Heat & Glo GATEWAY Assembly instructions

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 1
Model:
GATEWAY Installers Guide
Underwriters
Laboratories Listed
Î
- Do not store or use gasoline or other
flammablevaporsandliquidsin the vi-
cinity of this or any other appliance.
- What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your build-
ing.
• Immediatelycallyour gas supplierfrom
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
- Installation and service must be
performedby a qualified installer, service
agency, or the gas supplier.
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE ORADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICEAGENCY, OR THE
GAS SUPPLIER.
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THISAPPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTUREREFERENCE.
1.This appliance may be installed in an af-
termarket,permanentlylocated,manufac-
tured(mobile)home,wherenotprohibited
bylocalcodes.
2. Thisapplianceisonlyforusewiththe type
of gas indicated on the rating plate. This
appliance is not convertible for use with
othergases,unlessacertifiedkitisused.
Please contact your Heat & Glo dealer with any
questionsorconcerns. For thenumberof your nearest
Heat & Glo dealer, please call 1-888-427-3973.
Printed in U.S.A. Copyright 2006
Heat&Glo, a brandofHearth & HomeTechnologies Inc.
20802KensingtonBoulevard,Lakeville,MN55044
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
Thisproductmaybecoveredbyoneormoreofthefollowingpatents:(UnitedStates)4593510,4686807,4766876,4793322,4811534, 5000162, 5016609, 5076254,5113843,5191877,5218953,5263471,
5328356,5341794,5347983,5429495,5452708,5542407,5601073,5613487,5647340,5688568,5762062,5775408,5890485,5931661,5941237,5947112,5996575,6006743,6019099,6048195,6053165,
6145502,6170481, 6237588, 6296474,6374822,6413079,6439226,6484712,6543698,6550687, 6601579,6672860,6688302B2,6715724B2,6729551,6736133,6748940,6748942,6769426,6774802,
6796302,6840261,6848441,6863064,6866205, 6869278, 6875012, 6880275, 6908039,6919884,D320652,D445174, D462436; (Canada) 1297749,2195264,2225408,2313972;(Australia) 780250,
780403,1418504 or otherU.S. and foreignpatents pending.
IntheCommonwealthofMassachusetts:
• installation must be performed by a licensed
plumberorgasfitter;
SeeTable of Contentsfor location of additional
CommonwealthofMassachusettsrequirements.

Heat & Glo • Gateway • 288-900 Rev. S • 3/062
These units MUST use one of the vent systems
described in the Installing the Fireplace section of
the Installers Guide. NO OTHER vent systems or
components MAY BE USED.
This gas fireplace and vent assembly MUST be
vented directly to the outside and MUST NEVER be
attached to a chimney serving a separate solid fuel
burning appliance. Each gas appliance MUST USE
a separate vent system. Common vent systems are
PROHIBITED.
INSPECT the external vent cap on a regular basis to
make sure that no debris is interfering with the air
flow.
The glass door assembly MUST be in place and
sealed, and the trim door assembly MUST be in
place on the fireplace before the unit can be placed
into safe operation.
DO NOT OPERATE this appliance with the glass
door removed, cracked, or broken. Replacement of
the glass door should be performed by a licensed
or qualified service person. DO NOT strike or slam
the glass door.
The glass door assembly SHALL ONLY be
replaced as a complete unit, as supplied by the gas
fireplace manufacturer. NO SUBSTITUTE material
may be used.
DO NOT USE abrasive cleaners on the glass door
assembly. DO NOT ATTEMPT to clean the glass
door when it is hot.
Turn off the gas before servicing this appliance. It is
recommended that a qualified service technician
perform an appliance check-up at the beginning of
each heating season.
Any safety screen or guard removed for servicing
must be replaced before operating this appliance.
READ and UNDERSTAND all instructions carefully
before starting the installation. FAILURE TO
FOLLOW these installation instructions may result
in a possible fire hazard and will void the warranty.
Prior to the first firing of the fireplace, READ the
Using Your Fireplace section of the Owners Guide.
DO NOT USE this appliance if any part has been
under water. Immediately CALL a qualified service
technician to inspect the unit and to replace any part
of the control system and any gas control which has
been under water.
THIS UNIT IS NOT FOR USE WITH SOLID FUEL.
Installation and repair should be PERFORMED by a
qualified service person. The appliance and venting
system should be INSPECTED before initial use
and at least annually by a professional service
person. More frequent cleaning may be required
due to excessive lint from carpeting, bedding
material, etc. It is IMPERATIVE that the unit’s
control compartment, burners, and circulating air
passageways BE KEPT CLEAN to provide for
adequate combustion and ventilation air.
Always KEEP the appliance clear and free from
combustible materials, gasoline, and other
flammable vapors and liquids.
NEVER OBSTRUCT the flow of combustion and
ventilation air. Keep the front of the appliance
CLEAR of all obstacles and materials for servicing
and proper operations.
Due to the high temperature, the appliance should
be LOCATED out of traffic areas and away from
furniture and draperies. Clothing or flammable
material SHOULD NOT BE PLACED on or near the
appliance.
Children and adults should be ALERTED to the
hazards of high surface temperature and should
STAY AWAY to avoid burns or clothing ignition.
Young children should be CAREFULLYSUPERVISED
when they are in the same room as the appliance.
!
!
!
!
!
!
!
!!
!
!
!
!
!
!
!
!
SAFETY AND WARNING INFORMATION
!
DO NOT place furniture or any other combustible
household objects within 36 inches of the fireplace
front.
!

