HDanywhere DOLBY & DTS AV SIGNAL MANAGER User manual

DOLBY™& DTS®AV SIGNAL MANAGER
Product Guide (English UK)
CODE: DDSIGNALMANAGER
Revision 1: 05/09/19

Help is only an email away: [email protected].2
Contents
Content, In the box 2-3
Features, Specications 4-5
Panel description & diagram 6-7
Communicating over serial comms 8
Example applications 9
Conformity notice 10
Product Guarantee 11

3
In the box
x1 DOLBY™& DTS®AV Signal Manager
x1 5V/2A Multi-Territory Power Supply (Barrel Type)
x1 Mounting brackets
Name: DOLBY™& DTS®AV SIGNAL MANAGER
Product code: DDSIGNALMANAGER
The DOLBY™& DTS®AV Signal Manager (DDAV) is an audio down-mixer supporting Dolby® Digital/DTS® Stereo Audio Decoding. It can be used for bypassing bitstream
audio over HDMI and down-mixing to a secondary output which only support 2 channel stereo audio systems. The device can manage standard Dolby Digital & DTS formats
up to 7.1 and output the audio as stereo (LPCM 2.0) over HDMI & S/PDIF (optical and coaxial). Audio can also be set to be managed from ARC.

Help is only an email away: [email protected].4
FeaturesIMPORTANT:
Simultaneous down scaled 4K (+HDR) to 1080p and bypassed output
Down-mix audio in different formats: LPCM 7.1CH, DTS, DTS ES, AC3, DD+, Dolby
True HD
On-board EDID management
ARC routing and down-mix
Auto down scaling on all outputs
Control over serial
Informative LED indicators
For optimum performance and safety, please read these instructions carefully
before connecting and operating this product. Please keep this manual for future
reference.
To reduce the risk of re, electric shock or product damage refer to the statements
below.
EXPOSURE TO LIQUIDS
Do not expose this device to rain, moisture, dripping or splashing and ensure
that objects lled with liquids are not placed on or near the devices.
ENSURE DEVICE IS WELL VENTILATED AND NOT NEAR ANY HEAT SOURCES
Do not install or place this unit in a bookcase, built-in cabinet or in another conned
non-ventilated space. Ensure that device vents are not covered and do not install
near any heat sources or naked flames.
CLEANING
Clean the device with a dry cloth only.

5
Specication
HDMI version HDMI 2.0 (a/b)
HDCP compliance HDCP 2.2
Video bandwidth 18Gbps and above (using ICT)
Video resolution Up to 4K@60Hz (4:4:4) with HDR
Up to DCI 4K (4096x2160)
Colour space RGB, YCbCr 4:4:4, YUV 4:4:4, YCbCr 4:2:2/4:2:0
Colour depth 8-bit, 10-bit, 12-bit (1080p@60Hz)
8-bit (4K@60Hz)
HDR formats HDR10, HDR10+, Dolby Vision, HLG
Video & audio IO Inputs: x1 HDMI Outputs: x2 HDMI , x1 L/R Stereo Phono (unbal-
anced), x1 Phono RCA, x1 Optical Toslink
Transmission distance Dependent on HDMI cable
HDMI audio formats PCM2.0, LPCM 5.1/7.1, Dolby Atmos, Dolby Digital/ Plus, Dolby TrueHD, DTS 5.1, DTS-HD Master Audio,
DTS-X
Downmixed audio formats PCM2.0, LPCM 5.1/7.1, Dolby Digital/Plus, Dolby
TrueHD, DTS 5.1, DTS-HD Master Audio, DTS-X
Stereo audio formats PCM 2.0 44.1 / 48 / 88.2 / 96 / 176.4 / 192KHz,
16/20/24bit
Power consumption 6W (Maximum)
Power supply Chassis:
5V/2A Multi-Territory PSU
Operating temperature -5°C - 51°C / 23°F - 125°F
Storage temperature -20°C - 60°C / -4°F - 140°F
Relative humidity 5 - 90% (Non-condensing)
Housing Aluminium Enclosure
Colour Grey (Carbonite)
Dimensions (W/D/H) mm
Unit
129 x 92 x 12
Package
203 x 165 x 91
Weight
Unit
136g
Package
900g

