***CONTACT OUR CUSTOMER SERVICE TEAM
IF ANY PARTS ARE MISSING OR DAMAGED***
- Order form and warranty at back of manual -
Call: 1-877-743-3400 email: [e-mail]
OPTION 2:
DOOR LOCATION
CENTERED ON EAVE WALL
OPTION 3:
DOOR LOCATION
RIGHT SIDE OF EAVE WALL
OPTION 1:
DOOR LOCATION
LEFT SIDE OF EAVE WALL
01/11/2022
KEEP THIS MANUAL FOR FUTURE REFERENCE
ACTUAL FLOOR SIZE IS 120" x 144" (304,8 x 365,8 cm)
16408
BEFORE YOU BEGIN
IMPORTANT!
READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY.
HILLSDALE GABLE 10' x 12' (304,8 x 365,8 cm)
A Backyard Products Company
• BUILDING RESTRICTIONS AND APPROVALS
Be sure to check local building department and homeowners association for specic restrictions and/ or requirements before building.
• ENGINEERED DRAWINGS
Contact our Customer Service Team if engineered drawings are needed to pull local permits.
• SURFACE PREPARATION
To ensure proper assembly you must build your shed on a level surface.
Recommended methods and materials to level your shed are listed on page 9.
• CHECK ALL PARTS
Inventory all parts listed on pages 3-5.
• ADDITIONAL MATERIALS
You will need additional materials to complete your shed. See pages 6 for required and optional materials and quantities.

2
TOOLS
Safety! Always use approved safety glasses during assembly.
OptionalRequired
HELPFUL REMINDER SYMBOLS
Look for these symbols for helpful reminders throughout this manual.
ORIENT LUMBER AND TRIM FOR BEST APPEARANCE
= Assistance Required; two or more people.
= Ensure squareness.
= Important required step or operation.
= Helpful assembly hint.
= Mark part with pencil.
= Beginning of steps for assembly or installation.
= You have nished the assembly or installation.
= Level
❑Gloves
Framing lumber is graded for structural strength and not appearance. Exterior trim is graded for one good side.
Always install the material leaving the best edge and best surface visible. Please remember that these blemishes in no way
negatively affect the strength or integrity of our product. (See Fig. A, B, C.)
A
❑Safety Glasses
❑Tape Measure
❑Paint Tools
❑Ladder
❑Caulk Gun
❑Hammer
❑Level
FINISH
BEGIN
❑Pencil
❑Phillips
Screwdriver ❑Tool Belt/
Nail Pouch
❑Chalk Line
❑Nail Gun
• gun nails
❑Tin Snips
(for drip edge)
❑Square or
❑Utility Knife
❑Shingle Blades
B C
❑Drill / Driver
❑1/8" Drill Bit
❑#2 Philips Drive Bit
❑1/4" Drill Bit
❑5/16" Drill Bit
❑1/2" Drill Bit
❑Hand Saw