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 3
Safety and Warning Information. ..........................................2
Service Parts Lists. ...............................................................4
Section 1: Approvals and Codes..........................................7
ApplianceCertification..............................................................7
Installation Codes.....................................................................7
HighAltitudeInstallations..........................................................7
Requirements for the Commonwealth of Massachusetts .......8
Section 2: Getting Started. ...................................................9
Introducing the Heat & Glo Gas Fireplaces..............................9
Pre-installationPreparation ......................................................9
Section 3: Installing the Fireplace.....................................11
Constructing the Fireplace Chase .........................................11
Step 1 Locating the Fireplace .............................................11
Step 2 Framing the Fireplace .............................................12
Step 3 Negative Pressure...................................................13
Step 4 Installing the Vent System .......................................14
A. Vent SystemApprovals .......................................14
B. System Components..........................................14
C. Vent Termination .................................................20
Step 5 Positioning, Leveling,and
Securing the Fireplace ............................................22
Step 6 The Gas Control System.........................................23
Step 7 The Gas Supply Line ...............................................23
Step 8 Gas Pressure Requirements ..................................23
Step 9 Wiring the Fireplace ................................................24
Step10 Finishing ..................................................................25
Step 11 Installing Trim, Logs, and Ember Material ...............26
Installing the Trim ....................................................26
Shutter Settings.......................................................26
Positioning the Logs ................................................26
Placing the Ember Material .....................................26
Lava Rock ...............................................................27
Step 12 Before Lighting the Fireplace...................................27
Step 13 Lighting the Fireplace ..............................................27
After theInstallation ................................................................27
Section 4: Maintaining and Servicing Your Fireplace. ....28
Table of Contents
Î= Containsupdatedinformation.
Î
Î

Heat & Glo • Gateway • 288-900 Rev. S • 3/064
Partnumberliston following page.
6 Log Set Assembly
16
1
24
3
5
11
9
10 13
712 8
14
15
(NG, LP) Exploded Parts Diagram
Service Parts GATEWAY
Beginning Manufacturing Date: 1-02
Ending Manufacturing Date: ______
17
18
19

