Champlain (Model 8301)
Gas-Fired Direct Vent Heater
Owner’s Manual
Operation & Installation Guide
Read This Owner’s Manual
Operate and Maintain This Gas Heater
According to This Instruction Manual.
Save These Instructions!
WARNING: FOLLOW THE INFORMATION IN
THESE INSTRUCTIONS EXACTLY, IF NOT, A FIRE
OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
WARNING: DO NOT STORE OR USE GASOLINE
OR ANY OTHER FLAMMABLE VAPORS AND
LIQUIDS NEAR THIS OR ANY OTHER GAS
APPLIANCE.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone
in your building.
Immediately call your gas supplier from a phone
outside the structure. Follow your gas supplier’s
instructions.
If you cannot reach your gas supplier, call the fire
department or 911.
A qualified installer, service agency, or gas supplier must
perform installation and service of this appliance. In the
Commonwealth of Massachusetts, all installation of gas
lines and gas fittings must be performed by a licensed gas
fitter or licensed plumber.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN
SUIVRE LES INSTRUCTIONS DONNÉ DANS
CETTE NOTICE POUR RÉDUIRE AU MINIMUM LE
RISQUE D’INCENDIE OU POUR ÉVITER TOUT
DOMMAGE MATÉERIEL, TOUTE BLESSURE OU
LA MORT.
AVERTISSEMENT: NE PAS ENTRESPOSER NI
UTILISER D’ESSENCE NI D’AUTRE VAPERURS
OU LIQUIDES INFLAMMABLES DANS LE
VOISINAGE DE CET APPRAREIL OU DE TOUT
AUTRE APPAREIL.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d’allumer d’appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L’installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.

Intentionally Blank
Page 1 of 30

Page 2 of 30
Information Sheet
Use this page to record all relevant information concerning the purchase, installation, and maintenance of your
Champlain Model 8301 Direct -Vent heater. This information will facilitate servicing, purchase of replacement
parts, and warranty claims (if necessary). Keep your original receipt in a safe place as proof of purchase.
Serial Number:
Fuel type: Natural Gas Liquid Propane
Sold by: Date of Purchase:
Address:
Phone:
E-mail Website:
Installed by: Date of Installation:
Address:
Phone:
E-mail Website:
Gas Supplier:
Address:
Phone:
E-mail Website:
Read this Owner’s Manual before installing or operating your Champlain. Retain this manual for future
reference.
SERVICE RECORD
Date Who Performed Work Work Performed Notes:
WHAT WHEN
Firebox Cleaning............. annually
Glass Cleaning................ as needed
Gaskets.................... Replacement as needed

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
Table of Contents
INTRODUCTION ..........................................................................................................................4
WARNINGS,CAUTIONS,&SAFETY..........................................................................................................................4
SPECIFICATIONS ........................................................................................................................5
OWNER’S INFORMATION .............................................................................................................6
LIGHTING INSTRUCTIONS .......................................................................................................................................7
TO TURN OFF THE APPLIANCE...............................................................................................................................7
VARIABLE OUTPUT CONTROL.................................................................................................................................7
DAILY OPERATIONS...............................................................................................................................................7
INSTALLER’S INFORMATION ........................................................................................................8
CODES .................................................................................................................................................................8
UNPACKING AND INSPECTION.................................................................................................................................8
PACKING LIST .......................................................................................................................................................8
FIREBOX ACCESS..................................................................................................................................................8
ITEMS REQUIRED FOR INSTALLATION ......................................................................................................................9
CLEARANCES TO COMBUSTIBLES...........................................................................................................................9
HEARTH REQUIREMENT/FLOOR PROTECTION .........................................................................................................9
VENTING INFORMATION ............................................................................................................11
VENTING COMPONENTS &CONFIGURATION..........................................................................................................11
VENT CONNECTION .............................................................................................................................................11
ACCEPTABLE DIRECT-VENT TERMINATION CAP ROOF LOCATIONS.........................................................................13
VENT CONFIGURATION OPTIONS ..........................................................................................................................13
VENT RESTRICTOR ..............................................................................................................................................16
GAS SUPPLY &CONNECTIONS .................................................................................................17
GAS CONNECTIONS.............................................................................................................................................17
LOG PLACEMENT.................................................................................................................................................18
INSTALLATION OF THE LOG SET............................................................................................................................18
REMOVAL OF LOG SET.........................................................................................................................................19
LIGHTING THE UNIT THE FIRST TIME .....................................................................................................................20
INITIAL ADJUSTMENTS..........................................................................................................................................20
GAS CONVERSIONS.............................................................................................................................................21
ROUTINE MAINTENANCE AND CARE...........................................................................................22
REPLACING THE GLASS .......................................................................................................................................22
WIRING INSTRUCTIONS.............................................................................................................23
PARTS LIST.............................................................................................................................24
RATING LABEL ........................................................................................................................25
TROUBLESHOOTING .................................................................................................................26
Page 3 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
INTRODUCTION
Congratulations on your purchase of Hearthstone’s
Champlain DV Model 8301 Gas-Fired Direct Vent
heater. The Champlain DV will provide you with
clean, efficient heat for years to come. Combustion
air comes directly from the outside of your home to
the sealed firebox system, eliminating the potential
for annoying back drafts or other problems
associated with depressurization common in
modern, high efficiency homes.