3
WOOD SIZE CONVERSION CHART
Nominal Board Size Actual Size
PARTS IDENTIFICATION AND SIZES
RS RS
Part identication
letters are stamped on some parts.
Check these locations for
part stamp.
WALLS
x1 2 x 4 x 84" (5,1 x 10,2 x 213,4 cm)
TO
x25 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm)
AI
x8 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm)
YFA
x2 2 x 4 x 67" (5,1 x 10,3 x 170,2 cm)
AM
x2 2 x 4 x 44-3/8" (5,1 x 10,2 x 112,7 cm)
HVC
PARTS LIST
INVENTORY YOUR PARTS before you begin.
We suggest sorting parts by the category they are listed in.
RAFTERS
TRIM
x3 2 x 4 x 7" (5,1 x 10,2 x 17,8 cm)
AL
x3 2 x 4 x 6-1/2" (5,1 x 10,2 x 16,51 cm)
UY
x4 3/8 x 1-3/4 x 81-7/8" (1 x 4,4 x 208 cm)
1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) Gauge Block for 3/4" (1,9 cm) measurement
x1 GAA
3/4"
(1,9 cm)
x12 6 x 24" (15,2 x 61 cm) OSB OR WOOD GRAIN
1 x 3 x 72" (1,6 x 7,6 x 182,9 cm)
x2 HJ
x4 3/8 x 7-7/8 x 73-5/16" (1 x 20 x 186,2 cm)
x4 3/8 x 5-7/8 x 73" (1 x 14,9 x 185,3 cm)
x2 3/8 x 4-3/4 x 75-7/8" (1 x 12,1 x 192,7 cm)
x2 3/8 x 4-3/4 x 75-7/8" (1 x 12,1 x 192,7 cm)
x4 3/8 x 4-3/4 x 80-7/8" (1 x 12,1 x 205,3 cm)
x12 2 x 4 x 4-7/8" (5,1 x 10,2 x 12,4 cm)
CLA
x4 3/8 x 1-3/4 x 82-1/2" (1 x 4,4 x 209,6 cm)
x4 2 x 4 x 22-1/2" (5,1 x 10,2 x 57,1 cm)
AO
x4 2 x 4 x 23-1/4" (5,1 x 10,2 x 59,1 cm)
UV
x2 2 x 4 x 20-3/8" (5,1 x 10,2 x 51,8 cm)
JBD
x2 2 x 4 x 24" (5,1 x 10,2 x 61 cm)
RL
x2 2 x 4 x 28" (5,1 x 10,2 x 71,1 cm)
RR
x1 2 x 4 x 36" (5,1 x 10,2 x 91,4 cm)
SL
x2 2 x 4 x 35" (5,1 x 10,2 x 88,9 cm)
QT
x2 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm)
SP
x1 7/16 x 3-1/4 x 66-3/4" (1,1 x 8,3 x 169,5 cm)OSB
x14 2 x 4 x 75-1/4" (5,1 x 10,2 x 191,1 cm)
ECN
x8 2 x 4 x 75-1/4" (5,1 x 10,2 x 191,1 cm)
ECA
x4 2 x 4 x 92-5/8" (5,1 x 10,2 x 235,3 cm)
TJ
x4 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm)
TP

4
WINDOW & DOOR TRIM
NOTE: Panel parts are not stamped.
WALL PANELS & DOORS
3/8 x 48 x 84"
(1 x 121,9 x 213,4 cm)
x4 19/32 x 2-1/2 x 28-1/2" (1,5 x 6,3 x 72,4 cm)
ROR
x4 19/32 x 2-1/2 x 30-1/8" (1,5 x 6,3 x 76,5 cm)
AZ
x1 19/32 x 2-1/2 x 39-3/8" (1,5 x 6,3 x 100 cm)
GEA
LRA
x2 1 x 4 x 69-3/4" (2,5 x 10,2 x 177,2 cm)
ZJ
x2 19/32 x 3 x 72" (3,2 x 7,6 x 182,9 cm)
x3 19/32 x 2-1/2 x 26-5/8" (1,5 x 6,3 x 67,6 cm)
AH
x2 19/32 x 2-1/2 x 62" (1,5 x 6,3 x 157,5 cm)
AHR
x1 19/32 x 2-1/2 x 62" (1,5 x 6,3 x 157,5 cm)
AHL
OO
x3 69" (175,3 cm) Door Stiffener
x1
x5 x1 x1
x2
x1
UNIVERSAL DOOR
Right / Left
Painted
Black
on Ends
x1
LEFT DOOR x1
RIGHT DOOR
Painted
Green on End Painted Red on End
x1 3/8 x 23-7/8 x 84"
(1 x 60,6 x 213,4 cm)
x23/8 x 11-7/8 x 84"
(1 x 30,2 x 213,4 cm)
x2 x2x2

5
x335
x92
x28
x128
x150
x58
VENT/ DOOR HARDWARE/ WINDOWS
FASTENERS & HARDWARE
ROOF PANELS
1-5/8" (4,1 cm)
2" (5,1 cm)
3" (7,6 cm)
3/4" (1,9 cm)
2" (5,0 cm)
1-1/2" (3,8 cm)
x8
x2
NOTE: Panel parts are not stamped.Roof panels are 7/16" (1,1 cm) thick.
x1 64" Metal Threshold
3/4" (1,9 cm) x17
Bagged separately / special coating
Window
x2 Vent 32" Metal Threshold
x1
Spring Bolt
x2
1" (2,5 cm)
x8
(4 screws in each package)
x2
T-Handle
x4 1-1/2" (3,8 cm)
(2 screws in each package)
x2 5-1/2" Shaft
7/16 x 48 x 96"
(1,1 x 121,9 x 243,8 cm)
x2
7/16 x 48 x 47-7/8"
(1,1 x 121,9 x 121,6 cm)
x2
7/16 x 48 x 8-1/2"
(1,1 x 121,9 x 21,6 cm)
x4
7/16 x 27-1/4 x 48"
(1,1 x 69,2 x 121,9 cm)
x6 7/16 x 27-1/4 x 8-1/2"
(1,1 x 69,2 x 21,6 cm)
x4
NOTE:
If you are using a nail gun, nails
may be used where screws are
shown for quicker assembly.
Length of nail must match screw length.
#8 x 1" (2,5 cm)
Pan Head Screws

