HearthStone Champlain User manual

Champlain Model 8304
Manual: 6400-41424
R: 5/31/2022
Champlain (Model 8304)
Gas-Fired Direct Vent Heater
Owner’s Manual
Operation & Installation Guide
Read This Owner’s Manual
Operate and Maintain This Gas Heater
According to This Instruction Manual.
Save These Instructions!
WARNING: FOLLOW THE INFORMATION IN
THESE INSTRUCTIONS EXACTLY, IF NOT, A FIRE
OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR
LOSS OF LIFE.
WARNING: DO NOT STORE OR USE GASOLINE
OR ANY OTHER FLAMMABLE VAPORS AND
LIQUIDS NEAR THIS OR ANY OTHER GAS
APPLIANCE.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone
in your building.
Immediately call your gas supplier from a phone
outside the structure. Follow your gas supplier’s
instructions.
If you cannot reach your gas supplier, call the fire
department or 911.
A qualified installer, service agency, or gas supplier must
perform installation and service of this appliance. In the
Commonwealth of Massachusetts, all installation of gas
lines and gas fittings must be performed by a licensed gas
fitter or licensed plumber.
AVERTISSEMENT: ASSUREZ-VOUS DE BIEN
SUIVRE LES INSTRUCTIONS DONNÉ DANS CETTE
NOTICE POUR RÉDUIRE AU MINIMUM LE RISQUE
D’INCENDIE OU POUR ÉVITER TOUT DOMMAGE
MATÉERIEL, TOUTE BLESSURE OU LA MORT.
AVERTISSEMENT: NE PAS ENTRESPOSER NI
UTILISER D’ESSENCE NI D’AUTRE VAPERURS OU
LIQUIDES INFLAMMABLES DANS LE VOISINAGE
DE CET APPRAREIL OU DE TOUT AUTRE
APPAREIL.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d’allumer d’appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir
des téléphones se trouvant dans le batiment où vous
vous trouvez.
Appelez immédiatement votre fournisseur de gaz
depuis un voisin. Suivez les instructions du
fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service dos incendies.
L’installation et service doit être exécuté par un qualifié
installer, agence de service ou le fournisseur de gaz.
WARNING: This product can expose you to
chemicals including glass wool fiber and carbon
monoxide which are known to the State of California to
cause cancer, birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov
California Prop 65
PFS File #20-639
Tested to: ANSI Z21.88-2017
CSA 2.33-2017, CSA 2.17-17

Page 1 of 36
Intentionally Blank

Page 2 of 36
Information Sheet
Use this page to record all relevant information concerning the purchase, installation, and maintenance of your
Champlain Model 8304 Direct -Vent heater. This information will facilitate servicing, purchase of replacement
parts, and warranty claims (if necessary). Keep your original receipt in a safe place as proof of purchase.
Serial Number:
Fuel type:
Natural Gas
Liquid Propane
Sold by:
Date of Purchase:
Address:
Phone:
E-mail
Website:
Installed by:
Date of Installation:
Address:
Phone:
E-mail
Website:
Gas Supplier:
Address:
Phone:
E-mail
Website:
Read this Owner’s Manual before installing or operating your Champlain. Retain this manual for future
reference.
SERVICE RECORD
Date
Who Performed Work
Work Performed
Notes:
WHAT WHEN
Firebox Cleaning............. annually
Glass Cleaning................ as needed
Gaskets.................... replacement as needed
Glass inspection………… yearly, replace as needed

Page 1 of 36
Specifications………………………………………………………………………………………4
Introduction………………………………………………………………………………………...5
Safety Information…………………………………………………………………………………5
Installation Preparation…………………………………………………………………………..7
Codes…………………………………………………………………………………………………………….....7
Items Required for Installation………………………………………………………………………………… 8
Packing List………………………………………………………………………………………………………. 8
Unpacking and Inspection……………………………………………………………………………………… 8
Clearances to Combustibles…………………………………………………………………….9
Hearth Requirement/Floor Protection………………………………………………………………………….. 9
Venting Information……………………………………………………………………………...10
Venting Connection……………………………………………………………………………………………. 10
Approved Systems……………………………………………………………………………………………. 11
Minimum Venting……………………………………………………………………………………………… 12
Electrical System Information………………………………………………………………….16
Gas Supply & Connections……………………………………………………………………..17
Gas Connections………………………………………………………………………………………………….17
Initial Leak Check………………………………………………………………………………………………...18
Pre-Ignition Checks ….………………………………………………………................................................18
Firebox/Log Set Placement……………………………………………………………………. 19
Installation………………………………………………………………………………………………………… 19
Removal…………………………………………………………………………………………………..............20
Initial Lighting Instructions……………………………………………………………………. 21
Manual Ignition Instructions…………………………………………………………………………………….. 21
Air Shutter/Restrictor.........................................................................................................22
Routine Maintenance and Care……………………………………………………………….. 24
Parts List………………………………………………………………………………………….. 27
Troubleshooting…………………………………………………………………………………. 28
Rating Label……………………………………………………………………………………….31
Warranty…………………………………………………………………………………………... 32