The Champlain DV will also provide you with years
of practical and convenient service. However, as
with any gas appliance, the unit must be properly
and safely installed and maintained by qualified
service personnel to ensure safe and trouble-free
operation.
READ THIS OWNER’S MANUAL
Operate and maintain this gas heater according to
the instructions in this manual. For your safety, and
years of trouble free operation, read this manual in
its entirety. By following a few simple safety
precautions and by performing minimal
maintenance, the unit will remain appealing while
providing years of quality performance.
WARNINGS,CAUTIONS,&SAFETY
FUEL GAS
This gas heater is designed to burn natural gas (NG)
or with a conversion kit, liquid propane (LP). Never
burn any fuel not intended for use with this unit.
Never Burn Paper, Wood or Other Materials.
HOT SURFACES
Certain exposed surfaces of the Champlain DV will
reach high temperatures during normal operation.
Ensure you maintain clearances to combustibles, as
specified in the “Clearances to Combustibles”
section of this manual.
WARNING! USE ONLY A QUALIFIED SERVICE
TECHNICIAN TO DO THE INSTALLATION, AND
REPAIR. A QUALIFIED SERVICE TECHNICIAN
MUST INSPECT THE APPLIANCE BEFORE USE,
AND AT LEAST ANNUALLY. MORE FREQUENT
CLEANING MAY BE REQUIRED DUE TO
EXCESSIVE LINT FROM CARPETING, BEDDING
MATERIAL, PETS, ETC. IT IS IMPERATIVE THAT
THE CONTROL COMPARTMENTS, BURNERS,
AND CIRCULATING AIR PASSAGES OF THE
APPLIANCE ARE KEPT CLEAN AND FREE OF
OBSTRUCTIONS. (S’ASSURER QUE LE BRÛLEUR
ET LE COMPARTIMENT DES COMMANDES SONT
PROPRES. VOIR LES INSTRUCTIONS
D’INSTALLATION ET D’UTILISATION QUI
ACCOMPAGNENT L’APPAREIL.)
WARNING: DO NOT OPERATE THIS APPLIANCE
WITH THE GLASS, OR ANY PANEL REMOVED,
CRACKED, OR BROKEN. DO NOT SUBJECT THE
DOOR TO ABUSE, SUCH AS STRIKING OR
SLAMMING SHUT. ONLY A LICENSED OR
QUALIFIED SERVICE PERSON SHOULD
REPLACE THE GLASS PANEL WHEN
NECESSARY.
WARNING: DO NOT USE THIS APPLIANCE IF ANY
PART WAS SUBMERGED IN WATER.
IMMEDIATELY CALL A QUALIFIED SERVICE
TECHNICIAN TO INSPECT THE HEATER AND TO
REPLACE ANY PART OF THE CONTROL SYSTEM
AND GAS CONTROL THAT WAS SUBMERGED.
(NE SE SERVIR DE CET APPAREIL S’IL A ÉTÉ
PLONGÉ DANS L’EAU, COMPLÈTEMENT OU EN
PARTIE. APPELER UN TECHNICIEN QUALIFIÉ
POUR INSPECTER L’APPAREIL ET REMPLACER
TOUTE PARTIE DU SYSTÈME DE CONTRÔLE ET
TOUTE COMMANDE QUI ONT ÉTÉ PLONGÉS
DANS L’EAU.)
WARNING: DO NOT CONNECT THIS GAS
APPLIANCE TO A CHIMNEY FLUE SERVING A
SEPARATE SOLID-FUEL BURNING APPLIANCE.
NEVER VENT THE GAS HEATER INTO OTHER
ROOMS OR BUILDINGS. MASONRY
CONVERSIONS KITS ARE AN ACCEPTABLE
VENTING OPTION.
CAUTION: DUE TO HIGH TEMPERATURES,
LOCATE THE APPLIANCE OUT OF TRAFFIC AND
AWAY FROM FURNITURE, DRAPERIES,
CLOTHING AND FLAMMABLE MATERIALS.
ALERT CHILDREN AND ADULTS TO THE
HAZARDS OF HIGH SURFACE TEMPERATURES
SO THEY CAN AVOID BURNS TO SKIN OR
PREVENT CLOTHING IGNITION. SUPERVISE
YOUNG CHILDREN CAREFULLY WHEN THEY
ARE IN THE SAME ROOM AS THE APPLIANCE.
