EXPEDITION II AUSTRALIAN
WOOD INSERT
AUTOMATIC COMBUSTION
CONTROL (ACC)
MODEL NUMBER:
EXPEDITIONII-AU
Installation Manual
Installation & Appliance Set-Up
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
• Do not store or use gasoline or other ammable
vapors and liquids in the vicinity of this or any
other appliance.
• Do not over re - If appliance or chimney connector
glows, you are over ring. Over ring will void
your warranty.
• Comply with all minimum clearances to combustibles
as specied.
Failure to comply may cause house re.
If the information in these instructions is
not followed exactly, a re could result
causing property damage, personal injury,
or death.
WARNING
!
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass and appliance will cause burns.
• Do not touch glass until it is cooled
• Use leather gloves when reloading fuel
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room
as appliance.
• Alert children and adults to hazards of high
temperatures
• High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other
ammable materials away.
WARNING
!
Fire Risk.
For use with solid wood fuel only.
Other fuels may over re and generate
poisonous gases (i.e. carbon monoxide).
WARNING
!

7095-8182 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
1 Important Safety Information
A. Insert Certication ............................ 3
B. BTU & E󰀩ciency Specications .................. 3
C. Glass Specications........................... 3
D. Non-Combustible Materials . . . . . . . . . . . . . . . . . . . . . 3
E. Combustible Materials . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Getting Started
A. Design and Installation Considerations ............ 4
B. Fire Safety .................................. 4
C. Negative Pressure ............................ 5
D. Tools And Supplies Needed..................... 5
E. Inspection of Appliance and Components .......... 5
F. Install Checklist............................... 6
3 Dimensions and Clearances
A. Appliance Dimensions ......................... 7
B. Clearances to Combustibles .................... 9
4 Chimney Systems
A. Locating Your Appliance & Chimney ............. 12
B. Minimum Height of Flue System Exit ............. 13
C. Chimney Termination Requirements ............. 13
D. Venting Systems ............................ 14
E. Inspections................................. 14
F. Larger Chimneys ............................ 14
G. Masonry Chimney ........................... 15
H. Install into a Masonry Fireplace ................. 16
I. Install Into a Factory Built Fireplace .............. 16
J. Securing Chimney Components................. 16
K. Altering the Fireplace ......................... 16
L. Zero-Clearance Fireplace...................... 17
M. Ovalizing Round Stainless Steel Liners........... 17
N. Chimney Height / Rise and Run................. 17
5 Appliance Set-Up
A. Outside Air Kit .............................. 18
B. Stove Pipe or Liner to Flue Collar ............... 19
C. Optional O󰀨set Adapter ....................... 19
D. Power Cord ................................ 19
E. Appliance to Stove Pipe or Liner ................ 19
F. Flat Surround ............................... 20
G. Flat Surround with Trim Kit .................... 21
H. Standard Surround & Cast Trim Kit . . . . . . . . . . . . . . 22
6 Reference Materials
A. Service and Maintenance Log . . . . . . . . . . . . . . . . . . 23
B. Service Parts List ............................ 25
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
!
 = Contains updated information


7095-8183 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
Model: EXPEDITIONII-AU
Laboratory: ASFT
Report No: ASFT20046
Type: Hardwood only at 25% dry basis
Standard: AS/NZS4013 for Hardwood
The Quadra-Fire Expedition II Australian Wood Insert is Hardwood Certied. Hardwood Particulate Emissions equaling 1.3
g/kg with a Space Heating E󰀩ciency of 61%.
This wood appliance needs periodic inspection and repair for proper operation. It is against federal regulations to operate
this wood appliance in a manner inconsistent with operating instructions in this manual.
Overall Average E󰀩ciency
Burning Hardwood (AS/NZS 4014) 61%
Average Particulate Emission
Factor Burning Hardwood (AS/
NZS 4014)
1.3 g/kg
Maximum Average Heat Output
Burning Hardwood 8.5 kW
Wetback
Wetbacks are
NOT an approved
option and must
not be tted.
Vent Size: 6 inches
Firebox Size: 56.65 Litres
Recommended Wood Length: 457 mm
Fuel Orientation: Side to Side
Approved Fuel
Hardwood only
with a Moisture
content less than
25% (dry basis)
A. Insert Certication
B. BTU & E󰀩ciency Specications
C. Glass Specications
This appliance is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please contact
your dealer for replacement glass.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
For assistance or additional information, consult a qualied
installer, service agency or your dealer.
D. Non-Combustible Materials
Material which will not ignite and burn, composed of any
combination of the following:
- Steel
- Plaster
- Brick
- Iron
- Concrete
- Tile
- Glass
- Slate
E. Combustible Materials
Material made of/or surfaced with any of the following
materials:
- Wood
- Compressed Paper
- Plant Fibers
- Plastic
- Plywood/OSB
- Sheet Rock (drywall)
Any material that can ignite and burn: ame proofed or not,
plastered or non-plastered.
11 Important Safety Information
Hearth & Home Technologies WILL NOT warranty
appliances that exhibit evidence of over ring. Evidence
of over ring includes, but is not limited to:
• Warped air tube
• Deteriorated refractory brick retainers
• Deteriorated ba󰀪e and other interior components
NOTE: Hearth & Home Technologies, manufacturer of this appliance, reserves the right to alter its products, their
specications and/or price without notice.

