HDL MAIR-Q/H.10 User manual

MAIR-Q/H.10
AirKit Air Quality Sensor
User Manual
Version: V1.0.6
Published on Oct. 16, 2020

AirKit Air Quality Sensor User Manual Overview
Overview
MAIR-Q/H.10 AirKit Air Quality Sensor is a comprehensive index of intelligent air monitoring
instrument, which can monitor the air PM2.5 concentration, temperature, humidity, carbon
dioxide (CO2), TVOC, etc..
Remote data viewing and intelligent management can be performed through the HDL ON
mobile application. The sensor adopts RS-485 communication interface and integrates the
internationally accepted ModBus RTU protocol, which is convenient for users to quickly
integrate into existing systems.

Technical Data
Technical Data
General specification
AC power supply 180-240V
DC power supply 7-32V
Working current ≤250mA
Communication
interface RS-485
Installation
Ceiling mounting,
Wall mounting,
US/EU wall box
Dimensions 134×134×35 (mm)
TVOC sensor
Range 0.22-9.99mg/m³
Resolution 0.01mg/m³
PM2.5 parameter
Theory Laser scattering
Range 0~999μg/m³
Accuracy ±15%
Response time ≤5s
CO2 sensor
Theory Infrared
Range 0-9999ppm
Accuracy ±40ppm±3%
Resolution 1ppm
Temperature sensor
Range - 40℃~125℃
Accuracy ±0.3℃
Humidity sensor
Range 0-100%RH
Accuracy ±3%RH
AirKit Air Quality Sensor User Manual

Installation
Installation position
Installation method
This product is mainly point-mounted and only needs to be installed on the roof or wall of
the area of interest.
Since the air flow is constant, the parameters across regions are relatively close. If there are
specific or rigorous requirements, the sensor can be installed separately in each section.
The sensor can be installed in the standard 86 wall box, US standard wall box or directly
fixed on the roof or wall with screws.
Before installation, you need to wire (see "Wiring" for details) and leave a middle circle hole,
and then reinforce the connection with the matching screws. The installation steps are as
follows:
1. Fix the mounting plate on the wall with the fixing clip outward.
2. After connecting the device, fix the sensor on the mounting plate and rotate it clockwise
to lock.
Note: Please install the device in the direction shown by the arrow on the back of the de-
vice.
AirKit Air Quality Sensor User Manual
Mounting position Mounting plate Back of the device
Installing
screw hole Fixing clip Arrow up

Wiring
Wiring
1. The sensor is connected to the RS232/RS485 Gateway (Model: HDL-MRS232U.431,
Hardware Version: Timer) through the Modbus485 interface, please use them in conjunc-
tion.
2. There are two power interfaces on the product: DC (recommended) and AC power inter-
faces. Please ensure correct cable connection.
3. Follow the interface instructions on the back of the device for wiring.
AirKit Air Quality Sensor User Manual
RS232/RS485 Gateway
(Hardware Version: Timer)
1 Port Programming
Gateway
Power supply module
DC 24V or
AC 220V
485 cable
Buspro cable
Power cable

Device address setting
Device address setting
An AirKit Air Quality Sensor can only be used in conjunction with an RS232/RS485 Gate-
way (Hardware Version: Timer).
The sensor needs to be dialed as shown in the figure below, namely:
Position 5 is dialed to the top, and the rest positions are dialed to the bottom.
AirKit Air Quality Sensor User Manual
Address dial switch

Display light indication
Display light indication
This sensor is equipped with a circular indicator light in the middle of the front device, and
the corresponding relationship between the device status and the indicator status is as
follows:
Configuration status: flashing in blue every 1 second
Detecting air quality: rotating
Sleep status: breathing light
Note: When the device is in sleep mode, short press the central button to perform detection,
and short press again to enter sleep mode and turn off the indicator light.
The color of the indicator light changes with the air quality, and the corresponding relation-
ship between both of them is shown in the figure below:
Air Quality Excellent
Air Quality Good
Air Quality Poor
AirKit Air Quality Sensor User Manual

Registration in HDL ON, gateway MAC binding
HDL ON operation - Registration in HDL ON, gateway
MAC binding
1.Open the HDL ON App and enter the login interface. Click the Register button to enter the
registration interface, and register by email or mobile number.
2. After completing the HDL ON account registration, you need to bind the MAC address of
the HDL intelligent system gateway (take 1 Port Programming Gateway as an example). In
"Setting" interface→ click "Residence list" to enter the house editing page. Click "Add new
residence" at the bottom to fill in the residence name and MAC of the gateway, and then
save.
AirKit Air Quality Sensor User Manual

Project creation
HDL Buspro Setup Tool operation - Project creation
Open the HDL Buspro Setup Tool software, click "Function" in the menu bar → select "HDL
ON/Xiaobai/5.7" in the drop-down box to open the project management interface and create a
new project.
AirKit Air Quality Sensor User Manual

Add room, device
AirKit Air Quality Sensor User Manual
HDL Buspro Setup Tool operation - Add room, device
1. Click "Room" to add a room, select the room, and click "Add device".
2. Select the temperature, humidity, TVOC, PM2.5 and CO2parameters of the sensor.

