow familiarity or frequent use of your table
saw to cause careless mistakes. Remember that
even a careless fraction of a second is enough to
cause a severe injury.
●
Keep both hands away from the blade and path of
the blade.
●
The workpiece must have a straight edge against
the fence and must not be warped, twisted, or
bowed.
1. Remove the miter gauge. Secure the rip fence to
the table.
2. Raise the blade so it is about 1/8” higher than the
top of the workpiece.
3. Place the workpiece fl at on the table and against
the fence. Keep the workpiece about 1” away from
the blade.
4. Turn the saw ON and wait for the blade to come up
to speed.
5. Slowly feed the workpiece into the blade by
pushing forward only on the workpiece section (1)
that will pass between the blade and the fence.
(Fig. W)
WARNING

!
Before using the saw each and every time, check the
following:
1. Blade is tight on the arbor.
2. Bevel angle lock knob is tight.
3. If ripping, fence knob is tight and fence is
parallel to the miter gauge grooves.
4. Blade guard is in place and working properly.
5. Safety glasses are being worn.
The failure to adhere to these common safety rules,
and those printed in the front of this manual, can
greatly increase the likelihood of injury.
CUTTING OPERATIONS
There are two basic types of cuts: ripping and
crosscutting. Ripping is cutting along the length and the
grain of the workpiece. Crosscutting is cutting either
across the width or across the grain of the workpiece.
Neither ripping nor crosscutting may be done safely
freehand. Ripping requires the use of the rip fence, and
crosscutting requires the miter gauge.
WARNING

!
AVOID KICKBACK
by pushing forward on the section
of the workpiece that passes between the blade and the
fence.
Fig. W
NOTE
:
When width or rop is 2” to 6” wide use the push
stick to feed the work. When width of rop is narrower
than 2” the push stick cannot be used because the
guard will interfere… Use the auxiliary fence as
page 19.
6. Keep your thumbs off the table top. When both of
your thumbs touch the front edge of the table (2),
fi nish the cut with a push stick. Make a push stick
using the pattern on page 30.
7. The push stick (3) should always be used when the
ripped workpiece is 2” to 6” wide. (Fig. X)
8. Continue pushing the workpiece with the push stick
(3) until it passes the blade guard and clears the rear
of the table.
9. Never pull the piece back when the blade is turning.
Turn the switch OFF. When the blade completely
stops raise the anti-kickback pawls on each side of
the splitter and slide the workpiece out.
Fig.X
3
1
2
1

18
BEVEL RIPPING
This cut is the same as ripping except the blade bevel
angle is set to an angle other than “0”.
Cut only with the workpiece and the fence on the right
side of the blade.
RIPPING SMALL PIECES
Avoid injury from the blade contact. Never make through
saw cuts narrower than 1/2 in. wide.
1. It is unsafe to rip small pieces. Instead, rip a larger
piece to obtain the size of the desired piece.
2. When a small width is to be ripped, your hand cannot
be safely put between the blade and the rip fence,
therefore, use one or more push sticks to move the
workpiece.
CROSSCUTTING
(FIG. Y)
To prevent serious injury:
•
Do not allow familiarity or frequent use of your table
saw to cause careless mistakes. Remember that
even a careless fraction of a second is enough to
cause a severe injury.
•
Keep both hands away from the blade and the path
of the blade.
1. Remove the rip fence and place the miter gauge in
the left side groove.
2. Adjust the blade height so it is 1/8 in. higher than the
top of the workpiece.
3. Hold the workpiece fi rmly against the miter gauge
with the blade path in line with the desired cut
location. Keep the workpiece away from the blade.
4. Start the saw and wait for the blade (1) to come up to
full speed.
5. Keep the workpiece (2) against the face of the miter
gauge (3) and fl at against the face of the gauge and
fl at against the table. Then slowly push the workpiece
through the blade. (Fig. Y)
6. Do not try to pull the workpiece back with the blade
turning. Turn the switch OFF, and carefully slide the
workpiece out when the blade is completely stopped.
USING WOOD FACING ON THE MITER GAUGE
(Fig. DD)
Slots are provided in the miter gauge for attaching an
auxiliary facing (1) to make it easier to cut very long or
short pieces. Select a suitable piece of smooth wood,
drill two holes through it and attach it the miter gauge
face with screws. Make sure the facing does not
interfere with the proper operation of the sawblade
guard. When cutting long workpieces, you can make
a simple support by clamping a piece of plywood to a
sawhorse.
Fig. Y
Fig. Y-1
BEVEL CROSSCUTTING (FIG. Z)
This cutting operation is the same as crosscutting
except the blade is at bevel angle other than 0°.
1. Adjust the blade (1) to the desired angle, and tighten
the blade bevel lock knob.
Fig. Z
COMPOUND MITER CROSSCUTTING (FIG. AA)
This sawing operation is combining a miter angle with a
bevel angle.
1. Set the miter gauge (3) to the desired angle.
2. Place the miter gauge in the right side groove of
the table.
3. Set the blade (1) bevel to the desired bevel angle
and tighten the blade bevel lock knob.
4. Hold workpiece (2) fi rmly against the face of the miter
gauge throughout the cutting operation.
Fig. AA
WARNING
!
WARNING
!
WARNING
!
1
3
2
1
1
3
2
1
2
3