7095-8184 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
A. Design and Installation Considerations
Consideration must be given to:
- Safety
- Convenience
- Tra󰀩c ow
- Chimney and chimney connector required
It is a good idea to plan your installation on paper, using
exact measurements for clearances and oor protection,
before actually beginning the installation. If you are not
using an existing chimney, place the appliance where there
will be a clear passage for a factory-built listed chimney
through the ceiling and roof.
We recommend that a qualied building inspector and
your insurance company representative review your plans
before and after installation.
If this appliance is in an area where children may be near
it is recommended that you purchase a decorative barrier
to go in front of the appliance. Remember to always keep
children away while it is operating and do not let anyone
operate this appliance unless they are familiar with these
operating instructions.
B. Fire Safety
To provide reasonable re safety, the following should be
given serious consideration:
1. Install at least one smoke detector on each oor of your
home to ensure your safety. They should be located away
from the heating appliance and close to the sleeping
areas. Follow the smoke detector manufacturer’s
placement and installation instructions, and be sure to
maintain regularly.
2. A conveniently located Class A re extinguisher to
contend with small res resulting from burning embers.
3. A CO detector should be installed in the room with
the appliance.
4. A practiced evacuation plan, consisting of at least two
escape routes.
5. A plan to deal with a chimney re as follows:
In the event of a chimney re:
a. Evacuate the house immediately
b. Notify re department.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state
and national codes and regulations.
• Consult insurance carrier, local building, re o󰀩cials
or authorities having jurisdiction about restrictions,
installation inspection, and permits.
NOTICE: Hearth & Home Technologies assumes no
responsibility for the improper performance of
the appliance system caused by:
• Inadequate draft due to environmental conditions
• Down drafts
• Tight sealing construction of the structure
• Mechanical exhausting devices
• Over drafting caused by excessive chimney heights
• Ideal performance is with height of chimney between
14-16 feet (4.26-4.88m) measured from the base of
the appliance.
Asphyxiation Risk.
• Do NOT connect this appliance to a
chimney ue servicing another appliance.
• Do NOT connect to any air distribution
duct or system.
May allow ue gases to enter the house.
22 Getting Started
CAUTION
WARNING
!

7095-8185 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
C. Negative Pressure D. Tools And Supplies Needed
Before beginning the installation be sure the following tools
and building supplies are available:
- Reciprocating saw
- Pliers
- Hammer
- Phillips screwdriver
- Flat blade screwdriver
- Plumb line
- Level
- Misc. screws and nails
- Framing material
- High temp caulking material
- Gloves
- Framing square
- Electric drill and bits
- Safety glasses
- Tape measure
- 7/16 socket or wrench
- 1/2-3/4 in. length, #6 or #8 self-drilling screws
E. Inspection of Appliance and Components
• Remove appliance and components from packaging
and inspect for damage.
• Report to your dealer any parts damaged in shipment.
• Read all the instructions before starting the
installation. Follow these instructions carefully
during the installation to ensure maximum safety
and benet.
Negative pressure results from the imbalance of air available
for the appliance to operate properly. It can be strongest in
lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water
appliances and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
- Recessed lighting
- Attic hatch
- Duct leaks
To minimize the e󰀨ects of negative air pressure:
• Install optional outside air kit with the intake facing
prevailing winds during the heating season
• Ensure adequate outdoor air for all combustion
appliances and exhaust equipment
• Ensure furnace and air conditioning return vents are not
located in the immediate vicinity of the appliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and
seams taped or sealed
• Basement installations should be avoided
Asphyxiation Risk.
• Negative pressure can cause spillage
of combustion fumes, soot and
carbon monoxide.
• Appliance needs to draft properly for safety.
WARNING
!
Fire Risk.
Inspect appliance and components for damage.
Damaged parts may impair safe operation.
• Do NOT install damaged components.
• Do NOT install incomplete components.
• Do NOT install substitute components.
Report damaged parts to dealer.
WARNING
!
• Installation and use of any damaged appliance.
• Modication of the appliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installation and/or use of any component part not approved
by Hearth & Home Technologies.
• Operating appliance without fully assembling all
components.
• Operating appliance without legs attached (if supplied with
appliance).
• Do NOT Over re - If appliance or chimney connector
glows, you are over ring.
Any such action that may cause a re hazard.
Fire Risk.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be voided
by, the following actions:
WARNING
!