Help is only an email away: [email protected].6
1. HDMI (IN): HDMI video input port.
2. HDMI (OUT): HDMI video output ports. Port A & B serve different purposes:
HDMI (OUT) A
Can down-scale video. ARC is not supported.
HDMI (OUT) B
Can not down-scale video. ARC is supported.
3. Audio (OUT): Extracted audio will output from these ports. The audio will
always mirror whatever is being fed from HDMI (IN) and will always output 2
channel stereo.
4. Settings: Dip switch controls to adjust the behaviour of the device.
OFF ON
1HDMI (OUT) A audio bypass bitstream HDMI (OUT) A down-mix audio 2Ch stereo
2HDMI (OUT) B audio bypass bitstream HDMI (OUT) B down-mix audio 2Ch stereo
3Read/Use EDID from HDMI (OUT) B Use standard 4K 2Ch EDID prole
4Disable downscaling Enable downscaling
5. Service: Micro USB port for service and communicating with the device. To
connect, please page 12.
6. DC5V: Power inlet. Connect the supplied power lead to this port to provide
power to the device.
Panel description
A. Audio Type: Indicator light. Denotes what audio format is being detected and
decoded: PCM, DTS or Dolby.
B. HDMI Status: Indicator light detailing which HDMI ports are active or
connected. The light has 3 operational modes which denote the following:
- Solid
Connected correctly.
- Flashing during connection
Device is syncing
- Flashing continuously
There is a problem between HDMI device and unit. A picture may not be shown
on the display, for example. In the event that this occurs, check the following 1)
the source, by connecting it directly to the display to ensure that it is working
properly 2) try using a longer HDMI cable as shorter ones may not sync correctly
3) Set EDID position to #1.
- Off
Unable to detect a HDMI connection. Check HDMI cable and ensure all devices
are powered on.
C. ARC: Indicator light. Denotes if ARC is active or not.
- Solid
ARC audio is being extracted from HDMI (OUT) B.
- Off
Audio is being extracted from HDMI (IN) port. This is the default mode.
D. Audio Select: A single press will toggle between the modes described by the
ARC indicator light.

HDMI (OUT) Audio (OUT) Settings Service DC5VHDMI (IN)
PCM DTS DOLBY 1 ARC
Notice: For DTS patents, see http://patents.dts.com
Audio Select
A B
7
Panel diagram
REAR
FRONT
TOP
A B C
D
1 4
4
5 62 3

Help is only an email away: [email protected].8
Serial communication over USB
It is possible to communicate with the device over serial. This is achieved by using
a USB with a micro USB connector. Serial to USB is managed internally and the
driver (universal CH340 on Windows Operating System) should automatically
install once connected.
The HDMI (OUT) ports A and B on the device casing are addressed using numbers
1 and 2 when using serial comms.
H Help
STA System status
SET RST Reset to factory defaults
SET ADDR [XX] Set device address to XX (00-99) 00=Single
SET ARC ON/OFF Enable or disable ARC
GET ADDR Get device address
GET ARC Get ARC status
GET STA Get device status
GET IN1 SIG STA Get input & signal status from HDMI (IN) port
SET OUT[X] EXA EN/DIS Set extracted audio output to enabled or disabled (X=0, 0=ALL)
SET OUT[X] STREAM ON/OFF Set output [X] stream on/off (X=0-2, 0=ALL)
GET OUT[X] EXA Get status of extracted audio output enabled or disabled (X=0, 0=ALL)
GET OUT[X] EDID DATA Get output [X] EDID data (X=0-2)
GET OUT[X] STREAM Get output [X] stream on/off status (x=0-2, 0=ALL)
Serial settings:
Baud rate: 57600
Bit number: 8
Checksum/Flow/Parity: None
Stop bits: 1

