HEART HA6008 User manual

Fast User Guide for Electronic Cabinet Lock -HA6008
The HA6008 is an electronic cabinet lock which is
powered by 2 AAA 1.5V alkaline batteries.
It can be unlocked with user codes or RFID user cards,
also with mechanical keys in case of emergency.
Only one master – master code or master card, factory
master setting is under master code “22446688” which
is the factory user code, too.

Master Code
To manage of user codes, master card, user cards and
working modes. The digit of master code can be any
4~10 digits.
Master Card
Created by master code and same function as master
code.
User Code (Max. 100 Codes)
Used to unlock the HA6008. It can be any 4~10 digits.
User Card (Max. 100 Cards)
Used to unlock the HA6008.
Open with User Code
1. Press the user code one by one via keypad;
2. Confirm it with , until “beep” sounds and
green LED lights;
3. While LED green lights, turn lock knob to move cam
90°, then open door.
Open with User Card
1. Present the user card in front of reader range until
“beep” sounds and green LED lights;
2. While LED green lights, turn lock knob to move cam
90°, then open door.
Remark: the door must be closed manually– turn lock
knob and move back cam to close position.
HA6008 has 2 working mode, default working mode or
security working mode.
Default Working Mode:
open with user code or user card.
Security Working Mode:
open with user code and user card
Red LED
Green LED
Delete/Cancel Button
Unlock Button
Start Position Mark
Lock Knob
Cylinder Cover
RFID Key Card
Reading Range
PIN Code Keypad
Buzzer Indicator
(Invisible)
Cam
Security Working Mode:
open with user code and user card
How to reset to factory setting (Method A or B)
A.
B. Take a battery out and press button 1 or 2 with holding,
then put the battery in until hear sounds with 1 short
beep tone and 1 long beep tone. After 2 seconds, hear
another 1 short beep tone then LED green and red flash
alternative. By end it is successful to back factory
setting.
Anti-peep Function
Successful to open if the last 15 input digital numbers
included a string valid user code.
Example: 12345 is valid user code. You can input the below
code to open the door: 11009123452372361.

Master Code/Master Card and User Codes/User Cards Management
Function Operation
Factory Master Code
Factory User Code
Changemaster code
Addmaster card
Adduser code …
…
Adduser card …
…
Deletean user code …
…
Reset ECL208S
Delete all key cards
Delete all user codes
Delete all user codes
and all key cards
Set Default Mode
Set Security Mode

FCC STATEMENT:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