7095-8186 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
F. Install Checklist
ATTENTION INSTALLER:
Follow this Standard Work Checklist
This standard work checklist is to be used by the installer in conjuction with, not instead of, the instructions contained in this installation manual.
Customer:
Date Installed:
Lot / Address:
Location of Appliance:
Installer:
Dealer / Distributor Phone #:
Serial #:
Model:
WARNING! Risk of Fire or Explosion! Failure to install appliance according to these instructions can lead to a fire or explosion.
Appliance Install
Verified clearances to combustibles.
Appliance is leveled and connector is secured to appliance.
Hearth extension size/height decided.
Outside air kit installed.
Floor protection requirements have been met.
If appliance is connected to a masonry chimney, it should be cleaned and
inspected by a professional. If installed to a factory built metal chimney, the
chimney must be installed according to the manufacturer’s instructions and
clearances.
Chimney
Chimney configuration complies with diagrams.
Chimney installed, locked and secured in place with proper clearance.
Chimney meets recommended height requirements (14-16 feet).
Roof flashing installed and sealed.
Terminations installed and sealed.
Clearances
Combustible materials not installed in non-combustible areas.
Verified all clearances meet installation manual requirements.
Mantels and wall projections comply with installation manual requirements.
Protective hearth strips and hearth extension installed per manual requirements.
Appliance Setup
All packaging and protective materials removed.
Firebrick, baffle and ceramic blanket installed correctly.
All labels have been removed from the door.
All packaging materials are removed from inside/under the appliance.
Manual bag and all of its contents are removed from inside/under the appliance
and given to the party responsible for use and operation.
Hearth & Home Technologies recommends the following:
• Photographing the installation and copying this checklist for your file.
• That this checklist remain visible at all times on the appliance until the installation is complete.
Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, etc.) and corrective action needed:
Comments communicated to party responsible ____________________________ by _____________________ on ___________
(Builder / Gen. Contractor) (Installer) (Date)
_________________________________________________________________________________
______________________________________________________________________________
______________________________________________________________________________
________________________________________________________________________
___________________________________________________________________________________
___________________________________________________________________
___________________________________________________________________________________
____________________________________________________________________________________
YES IF NO, WHY?
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________
______________________________________

7095-8187 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
A. Appliance Dimensions
33 Dimensions and Clearances
Figure 3.1 - Top View with Flat Surround
2-3/8 in
(60mm)
2-3/8 in
(60mm)
18 in
(457mm)
18 in
(457mm)
23-5/8 in (600mm)
23-5/8 in (600mm)
31-1/2 in (800mm)
31-1/2 in (800mm)
31 in
(787mm)
31 in
(787mm)
42-3/4 in
(1086mm)
42-3/4 in
(1086mm)
22-1/4 in
(564mm)
22-1/4 in
(564mm)
12-3/8 in
(313mm)
12-3/8 in
(313mm)
Figure 3.2 - Front View with Small Flat Surround (SP2-4331)
Figure 3.4 - Top View with Cast Surround
3-1/8 in
(79mm)
3-1/8 in
(79mm)
17-1/4 in
(438mm)
17-1/4 in
(438mm)
23-5/8 in (600mm)
23-5/8 in (600mm)
31-1/2 in (800mm)
31-1/2 in (800mm)
43 in (1092mm)43 in (1092mm)
31 in
(787mm)
31 in
(787mm)
22-1/4 in
(564mm)
22-1/4 in
(564mm)
12-3/8 in
(313mm)
12-3/8 in
(313mm)
Figure 3.5 - Front View with Small Flat Surround (CT2-4331) with
Cast Trim (811-0930)
50-3/4 in
(1289mm)
50-3/4 in
(1289mm)
22-1/4 in
(564mm)
22-1/4 in
(564mm)
34 in
(864mm)
34 in
(864mm)
12-3/8 in
(313mm)
12-3/8 in
(313mm)
Figure 3.3 - Front View with Large Flat Surround (SP2-5134)
51 in (1295mm)51 in (1295mm)
34 in
(863mm)
34 in
(863mm)
22-1/4 in
(564mm)
22-1/4 in
(564mm)
12-3/8 in
(313mm)
12-3/8 in
(313mm)
Figure 3.6 - Front View with Large Flat Surround (CT2-5134) with
Cast Trim (811-0930)