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
2
SPECIFICATIONS
Testing Agency: Intertek Testing Services NA, Inc.
(ITS)
Listing Agency: PFS TECO
Listed: Direct Vent Gas Heater
Model: Champlain Model 8304
Tested to: ANSI Z21.88-2017 / CSA 2.33-2017
Certified for Canada, CSA 2.17-2017
Approved for Mobile Home Installation
Certified for use by:
Board of State Examiners of Plumbers and Gasfitters
100 Cambridge Street, Room 1511
Boston, Massachusetts 02202
Manufactured and Warranted by:
Hearthstone Quality Home Heating Products, Inc.
317 Stafford Ave.
Morrisville, VT 05661-8695, USA
www.hearthstonestoves.com
Figure 1 Champlain DV Dimensions
Specification
NG
LP
Input rating (Btu/hr) 0-2000 ft
35,000
35,000
Input rating (Btu/hr) 2000-4500 ft
35,000
35,000
Orifice size (DMS) 0-2000 ft
31
50
Orifice size (DMS) 2000-4500 ft
31
50
Man. press. –LO setting (in.w.c./kPa)
1.3/0.32
3.2/0.8
Man. press. –HI setting (in.w.c./kPa)
3.5/0.87
9.7/2.42
Inlet press. –Minimum (in.w.c./kPa)
5.0/1.24
11.0/2.74
Minimum input rating rating (Btu/hr)
21,000
21,000

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
3
INTRODUCTION
Congratulations on your purchase of the Champlain
Model 8304, Gas-Fired Direct-Vent heater. The
Champlain, by Hearthstone, incorporates the latest in
direct vent gas technology, which will provide you
with clean, efficient heat for years to come. The
enameled or painted cast iron gives the Champlain a
pleasing look that is maintained with minimum care.
The Champlain will provide you with years of practical
and convenient service. However, as with any gas
appliance, the unit must be properly and safely
installed and maintained by qualified service
personnel to ensure safe and trouble-free operation.
CHAMPLAIN MODEL 8304 FEATURES:
1. SIT 820 valve system
2. 6-piece log set
3. Safety Barrier Screen
4. Platinum Bright Embers.
5. Optional blower
Part #
Description
8304-0010NP
Matte Black
8304-0020NP
Brown Enamel
Read this Owner’s Manual
Operate and maintain this gas heater according to the
instructions in this manual. For your safety, and years
of trouble free operation, read this manual in its
entirety.
Heater Must Be Installed and Maintained By
Qualified Service Personnel
Verify the gas connections and venting systems meet
the requirements of local, regional or national
installation codes. Qualified service personnel must
inspect the gas heater before use, and at least
annually.
Manufactured & warranted by:
Hearthstone Quality Home heating Products, Inc.
317 Stafford Ave.
Morrisville, VT 05661
www.hearthstonestoves.com
[email protected]
SAFETY INFORMATION
Your Champlain is an attractive and extremely efficient
heater, utilizing today’s best technologies. By following
a few simple safety precautions and by performing
minimal maintenance, the unit will remain appealing
while providing years of quality performance.
The installation must conform to local codes or, in the
absences of local codes, the current National Fuel Gas
Code, ANSI Z223.1 (NFPA 54) or CAN/CGA B149
Installation Code. (Installer l’appareil selon les codes
ou réglements locaux, ou, en l’absence de tells
réglements, selon les Codes d’installation CAN/CGA
B149.)
CAUTION: DO NOT USE THIS APPLIANCE IF ANY
PART WAS UNDER WATER. IMMEDIATELY CALL A
QUALIFIED SERVICE TECHNICIAN TO INSPECT THE
HEATER AND TO REPLACE ANY PART OF THE
CONTROL SYSTEM AND GAS CONTROL THAT HAS
BEEN UNDER WATER. (NE PAS SE SERVIR DE CET
APPAREIL S’IL A ÉTÉ PLONGÉ DANS L’EAU,
COMPLÉTEMENT OU EN PARTIE. APPELER UN
TECHNICIEN QUALIFIÉ POUR INSPECTOR
L’APPAREIL ET REMPLACER TOUTE PARTIE DU
SYSTÉME DE CONTRÔLE ET TOUTE COMMANDE
QUI ONT ÉTÉ PLUNGES DANS L’LAU.)
During the first few hours of operation the appliance
may produce smoke and/or odor. This is normal during
the first several burns and also after long periods when
the stove is not burned. During these initial burns,
open a window(s) to assist in the removal of the
smoke/odor.
The appliance and its individual shutoff valve must be
disconnected from the gas supply piping system
during any pressure testing of that system at test
pressures in excess of ½ psig. (3.5k Pa). The
appliance must be isolated from the gas supply piping
system by closing its individual manual shutoff valve
during any pressure testing of the gas supply piping
system at test pressures equal to or less than ½ psig
(3.5k Pa).
Fire Hazard
Do not store or use gasoline or other flammable
vapors or liquids in the vicinity ofthis appliance. Locate
the Champlain out of traffic areas and away from
furniture, draperies, clothing, and flammable material.
Vent Only to the Outside. Never vent the gas
heater to other rooms or buildings.
Service Caution
If you believe your Champlain is not, in any way,
performing properly, immediately discontinue
operation until the unit is inspected and approved by