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 5
Service Parts List
ITEM DESCRIPTION SERIAL # PART NUMBER
1 Burner NG 288-176A
1 Burner LP 288-175A
2 Glass Door Assembly GLA-GATEWAY
3 Louver Assembly, Top 288-252A
4 Louver Assembly, Bottom 288-249A
5 Hood 288-174
6 Log Set Assembly LOGS-GATEWAY
7 Log 1 SRV288-721
8 Log 2 SRV675-722
9 Log 3 SRV288-726
10 Log 4 SRV288-723
11 Log 5 SRV285-720
12 Log 6 SRV278-705
13 Log 7 SRV285-725
14 Side Refractory 288-280
15 Log Grate 288-360A
16 Draft Assist Blower 288-500
17 Surround 288-130
18 Non-combustible Board 288-401
19 Trim Door Mesh MESH-550-C
4" Exhaust Collar Assembly 288-210A
Touch Up Paint TUP-GBK-12
Glass Latch Assembly 386-122A
Outside Air Handle 288-103
Lava Rock Bag 705-420
Mineral Wool 050-721
ACCESSORIES
Fan Kit GFK-160A
Remote Control Kit RC-SMART-HNG
Remote Control Kit SMART-STAT-HNG
Conversion Kit NG NGK-GATEWAY
Conversion Kit LP LPK-GATEWAY
IMPORTANT: THISISDATEDINFORMATION.Themostcurrentinformationislocatedonyourdealers VIPsite.Whenordering,
supplyserialand modelnumbersto ensurecorrectserviceparts.
GATEWAY

Heat & Glo • Gateway • 288-900 Rev. S • 3/066
(NG, LP) Exploded Parts Diagram
Service Parts GATEWAY
Beginning Manufacturing Date: 1-02
Ending Manufacturing Date: ______
ITEM DESCRIPTION SERIAL # PART NUMBER
1 ON/OFF Rocker Switch 060-521A
2ValveNG 593-500
2 Valve LP 593-501
3 Flexible Gas Connector 477-301A
4Module 593-592
5 Wire Assembly 288-593a
6PilotAssemblyNG 385-510a
6 Pilot Assembly LP 385-511a
7 Pilot Brackete 288-163
8 Valve Bracket 288-145
9 Flex Ball Valve Assembly 302-320A
10 Vacuum Switch 288-521
11 Junction Box 288-250A
12 3V Adaptor Plug 593-593a
13 Burner Orifice (#32A) NG 420-800
13 Burner Orifice (#50A) LP 446-801
14 Vacuum Hose (Teflon Tube) 421-9
Ground Strap 385-512
Pilot Spud (NG) 446-505
Pilot Spud (LP) 446-517
Regulator (NG) NGK-DXF
Regulator (LP) LPK-DXF
Intermittent Pilot Ignition
ValveAssembly
2
9
10
4
1
5
3
6
13 7
12
11
8
14
Í
Í
Í
Í

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 7
Appliance Certification
TheHeat&Glofireplace model discussed in this Installers
Guidehasbeentestedtocertification standards and listed
bytheapplicablelaboratories.
Certification
MODEL: GATEWAY
LABORATORY: UnderwritersLaboratories
TYPE: Vented Gas Fireplace
STANDARD: ANSI Z21.50•CSA2.22
Installation Codes
Thefireplaceinstallationmustconformtolocalcodes.Before
installing the fireplace, consult the local building code
agency to ensure that you are in compliance with all
applicable codes, including permits and inspections.
Intheabsenceoflocal codes,thefireplace installationmust
conform to the National Fuel Gas Code ANSI Z223.1 (in
theUnited States)ortheCAN/CGA-B149InstallationCodes
(in Canada). The appliance must be electrically grounded
in accordance with local codes or, in the absence of local
codes with the National Electric CodeANSI/NFPA No. 70
(intheUnitedStates),ortothe CSAC22.1CanadianElectric
Code(inCanada).
Thesemodels(naturalgasandpropane)canbeinstalledin
a bedroom (in the United States) which has a total volume
ofunconfinedspaceappropriatetotheparticularinstallation.
Refertothe NationalFuelGasCodeANSI Z223.1/NFPA54
(current edition). The Uniform Mechanical Code - (current
1Approvals and Codes
edition),andlocalBuildingOfficials for the options allowed
in obtaining an effective bedroom volume of unconfined
space.
Thesemodels(naturalgasandpropane)canbeinstalledin
abedroom(in Canada)ifa thermostat(Model WH-STAT)is
installed with the unit. Consult local code authorities.
Detailed installation instructions for Model WH-STAT are
included with the kit.
HighAltitude Installations
U.L. Listed gas appliances are tested and approved with-
outrequiringchangesforelevationsfrom 0 to 2,000 feet in
the U. S.A. and in Canada.
Wheninstallingthisapplianceat an elevation above 2,000
feet, it may be necessary to decrease the input rating by
changingtheexistingburnerorificeto a smaller size. Input
rate should be reduced by 4% for each 1000 feet above a
2000 foot elevation in the U.S.A. or 10% for elevations
between2000 and4500feet inCanada.Iftheheating value
of the gas has been reduced, these rules do not apply. To
identify the proper orifice size, check with the local gas
utility.
Ifinstallingthisapplianceatanelevationabove4,500feet
(in Canada), check with local authorities.
Heat & Glo Quality Systems
registered by SGS ICS