7095-8188 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
Figure 3.7 - Side View with Flat Surround
14 in
(356mm)
14 in
(356mm)
23-3/4 in
(604mm)
23-3/4 in
(604mm)
23-1/8 in
(589mm)
23-1/8 in
(589mm)
15°15°
13-1/4 in
(337mm)
13-1/4 in
(337mm)
23-1/8 in
(589mm)
23-1/8 in
(589mm)
23-3/4 in
(604mm)
23-3/4 in
(604mm)
15°15°
Figure 3.10 - Side View with Cast Surround
Figure 3.8 - Side View with Flat Surround and Optional 15 Degree
Adapter (DV-6DLR-E15ADSS)
14-1/8 in
(359mm)
14-1/8 in
(359mm)
25-3/8 in
(645mm)
25-3/8 in
(645mm)
13-3/8 in
(340mm)
13-3/8 in
(340mm)
25-3/8 in
(645mm)
25-3/8 in
(645mm)
Figure 3.11 - Side View with Cast Surround and Optional 15
Degree Adapter (DV-6DLR-E15ADSS)
Figure 3.9 - Side View with Flat Surround and Optional 15 Degree
Adapter (DV-6DLR-E15ADSS)
15-1/8 in
(385mm)
15-1/8 in
(385mm)
26-5/8 in
(676mm)
26-5/8 in
(676mm)
14-3/8 in
(366mm)
14-3/8 in
(366mm)
26-5/8 in
(676mm)
26-5/8 in
(676mm)
Figure 3.12 - Side View with Cast Surround and Optional 15
Degree Adapter (DV-6DLR-E15ADSS)

7095-8189 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
B. Clearances to Combustibles
THESE MEASUREMENTS ARE FOR WHEN USING THE OPTIONAL ZERO CLEARANCE BOX - PLEASE REFER TO
ADDTIONAL MANUAL.
Figure 3.13 - When using optional Zero Clearance Box
Triple Skin
Flue
Non-Combustible
Mantel Key 525mm
Mantel Shelf 575mm
300mm
575mm 450mm
50mm Gap
120mm
100mm Gap
50mm Gap
Non-Combustible
Material
100mm Gap
1200mm Gap 1200mm Gap
Figure 3.14
Triple Skin
Flue
Non-Combustible
Mantel Key 525mm
Mantel Shelf 575mm
300mm
575mm 450mm
50mm Gap
120mm
100mm Gap
50mm Gap
Non-Combustible
Material
100mm Gap
1200mm Gap 1200mm Gap
Figure 3.15
Triple Skin
Flue
Non-Combustible
Mantel Key 525mm
Mantel Shelf 575mm
300mm
575mm 450mm
50mm Gap
120mm
100mm Gap
50mm Gap
Non-Combustible
Material
100mm Gap
1200mm Gap 1200mm Gap


7095-81810 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
HEARTH EXTENSION
(MINIMUM EMBER PROTECTION)
SIDE TRIM (76mm max depth)
SIDE WALL
TOP TRIM (3/4” max depth)
1647mm 547mm
1110mm
1220mm
Figure 3.16
HEARTH EXTENSION
(EMBER PROTECTION)
FIREPLACE FRONT SURFACE
MANTEL
(305mm max depth)
1143mm1143mm
450mm
Figure 3.17
NOTE: Keep Ashlip
Clear of Ashes
450mm
Figure 3.19
Figure 3.18
C
DA
B
Minimum Opening Dimensions Millimeters
AHeight 594
BFront Width 813
CBack Width 606
DDepth (Steel Surround) 464
Depth (Cast Surround) 445
NOTE: Clearances may only be reduced by means
approved by AS/NZS 2918-2018.
NOTE: If trim measurement is over 76mm in depth use
mantle or side clearances to combustibles.
NOTE: Minimum opening dimensions include a 1/4 inch
(6mm) clearance around unit.
Fire Risk.
• Comply with all minimum clearances to
combustibles as specied.
• Failure to comply may cause house re.
WARNING
!