6
DRIP EDGE ..................... 60 Feet #15 ROOFING FELT
To cover 197 sq. ft. of roof area.
1" GALVANIZED ROOFING NAILS.........1/4 Lb
For roong felt.
IMPORTANT! Depending on your specic use you may want to construct a heavy duty oor frame by adding additional oor joists
(shown below as shaded). Below is a list of additional materials (not included):
x3
x12
2 x 4 x 10' (5 x 10 x 304,8 cm) Treated Lumber
Cut to (3) 2 x 4 x 117" (5 x 10 x 297,2 cm)
ea. 3" (7,6 cm) Hot Dipped Galvanized Nails
OPTIONAL MATERIALS
REFER TO THE BACK OF THIS MANUAL AND THE MANUFACTURER’S INSTRUCTIONS FOR
INSTALLATION OF SHINGLES, DRIP EDGE AND FELT.
COMPLETING YOUR SHED
You will need these additional materials:
REINFORCED WOOD FLOOR FRAME (OPTIONAL)
FOUNDATION OR FLOOR MATERIALS
ADDITIONAL MATERIALS
• This shed does not include any oor or leveling materials. Use our optional oor kit with building instructions and nails included.
• See the FLOOR LEVELING section on page 9 for recommended methods and suggested materials to properly level your oor,
as this will vary depending on your specic site.
• If you choose to install your kit on a concrete slab refer to page 7.
• If you choose to build your own wood oor foundation refer to page 8.
3-TAB SHINGLES ............................. 7 Bundles
PAINT FOR SIDING .......................... 3 Gallons
Use 100% acrylic latex exterior paint. (2) coats recommended.
CAULK .............................................. 3 Tubes
Use acrylic latex exterior caulk that is paintable.
1" GALVANIZED ROOFING NAILS.... 4 Lbs
For shingles.
PAINT FOR TRIM ...........................2 Quarts
Use 100% acrylic latex exterior paint.
Optional 12" (30,5 cm) spacing
Standard 16" (40,7 cm) spacing

7
A
B
C
4"
(10,2 cm)
3-1/2"
(8,9 cm)
CONCRETE FOUNDATION
Your kit contains all materials to construct a wooden oor. If you choose to install your kit
on a concrete slab refer to the diagram below.
• A treated 2 x 4 (5,1 x 10,2 cm) sill plate is required when installing your shed on concrete.
Hint: Purchase full length treated lumber.
• Use a high quality exterior grade caulk beneath all sill plates.
• Fasten 2 x 4 (5,1 x 10,2 cm) sill plates to slab using approved concrete anchors (fasteners not included).
• Check local code for concrete foundation requirements.
NOTES
Allow new concrete slabs to cure for at least seven (7) days.
2 x 4 x 10' (5,1 x 10,2 x 244 cm)
Caulk
Requires:
x2
x2
x1
MUST be treated lumber.
MUST be treated lumber.
120" (304,8 cm)
120" x 144" (304,8 x 365,8 cm) 137" (348 cm)
10' x 12' (304,8 x 365,8 cm) 144" (365,8 cm)
AActual Size B CBuilding Size
Treated Sill Plate
Caulk between sill
plate and concrete.
2 x 4 x 12' (5,1 x 10,2 x 365,8 cm)
DOUBLE
DOOR
SINGLE
DOOR