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
4
qualified service personnel. Prior to servicing the unit,
turn the gas to the valve off, and disconnect any
electrical source. Ensure the unit is cool prior to
servicing and cleaning. Replace any safety screen,
guard, or component removed during servicing prior to
operation. Use of any components not supplied by
Hearthstone on the stove voids all warranties. Do not
substitute components.
Proper Fuel
This gas heater is designed to burn natural gas (NG)
or with conversion, liquid propane (LP). Never burn
any fuel gas not intended for use with this unit. Never
burn paper, wood, or other materials in this appliance.
This heater is factory equipped to burn natural gas
(NG). To burn propane (LP), you must install the
included LP conversion kit #93-56030
This appliance is only for use with the type(s) of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used. Cet appareil doit être atilisé uniquement
avec les types de gas indiqués sur la plaque
signalétique. Ne pas l’utiliser avec d’autres gas sauf si
un kited conversion certifié est installé. )
WARNING: THIS GAS APPLIANCE MUST NOT BE
CONNECTED TO A CHIMNEY FLUE SERVING A
SEPARATE GAS OR SOLID-FUEL BURNING
APPLIANCE
WARNING: DO NOT OPERATE THE APPLIANCE
WITH THE FRONT GLASS REMOVED, CRACKED, OR
BROKEN. REPLACEMENT OF GLASS SHOULD BE
DONE BY A LICENSED OR QUALIFIED SERVICE
PERSON. ONLY OPEN FRONT FOR ROUTINE
SERVICE. DO NOT SLAM FRONT OR STRIKE
GLASS.
WARNING: HEARTHSTONE RECOMMENDS THAT
ONLY AN NFI CERTIFIED SERVICE TECHNICIAN
INSTALLS, AND REPAIRS THIS APPLIANCE. A
QUALIFIED SERVICE TECHNICIAN MUST INSPECT
THE APPLIANCE BEFORE USE, AND AT LEAST
ANNUALLY. MORE FREQUENT CLEANING MAY BE
REQUIRED DUE TO EXCESSIVE LINT FROM
CARPETING, BEDDING MATERIAL, PETS, ETC. IT IS
IMPERATIVE THAT THE CONTROL
COMPARTMENTS, BURNERS, AND CIRCULATING
AIR PASSAGES OF THE APPLIANCE ARE KEPT
CLEAN AND FREE OF OBSTRUCTIONS.
(S’ASSURER QUE LE BRÛLEUR ET LE
COMPARTIMENT DES COMMANDES SONT
PROPRES. VOIR LES INSTRUCTIONS
D’INSTALLATION ET D’UTILISATION QUI
ACCOMPAGNENT L’APPAREIL.)
Hot Surfaces
Certain exposed surfaces of the Champlain will reach
high temperatures during normal operation.
Clearances to combustibles must be maintained, as
specified in the “Clearances To Combustibles” section
of this manual.
DUE TO HIGH TEMPERATURES THE APPLIANCE
SHOULD BE LOCATED OUT OF TRAFFIC AND
AWAY FROM FURNITURE, DRAPERIES, CLOTHING
AND FLAMMABLE MATERIALS. EN RAISON DES
TEMPÉRATURES ÉLEVÉES, L’APPAREIL DEVRAIT
ÊTRE INSTALLÉ DANS UN ENDROIT OÙ IL Y A PEU
DE CIRCULATION ET LOIN DU MOBILIER ET DES
TENTURES
CHILDREN AND ADULTS SHOULD BE ALERTED TO
THE HAZARDS OF HIGH SURFACE
TEMPERATURES AND SHOULD STAY AWAY TO
AVOID BURNS TO SKIN OR CLOTHING IGNITION.
LES ENFANTS ET LES ADULTES DEVRAIENT ÊTRE
INFORMÉS DES DANGERS QUE POSENT LES
TEMPÉRATURES DE SURFACE ÉLEVÉES ET SE
TENIR À DISTANCE AFIN D’ÉVITER DES BRÛLURES
OU QUE LEURS VÊTEMENTS NE S’ENFLAMMENT.
CAREFULLY SUPERVISE YOUNG CHILDREN WHEN
THEY ARE IN THE SAME ROOM AS THE APPLIANCE.
TODDLERS, YOUNG CHILDREN, AND OTHERS MAY
BE SUSCEPTIBLE TO ACCIDENTAL CONTACT
BURNS. A PHYSICAL BARRIER IS
RECOMMENDED IF THERE ARE AT RISK
INDIVIDUALS IN THE HOUSE. TO RESTRICT
ACCESS TO A FIREPLACE OR STOVE, INSTALL AN
ADJUSTABLE SAFETY GATE TO KEEP TODDLERS,
YOUNG CHILDREN, AND OTHER AT RISK
INDIVIDUALS OUT OF THE ROOM AND AWAY FROM
HOT SURFACES. LES JEUNES ENFANTS
DEVRAIENT ÊTRE SURVEILLÉS ÉTROITEMENT
LORSQU’ILS SE TROUVENT DANS LA MÊME PIÈCE
QUE L’APPAREIL. LES TOUT PETITS, LES JEUNES
ENFANTS OU LES ADULTES PEUVENT SUBIR DES
BRÛLURES S’ILS VIENNENT EN CONTACT AVEC LA
SURFACE CHAUDE. IL EST RECOMMANDÉ
D’INSTALLER UNE BARRIÈRE PHYSIQUE SI DES
PERSONNES À RISQUES HABITENT LA MAISON.
POUR EMPÊCHER L’ACCÈS À UN FOYER OU À UN
POÊLE, INSTALLEZ UNE BARRIÈRE DE SÉCURITÉ;
CETTE MESURE EMPÊCHERA LES TOUT PETITS,
LES JEUNES ENFANTS ET TOUTE AUTRE
PERSONNE À RISQUE D’AVOIR ACCÈS À LA PIÈCE
ET AUX SURFACES CHAUDES.
CLOTHING OR OTHER FLAMMABLE MATERIAL
SHOULD NOT BE PLACED ON OR NEAR THE
APPLIANCE. ON NE DEVRAIT PAS PLACER DE
VÊTEMENTS NI D’AUTRES MATIÈRES
INFLAMMABLES SUR L’APPAREIL NI À PROXIMITÉ.
CLEAN THE AREA AROUND, UNDER, AND BEHIND
THE UNIT ON A REGULAR BASIS TO
PREVENT THE ACCUMULATION OF DUST AND
LINT.