Heat & Glo • Gateway • 288-900 Rev. S • 3/068
For all side wall horizontally vented gas fueled equipment
installed in every dwelling, building or structure used in
whole or in part for residential purposes, including those
owned or operated by the Commonwealth and where the
side wall exhaust vent termination is less than seven (7)
feetabovefinished grade intheareaof theventing,includ-
ing but not limited to decks and porches, the following re-
quirements shall be satisfied:
Installation of Carbon Monoxide Detectors
Atthetimeofinstallationof the side wall horizontal vented
gas fueled equipment, the installing plumber or gasfitter
shallobservethatahardwiredcarbonmonoxidedetector
with an alarm and battery back-up is installed on the floor
level where the gas equipment is to be installed. In addi-
tion,theinstallingplumberorgasfittershall observe that a
battery operated or hard wired carbon monoxide detector
with an alarm is installed on each additional level of the
dwelling,buildingorstructureservedby the side wall hori-
zontalventedgas fueled equipment.Itshall be therespon-
sibilityofthe property ownertosecure the servicesofqual-
ifiedlicensedprofessionals fortheinstallation ofhardwired
carbonmonoxidedetectors.
In the event that the side wall horizontally vented gas fu-
eledequipmentisinstalled in a crawl space oranattic,the
hard wired carbon monoxide detector with alarm and bat-
tery back-up may be installed on the next adjacent floor
level.
In the event that the requirements of this subdivision can
not be met at the time of completion of installation, the
ownershallhave a period ofthirty(30) days to complywith
theaboverequirements;provided,however,thatduringsaid
thirty(30)day period, a batteryoperatedcarbonmonoxide
detector with an alarm shall be installed.
Approved Carbon Monoxide Detectors
Eachcarbonmonoxide detectorasrequired in accordance
withtheaboveprovisions shall comply withNFPA720 and
beANSI/UL2034 listed and IAS certified.
Signage
Ametalorplasticidentificationplateshallbepermanently
mountedtothe exteriorofthebuilding ataminimumheight
of eight (8) feet above grade directly in line with the ex-
haust vent terminal for the horizontally vented gas fueled
heating appliance or equipment. The sign shall read, in
print size no less than one-half (1/2) inch in size, “GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB-
STRUCTIONS”.
Inspection
Thestateorlocalgasinspectorofthesidewallhorizontally
ventedgasfueled equipmentshallnotapprove theinstalla-
tionunless, uponinspection,the inspectorobservescarbon
monoxidedetectorsandsignageinstalledinaccordancewith
theprovisions of248CMR5.08(2)(a)1through 4.
Exemptions
Thefollowingequipmentisexemptfrom248CMR5.08(2)(a)1
through4:
• Theequipmentlistedin Chapter 10 entitled“Equipment
Not Required To Be Vented” in the most current edition
of NFPA54 as adopted by the Board; and
• ProductApproved side wall horizontally vented gas fu-
eled equipment installed in a room or structure sepa-
ratefrom thedwelling, buildingorstructureusedinwhole
orinpartforresidentialpurposes.
MANUFACTURERREQUIREMENTS
Gas Equipment Venting System Provided
Whenthemanufacturer of ProductApprovedsidewall hor-
izontallyventedgasequipmentprovidesaventingsystem
designorventingsystem components with the equipment,
the instructions provided by the manufacturer for installa-
tionoftheequipment and the ventingsystemshallinclude:
• Detailed instructions for the installation of the venting
system design or the venting system components; and
• A complete parts list for the venting system design or
ventingsystem.
Gas Equipment Venting System NOT Provided
When the manufacturer of a Product Approved side wall
horizontallyventedgas fueled equipment doesnotprovide
the parts for venting the flue gases, but identifies “special
venting systems”, the following requirements shall be sat-
isfiedbythemanufacturer:
• Thereferenced“specialventingsystem”instructionsshall
beincludedwith the appliance orequipmentinstallation
instructions;and
• The“specialventingsystems”shallbeProductApproved
by the Board, and the instructions for that system shall
includeapartslistand detailed installation instructions.
A copy of all installation instructions for all Product Ap-
provedsidewall horizontally ventedgasfueledequipment,
all venting instructions, all parts lists for venting instruc-
tions, and/or all venting design instructions shall remain
with the appliance or equipment at the completion of the
installation.
See Gas Connection section for additional Common-
wealth of Massachusetts requirements.
NOTE: The following requirements reference various
Massachusetts and national codes not contained in
this document.
Requirements for the Commonwealth of
Massachusetts