NEVER PLACE CLOTHING OR OTHER
FLAMMABLE MATERIAL ON OR NEAR THE
APPLIANCE. (SURVEILLER LES ENFANTS.
GARDER LES VÊTEMENTS, LES MEUBLES,
L’ESSENCE OU AUTRES LIQUIDES À VAPEUR
INFLAMMABLES LOIN DE L’APPAREIL.)
FIRE HAZARD: DO NOT STORE OR USE
GASOLINE OR OTHER FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY OF THIS APPLIANCE.
REPLACE ANY SHIELD, DOOR, OR SAFETY
SCREEN COMPONENT REMOVED FOR
SERVICING PRIOR TO OPERATING THE UNIT.
Page 4 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
SPECIFICATIONS
Testing Agency: Intertek Testing Services NA, Inc.
(ITS)
Listed: Direct Vent Gas Heater
Model: Champlain DV Model 8301
Tested to: ANSI Z21.88b – 2008/CSA 2.33b - 2008
Certified for Canada, CSA P.4.1
Approved for Mobile Home Installation
Certified for use by:
Board of State Examiners of Plumbers and Gasfitters
100 Cambridge Street, Room 1511
Boston, Massachusetts 02202
Manufactured and Warranted by:
Hearthstone Quality Home Heating Products, Inc.
317 Stafford Ave.
Morrisville, VT 05661-8695, USA
www.hearthstonestoves.com
Figure 1 – Champlain DV Dimensions
Specification NG LP
Input rating (Btu/hr) 0-2000 ft 35,000 35,000
Input rating (Btu/hr) 2000-4500 ft 35,000 33,300
Orifice size DMS 0-2000 ft 32 49
Orifice size DMS 2000-4500 ft 32 50
Man. press.-LO setting (in.w.c./kPa) 1.2/0.3 3.3/0.8
Man. press.-HI setting (in.w.c./kPa) 3.5/0.87 10.0/2.48
Inlet press.-LO setting(in.w.c./kPa) 5.0/1.24 11.0/2.88
Inlet press.-HI setting(in.w.c./kPa) 7.0/1.74 13.0/3.22
Minimum input rating rating (Btu/hr) 21,500 20,400
Maximum output (Btu/hr) 0-2000 ft 25,600 25,600
Page 5 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
OWNER’S INFORMATION
The installation must conform with local codes or, in
the absences of local codes, the current National
Fuel Gas Code, ANSI Z223.1 (NFPA 54), or
CAN/CGA B149 Installation Code. (Installer
l’appareil selon les codes ou règlements locaux, ou,
en l’absence de tels règlements, selon les Codes
d’installation CAN/CGA-B149.)
Service Caution
Replace any components of the stove removed for
servicing before operating. If you believe your
Champlain is not performing properly, immediately
discontinue operation until the unit is inspected and
approved for operation by qualified service
personnel. Prior to servicing the unit, turn the gas
supply to the valve off. Ensure the unit is cool before
servicing and cleaning.
Do not use any components other than those
approved by Hearthstone Quality Home Heating
Products, Inc., otherwise all warranties are void. Do
not substitute components!
FIRE HAZARD
Do not store, or use gasoline, or other flammable
vapors or liquids near this appliance. The Champlain
should be located out of traffic, and away from
furniture, draperies, clothing, and other flammable
materials.
SHOCK HAZARD
(If equipped with accessory blower) The accessory
blower is equipped with a three-prong (grounding)
plug for protection against shock hazard and must
be plugged directly into a properly grounded three-
prong receptacle. Do not cut, or remove, the
grounding prong from the plug.
HOT SURFACES
Certain exposed surfaces of the Champlain will
reach high temperatures during normal operation.
Clearances to combustibles must be maintained, as
specified in the “Clearances To Combustibles”
section of this manual. Due to high temperatures,
the appliance should be located out of traffic and
away from furniture, draperies, clothing, and other
flammable materials. Alert children and adults to the
hazards of high surface temperatures and that they
must stay away to avoid burns to skin or possible
clothing ignition.
Supervise young children carefully when in the same
room as the appliance. Do not place clothing or
other flammable material on or near the appliance.
(Surveille les enfants. Garder les vêtements, les
meubles, l’essence ou autres liquides à vapeur
inflammables lin de l’appareil.)
Clean the area around, under, and behind the unit
on a regular basis to prevent the accumulation of
dust and lint.
WARNING! DO NOT OPERATE THIS APPLIANCE
WITH THE FRONT GLASS REMOVED, CRACKED,
OR BROKEN. REPLACEMENT OF GLASS
SHOULD BE DONE BY A LICENSED OR
QUALIFIED SERVICE PERSON. ONLY OPEN
FRONT FOR ROUTINE SERVICE. DO NOT SLAM,
OR STRIKE THE GLASS.