7095-81811 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
2- 15mm layers of compressed cement
sheets or similar material with a thermal
conductivity of 0.003m2/kw
Figure 3.20
Fire Risk.
• Comply with all minimum clearances to
combustibles as specied.
• Failure to comply may cause house re.
WARNING
!

7095-81812 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
A. Locating Your Appliance & Chimney
Location of the appliance and chimney will a󰀨ect
performance. As shown in Figure 4.1 the chimney should:
• Install through the warm space enclosed by the building
envelope. This helps to produce more draft, especially
during lighting and die down of the re.
• Penetrate the highest part of the roof. This minimizes the
a󰀨ects of wind turbulence and down drafts.
• Consider the appliance location in order to avoid oor
and ceiling attic joists and rafters.
• Locate termination cap away from trees, adjacent
structures, uneven roof lines and other obstructions.
Your local dealer is the expert in your geographic area and
can usually make suggestions or discover solutions that will
easily correct your ue problem.
44 Chimney Systems
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward
Outside Air Kit Termination Cap
Figure 4.1

7095-81813 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
C. Chimney Termination Requirements
Follow manufacturer’s instructions for clearance, securing ashing and terminating the chimney.
• Must have an approved and Listed cap
• Must not be located where it will become plugged by snow or other material
• Must terminate at least 91cm above the roof and at least 61cm above any portion of the roof within 305cm.
• Must be located away from trees or other structures
B. Minimum Height of Flue System Exit
NOTICE:
• Chimney performance may vary.
• Trees, buildings, roof lines and wind conditions
a󰀨ect performance.
• Chimney height may need adjustment if smoking or
overdraft occurs.
NOTICE: Locating the appliance in a basement or in a
location of considerable air movement can cause
intermittent smoke spillage from appliance. Do not
locate appliance near
• Frequently open doors
• Central heat outlets or returns
Figure 4.2
increase as necessary until nothing
within 3000mm of fluetop
increase from
1000mm minimum
until clear within
3000mm of flue top
any nearby structure
6000mm
3000mm
3000mm
or less
more than 3000mm
600mm
minimum
Asphyxiation Risk.
• DO NOT CONNECT THIS Appliance
TO A CHIMNEY FLUE SERVICING
ANOTHER APPLIANCE.
• DO NOT CONNECT TO ANY AIR
DISTRIBUTION DUCT OR SYSTEM.
May allow ue gases to enter the house.
WARNING
!
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property damage.
Refer to the owner’s information manual provided with
this appliance. For assistance or additional information
consult a qualied installer, service agency or your dealer.
WARNING
!
Fire Risk.
Follow Chimney Connector Manufacturer’s
Instructions for Proper Installation.
ONLY use connector:
• Within the room, between appliance and
ceiling or wall.
• Connector shall NOT pass through:
• Attic or roof space
• Closet or similar concealed space
• Floor or ceiling
Maintain minimum clearances to combustibles
WARNING
!

7095-81814 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
D. Venting Systems
Chimney Connector:
It is also known as ue pipe or stove pipe. It must be 152mm
minimum diameter stainless steel connector pipe. (Solid or
Flex and must run the entire chimney)
Chimney:
The chimney can be new or existing, masonry or
prefabricated and must meet the following minimum
requirements as specied below.
E. Inspections
Existing chimneys should be inspected and cleaned by a
qualied professional prior to installation. The chimney
must not have cracks, loose mortar or other signs of
deterioration and blockage. Hearth & Home recommends a
certied professional or a technician, under the direction of
a certied professional.
F. Larger Chimneys
Per Australian Standard, all replace inserts being installed
into an existing masonry replaces require a full 152 (6”)
liner
NOTICE: Check with your local building authorities.
Risk of Fire!
Follow venting manufacturer’s clearances
and instructions when installing venting
system.
WARNING
!
Fire Risk.
Inspection of Chimney:
• Chimney must be in good condition.
• Factory-built chimney must be 152mm.
WARNING
!