9
In diagram (A) an 18Gbps source outputting a digital audio format such as Dolby
Digital or DTS is fed in to the input port on the Dolby Digital Down-Mixer. The audio
is down-mixed to 2Ch stereo internally and extracted from the analogue audio
ports which then is fed to an audio distribution amplier or MHUB AUDIO (6x4)
for distribution around a property. Simultaneously, the AVR receives an untouched
HDMI signal and output whatever the source device is sending.
In diagram (B) the source content is being provided by a video distribution system
like MHUB PRO (4x4) 40, here, it is presumed that all outputs from MHUB are
delivering 5.1 audio. This is being fed in to and passed through the Dolby Digital
Down-Mixer to the display. Using ARC it is now possible to extract the 5.1 audio
back to the Dolby Digital Down-Mixer and route it to a local AVR using the Toslink
port.
Example applications
HUBCONTROL
AUDIODIGITAL (IN)
1 2 3 4
AUX1 AUX2
sub/ SLAVE (out)
AUDIOANALOGUE (IN)
IP
hubir (IN) MHUB LINK
A
A B
C D
2X55W/4Ω
(-R +) (-L +)
B
(-R +) (-L +)
C
(-R +) (-L +)
D
(-R +) (-L +)
100-240VAC 50/60HZ
AVR
AVR
SOURCEINPUT
1 2 3 4 HDBASET
RS232 DIGITAL STEREO
HDMI HDBASET
RS232 DIGITAL STEREO
HDMI HDBASET
RS232 DIGITAL STEREO
HDMI HDBASET
RS232 DIGITAL STEREO
HDMI
1 2 3 4
aMPIR (OUT)SOURCEIR (OUT)
A B C D
allIR (IN)
DISPLAYIR (IN)hubir (IN) A B C D
IP
RS232
HUBCONTROL LAN
DISPLAY
ARC
HDMI Cable
Audio Cable
18Gbps Source
with Dolby Digital / DTS Audio Video distribution source
Outputting 5.1 to all zones
Audio extracted from display using ARC
5.1 ARC audio sent to local AVR
18Gbps Source
with Dolby Digital / DTS Audio
Down-mixed 2Ch Stereo outputDolby Digital / DTS Audio
Audio distribution amplier or
MHUB AUDIO (6x4)
DIAGRAM (A) DIAGRAM (B)

Help is only an email away: [email protected].10
Terms & Policies, including General Data Protection Regulation (GDPR) and other Data Protection Laws.
During the setup of MHUB, the HDA Pro (Installer) and End-User are required to agree to a set of terms, conditions, rules, policies and license agreements, including the
HDANYWHERE Privacy Policy. These terms, notices and policies are, collectively, the “Agreements”. By installing or using MHUB, you agree to be bound by the Agreements.
EU Conformity
Hereby, HDANYWHERE declares that this HDMI connectivity device is in compliance with the essential requirements and other relevant provisions of the following Directives:
2006/95/EC (LVD Directive); 2004/108/EC (EMC Directive); 1999/5/EC (R&TTE Directive). The full text of the EU declaration of conformity is available in the compliance
section at HDANYWHERE.com/legals
Recycling your device properly
In some areas, the disposal of certain electronic devices is regulated. Make sure you dispose of or recycle your device in accordance with your local laws and regulations.
Important information