WARNING! A QUALIFIED SERVICE TECHNICIAN
SHOULD PERFORM THE INSTALLATION, AND
ANY REPAIRS. A QUALIFIED SERVICE
TECHNICIAN MUST INSPECT THE APPLIANCE
BEFORE USE, AND AT LEAST ANNUALLY. MORE
FREQUENT CLEANING MAY BE REQUIRED DUE
TO EXCESSIVE LINT FROM CARPETING,
BEDDING MATERIAL, PETS, ETC. IT IS
IMPERATIVE THAT THE CONTROL
COMPARTMENTS, BURNERS, AND CIRCULATING
AIR PASSAGES OF THE APPLIANCE ARE KEPT
CLEAN AND FREE OF OBSTRUCTIONS.
(S’ASSURER QUE LE BRÛLEUR ET LE
COMPARTIMENT DES COMMANDES SONT
PROPRES. VOIR LES INSTRUCTIONS
D’INSTALLATION ET D’UTILISATION QUI
ACCOMPAGNENT L’APPAREIL.)
Page 6 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
LIGHTING INSTRUCTIONS
1. Set the on/off/T-stat switch or thermostat to the
off position.
2. Unplug the blower accessory, if so equipped.
3. Push in and turn gas control knob clockwise to
“OFF”. (If not previously lit, the knob should be
in this position.)
4. Wait (5) five minutes to clear out any gas. If you
then smell gas, STOP! Smell all around the
appliance area for gas. Be sure to smell next to
the floor because some gases (LPG) are heavier
than air and will settle on the floor. If you smell
gas immediately, follow the What To Do If You
Smell Gas! warning on the cover of this Manual.
If you do not smell gas, go to the next step.
5. Turn gas control knob counterclockwise to
“PILOT”.
6. Push in control knob all the way and hold in.
Immediately light the pilot with the gas lighter
(push in and “click” the piezoelectric spark
igniter button several times until lit). Continue to
hold the control knob in for about 20 seconds
after the pilot is lit. Release the knob and it will
pop back out. Pilot should remain lit. If the pilot
goes out, repeat the operation.
If knob does not pop out when released,
stop and immediately call a qualified service
technician or gas supplier.
If the pilot will not stay lit after several tries,
turn the gas control knob “OFF” and call a
qualified service technician or gas supplier.
7. Turn gas control knob counterclockwise to “ON”.
8. Select “ON” or “T-STAT” position on the on/off/t-
stat switch.
9. Shut the gas control valve access door.
10. Plug in the blower accessory, if so equipped.
11. Set thermostat to “ON” and set the desired
temperature setting.
Normally, if the “T-STAT” position was selected, the
main burner is cycled on and off by the Thermostat
or the “on”, “off” switch located on the bottom of the
Thermostat body.
TO TURN OFF THE APPLIANCE
Turn the gas control knob clockwise to “OFF”
position, and shut off the gas supply to the valve if
shutting the unit off for the non-heating season. This
will improve the overall efficiency of the unit as the
heat from the pilot is wasted in the summer. Follow
the lighting instructions outlined on this page when
putting the unit back into service.
VARIABLE OUTPUT CONTROL
The gas control valve is equipped with a variable
output control. This control varies the rate of heat
produced by the unit by varying the gas pressure to
the main burner tube.
DAILY OPERATIONS
The Champlain gas-fired heater is easy to operate.
The Champlain comes with a standard thermostat.
Optional remote, or programmable thermostats are
available for purchase from your local Hearthstone
dealer. The desired room temperature is maintained
with a properly adjusted and installed thermostat.
By adjusting the variable output control located on
the gas control valve, the rate of heat output is
varied to meet the heating requirements of the
season. Choosing a low flame setting will result in
longer burn cycles at a reduced output, while
choosing a high flame setting will result in a shorter,
hotter burn cycle. Through trial and error, the
homeowner can select the optimum flame size for
their setting, and application. Also available is a
optional variable speed blower.
Page 7 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
INSTALLER’S INFORMATION
CODES
Adhere to all local codes or, in their absence,
obtain the latest edition of THE NATIONAL FUEL
GAS CODE ANSI Z223.1 (NFPA 54) or CAN/CGA
B149 Installation Code from:
AMERICAN NATIONAL STANDARDS INSTITUTE, INC.
1430 BROADWAY
NEW YORK, NY 10018
www.ansi.org
OR
NATIONAL FIRE PROTECTION ASSOCIATION, INC.
BATTERY MARCH PARK
QUINCY, MA 02269
www.nfpa.org
The appliance, when installed with a blower, must
be electrically connected and grounded in
accordance with local codes or, in the absence of
local codes, with the current NFPA 70-National
Electrical Code or CSA C22.1-Canadian Electric
Code.
