HD 39305 User manual

HD Rehab AB, Tryffelslingan 4, 181 57 Lidingö, Sweden
tel. [phone] [e-mail] www.hdrehab.se
MD
Thoracic support, Swing
Art. nr. 39305 / 39306 / 39317 / 39318 Doc. nr. 96807-1 Rev A 2020-10-15
User manual /
Assembly instructions
Page 1 (2)
Intended use
Thoracic support with Swing-away is intended to be used with a thoracic support mount from HD Rehab.
See the assembly instructions Thoracic support mount, document number 96808-1.
Parts included
Assembly
Insert the thoracic support in the thoracic support mount. When the support is at the desired position
tighten the knob rmly.
Fine adjustment of the vertical position is done by loosening the nuts (a) and sliding the mount up or
down in the slots.
1 x thoracic support, Swing (adjustable LH model shown)
a

Page 2 (2)
User manual/Assembly instructions - Thoracic support
Adjustment of position
To be done by a duly qualied person.
1. Put the thoracic support in the mount.
2. Ensure that the swing-away mechanism is in a locked position. Loosen the screws (d) slightly.
3. Turn the thoracic support cushion inward against the user's body.
4. Tighten the screws (d) rmly to lock the thoracic support in position.
5. Adjustable models: The cushion can be adjusted in depth. This is done with the set screw (c)
under the cover.
6. Adjustable models: The cushion can be formed by adjusting the angle. This is done with the
set screw (b) under the cover.
Use
Use the button (e) to release and swing away the thoracic support when necessary.
Note: The support should be relieved of pressure to make it easy to push the button.
Care instructions
Hard surfaces can be wiped clean with mild cleaner and water as needed. The cover can be washed per
the instructions which are sewn in.
Always replace damaged parts immediately. For more information see Maintenance Instructions,
document number 96730-1.
b
c
e
d