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
5
Ceramic Logs, Burner, & Baffle
If the decorative ceramic log or burner material
supplied with the Champlain is damaged or parts are
missing, they must be replaced with the same, or
approved Hearthstone replacement parts. These
components affect the combustion quality and safety
of the heater. Do not replace ceramic logs, the burner,
or baffle with unapproved ceramic components or any
other material. We recommend you always wear
gloves and safety goggles while handling the ceramic
log set and burner materials.
Electrical Hazard
If present, any three-prong grounded plug must be
plugged directly into a properly grounded three-prong
receptacle. Do not cut or remove the grounding prong
from any plug or otherwise attempt to circumvent the
grounding protection provided with the unit.The Stowe
must be electrically grounded in accordance with local
codes, or in the absence of local codes, with the
National Electrical Code, ANSI.NFPA 70 in the U.S. or
CSA C22.1 Canadian Electrical Code in Canada.
Do Not Light Pilot or Burner by Hand
The pilot light on this gas heater is lit by using the
remote control as described elsewhere in this manual.
Never attempt to light the pilot or main burner by hand
with a match or lighter.
INSTALLATION PREPARATION
CODES
Adhere to all local codes or, in their absence, the
latest edition of THE NATIONAL FUEL GAS CODE
ANSI Z223.1 (NFPA 54) or CAN/CGA B149 (Installer
l’appareil selon les codes ou règlements locaux, ou, en
l’absence de tels règlements, selon les Codes
d’installation CAN/CGA-B149.)
Installation Codes can be obtained from:
AMERICAN NATIONAL STANDARDS
INSTITUTE, INC.
1430 BROADWAY
NEW YORK, NY 10018
www.ansi.org
NATIONAL FIRE PROTECTION ASSOCIATION,
INC.
BATTERY MARCH PARK
QUINCY, MA 02269
www.nfpa.org
The appliance when installed must be electrically
connected and grounded in accordance with local
codes or, in the absence of local codes, with the
current NFPA 70-National Electrical Code or CSA
C22.1-Canadian Electric Code.
Mobile Home Installations
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only),
where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gasses, unless a certified
kit is used.
A manufactured home (mobile) OEM installation must
conform to the Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280 (U.S.) or
Standard for Manufactured Home Installation,
ANSI/NCBCS A225.1 or Standard for Gas Equipped
Recreational Vehicles and mobile Housing, CSA
Z240.4.CAN/SCA Z240 MH (Canada). This appliance
is only for use with the type(s) of gas indicated on the
rating plate. Cet appareil peut être installé comme du
matériel d’origine dans une maison préfabriquée (É.-
U. seulement) ou mobile et doit être installé selon les

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
6
instructions du fabricant et conformément à la norme
Manufactured Home Construction and Safety
Standard, Title 24 CFR, Part 3280 aux États-Unis ou à
la norme CAN/CSA-Z240 Série MM, Maisons mobiles
au Canada. Cet appareil doit être utilisé uniquement
avec les types de gaz indiqué s sur la plaque
signalétique.
This appliance is equipped for use at 0 to 2000 feet (0-
610 meters) altitude. (Cet appareil est equipè pour des
altitudes compries entre 0 et 2000 pieds (0-610 m)
seulement.)
Items Required for Installation
External regulator (for propane (LP) only)
LP conversion kit (for propane only))
Piping which complies with local codes
Pipe sealant approved for use with
propane (LP) (resistant to sulfur compounds).
Manual shutoff valve
Sediment trap (see page 18)
Pipe wrench
Phillips head screwdriver
7/16-inch wrench
5/23” (4mm) allen wrench
Other parts as required by local code
Safety Glasses
Gloves
Packing List
1- Champlain 8304 Gas-Fired Heater
1- Pan Burner
1- Owner’s Packet (manual, warranty card)
1- LP Conversion Kit
6- Decorative Ceramic Logs (in separate box)
1- Bag of Platinum Bright Embers
Note: Vent kits and components are supplied
separately. Failure to use the venting components
approved by Hearthstone for this appliance will
void your warranty.
Unpacking and Inspection
Hearthstone packages your Champlain to withstand
normal shipment without damage. However, damage
can still occur during transit. Take care to inspect for
damage when unpacking and installing the unit.
DO NOT INSTALL, OR PUT INTO SERVICE, A
DAMAGED OR INCOMPLETE HEATER.
Remove the shrink-wrap and other packaging
materials taking care not to damage the stove’s finish.
Inspect the Champlain for visible or concealed
damage. The unit should be square and true. The
sheet metal parts should be smooth and free of bends
and dents. Any enameled cast iron should be free of
chips or cracks. If visible or concealed damage is
found or suspected, contact your dealer for
instructions.
Always use gloves and eye protection when handling
the decorative ceramic fire logs and burner. Use care
when handling these parts as they are fragile and
subject to damage and breakage if handled roughly.
See the firebox access instructions on page 9. Unpack
and inspect the logs for damage. Inspect the metal
burner as well. Open the other boxes and inspect the
components. If log, burner or any other component
damage is encountered, contact your dealer for a
replacement. Otherwise, set the logs and other
components aside until called for during the
installation.
Dismounting from Pallet
With the accessory boxes removed and set aside,
remove the four lag screws that fasten the unit to the
pallet. Take care not to mar or chip the stove’s finish.
Have someone help lift the stove off the pallet, taking
care to avoid damaging components mounted under
the stove.
INSTALLER: Leave this manual with the appliance.
INSTALLATEUR : Laissez cette notice avec
l’appareil.
CONSUMER: Retain this manual for future reference.
CONSOMMATEUR : Conservez cette notice
pour consultation ultérieure
Firebox Access
1. Remove top of the stove (lift off). Set carefully
aside on a soft surface.
Figure 2 –Top Removal
2. Release the front panel by lifting up and off of the
stove body. Set aside on a soft surface.