A manufactured home (or mobile) OEM installation
must conform to the Manufactured Home
Construction and Safety Standard, Title 24 CFR,
Part 3280 (U.S.) or Standard for Manufactured
Home Installation, ANSI/NCBCS A225.1 or Standard
for Gas Equipped Recreational Vehicles and mobile
Housing, CSA Z240.4.CAN/SCA Z240 MH
(Canada). (Installer l’appareil selon les codes ou
règlements locaux, ou, en l’absence de tels
règlements, selon les Codes d’installation
CAN/CGA-B149.)
For installations from 610-1370 meters (2000-4500
ft.) the orifice sizes (DMS) for natural and propane
gas are 32 and 52 respectively. See data plate for
additional information. For high altitude installations
consult the local gas distributor or the authority
having jurisdiction for proper rating methods. If the
installer must convert the unit to adjust for varying
altitudes, the information sticker must be filled out by
the installer and adhered to the appliance at the
same time of conversion. (Cet appareil est equipè
pour des altitudes compries entre 0 et 2000 pieds
(0-610 m) seulement.)
UNPACKING AND INSPECTION
Unpack and Inspect for Damage
Hearthstone packages the Champlain to withstand
normal shipment without damage. However,
damage can still occur during transit, so take care to
inspect for damage when unpacking and installing
the unit. If you detect any damage, or a missing part,
immediately contact your dealer.
Do not install or put into service a damaged
or incomplete heater.
The unit should appear square and level, with the
sheet metal parts smooth and free of bends or
dents. Enameled cast iron should be free of chips or
cracks. If you find visible or concealed damage,
contact your dealer.
PACKING LIST
1-Champlain DV Gas-fired Heater containing:
6-Decorative Fiber Logs
1-Pan Burner
1-Owner’s Manual and Warranty
1-Bag Charcoal Embers
1-Bag Platinum Bright Embers
2-Decorative Caps
1-Accessory box containing:
1-Top Grille
1-Thermostat with Thermostat Wire
2-Extension control Knobs
1-LP Conversion kit
FIBER LOG SAFETY INFORMATION
The decorative fiber logs supplied with the
Champlain are located in the firebox. Always use
great care when handling the decorative fiber logs,
as they are fragile and subject to damage and
breakage. If the decorative fiber logs supplied with
the Champlain are damaged, they must be replaced.
Contact your local Hearthstone dealer for
replacement parts. Do not replace fiber logs, or the
embers, with any materials not approved by
Hearthstone.
FIREBOX ACCESS
To open the firebox:
1. Remove the two upper front screws (located in
the grill of the front) that hold the cast façade
onto the unit. (These screws ship on the unit
for transit purposes only and are removed
during installation.)
2. Open the valve access door by pulling the ash
lip out off the magnet and down. Allow the door
to swing down completely.
Page 8 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
Figure 2: Façade Spring Latch Detail
3. Grasp the handle of the spring latch, located in
the center of the opening, pull out towards you
and then move the handle to the right to
disengage the catch, then release tension on the
latch - be careful not to drop the front as the
latch is unfastened. Be careful not to chip the
enamel when handling the front façade.
4. Grasp the bottom of the façade, lift it up slightly
and out off the L-brackets. Lower the façade and
move it away from the unit - set aside
5. To remove the glass, reach over the firebox, and
under the front grill. With a flat screwdriver, pry
the retaining clips up. There are two separate
clips. Be careful, when you lift the last one, as it
will free the glass and frame from the unit.
Note: The two screws holding the top of the front
on are for shipping purposes only. Once the stove
has arrived at the final destination, remove these
two screws and replace them with the two
decorative caps provided with the unit.
6. To re-install – reverse the outlined steps above.
ITEMS REQUIRED FOR INSTALLATION
External regulator (for LP) Phillips head screwdriver
Code Compliant Piping 7/16-inch wrench
Pipe sealant approved for
use with LP Other parts as required by local code
Manual shutoff valve *Safety Glasses
Sediment trap (page 17) *Gloves
Tee joint
Pipe wrench
*Recommended
CLEARANCES TO COMBUSTIBLESL-Bracket (2)
Catch Always maintain clearances around the air openings
in the stove. This allows for adequate ventilation. (As
shown in Figures 3, through 6.) The corner
clearance for the Champlain is 2”, measured from
the edge of the top castings to the adjacent wall.
HEARTH REQUIREMENT/FLOOR
PROTECTION
Latch Handle
You can install the Champlain on any non-
combustible surface, or wood floor. For placement of
the Champlain on carpeting, vinyl tile, or other
combustible materials, you must install the appliance
on any noncombustible or wood panel extending the
full width and depth of the appliance. Installations
must meet all codes.
Figure 3: Mantle Clearance Horizontal Vent
Page 9 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
Figure 4: Wall Clearances Horizontal Vent
Figure 5: Snorkel Mantle Clearance
Figure 6: Snorkel Wall Clearances
CONDITIONALLY APPROVED FOR PURCHASED
MOBILE HOME INSTALLATION. THIS APPLIANCE
MAY BE INSTALLED IN AN AFTERMARKET
PERMANENTLY LOCATED, MANUFACTURED (OR
MOBILE) HOME, WHERE NOT PROHIBITED BY
LOCAL CODES.