7095-81815 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
G. Masonry Chimney
• Must have at least 16mm re clay lining joined with refractory cement.
NOTE: Installations into a clay ue without a stainless steel liner may reduce draw which a󰀨ects performance, will cause
the glass to darken and produce excessive creosote and create start-up issues.
NOTE: Masonry chimneys are signicantly less than ideal for venting solid fuel appliances. A masonry chimney is not
subject to any temperature limit test, therefore a full reline is required to meet AS/NZS 2918.
• The masonry wall of the chimney, if brick or modular block, must be a minimum of 102mm nominal thickness.
• A chimney of rubble stone must be at least 305mm thick.
• Must be lined with a 152mm stainless steel ue liner to improve performance and reduce creosote build-up.
• An equivalent liner must be a listed chimney liner system or other approved material.
• No dilution air is allowed to enter the chimney.
- Secure the replace damper in the open position. If this cannot be accomplished, it will be necessary to remove the
damper
- Seal damper area of chimney around chimney connector with a high temperature sealant or seal insert against the
face of the replace.
- Both methods must be removable and replaceable for cleaning and re-installation.
• When possible, install an airtight clean-out door to the rear of the smoke shelf.
UL 1777 Insulated Stainless Steel
Liner or Other Approved Lining System
Follow Manufacturer’s Instructions
on Insulation and Support
For Zero or Other Non-Code Clearances,
Follow Approved Liner Manufacturer’s Specific
Insulation Requirements: Different Clearances
May Require Different Specifications
Masonry Chimney Must
Have Structural Integrity
UL 1777 Insulated Stainless Steel
Liner or Other Approved Lining System
Minimum 8 in. (203mm) Masonry
Thickness in Front of Smoke Chamber
Damper Plate Removed or
Fastened in Open Position
Seal with Non-Combustible Material
Minimum Clearance in Accordance
with Insert Listing
Floor Protection in
Accordance with Insert
Listing
Follow Manufacturer’s
Instructions for Maximum
Liner Extension Above
Chimney
Maximum 30 Degrees
Offset in Chimney
Combustible Floor
Figure 4.3 - Generic Insert Model Shown in Illustration

7095-81816 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
The following parts may be removed:
Damper Smoke Shelf or Ba󰀪e
Ember Catches Fire Grate
Viewing Screen/Curtain Doors
K. Altering the Fireplace
The following modications of factory-built replaces
are permissible:
H. Install into a Masonry Fireplace
The insert must be installed as per the requirements of
your local inspection authority. It is recommended to use
a full liner as it is the safest installation and provides the
most optimum performance. Your retailer should be able
to help you decide which system would be the best for
your application.
The use of this connection method not only increases the
safety of your insert by directing the hot gases up the ue,
but will also help increase the unit’s e󰀩ciency and decrease
creosote deposits in the chimney.
When a connected ue or liner is in use, the insert is able
to “breathe” better by allowing a greater draft to be created.
This great draft can decrease problems such as di󰀩cult
start-ups, smoking out the door and dirty glass.
I. Install Into a Factory Built Fireplace
1. When installed in a factory built replace, a full stainless
steel rigid is mandatory, for both safety and performance
purposes. When a ue or liner is in use, the insert is able
to breathe better by allowing a great draft to be created.
The great draft can decrease problems such as di󰀩cult
start-ups, smoking out the door, and dirty glass.
2. In order to position the ue liner, the existing rain cap
must be removed from your chimney system. In most
cases the ue damper should also be removed to allow
passage of the liner.
3. In most cases opening the existing spark screens fully
should give enough room for the insert installation. If it
does not, remove and store.
4. If the oor of your replace is below the level of the
replace opening, adjust the inserts leveling bolts to
accommodate the di󰀨erence. When additional shimming
is required, use non-combustible masonry or steel shims.
5. Measure approximately the alignment of the ue liner
with the position of the smoke outlet hole on the insert
to check for possible o󰀨set. If an o󰀨set is required,
use a proper stainless steel unit available with the
chimney liner.
6. Once the above items have been checked, slide your
insert into position after rst positioning the ue liner and
o󰀨set if required. (Re-install rain-cap at completion of
installation).
J. Securing Chimney Components
All joints should be secured with 3 sheet metal screws or
rivets per pipe manufacturers instructions. The sections
must be attached to the insert and to each other with the
crimped (male) end pointing toward the insert (Figure 4.5).
LINER CONNECTOR
FLUE
GAS
DIRECTION
CRIMPED
END
TOWARDS
STOVE
Figure 4.5
Risk of Fire!
Follow venting manufacturer’s clearances
and instructions when installing venting
system
WARNING
!
• The replace must not be altered. Cutting any sheet
metal parts of the replace in which the replace insert is
to be installed is prohibited per ANSI Z21.88 except that
the damper may be removed to accommodate a direct-
connect starter pipe or chimney liner,
• External trim pieces which do not a󰀨ect the operation
of the replace may be removed providing they can be
stored on or within the replace for reassembly if the
insert is removed.
• The permanent metal warning label provided in the
component pack must be attached to the back of the
replace, with screws or nails, stating that the replace
may have been altered to accommodate the insert,
and must be returned to original condition for use as a
conventional replace.
• If the hearth extension is lower than the replace opening,
the portion of the insert extending onto the hearth must
be supported.
• Manufacturer designed adjustable support kit can be
ordered from your dealer.
• Final approval of this installation type is contingent upon
the authority having jurisdiction.