8
BUILD YOUR OWN WOOD FLOOR OPTION
(Materials not included.)
2 x 4 x 10' (5,1 x 10,2 x 304,8 cm)
x10 MUST be treated lumber
2 x 4 x 12' (5,1 x 10,2 x 365,8 cm)
x2 MUST be treated lumber
5/8" x 48" x 96" (1,6 x 121,9 x 243,8 cm)
x4
x1
x40
x60
1 lb. of 2" (5,1 cm) Hot Dipped Galvanized Box-Type Nails
40 Nails - 3" (7,6 cm) Hot Dipped Galvanized Box-Type Nails
3" (7,6 cm)
2" (5,1 cm)
3" (7,6 cm)
MATERIAL REQUIRED
MUST be treated lumber
4 x 4 x 12' (10,2 x 10,2 x 365,8 cm)
x3
Screws for Frame to 4 x 4
Minimum 3" screws / exterior grade.
144"
(365,8 cm)
120"
(304,8 cm)
117"
(297,2 cm)
16"
(40,6 cm)
16"
(40,6 cm)
DOUBLE
DOOR
SINGLE
DOOR

9
• Level under 4x4 runners only.
• Locate leveling material 12" from ends of runners and no more than 48" apart.
• Asphalt shingles should be used between 4x4 runners and blocks or treated lumber.
Never use shingles in direct contact with ground.
• For best results and aiding in water drainage use gravel under each concrete block.
LEVELING METHODS
• If you are building your shed on a concrete foundation see the following page.
CONCRETE
Use only wood treated for ground contact and fasteners approved for use with treated wood.
Always support frame seams.
Leveling higher than 16" not recommended.
LEVELING MATERIALS
Gravel
2x4 Treated Lumber
Solid Masonry Blocks in 1", 2", 4" or 8" thickness
Asphalt Shingles
8" Block
4" Block
Gravel
Gravel Do not exceed 16".
4x4 Runner
Shingle
Shingle
Maximum between leveling
material locations.
48"
12"
2x4 Treated Lumber
2" Block
Level
12"
• 3" Screws angled into 4 x 4.
• (2) at each frame contact point. Runners are generally 12" (30,5 cm) from

FLOOR FRAME NOT INCLUDED
OPTIONAL WOOD FRAME FLOOR LEVELING OPTIONS

Leveling materials are not included in this kit.
PREFERRED METHOD - 4 x 4 TREATED RUNNERS (Typical for 10' x 12' Kit)
MATERIAL REQUIRED
4 x 4 x 12' (10,2 x 10,2 x 365,8 cm) Treated Lumber
8' x 12' x3 x60 3" (7,6 cm)
Fasteners for Frame to 4 x 4.
(3" Screws shown as one option.)
Minimum 3" screws / exterior grade.
12"
(30,5 cm)
12"
(30,5 cm)
Measurements to
centers of 4 x 4's.

10
FINISH
LEVEL AND SQUARE FLOOR FRAME
Before attaching oor decking, it is important to level and square the oor frame.
A level and square oor frame is required to correctly construct your shed.
BEGIN
2
3
4
1
Use level and check the frame is level before applying oor panels.
Check for frame squareness by measuring diagonally across corners. If the measurements are the
same, the frame is square. The diagonal measurement will be approximately 187-7/16" (496,3 cm).
When the frame is level and square secure one side of frame to the 4x4 runners using one fastener at
ends of each runner. Move to the opposite end of the frame. Secure the frame to 4x4 runners with one
fastener at ends of each runner making sure the frame remains square (Fig. A).
Once the oor frame is level and square, fasten the frame to the 4x4 runners at each point
where the frame contacts the 4x4 runners.
See page 9 for the preferred oor leveling method.
Fig. A
Second, secure
at ends with
one fastener.
First, secure
at ends with
one fastener.
187-7/16"
(476,3 cm)
187-7/16"
(476,3 cm)

11
GABLE END
WALL
GABLE DOOR
WALL
EAVE SIDE WALL

Re-level if needed.
HINT:
IMPORTANT!

• Organize your assembly procedure during the build process
to avoid over-handling of the walls.
EAVE SIDE WALL
(Your door location may vary.)