THIS APPLIANCE IS ONLY FOR USE WITH THE
TYPE OF GAS INDICATED ON THE RATING
PLATE. THIS APPLIANCE IS NOT CONVERTIBLE
FOR USE WITH OTHER GASES, UNLESS A
CERTIFIED KIT IS USED, AVAILABLE THROUGH
YOUR LOCAL HEARTHSTONE DEALER.
CET APPAREIL PEUT ÊTRE INSTALLÉ DANS UN
MAISON PRÉFABRIQUÉE (MOBILE) DÉJÀ
INSTALLÉE À DEMEURE SI LES RÈGLEMENTS
LOCAUX LE PERMETTENT.
CET APPAREIL DOIT ÊTRE UTILISÉ
UNIQUEMENT AVEC LES TYPES DE GAS
INDIQUÉS SUR LA PLAQUE SIGNALÉTIQUE. NE
PAS L’UTILISER AVEC D’AUTRES GAS SAUF SI
UN KITDE CONVERSION CERTIFIÉ EST INSTALLÉ
Page 10 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
VENTING INFORMATION
There are many configurations of vent
installations for your stove. Please review the
following pages for the venting installation that
works best for you.
Figure 7: General Venting Rules
VENTING COMPONENTS &
CONFIGURATION
Do not vent the Champlain jointly with any other
solid fuel or gas appliance. Vent the stove directly to
the outside of the building using a proper termination
as listed in this manual. The only types of venting
pipe approved for use with your Champlain Direct-
Vent stove are those listed in this manual. The
venting configuration diagram is shown in Figure 13.
After determining the proper venting configuration
for your stove, select the vent system that will
accommodate your installation.
CAUTION: ENSURE NO WIRING OR PLUMBING IS
IN THE CHOSEN LOCATION.
CAUTION: DO NOT RECESS VENTING
TERMINATIONS INTO A WALL OR SIDING.
Note: If you need further direction for installation,
please refer to the venting instructions provided with
the venting components.
VENT CONNECTION
The Champlain Direct Vent Model 8301 is approved
for installation only with the vent connecting
components listed in this manual. Use the following
instructions along with the pipe manufacturer’s
instructions to complete the installation.
The starter collar is factory installed. Install the rest
of the vent system according to the manufacturer’s
instructions.
SPECIFIED VENTING MANUFACTURERS
This heater is approved for installation only with the
venting components provided by manufacturers
listed on this page.
Simpson Dura-Vent, Inc.
P.O. Box 1510
Vacaville, CA 95696-1510 800-835-
4429
American Metal Products (AmeriVent)
8601 Hacks Cross Rd.
Olive Branch, MS 38654 800-423-
4270
Selkirk Corporation
1301 W. President George Bush Hwy, Suite 330
Richardson, TX 75080-1139 800-992-8368
Security Chimneys International Ltd (Secure Vent)
2125 Monterey, Laval, Quebec
Canada, H7L 3T6 450-973-
9999
ICC, Inc.
400 J-F Kennedy, St. Jerome, Quebec
Canada, J7Y 4B7 450-565-
6336
Metal-Fab, Inc.
P.O. Box 1138
Wichita, Kansas 67201 316-943-2351
Page 11 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
Figure 8: Termination Location & Clearances
A = Clearance above grade, veranda, porch, deck,
or balcony: 12 inches (30cm) minimum.
B = Clearance to window or door that may be
opened: **Min. 9 inches U.S./*12 inches (30cm)
CAN. We recommend 12 in, minimum to prevent
condensation on the window.
C = Clearance to permanently closed window: **Min.
9 inches, U.S./*12 inches (30cm) CAN.
We recommend 12 in. minimum to prevent
condensation on the window.
D = Vertical clearance to ventilated soffit located
above the termination within a horizontal distance of
2 feet (60cm) from the center line of the termination:
18 inches (46cm) minimum.
E = Clearances to unventilated soffit: 12 inches
(30cm) minimum.
F = Clearance to outside corner: **Min. 9 inches,
U.S./12 inches (30cm) CAN. We strongly
recommend 12 inches, particularly where windy
conditions prevail.
G = Clearance to inside corner: **Min. 6 inches,
U.S./12 inches (30cm) CAN. We strongly
recommend 12 inches, particularly where strong
winds prevail.
H = *Not to be installed within 15 feet (4.5m) above
a meter/regulator assembly within 3 feet (91cm)
horizontally from the center line of the regulator.
I = Clearance to service regulator vent: 3 feet (91cm)
J = Clearance to non-mechanical air supply inlet to
building or the combustion air inlet to any other
appliance: 12inches (30cm) minimum.