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
7
Figure 3 –Front Panel Removal
3. Remove glass by rotating retention clips up until
clear of the clip slot. Lean the glass away from the
firebox at the top and pick straight up off of the
stove.
Figure 4 –Glass Removal
4. Reinstall by reversing the previous steps.
Clearances to Combustibles
Note: Ensure clearances are in accordance with
local installation codes andthe requirements of the
gas supplier. Dégagement conforme aux codes
d’installation locaux et aux exigences du
foumisseunde gaz.
Due to high surface temperatures, locate the unit
out of traffic areas and away from furniture and
draperies. Do not place clothing and other
flammable material on or near the heater. When
positioning the unit always maintain adequate
clearances around air openings into the
combustion chamber and allow for adequate
ventilation. Minimum clearances to combustibles
must be maintained as shown in Figures 5 - 8.
Note: The rear clearance to combustibles is
determined by either the unit’s or the vent pipe’s
minimum clearance, depending on whether the
installation calls for vertical rise within the room or a
rear exit, through-the-wall vent pipe. Ensure you
consider the need for access to the gas control valve
access door on the front of the unit as well as full
access for periodic cleaning and servicing. Also
consider clearance for the blower assembly if present,
or planned in the future
CAUTION: THESE CLEARANCES REPRESENT
MINIMUM DISTANCES IN ALL CASES, WHICH,
THROUGH TESTING IN AN INDEPENDENT
LABORATORY TO ANSI AND CSA STANDARDS,
WILL PREVENT FIRE OR SPONTANEOUS
COMBUSTION. WE DO NOT CONTROL THE
COMBUSTIBLE MATERIALS EXPOSED TO HEAT
BY THIS PRODUCT; THEREFORE, AN
ASSESSMENT MUST BE MADE BY THE INSTALLER
TO PREVENT CONSEQUENTIAL DAMAGE OF
WALLS AND FLOORING.
Hearth Requirement/Floor
Protection
You can place the Champlain directly on any non-
combustible surface or on a wood floor. When placing
the Stowe on any other type of combustible surface
you must install a panel made of metal, wood, stone,
or glass under the appliance. The panel must
extending the full width and depth of the appliance.
Installations must meet all local codes.
Figure 5 - Minimum Wall Clearances Horizontal Vent

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
8
Figure 6 –Minimum Snorkel Wall Clearances
Figure 7 - Horizontal Vent Mantle Clearance
Figure 8 - Snorkel Termination Mantle Clearance
The corner clearance for the Champlain 8304 is 4”,
measured from the edge of the firebox to the adjacent
wall.
Installing the stove in a room with Luxury Vinyl Plank
(LVP) or Luxury Vinyl Tile (LVT) flooring requires a
minimum clearance from the stove to the LVP or LVT
flooring. LVP and LVT flooring begins to warp at 110
degrees Fahrenheit. The minimum required clearance
for the LVP or LVT flooring to the front glass of the
stove is 6”.
Venting Components &
Configuration
Do not vent the Champlain jointly with any other solid
fuel or gas appliance. Vent the stove directly to the
outside of the building using a proper termination as
listed in this manual. The only types of venting pipe
approved for use with your Champlain Direct-Vent
stove are those listed in this manual. The venting
configuration diagram is shown in Figures 9 - 13. After
determining the proper venting configuration for your
stove, select the vent system that will accommodate
your installation.
CAUTION: ENSURE NO WIRING OR PLUMBING IS
IN THE CHOSEN LOCATION.
CAUTION: DO NOT RECESS VENTING
TERMINATIONS INTO A WALL OR SIDING.
Note: If you need further direction for installation,
please refer to the venting instructions provided with
the venting components.
Vent Connection
The Champlain Direct Vent Model 8304 is approved
for installation only with the vent connecting
components listed in this manual. Use the following
instructions along with the pipe manufacturer’s
instructions to complete the installation.
The starter collar is factory installed. Install the rest of
the vent system according to the manufacturer’s
instructions.
Specified Venting Manufacturers
This heater is approved for installation only with the
venting components provided by manufacturers listed
on this page.
Simpson Dura-Vent, Inc.
P.O. Box 1510
Vacaville, CA 95696-1510 800-835-4429