19
Make sure the screw heads do not stick out from the
bottom of the base, they must be fl ush or recessed. The
bottom must be fl at and smooth enough to rest on the
saw table without rocking.
Fig. CC-1
Fig. CC-1
WARNING
!
2
1
3
MITERING (FIG. BB)
This sawing operation is the same as crosscutting
except the miter gauge is locked at an angle other than
90°
1. Hold the workpiece (2) fi rmly against the miter
gauge (3).
2. Feed the workpiece slowly into the blade (1) to
prevent the workpiece from moving.
Fig. BB
USING WOOD FACING ON THE RIP FENCE
(FIG. CC)
When performing some special cutting operations, add
a wood facing (1) to either side of the rip fence (2).
1. Use a smooth straight 3/4 in. thick wood board (1)
that is as long as the rip fence.
2. Attach the wood facing to the fence with wood
screw (3) through the holes in the fence. A wood
fence should be used when ripping material such as
thin paneling to prevent the material from catching
between the bottom of the fence and the table.
Fig. CC
AUXILIARY FENCE (FIG. CC-1)
Making the base:
•
Start with a piece of 3/8 in. plywood at least 5-1/2 in.
wide or wider and 30” long or longer.
•
Cut the piece to shape and size shown:
Making the side:
•
Start with a piece of 3/4 in. plywood at least 2-3/8 in.
wide or wider and 27 in. long or longer/
•
Cut the piece to shape and size shown:
Putting it together:
•
Put the pieces together, as shown:
1
2
3
3
3
1
2
2
DADO CUTS (FIG. DD)
1. The dado table insert is included with this saw.
Remove saw blade, blade guard, installed dado, and
dado table insert.
2. Instruction for operating the dado is packed with the
separately purchased dado set.
3. The arbor (1) on this saw restricts the maximum
width of the cut to 1/2”.
4. It is not necessary to install the outside fl ange (2)
before screwing on the arbor nut (3). Make sure that
the arbor nut (3) is tight, and that at least one thread
of the arbor sticks out past the nut.
5. Use only the 6” dado set and keep the width 1/2” or
less. It will be necessary to remove the blade guard
and splitter when using a dado blade. Always use
caution when operating a dado blade.
6. Use only the correct number of round outside blades
and inside chippers as shown in the dado set’s
instruction manual. Blade or chipper must not exceed
1/2”.
7. Check saw to ensure that the dado will not strike the
housing, insert, or motor when in operation.
For your own safety, always replace the blade, blade
guard assembly, and blade insert when you are fi nished
with the dado operation.
fi nished with the dado operation. You must also realign
the blade guard assembly.
Fig. DD
WARNING
!

20
MAINTENANCE
MAINTAINING YOUR TABLE SAW
GENERAL MAINTENANCE
For your own safety, turn the switch OFF and remove
the switch key. Remove the plug from the power source
outlet before maintaining or lubricating your saw.
1. Clean out all sawdust that has accumulated inside
the saw cabinet and the motor.
2. Polish the saw table with an automotive wax to keep
it clean and to make it easier to slide the workpiece.
3. Clean cutting blades with pitch and gum remover.
4. A worn, cut, or damaged power cord should be
replaced immediately.
All electrical or mechanical repairs should be attempted
only by a trained repair technician. Contact the
nearest Service Center for service. Use only identical
replacement parts. Any other parts may create a hazard.
5. Use liquid dish washing detergent and water to clean
all plastic parts.
NOTE:
Certain cleaning chemicals can damage
plastic parts.
6. Avoid use of the following cleaning chemicals or
solvents; ammonia and household detergents
containing ammonia.
BLADE RAISING AND TILTING MECHANISM
(FIG. EE)
After each fi ve full hours of operation, the blade raising
mechanism and tilting mechanism should be checked
for looseness, binding, or other abnormalities. With the
saw disconnected from the power source, turn the saw
upside down and alternately pull upward and downward
on the motor unit. Observe any movement of the motor
mounting mechanism. Looseness or play in the blade
raising screw (1) (Fig. EE) should be adjusted as
follows:
1. Using a wrench, loosen the check-nut (2).
2. Adjust nut (3) until it is fi nger-tight against the bracket
(4), and then back off the nut (3) 1/6 turn.
3. Tighten nut (2) with the wrench, while holding nut (3)
in place. Maximum allowable play of the screw rod (1)
is 0.16 in. (4 mm).
Fig.
EE
Place a small amount of dry lubricant on bevel
gear (2). Srew rod (1) must be kept clean and free of
sawdust, gum, pitch, and other contaminants for smooth
operation.
If excessive looseness is observed in any parts of the
blade raising mechanism or tilting mechanism, take the
complete unit to a Service Center.
LUBRICATION
All motor bearings are permanently lubricated at the
factory and require no additional lubrication.
On all mechanical parts of your table saw where a pivot
or threaded rod are present, lubricate using graphite or
silicone. These dry lubricants will not hold sawdust as
would oil or grease.
WARNING

!
WARNING

!
1
2
3
4