K = Clearance to a mechanical air supply inlet:
**Min. 3 feet (91cm) above if within 10 feet
horizontally, U.S./*6 feet (1.83m) CAN minimum.
L = ¹Clearance above paved sidewalk or a paved
driveway located on public property: 7 feet (2.1m)
minimum.
M = ²Clearance under veranda, porch, deck, or
balcony: 12 inches (30cm) minimum.
*In accordance with CSA B149 Installation codes.
**In accordance with the current ANSI Z223.1/NFPA 54,
National Fuel Gas Code. Note: Local Codes and
Regulations may require different clearances.
¹A vent shall not terminate directly above a sidewalk or
driveway which is located between two single family
dwellings and serves both dwellings
²Only permitted if veranda, porch, deck or balcony, is fully
open on a minimum of two sides beneath the floor.*
Page 12 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
ACCEPTABLE DIRECT-VENT
TERMINATION CAP ROOF LOCATIONS
The vent/air intake termination clearances above the
high side of an angled roof as follows:
Roof Pitch Feet Meters
Flat to 6/12 10.3
7/12 to 9/12 20.6
10/12 to 12/12 41.2
13/12 to 16/12 61.8
17/12 to 21/12 82.4
Figure 9: Termination Cap clearances
APPROVED VENTING SYSTEM COMPONENTS
(The following are components that are available, BUT NOT
necessary for all installations)
900 Elbow Vertical Vent Cap
450 Elbow 36” Snorkel
6" Straight
9" Straight (Simpson only) Vinyl Siding Standoff 4” x
6 5/8"
12" Straight Round Ceiling Support
24" Straight Thimble Covers
36" Straight Wall thimble
48" Straight Horizontal Vent Cap
11"-14 5/8" Adjustable
Pipe
CHIMNEY LINER SYSTEM
Direct-Vent Chimney Liner Termination Kit
Chimney Liner Flex
Co-Linear Flex Connector
-
Axial to Co-Linear Appliance Connect (Masonry
approved, not to exceed 16’ measured from the stove
top)
7. If the vent system is disassembled for any
reason, it must be reinstalled per the
instructions provided for in the initial
installation or in this manual.
VENT CONFIGURATION OPTIONS
I. STANDARD HORIZONTAL INSTALLATION
Kit #93-65000)
8. Note: Install the 45º elbow over the outer collar.
Place the elbow so that the twist lock end is
pointing straight up. Install the 2’ pipe section
into this elbow by fully inserting it, and turning
approximately ¼ turn clockwise until the two
sections are fully locked. Install the 90º elbow in
similar fashion with the opening pointing to the
rear.
9. Note: Ensure there is no Wiring or Plumbing in
the chosen wall location.
Move the stove and pipe assembly back until the 90º
elbow is flush to the wall. Ensure the 2’ vertical pipe
is still parallel to the wall. Draw a circle around the
pipe where it touches the wall. Use the center of
this circle as the center point of the 10” x 10” square
wall pass through.
Cut and frame the wall for the vent pipe. Install the
horizontal vent termination on the outside of the wall.
Ensure both of the retaining straps extend through
the wall pass through to the inside of the wall.
Before attaching the vent termination to the outside
of the house, run a bead of non-hardening mastic
around the outside edges, between the vent
termination and the wall. The arrow on the end cap
should point up. Secure the cap to the wall with the
appropriate screws.
Put the adjustable (11”-14”) pipe into the horizontal
vent cap, (the vent pipe must extend into the
horizontal vent cap a minimum of 1 ¼”). Move the
stove and vent pipe into position, insert the
adjustable (11”-14”) pipe into the 90° elbow, twist
lock it.
Secure the straps from the horizontal vent
termination to the interior pipe with two sheet metal
Page 13 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
Page 14 of 30
screws, keeping the screws as close to the wall
thimble as possible. Bend or cut the excess
strapping so the thimble cover will fit properly.
Screw the thimble cover to the wall.
The adjustment range for wall thickness for
this configuration is 3”min to 9”max.
II. FIREPLACE VENTING INSTALLATIONS
-40' maximum system height (without offsets)
-14' maximum offset (refer to Figures 10 - 12)
-Maximum rise to run = 1 to 5 (refer to Figures 9-
13)
-The termination must meet the requirements
outlined in Figure 8 and Figure 9.
Figure 10: Vertical Venting Rules
III. VERTICAL TERMINATION VENTING CONFIGURATIONS
-40' maximum system height (without offsets)
Figure 11: Approved DV Vertical Co-Axial Termination Configurations

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
IV. HORIZONTAL TERMINATION VENTING CONFIGURATIONS
-A minimum of 24" rise is required (with or w/o
offsets)
-40' maximum system height (without offsets)
-Maximum rise to run = 1 to 5
-The termination must meet the requirements
outlined in Figure 8 & 9. Use a vinyl siding Stand off
when installing against vinyl siding.
-Horizontal sections require a 1/4" rise every 12" of
horizontal run.