7095-81817 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
N. Chimney Height / Rise and Run
To be sure that your Quadra-Fire insert burns properly, the
chimney draft (static pressure) should be approximately
-2.54mm water column (W.C.) during a high burn and
-1.016mm W.C. during a low burn, measured 152mm above
the top of the insert after one hour of operation at each burn
setting.
L. Zero-Clearance Fireplace
A permit may be required for installations, nal approval is
contingent of the authority having local jurisdiction. Consult
insurance carrier, local building, re o󰀩cials or authorities
having jurisdiction about restrictions, installation inspection,
and permits.
Inspect the existing replace and chimney for any damage
or aws such as burnouts, metal or refectory warping.
Inspection to a minimum of NFPA 211 Level II is
recommended. All repairs must be made prior to installing
an insert. The replace must be structurally sound and be
able to support the weight of the solid-fuel insert
The factory-built chimney must be listed per UL 127 or ULC
610-M87 for all installations. Install thermal protection per
this appliance listing requirements.
A full height 6 inch diameter stainless steel full height listed
chimney liner must be installed meeting type HT (2100°F)
requirements per UL 1777 (USA) or ULC S635 with “0”
clearance to masonry (Canada). The full liner must be
attached to the insert ue collar and to the top of the existing
chimney.
The ue liner top support attachment must not reduce the air
ow for the existing air-cooled chimney system. Re-install
original factory-built chimney cap only (See Prefabricated
Metal Chimney on page 14).
To prevent room air passage to the chimney cavity of the
replace, seal either the damper area around the chimney
liner or the insert surround. Circulating air chamber (i.e. in a
steel replace liner or metal hearth circulatory) may not be
blocked. The air ow within and around the replace shall
not be altered, blocked by the installation of the insert. (i.e.
no louvers or cooling air inlet or outlet ports may be blocked
by the insert or the insert surround.
See Altering the Fireplace on page 15 for modications
allowed for factory-built replaces.
NOTE: These are guidelines only, and may vary
somewhat for individual installations.
• This product was designed for and tested on a 152mm
chimney, 4.27-4.87m high, (includes appliance height)
measured from the base of the appliance.
• The further your stack height or diameter varies from this
conguration, the possibility of performance problems
exists.
• Chimney height may need to be increased by 2 - 3% per
each 304.8m above sea level.
• It is not recommended to use o󰀨sets or elbows at
altitudes above 1219.2m above sea level or when there
are other factors that a󰀨ect ue draft.
Risk of Asphyxiation!
• Do NOT connect this appliance to a chimney ue
servicing another appliance or to any air distribution
duct or system.
This may allow ue gases to enter the house.
WARNING
!
M. Ovalizing Round Stainless Steel Liners
Ovalizing round stainless steel liners to accommodate the
liner passing through the damper region of a replace is an
allowable and acceptable practice.
Ensure that the ovalization is minimized to the extent
required to t through the damper.
Fire Risk.
Do NOT pack insulation or other
combustibles between spacers.
• ALWAYS maintain specied clearances
around venting and spacers.
• Install spacers as specied.
Failure to keep insulation or other material
away from vent pipe may cause re.
WARNING
!
Fire Risk.
This appliance relies upon natural draft to
operate properly.
• Chimney heights exceeding 7.62m from
base of appliance may create an over-
draft situation.
• Overdraft condition may create over ring.
Over ring may ignite creosote and/or
damage appliance and chimney
WARNING
!