12
PARTS REQUIRED: RAFTER ASSEMBLY
3" (7,6 cm)
x6
It is very important to assemble your rafters using the following method for an even and at roof.
x2 2 x 4 x 7" (5,1 x 10,2 x 17,8 cm)
AL
FINISH
You have nished building the main roof rafter jig. Proceed to assemble your rafters.
120"
(304,8 cm)
144"
(365,8 cm)
3/4"
(1,9 cm)
AL x2
BEGIN
¸
1Secure (1) AL ush to the oor deck with (2) 3" screws.
Measure over 120-3/4" and install a second GPC ush to the oor deck. AL will overhang oor.
Secure with (2) 3" screws.
120-3/4"
(306,7 cm) IMPORTANT MEASUREMENT !!
Floor Width
Flush Flush
(2) 3" (7,6 cm)
Screws
120"
(304,8 cm)
There will be an
overhang on
this end.

13
BEGIN
¸
1
PARTS REQUIRED: x 144 2" (5,1 cm)
RAFTER ASSEMBLY
x12 6 x 24" (15,2 x 61 cm)
OSB OR WOOD GRAIN
1/4" (1,9 cm)
GAP
1/4" (1,9 cm)
GAP
ECN x2
Fig. A
AL at both ends when securing gusset.
You have nished assembling your rafters.
Remove jig parts AL from oor.
Flip rafters over and fasten a second gusset with (12) 2" nails. No need to use jig for the 2nd gusset.
3
4
2 Place gusset on ECN, holding a 1/4" gap from edge (Fig. B) and keeping rafters rm, as instructed.
Secure the gusset to the rafters with (12) 2" nails in the pattern shown (Fig. B).
Place (2) rafters ECN in the jig, as shown. Hold ECN rm against outside AL's as shown (Fig.A)
and push rafters tight to the middle AL. Rafters should touch at tips (Fig. B).
FINISH
Place two rafter-halves ECN in the jig, as shown (STEP - 1).
Flush rafters at peak. Secure gusset to rafters with 2" nails following the pattern shown (FIg. B).
120-3/4"
(304,8 cm)
120-3/4"
(304,8 cm)
x142 x 4 x 75-1/4" (5,1 x 10,2 x 191,1 cm)
ECN
Build (2) rafter assemblies with (1) gusset (Fig. C).
Build 5 rafter assemblies with (2) gussets (Fig. D).
SET ASIDE THESE TWO RAFTER ASSEMBLIES.
Fig. C - Build 2 Fig. D - Build 5
Fig. B
1/4"
(1,9 cm) 1/4" (1,9 cm)
Flush

14
PARTS REQUIRED: 3" (7,6 cm)
DOOR HEADER
x18
x2 2 x 4 x 67" (5,1 x 10,2 x 170,2 cm)
AM
x1 7/16 x 3-1/4 x 66-3/4" (1,1 x 8,3 x 170,2 cm) OSB
Place (1) AM and OSB end-to-end on at surface, ush in middle.
Center OSB on top of AM.
Fasten together with 3" nails in the pattern shown.
Your door header is now assembled.
FINISH
OSB
ASSEMBLED
END VIEW
BEGIN
1
AM
AM
2Flip header assembly over and nail as shown on the other side.
Flush
Flush
Assemble this door header before building any walls!

15
x40 2" (5,1 cm)
PARTS REQUIRED:
Place a 48" X 84" panel on the wall frame, as shown.
Locate the panel 1-1/2" above the top plate.
Use a 2 x 3 as a gauge block for the 1-1/2" top overhang measurement.
Use the gauge block to mark the 3/4" side measurement on the wall stud.
Secure panel with (2) 2" nails in the corners (Fig. A).
2
Secure panel with 2" nails spaced 6" apart on edges and 12" apart inside panel.
EXAMPLE WALL
Ensure your wall is square by installing one panel and squaring frame.
Move to the opposite end. Using the long edge of the panel as a lever,
move the panel side-to-side until you have a 3/4" measurement on the wall stud.
Secure corner with (2) 2" nails (Fig. B).
3/4" Gauge
Block
x1 3/8 x 48 x 84"
(1 x 121,9 x 213,4 cm )
For squareness maintain 3/4" and 1-1/2"
measurement along panel edge.
BEGIN HERE
3/4"
(1,9 cm)
6" (15,2 cm)
12" (30,5 cm)
2x3"
TEMP. SPACER
3/4" GAUGE
BLOCK
GAA
WALL PANEL INSTALLATION HINTS & EXAMPLES
BEGIN
1
Install all wall panels with the primed side facing up.
2x3
1-1/2"
(3,8 cm)
3/4"
(1,9 cm)
Fig. A 3/4"
(1,9 cm)
2 Nails1-1/2" (3,8 cm)
Overlap
Fig. B 3/4"
(1,9 cm)
1-1/2" (3,8 cm)
Overlap
2 Nails