11
WHO WE ARE
1. We are HD CONNECTIVITY LTD trading as HDANYWHERE (“HDA”), a limited company registered under number
06046737 in England and Wales with its registered ofces at The Hayseld, Malvern, WR14 1GF, United Kingdom.
OUR GUARANTEE TO YOU
2. We, HDANYWHERE warrant to you, the end user [MG1] of the HDA hardware (the “Products”) that on the date of
delivery of the Products to you, and for a period of 3 years from that date of delivery, the Products shall:
(a) match any description that has been provided to you;
(b) be free from any signicant defects in their design, the materials used to make them, and the way they are
made;
(c) be of satisfactory quality (within the meaning of the Consumer Rights Act 2015); and
(d) be t for any purpose held out by us.
This 3 year period, or, if the period has been extending to 4 years in accordance with paragraph 3, will be the
“Guarantee Period”. We offer this guarantee to all our customers who are resident and have an address in Great
Britain and Northern Ireland. [MG2]
EXTENDING YOUR GUARANTEE
3. On registering your Products with the HDA Cloud, the guarantee offered in paragraph 2 by us will automatically
extend for a period of one year, provided that your registration takes place within 30 days from the date of delivery.
The one year guarantee extension starts automatically from the date that the original 3 year guarantee ends.
HOW TO CLAIM ON YOUR GUARANTEE AND YOUR REMEDIES
4. Subject to paragraphs 5 and 6 of this guarantee, Your sole remedies under Our guarantee to You are as follows:
(i)Up to 30 days: we will repair or replace your Products or provide you with a full refund of the price of the defective
Products at your option.
(ii) Up to 6 Months: we will repair or replace your Products. If we are unable to repair or replace your Products we
will provide you with a full refund of the price of the defective Products.
(iii) Up to 3 (4) Years: we will repair or replace your Products. If we are unable to repair or replace your Products
we will provide you with a partial refund of the price of the defective Products based upon the devaluation of the
Products since the time of purchase.
5. In order to claim under the guarantee given to you in paragraph 2 you will need to:
(a) give us notice in writing of your intention to claim under the guarantee during the Guarantee Period, and do
so within a reasonable time after nding that some or all of the Products do not comply with the guarantee set out
in paragraph 2;
(b) show that the Products that you claim are defective, have been examined by a HDA Pro or other authorised or
suitably qualied installer, and that they have[MG3] conrmed in writing that the suspected defect in the Products
stems solely from a fault in the HDA hardware;
(c) give us a reasonable opportunity to examine the Products in question;
(d) provide us with an order number and a dated sales or delivery receipt from an HDA Distributor, HDA Pro or other
authorised dealer, reseller or installer of the Products.
(e) obtain from us in advance of returning the Products a return merchandise authorisation and/or case
number[MG4] ; and
(f) (if asked to do so by us) return such Products to our place of business at our cost.
CIRCUMSTANCES WHERE YOUR GUARANTEE DOESN’T APPLY
6. We shall not be liable for the Products’ failure to comply with the guarantee set out in paragraph 2 in any of the
following events:
(a) If you make any further use of the Products after giving us notice of an issue in accordance with paragraph 5;
(b) the defect arises because you failed to follow our oral or written instructions as to the storage, installation[MG5]
, use and maintenance of the Products;
HDANYWHERE Limited Product (2 Year) Guarantee
(c) the defect arises as a result of your use of the Products with any other software or hardware that is not
compatible with the Products;
(d) the products are used by you for any commercial purpose, including rental or demonstrative purposes;
(e) you alter or repair the Products without the written consent of HDA;
(f) the defect arises as a result of an act of god, fair wear and tear, or your misuse, abuse, unreasonable use, wilful
damage, negligence, or abnormal storage of the Products or by any other causes unrelated to defective hardware
or manufacturing;
(g) where the serial number has been altered, defaced or removed;
(h) where the warranty seal on the system has been altered, defaced or removed; or
(i) where the Products differ from their description as a result of changes made to ensure they comply with
applicable statutory or regulatory requirements.
TRANSFERRING YOUR GUARANTEE TO SOMEONE ELSE
7. [HDA will not accept any liability under such guarantee unless you are the original customer or can produce a
letter or chain of letters from the original customer and subsequent customers (where appropriate) transferring the
benet of the guarantee to you.]
PRODUCTS THAT ARE NOT COVERED BY THIS GUARANTEE
8. This guarantee does not cover products sold and clearly marked “as is”, “B-grade”, or with faults. This guarantee
does not apply to any system software that is preinstalled in the HDA hardware, or is subsequently provided via
update or upgrade releases. Any and all HDA software is licensed to you under the terms of a separate end user
licence agreement found here: [EULA Link]
HOW THIS GUARANTEE WORKS WITH OUR EULA
9. We may void this guarantee if we reasonably believe that the HDA system has been used in a manner that
violates terms of our separate End User Licence Agreement (EULA) for the HDA software. You assume all-risk and
liabilities associated with the use of third party products in conjunction with the Products.
YOUR STATUTORY RIGHTS
10. This guarantees is in addition to your statutory rights (including under the Consumer Rights Act) which are not
affected by this guarantee
GENERAL TERMS OF THIS GUARANTEE
11. Except as provided in this guarantee, we shall have no liability to you in respect of the Products’ failure to
comply with the guarantee set out in paragraph 2.
12. We reserve the right to amend or withdraw this guarantee at any time although for the avoidance of doubt any
guarantees that are in existence at such a time will be honoured.
13. These Conditions shall apply to any repaired or replacement Product supplied by us.
GUARANTEE CONTACT INFORMATION
To contact (suppor[email protected]) or call HDANYWHERE Technical Support (call charges will depend on your
telephone provider. Please check with your operator for exact charges).
The team is available 9am - 5pm weekdays.
To help us handle your query promptly, please have your invoice number and model SKU and serial ready.

Let us know what you think.
We would love to hear how we could further improve our products and services.
If we can make something better, please let us know!
[email protected]
Copyright © HDANYWHERE.
HDANYWHERETM is a trading name of HD Connectivity Ltd.
Registered in England & Wales 06046737 VAT 913222367
HDANYWHERE assumes no responsibility for any inaccuracies that may be contained in this document. In no event
will HDANYWHERE be liable for direct, indirect, special, incidental, or consequential damages resulting from any
defect or omission in this document, even if advised of the possibility of such damages.
