HDCVT TECHNOLOGY HBT-B100 User manual

1/11

2/11

3/11
The 18Gbps HDMI Extender is a tool which can extend your HDMI signal over
328fts/100meters to a compatible display. It is designed to convert HDMI signal
to standard HDBaseT signal which can be transmitted by LAN cable. It also
supports Transfer Bidirectional Infrared control signal together with the HDMI
signal, so you can control the Source in the Sink side which is 328fts outside,
also you can control the Sink in the Source side which is 328fts outside by using
the HDMI Extender.
Transfer Bidirectional Ethernet signal together with the HDMI signal.

4/11
※ See the description 4.
Transmission distance: ※Over CAT6 cable
100 meters: 1080P @60Hz36bit; 3D1080P@30Hz36bit;
70 meters: 1080P @60Hz@48bit; 1080P @120Hz@24bit;
3D1080P@60Hz@36bit; 4K x 2K@30Hz@24bit.
4K2K@50/60Hz (YUV420), 4K2K@50/60Hz (YUV444)

5/11
Transmitter :1x HDMI Type A [19-pin female]
1x IR INPUT [3.5mm Stereo Mini-jack]
1x RS232 [Phoenix jack]
1x Service [Mini-USB jack]
1x Ethernet In/Out[RJ45]
Receiver: 1x HDBaseT In [RJ45]
1x Ethernet In/Out[RJ45]
1x IR INPUT [3.5mm Stereo Mini-jack]
1x RS232 [Phoenix jack]
1x Service [Mini-USB jack]
Transmitter : 1x HDBaseT Out [RJ45]
1x IR OUTPUT [3.5mm Stereo Mini-jack]
Receiver : 1x HDMI Type A [19-pin female]
1x IR INPUT [3.5mm Stereo Mini-jack]

6/11

7/11

11/11