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 9
2Getting Started
Introducing the Gateway Fireplace
The Gateway fireplace is designed to operate with all ex-
haust gases expelled to the outside.
The information contained in this Installers Guide, unless
noted otherwise, applies to all models and gas control
systems.Gas fireplacediagrams,includingthedimensions,
are shown in this section.
Pre-install Preparation
Thisgasfireplaceanditscomponentsaretestedandsafe
when installed in accordance with this Installers Guide.
Report to your dealer any parts damaged in shipment,
particularly the condition of the glass. Do not install any
unit with damaged, incomplete, or substitute parts.
The vent system components are shipped in separate
packages. The gas logs are shipped in the fireplace and
mustbeonunwrappedbeforefiring the unit.
Read all of the instructions before starting the
installation. Follow these instructions carefully during
the installation to ensure maximum safety and benefit.
Failure to follow these instructions will void the
owner’s warranty and may present a fire hazard.
When planning a fireplace installation, it’s necessary to
determine:
•Where the unit is to be installed.
•Theventsystemconfigurationtobeused.
•Gas supply piping.
•Electricalwiring.
•Framingandfinishingdetails.
•Whetheroptionalaccessories—devices such as a fan,
wallswitch,fresh air kit orremotecontrol— are desired.
If the fireplace is to be installed on carpeting or tile, or on
any combustible material other than wood flooring, the
fireplace must be installed on a metal or wood panel that
extends the full width and depth of the fireplace.
Warranty
TheHeat&GloWarrantywill be voided by,andHeat& Glo
disclaims any responsibility for, the following actions:
• Installationof anydamaged fireplaceor ventsystem com-
ponent.
• Modificationofthefireplaceorventsystem.
• Installation other than as instructed by Heat & Glo.
• Improper positioning of the gas logs or the glass door.
• Installationand/oruseof any component partnotmanu-
factured and approved by Heat & Glo, not withstanding
anyindependenttestinglaboratoryorotherpartyapproval
of such component part or accessory.
ANY SUCH ACTION MAY POSSIBLY CAUSE A FIRE
HAZARD.

Heat & Glo • Gateway • 288-900 Rev. S • 3/0610
Figure 2.1 Diagram of the GATEWAY
22 5/8
(575mm)
39 ¼
(997mm)
31 ¼
(794mm)
3 1/8
(80mm)
37 5/8
(955mm)
GAS LINE
ACCESS
ELECTRICAL
ACCESS
2 1/8
(54mm)
2
(51mm)
2 5/8
(67mm) 5 1/8
(131mm)
39 9/16
(1005mm)
3 5/8
(92mm)
14 1/16
(357mm)
38 1/8
(968mm)
TOP STANDOFFS
TOP GRILLE
LOWER
GRILLE
GAS CONTROLS
RATING PLATE
/LABELS
GAS
ACCESS
ELECTRICAL
ACCESS
AIR KIT
KNOCKOUT