-For each 90° elbow after the second, remove 5'
from horizontal run.
-Use with snorkel termination 45" maximum
horizontal run.
Figure 12: Approved DV Venting Alternate Configurations for Vertical Termination
Page 15 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
Figure 13: Venting Configuration and Restrictor Settings
VENT RESTRICTOR
To adjust your restrictor for maximum flame
appearance, loosen the phillips head screw and spin
the locator, found on the rear left side of the stove
(Refer to figure 13 above)
Page 16 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
GAS SUPPLY &CONNECTIONS
GAS CONNECTIONS
The gas supply line connection is made to the
Champlain’s gas control valve located under the unit
on the left side using a 3/8" NPT fitting. The pipe
must be sized to provide sufficient gas supply to
meet the maximum demand of the unit. The supply
line must include a manual shut-off valve and union
so that the unit can be disconnected for servicing.
Use of a dedicated sediment trap (see figure 14) is
required by code, and by Hearthstone. Damage to
components caused by the lack of a sediment
trap is not covered by warranty.
Once connected to the gas supply, the gas inlet
pressure, and manifold gas pressure, must be
tested. The gas control valve has built in pressure
taps for test gauge connections. The supply line
pressure must be tested to ensure it meets the
minimum pressure for the type of fuel in use (NG or
LP).
Pressure Measurements: To measure the gas
pressures, connect a manometer to the gas inlet tap
(6) and manifold pressure tap (7) in Figure 15.
Figure 14: Typical Sediment Trap
GAS PRESSURE ADJUSTMENT
A qualified technician must connect the heater to the
gas supply, and leak test the unit before it is
approved for use. Consult all applicable codes. The
appliance, and its main gas valve, must be isolated
from the gas supply piping system by closing its
individual manual shutoff valve during any pressure
testing of the gas supply piping system at test
pressures equal to or greater than ½ psig (3.5kPa).
Figure 15: Gas Control Valve Detail
Page 17 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
LOG PLACEMENT
Place only the decorative fiber log set supplied with
the unit in the firebox. This log set is specifically
designed for the provided pan burner. Do not use
any other type of fiber logs, wood logs, or other
materials in the firebox. If the original log set is
damaged, or broken, contact your Hearthstone
dealer for replacement. The decorative fiber log set
is durable, however, they will break easily if
subjected to rough or improper handling.
Position the log set exactly as shown in order to
obtain a pleasing flame pattern and efficient
combustion. Incorrect log placement can cause
carbon build-up; excess thermal stress on the log
set and stove parts, reduced efficiency, and high
levels of carbon monoxide. If the log set does not fit
into the firebox exactly as outlined, contact your
dealer for assistance.
INSTALLATION OF THE LOG SET
CAUTION: DO NOT PLACE EMBERS NEAR THE
PILOT.
(Refer to the figures in this section)
1. If not already opened, follow the instructions for
firebox access on page 8.
2. Remove the packaging material around the log
set assembly. Be careful not to damage the log
set when unpacking. Observe the 5 mounting
“posts”, A, B, C, D, and E.
3. Gently slide the Y-shaped Log (1) onto pins A
and C, as shown next.
4. Gently slide the longer, “half” log (2) onto pin D.
Be sure to position the rear of the log in front of
the pilot assembly and against the left side of
the firebox as shown below.
5. Gently slide the shortest of the “half” logs (3)
onto pin B as shown below.
6. Gently slide the medium length of the “half” logs
(4) onto pin E as shown next.
Page 18 of 30

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN DV Model 8301
7. Gently slide the split log (5) onto pins C and D
as shown below.
8. Place the right end of the curved log (6) onto the
protruding pin C on log 1, and rest its left end on
log 2 as shown below. Push this log back until
the curve is against the baffle.
9. Spread the Charcoal Embers evenly across the
front portion of the Pan Burner, one layer high.
You may or may not need to use all of the
Charcoal Embers. Keep the rest for use in the
future. Do not drop the embers into the burner
holes. Locate and open the bag of Platinum
Bright Embers. Pull apart small pieces of the
wool and sprinkle over the Charcoal Embers
randomly. This wool will glow brightly once the
unit is running.
10. Replace the glass frame by sliding it down the
face of the firebox and pushing the top back.
Slide the two clips back down to hold the frame
in place.
REMOVAL OF LOG SET
CAUTION! LOG SET AND CHARCOAL EMBERS
WILL RETAIN HEAT AND CAN BE VERY HOT, IF
PREVIOUSLY LIT! ALLOW AT LEAST 1 HOUR
AFTER PILOT LIGHT IS TURNED OFF BEFORE
HANDLING.
To remove the log set, follow the Installation of Log
Set instructions in the reverse order.
CAUTION! FRAGILE! HANDLE LOG SET AND
CHARCOAL EMBERS WITH CARE.
Page 19 of 30