16
GABLE WALL WITH DOOR
x2 2 x 4 x 68-1/2" (5,1 x 10,2 x 174 cm)
YFA
Fig. B
3" (7,6 cm)
Screws
Pre-Assembled Header
Install Header in
this position
Fig. A
PARTS REQUIRED: 3" (7,6 cm)
x64
2
1
BEGIN
3" (7,6 cm)
x6
x1 Pre Assembled Header
x6 2 x 4 x 78-1/2" (5,1 x 10,2 x 199,4 cm)
AI
x1 2 x 4 x 84" (5,1 x 10,2 x 213,4 cm)
TO
2 x 4 x 36" (5,1 x 10,2 x 91,4 cm)
x1 SL
RR
YFA YFA
TO
RR
SL
AI x6
UY x3
Flush Flush
Flush Flush Flush Flush
Seam
3" (7,6 cm)
Screws
Orient parts on edge on oor as shown. Measure and mark from end of boards.
Orient Pre Assembled Header on at side (Fig. A).
Secure with (2) 3" nails at each connection and (4) 3" nails at seams.
Fasten (3) middle parts UY to Pre Assembled Header with (2) 3" screws (Fig. B).
Secure parts UY to top plates with (2) 3" nails at each connection and (4) 3" nails at seam.
Seam
64"
(162,6 cm)
x2 2 x 4 x 28" (5,1 x 10,2 x 71,1 cm)
RR
x3 2 x 4 x 6-1/2" (5,1 x 10,2 x 16,51 cm)
UY

17
GABLE WALL WITH DOOR
Your 10' gable wall with door
is now assembled.
Carefully ip the wall over.
Install the left panel 1-1/2"
from the top plate.
Use a 2x3 spacer for
consistent measurement.
Secure panel with 2"
nails spaced 6" apart on
edges.
Install the right panel ush
to installed panel,
as shown.
Ensure 64" (162,8 cm) door
measurement.
Use part OO as a
temporary brace. Secure
with with (2) 3" screws.
Secure panels with 2" nails
spaced 6" apart on edges.
2x3
2x32x3
PARTS REQUIRED:
2" (5,1 cm)
x150
x1 x1
6" (15,2 cm)
1-1/2"
(3,8 cm)
BEGIN HERE
3/4"
(1,9 cm)
Flush Flush
OO Temporary Brace
3" (7,6 cm)
x2
4
3
64"
(162,6 cm)
3" (7,6 cm)
Screw 3" (7,6 cm) Screw 3/4"
(1,9 cm)
x1 69" (75,3 cm) Door Stiffener
OO Temporary Brace
Install (2) 11-7/8" x 84"
panels ush to installed
panels and 1-1/2" from
the top plate.
Secure panels with 2"
nails spaced 6" apart on
edges.
Flush Flush
Flush
Flush
5
FINISH
11-7/8"
(30,2 cm)
11-7/8" x 84" (30,2 x 213,4 cm)
x2
1-1/2"
(3,8 cm)
6" (15,2 cm)
3/4" Gauge
Block 3/4" Gauge
Block
Flush

18
AS YOU FACE YOUR BUILDING, CHOOSE YOUR SINGLE DOOR (EAVE) LOCATION -
LEFT, CENTER OR RIGHT
STOP
OPTION 2:
DOOR LOCATION
CENTERED ON EAVE WALL
OPTION 1:
DOOR LOCATION
LEFT SIDE OF EAVE WALL
OPTION 3:
DOOR LOCATION
RIGHT SIDE OF EAVE WALL
IF YOU CHOOSE TO LOCATE THE DOOR TOWARD THE RIGHT
GO TO Page 22 TO BEGIN BUILDING YOUR WALL.
IF YOU CHOOSE TO LOCATE THE DOOR CENTERED
GO TO Page 25 TO BEGIN BUILDING YOUR WALL.
IF YOU CHOOSE TO LOCATE THE DOOR TOWARD THE LEFT
GO TO Page 19 TO BEGIN BUILDING YOUR WALL.
EAVE WALL
GABLE WALL
DOUBLE DOORS
GABLE WALL
DOUBLE DOORS