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
9
American Metal Products (AmeriVent)
8601 Hacks Cross Rd.
Olive Branch, MS 38654 800-423-4270
Selkirk Corporation
1301 W. President George Bush Hwy, Suite 330
Richardson, TX 75080-1139 800-992-8368
Security Chimneys International Ltd (Secure Vent)
2125 Monterey, Laval, Quebec
Canada, H7L 3T6 450-973-9999
ICC, Inc.
400 J-F Kennedy, St. Jerome, Quebec
Canada, J7Y 4B7 450-565-6336
Metal-Fab, Inc.
P.O. Box 1138
Wichita, Kansas 67201 316-943-2351
Acceptable Direct-Vent Termination Cap
Roof Locations
The vent/air intake termination clearances above the
high side of an angled roof as follows:
Roof Pitch
Feet
Meters
Flat to 6/12
1
0.3
7/12 to 9/12
2
0.6
10/12 to 12/12
4
1.2
13/12 to 16/12
6
1.8
17/12 to 21/12
8
2.4
Figure 9: Termination Cap clearances
Approved Venting System Components
(The following are components that are available, BUT NOT
necessary for all installations)
900 Elbow
Vertical
Vent Cap
450 Elbow
36”
Snorkel
6" Straight
Vinyl
Siding
Standoff
4” x 6 5/8"
9" Straight (Simpson only)
12" Straight
Round
Ceiling
Support
24" Straight
Thimble
Covers
36" Straight
Wall
thimble
48" Straight
Horizontal
Vent Cap
11"-14 5/8" Adjustable
Pipe
Chimney Liner System
Direct-Vent Chimney Liner Termination Kit
Chimney Liner Flex
Co-Linear Flex Connector
Axial to Co-Linear Appliance Connect (Masonry
approved, not to exceed 16’ measured from stove
top).
IF THE VENT SYSTEM IS DISASSEMBLED FOR ANY
REASON,IT MUST BE REINSTALLED PER THE
INSTRUCTIONS PROVIDED FOR IN THE INITIAL
INSTALLATION OR IN THIS MANUAL.
Vent Configuration Options
I. STANDARD HORIZONTAL INSTALLATION
Note: Install the 45º elbow over the outer collar.
Place the elbow so that the twist lock end is
pointing straight up. Install the 2’ pipe section into
this elbow by fully inserting it, and turning
approximately ¼ turn clockwise until the two
sections are fully locked. Install the 90º elbow in
similar fashion with the opening pointing to the
rear.
Note: Ensure there is no wiring or plumbing in
the chosen wall location.
Move the stove and pipe assembly back until the 90º
elbow is flush to the wall. Ensure the 2’ vertical pipe is
still parallel to the wall. Draw a circle around the pipe

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
10
where it touches the wall. Use the center of this circle
as the center point of the 10” x 10” square wall pass
through.
Cut and frame the wall for the vent pipe. Install the
horizontal vent termination on the outside of the wall.
Ensure both of the retaining straps extend through the
wall pass through to the inside of the wall.
Before attaching the vent termination to the outside of
the house, run a bead of non-hardening mastic around
the outside edges, between the vent termination and
the wall. The arrow on the end cap should point up.
Secure the cap to the wall with the appropriate screws.
Put the adjustable (11”-14”) pipe into the horizontal
vent cap, (the vent pipe must extend into the horizontal
vent cap a minimum of 1 ¼”). Move the stove and vent
pipe into position, insert the adjustable (11”-14”) pipe
into the 90° elbow, twist lock it.
Secure the straps from the horizontal vent termination
to the interior pipe with two sheet metal screws,
keeping the screws as close to the wall thimble as
possible. Bend or cut the excess strapping so the
thimble cover will fit properly. Screw the thimble cover
to the wall.
The adjustment range for wall thickness for
this configuration is 3”min to 9”max.
II. FIREPLACE VENTING INSTALLATIONS
-40' maximum system height (without offsets)
-14' maximum offset (refer to Figures 10 - 11)
-Maximum rise to run = 1 to 5 (refer to Figures 10
-13)
-The termination must meet the requirements
outlined in Figures 7 - 9.
Figure 10: Vertical Venting Rules
III. Vertical Termination Venting
Configurations
-40' maximum system height (without offset)
IV. HORIZONTAL TERMINATION VENTING
CONFIGURATIONS
•A minimum of 24" rise is required (with or w/o
offsets)
•40' maximum system height (without offsets)
•Maximum rise to run = 1 to 5
•The termination must meet the requirements
outlined in Figures 7 - 9. Use a vinyl siding stand
off when installing against vinyl siding.
•Horizontal sections require a 1/4" rise every 12"
of horizontal run.
•For each 90° elbow after the second, remove 5'
from horizontal run.
•Use with snorkel termination 45" maximum
horizontal run
Figure 11: Approved DV Vertical Co-Axial
Termination Configurations

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
11
Figure 12: Approved DV Venting Alternate Configurations for Vertical Termination

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
12
Figure 13: Venting Configuration and Restrictor Settings*
* To adjust your restrictor for optimum flame appearance, follow the instructions in Restrictor Plate, p.23