Parameter settingAirKit Air Quality Sensor User Manual
HDL Buspro Setup Tool operation - Parameter setting
1. Set the subnet ID, device ID and channel number of temperature, humidity, TVOC, PM2.5
and CO2sensor respectively.
2. Fill in the subnet number and device number of the RS232/RS485 Gateway that the AirKit
sensor is connected to. Fill in the channel number with 1 for parameters such as temperature,
humidity, TVOC, PM2.5 and CO2.

Data upload
AirKit Air Quality Sensor User Manual
HDL Buspro Setup Tool operation - Data upload
In the upload window, select "HDL ON/5.7" and click "Find ON" to search for HDL ON in the
LAN to obtain its IP address and HDL ON account. After obtaining the IP address and HDL
ON account, click "Upload" to upload the HDL ON project data to HDL ON.

View overview of device monitoring data
HDL ON operation - View overview of device monitoring data
1. In HDL ON, click "Functions" → "Environment Monitor" in order, and select the room
name, you can view the real-time monitoring data of the selected items presented in a circle.
If the number of selected monitoring items is not less than 1, you can view the reference
data of different items by sliding left and right below.
2. Click on the circle to view the historical data of the project, which can be filtered in "this
year", "this month", "today", and "recent 7 days".
AirKit Air Quality Sensor User Manual

Search device/change enable function
HDL Buspro Setup Tool operation - Search device/change
enable function
1. After the device is correctly connected, click "Quick Search" in the HDL Buspro Setup
Tool, and you can find 1 Port Programming Gateway and AirKit Air Quality Sensor.
2. Double-click the "Model" or "Description" of the AirKit Air Quality Sensor to open the
configuration interface.
3. In the "Analog Broadcast Enable" configuration interface, check the monitoring
items that need to be enabled and click "Save".
AirKit Air Quality Sensor User Manual

Push enable function
HDL Buspro Setup Tool operation - Push enable function
The condition for receiving the push on the mobile phone must be that the push function is
enabled in the HDL Buspro Setup Tool and HDL ON mobile application.
1. Click the "Remark and Range" tab in the configuration interface.
2. Select the monitoring items that need to be pushed in "Choose Type".
3. Check the level that needs to be pushed in the "Push Enable" column below, fill in the
subnet ID and device ID of the 1 Port Programming Gateway, and click "Save".
Note: If the push broadcast function is required, both the push subnet ID and device ID
should be filled in 255.
AirKit Air Quality Sensor User Manual

Automation configuration
HDL Buspro Setup Tool operation - Automation configuration
1. Click the "Automation" tab in the configuration interface.
2. Click the "+" on the left to add a new trigger condition.
3. Select the trigger condition in the condition list on the left, configure the device that needs
to be executed automatically on the right, and click "Save" when finished.
AirKit Air Quality Sensor User Manual

Automation running time configuration
HDL Buspro Setup Tool operation - Automation running time configuration
1. In the configuration interface, click the "Automation running time" tab.
2. The trigger condition can be selected on the left, and the automation running time can be
selected or customized on the right.
Examples are as follows:
If the input condition of a certain automation is "CO2fresh air", the output is "Light 1 on".
A. If the cycle period is "executes only once", the automation will only be triggered once
within the cycle time. Even if the Light 1 is off and the input conditions are met, the Light 1
will not be turned on again.
B. If the cycle period is "not repeat", the Light 1 will not turn on whenever the trigger condi-
tion is met.
C. If the cycle period is other than the conditions described in A and B, then within the cycle
time, when the Light 1 is not turned on, as long as the trigger condition is met, the Light 1
will be turned on.
AirKit Air Quality Sensor User Manual

Notes, Technical support
Notes
1. The sensor is wall-mounted, please pay attention to the back of the product and keep the
arrow pointing upwards for installation.
2. The power wiring terminal is suitable for AC180-240V, DC7-32V(recommended), exceed-
ing the specified range or connecting the wrong terminal will permanently damage the de-
vice.
3. There will be a slight motor noise during the PM2.5 detection process of the device. This
is a normal phenomenon and will not cause noise interference.
4. This product is only suitable for indoor use, please do not place this product in an outdoor
environment.
5. Do not use this product in an environment with extreme temperature and humidity.
6. Do not use this product in a severely dust-polluted environment for a long time to avoid
errors in the monitoring results.
7. Do not subject the product to severe impact and vibration (such as falling from a height).
Therefore, after installation, please make sure that the product has no risk of falling.
8. Please do not privately disassemble the device or change components, otherwise it may
cause mechanical failure, electric shock, fire or body injury.
9. Please resort to our customer service department or designated agencies for mainte-
nance service. The warranty is not applicable for the product fault caused by private disas-
sembly.
E-mail: [e-mail]
Website: https://www.hdlautomation.com
AirKit Air Quality Sensor User Manual
Package contents
AirKit Air Quality Sensor*1 / Mounting plate*1 / Screw*4 / User manual*1
Technical support

©Copyright by HDL Automation Co., Ltd. All rights reserved.
Specifications subject to change without notice.