7095-81818 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
A. Outside Air Kit
A source of air (oxygen) is necessary in order for combustion
to take place. Whatever combustion air is consumed by the
re must be replaced. Air is replaced via air leakage around
windows and under doors. In homes that have tightly sealed
doors and windows, an outside air source is needed. An
optional Outside Air Kit is available.
Items Needed for Installation (not supplied)
• Needed for option two:
- 4 inch ex aluminum pipe, or if using alternate
material, then it shall be made from durable, non-
combustible, heat resistant material up to 350°F.
- Cut the pipe to the required length for your
installation.
• Needed for both options:
- Phillips head screw driver
- 5/32 Allen Wrench
- Silicone sealant
Option One - Installation Instructions
1. Ensure existing access hole in replace will not be
covered by the outer can. Existing outside air intake
hole may be under at the rear or side of outer can.
Outside air may also enter down existing chimney
chase in some situations.
2. Level outer can and install appliance. After installing
the appliance in the outer can, seal the replace
opening and trim package with insulation to prevent air
leakage into the room.
Option Two - Installation Instructions
3. Ensure existing access hole in replace is su󰀩cient to
feed the 4 inch ex.
4. After sliding can into replace, feed ex into cut opening
to obtain outside combustion air.
5. Level outer can and install appliance.
NOTE: Do not use plastic wire ties that come with the kit
as they will melt. You may need to install the ex pipe into
the rebox rst depending on installation. Attach ex to
adapter with at least 2 screws.
Fire Risk. Asphyxiation Risk.
Do not draw outside combustion air from:
• Wall, oor or ceiling cavity
• Enclosed space such as an attic or garage
• Close proximity to exhaust vents
or chimneys
Fumes or odor may result
55 Appliance Set-Up
WARNING
!
Figure 5.1
Figure 5.2
Termination
cap
Flex Adapter
Asphyxiation Risk.
Outside air inlet must be located to prevent
blockage from:
• Leaves
• Snow or ice
• Other debris
Block may cause combustion air starvation.
Smoke spillage may set o󰀨 alarms or irritate
sensitive individuals.
WARNING
!
Asphyxiation Risk.
Length of outside air supply duct shall NOT
exceed the length of the vertical height of
the exhaust ue.
• Fire will not burn properly
• Smoke spillage occurs when door is
opened due to air starvation.
WARNING
!

7095-81819 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
B. Stove Pipe or Liner to Flue Collar
1. There are 4 already drilled holes in the ue collar 90
degrees apart. Attach the ue collar to the stove pipe/
liner. If the seal is questionable use high temperature
sealant such as stove mastic (Figure 5.3).
2. Attach gasket to bottom side of ue collar with a thin coat
of silicone.
C. Optional O󰀨set Adapter
Optional use of a Simpson Duravent 15° Universal Elbow
Part Number 4615 may be purchased directly through your
local Simpson Duravent Pipe Distributor or from your local
Quadra-Fire dealer, Part Number DV-6DLR-E15ADSS.
Figure 5.4 shows a vertical installations and also how to
create an optional 30° elbow installation.
The 15° elbow may be secured directly to the ue collar.
Follow the pipe manufacturer’s instructions for using screws
or rivets for attachment. Most pipe manufacturer’s 6 inch
(152mm) diameter ue liners may be attached directly to the
top of the 15° elbow.
D. Power Cord
The power cord is shipped assembled to the appliance.
You may route the power cord either to the left or right
side depending on your conguration for power source
(Figure 5.5).
Flue Collar Stove Pipe/Liner
Gasket
Figure 5.3
Figure 5.4
30 degree
30
o
Vertical
Figure 5.5
E. Appliance to Stove Pipe or Liner
1. Once you have the appliance in place and secured, reach
up through the ue opening and grab the attachment bar
and pull down inside ue opening (Figure 5.6).
2. Insert the 5/16 bolts inside the cast ue and through
the chimney mounting bar. Securely tighten the nuts;
fasteners are provided.
3. Re-install the tube channel assembly, ba󰀪e board,
ceramic blanket and ba󰀪e protection channel.
5/16 Nuts
Attachment
Bar
5/16 Bolts
Figure 5.6

7095-81820 Quadrare • Expedition II AU Install Manual_Rev B • 2020 - ___ • 09/20
NOTE: These are generic drawings and may not
represent your specic model.
F. Flat Surround
1. Lay surround face down on a protected surface to
prevent scratching.
2. Remove door by unlatching handle from face and lifting
up on door, set aside by laying it onto a protective surface
(Figure 5.7).
Overall Dimensions Part Number
Standard Size 43” x 31” SP2-4331
Large Size 51” x 34” SP2-5134
Table 5.1
4. Lift surround on to front of appliance (Figure 5.9).
3. Remove face by lifting up then out away from appliance
and set aside laying it onto a protective surface
(Figure 5.8).
Figure 5.7
Figure 5.8
Figure 5.9
Top: over lip on top of
Sides: through
cut outs on
sides and
then down
appliance
6. Reinstall door to face of appliance (Figure 5.11).
5. Reinstall face to front of appliance (Figure 5.10).
Figure 5.10
Figure 5.11