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
13
Figure 14 - Acceptable Direct Vent Terminal Vent Cap Locations
A = Clearance above grade, veranda, porch, deck,
or balcony: 12 inches (30cm) minimum.
B = Clearance to window or door that may be
opened: **Min. 9 inches U.S./*12 inches (30cm)
CAN. We recommend 12 in, minimum to prevent
condensation on the window.
C = Clearance to permanently closed window:
**Min. 9 inches, U.S./*12 inches (30cm) CAN.
We recommend 12 in. minimum to prevent
condensation on the window.
D = Vertical clearance to ventilated soffit located
above the termination within a horizontal distance of
2 feet (60cm) from the center line of the termination:
18 inches (46cm) minimum.
E = Clearances to unventilated soffit: 12 inches
(30cm) minimum.
F = Clearance to outside corner: **Min. 9 inches,
U.S./12 inches (30cm) CAN. We strongly
recommend 12 inches, particularly where windy
conditions prevail.
G = Clearance to inside corner: **Min. 6 inches,
U.S./12 inches (30cm) CAN. We strongly
recommend 12 inches, particularly where strong
winds prevail.
H = *Not to be installed within 15 feet (4.5m) above
a meter/regulator assembly within 3 feet (91cm)
horizontally from the center line of the regulator.
I = Clearance to service regulator vent: 3 feet
(91cm)
J = Clearance to non-mechanical air supply inlet to
building or the combustion air inlet to any other
appliance: 12inches (30cm) minimum.
K = Clearance to a mechanical air supply inlet:
**Min. 3 feet (91cm) above if within 10 feet
horizontally, U.S./*6 feet (1.83m) CAN minimum.
L = ¹Clearance above paved sidewalk or a paved
driveway located on public property: 7 feet (2.1m)
minimum.
M = ²Clearance under veranda, porch, deck, or
balcony: 12 inches (30cm) minimum.
*In accordance with CSA B149 Installation codes.
**In accordance with the current ANSI Z223.1/NFPA 54,
National Fuel Gas Code. Note: Local Codes and
Regulations may require different clearances.
¹A vent shall not terminate directly above a sidewalk or
driveway which is located between two single family
dwellings and serves both dwellings
²Only permitted if veranda, porch, deck or balcony, is fully
open on a minimum of two sides beneath the floor.*

Hearthstone Quality Home Heating Products, Inc CHAMPLAIN Model 8304
14
ELECTRICAL SYSTEM INFORMATION
CAUTION: LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN SERVICING CONTROLS. WIRING ERRORS
CAN CAUSE IMPROPER AND DANGEROUS OPERATION. VERIFY PROPER OPERATION AFTER SERVICING.
(ATTENTION: AU MOMENT DE L’ENTRETIEN DES COMMANDES, ÉTIQUETEZ TOUS LES FILS AVANT LE
DÉBRANCHEMENT. DES ERREURS DE CÂBLAGE PEUVENT ENTRAÎUN FONCTIONNEMENT INADEQUATE ET
DANGEREUX.)
The proper location of wire connections is shown in the following figure.
Figure 15 –Champlain 8304 Wiring Diagram

Hearthstone Quality Home Heating Products, Inc. CHAMPLAIN Model 8304
15
Gas Supply & Connections
Connection Location
The gas supply connection is made to the
Champlain’s gas control valve under the bottom right
center of the unit using a 3/8” male NPT fitting. The
supply line should be ½” diameter, or appropriately
sized to provide a sufficient gas supply to meet the
maximum demand of the unit without undue loss of
pressure. We recommend a flexible line to avoid
undue mechanical load on the valve and to ease
thread alignment, but refer to local codes.
The Champlain is factory equipped to use natural gas
(NG) and requires conversion for use with propane
(LP). A propane (LP) fuel conversion kit is included
with your stove purchase.
Gas Supply
This appliance and its individual shutoff valve must be
disconnected from the gas supply piping system
during any pressure testing of that system at test
pressures in excess of ½ psig. The Champlain must
be isolated from the gas supply piping system by
closing its individual manual shutoff valve during any
pressure testing of the gas supply piping system at
test pressures equal to or greater than ½ psig. Over
pressurizing can damage the control resulting in
leakage or control malfunction.
NOTICE: A QUALIFIED TECHNICIAN MUST
CONNECT THE HEATER TO THE GAS SUPPLY
AND LEAK TEST THE UNIT BEFORE IT IS
APPROVED FOR USE. CONSULT ALL CODES.
WARNING: THE UNIT MUST BE INSTALLED AND
CONNECTED IN ACCORDANCE WITH LOCAL
CODES, OR IN THE ABSENCE OF LOCAL CODES,
WITH THE MOST CURRENT EDITION OF THE
NATIONAL FUEL GAS CODE ANSI Z223.1 (NFPA
54) OR CAN/CGA B149 INSTALLATION CODE.
INSTALLER L'APPAREIL SELON LES CODES OU
RÈGLEMENTS LOCAUX, OU, EN L'ABSENCE DE
TELS RÈGLEMENTS, SELON LES CODES
D'INSTALLATION CAN/CGA-B149
NFPA Code and Hearthstone require the use of a
dedicated sediment trap just upstream of the unit.
Damage to the valve, or other components due to
the lack of a sediment trap are not covered by
warranty (see figure 17).
High Altitude Installations
For high altitude installations consult the local gas
distributer or the authority having jurisdiction for
proper rating methods.
The decreased atmospheric pressure at higher
altitudes affects the heat value of fuel gases. Gas
suppliers typically derate the gas intended for use at
elevations above 2000 feet (610 meters). This is not
necessary with the Champlain.
Figure 16 –SIT 820 Valve

Hearthstone Quality Home Heating Products, Inc. CHAMPLAIN Model 8304
16
WARNINGS
•Fire or Explosion Hazard. Can cause property
damage, severe injury, or death. Do NOT bend
tubing at gas valve connection point after
compression fitting has been tightened. This
can result in gas leakage at the connection.
•Use new properly prepared pipe free from metal
or material chips. When tubing is used, assure
that ends are square, de-burred and clean. All
tubing bends must be smooth and free of
distortion.
•Do NOT over tighten connections.
Over tightening can damage the control body
resulting in leakage or control malfunction.
•Do NOT remove screws from the gas valve. Do
NOT adjust and/or alter any components
marked with tamper indicating paint. Motor
knob is not to be removed.
•Turn off gas supply at the appliance service
valve before starting installation, and perform a
Gas Leak Test after the installation is complete.
•Install the sediment trap (where required) in the
gas supply line to prevent contamination of the
gas valve (see figure 17).
•Use only your hand to push in or turn, the
gas Control knobs. Never use tools. If a
knob will not push in or turn by hand, do
NOT try to repair it. Call a qualified service
technician. Force or attempted repair will
void warranty and can result in a fire or
explosion.
GAS CONNECTIONS
Connection Main Gas (Tubing connections)
1. Do NOT use pipe joint compound or
Teflon®/PTFE tape.
2. Slip nut and ferrule over tubing.
3. Slide nut and ferrule into place, and insert
tubing into inlet/outlet connection until it
bottoms. Turn until finger-tight.
4. Use a wrench to tighten nut about 1 turn beyond
finger tight.
Connection Main Gas (Pipe Connections)
1. Do NOT use Teflon®/PTFE tape.
2. Pipe to be inserted into the valve must be the
proper thread length and to gauge. Thread
that IS cut too long can cause distortion or
malfunction if inserted too deeply.
3. Apply a moderate amount of approved
pipe\sealant to the pipe only, leaving the
two end threads bare.
4. Connect pipe to valve inlet and outlet.
Figure 17 –Sample Gas Supply Sediment Traps
PERFORM INITIAL GAS LEAK TEST
1. Check carefully for gas leaks immediately after
the appliance has been installed and the gas
turned on. Do this before attempting to operate
the appliance or other gas burning device.
1. Use an approved non-corrosive leak detection
fluid, or other approved leak detection method,
around the diaphragm flanges, pipe connections,
seal cap, and all other joints. Bubbles indicate a
leak.
2. If no leakage is detected, proceed with the
instructions listed on page 21 to light the main
burner and perform a secondary leak check of the
appliance gas supply system.
5. If a leak is detected, tighten pipe connections
(including adapters) according to "GAS
CONNECTIONS" (page 18).

Hearthstone Quality Home Heating Products, Inc. CHAMPLAIN Model 8304
17
WARNING
Absolutely no leakage should occur, otherwise
there is a danger of fire or explosion depending upon
conditions. Never use if leakage is detected.
Log Set Placement
CAUTION: FRAGILE! HANDLE LOG SET WITH
CARE. ALWAYS WEAR GLOVES AND SAFETY
GOGGLES WHILE HANDLING THE LOG SET.
WARNING: FAILURE TO POSITION THE PARTS IN
ACCORDANCE WITH THESE DIAGRAMS OR
FAILURE TO USE ONLY PARTS SPECIFICALLY
APPROVED WITH THIS APPLIANCE MAY RESULT
IN PROPERTY DAMAGE OR PERSONAL INJURY.
AVERTISSEMENT. RISQUE DE DOMMAGES OU DE
BLESSURES SI LES PIÈCES NE SONT PAS
INSTALLÉES CONFORMÉMENT À CES SCHÉMAS
ET OU SI DES PIÈCES AUTRES QUE CELLES
SPÉCIFIQUEMENT APPROUVÉES AVEC CET
APPAREIL SONT UTILISÉES.
Place only the ceramic log set supplied with the unit
in the firebox. Do not place any other ceramic logs,
wood logs, or other materials in the firebox. If the log
set is damaged or broken contact your dealer for
replacement. The ceramic logs will last a long time;
however, they will break if subjected to rough or
improper handling. Exact positioning of the log set is
required in order to obtain a pleasing flame pattern
and efficient combustion. Incorrect log placement
may cause carbon build-up; excess thermal stress on
the log set and stove parts, reduced efficiency, and
high levels of carbon monoxide. Position the log set
exactly as shown in order to obtain a pleasing flame
pattern and efficient combustion. Incorrect log
placement can cause carbon build-up; excess
thermal stress on the log set and stove parts, reduced
efficiency, and high levels of carbon monoxide. If the
log set does not fit into the firebox exactly as outlined,
contact your dealer for assistance.
Installation of the Log Set
CAUTION: DO NOT PLACE EMBERS NEAR THE
PILOT.
(Refer to the figures in this section)
1. If not already opened, follow the instructions for
firebox access on page 8.
2. Remove the packaging material around the log
set assembly. Be careful not to damage the log
set when unpacking. Observe the 5 mounting
“posts”, A, B, C, D, and E.
3. Gently slide the Y-shaped Log (1) onto pins A and
C, as shown next.
4. Gently slide the longer, “half” log (2) onto pin D.
Be sure to position the rear of the log in front of
the pilot assembly and against the left side of the
firebox as shown below.