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 11
3Installing the Fireplace
Step 1. Locating the Fireplace
Thefollowingdiagramshowsspace andclearancerequire-
ments for locating a fireplace within a room.
Minimum Clearances from the Fireplace to
Combustible Materials Inches mm
Glass Sides or Ends.......... 36.................914
Floor....................................... 0 .................... 0
Metal Sides or Ends...........1/2 ........... 12.5mm
Edges of Front Face*.......... 0 ....................0
Top....................................... 3 1/2 ...............89
Ceiling**............................... 36.................914
Figure 3.1 Fireplace Dimensions, Locations,
and Space Requirements
Minimum Clearances from the Vent Pipe to
Combustible Materials
B-Vent PV-Flex
Inches (mm) Inches (mm)
Vertical Sections. ......... 1 (25) .............1 (25)
Horizontal Sections
Top..................................... 1 (25) ..... 1-1/2 (38)
Bottom .............................. 1 (25) .............1 (25)
Sides................................. 1 (25) .............1 (25)
At Wall Firestops
Top..................................... 1 (25) ..... 1-1/2 (38)
Bottom .............................. 1 (25) .............1 (25)
Sides................................. 1 (25) .............1 (25)
* Refer to Diagram of GATEWAY (see Figure 2.1).
** The clearance to the ceiling is measured from the top
of the non-combustible board (see Figure 3.29).
For minimum clearances, see the direct vent termination
clearancediagraminthis manual (see Figure3.22).
44” (1118mm)
44” (1118mm)
Constructing the Fireplace Chase
A chase is a vertical box-like structure built to enclose the
gasfireplaceand/oritsvent system. Vertical ventsthatrun
on the outside of a building may be, but are not required to
be, installed inside a chase.
CAUTION: TREATMENT OF FIRESTOP SPACERS AND
CONSTRUCTIONOFTHECHASE MAYVARYWITHTHE
TYPE OF BUILDING. THESE INSTRUCTIONSARE NOT
SUBSTITUTES FOR THE REQUIREMENTS OF LOCAL
BUILDINGCODES.THEREFORE, YOURLOCALBUILD-
ING CODES MUST BE CHECKED TO DETERMINE THE
REQUIREMENTSFORTHESESTEPS.
Factory-builtfireplacechases should beconstructed inthe
manner of all outside walls of the home to prevent cold air
draftingproblems.Thechaseshould not break the outside
buildingenvelope inanymanner.
Thismeansthat thewalls,ceiling, baseplateand cantilever
floorofthe chaseshouldbe insulated. Vaporandair infiltra-
tionbarriersshould beinstalledin thechaseas perregional
codesfor therestofthehome.Additionally,inregions where
cold air infiltration may be an issue, the inside surfaces
maybesheetrockedandtapedformaximumairtightness.
To further prevent drafts, the firestops should be caulked
with high temperature caulk to seal gaps. Gas line holes
andotheropenings shouldbecaulked withhightempcaulk
or stuffed with unfaced insulation. If the appliance is being
installedonacementslab,alayerofplywoodmaybeplaced
underneathtopreventconducting cold upintotheroom.
THECHASESHOULD BECONSTRUCTEDSO THATALL
CLEARANCES TO THE FIREPLACEARE MAINTAINED
AS SPECIFIED WITHIN THIS INSTALLERS GUIDE.
Clearance Requirements
The top, back, and sides of the fireplace are defined by
stand-offs.Theminimum clearance toaperpendicularwall
extendingpastthe face ofthefireplace is oneinch(25mm).
The metal endsof the fireplace may NOTberecessedinto
combustible construction.
The distance from the unit to combustible construction
is to be measured from the unit outer wrap surface to
thecombustibleconstruction,NOTfrom thescrewheads
that secure the unit together.

Heat & Glo • Gateway • 288-900 Rev. S • 3/0612
Figure 3.2 Framing Dimensions
Step 2. Framing the Fireplace
Fireplaceframingcan bebuiltbefore orafterthe fireplaceis
set in place. Framing should be positioned to accommo-
date wall coverings and fireplace facing material. The dia-
grambelowshows framingreferencedimensions.
CAUTION: MEASURE FIREPLACE DIMENSIONS AND
VERIFY FRAMING METHODS AND WALL COVERING
DETAILSBEFORE FRAMING.
NOTE: A 1” clearance (B-Vent) or 1-1/2” clearance
(PV-FLEX) must be maintained between the top of
the pipe in a horizontal configuration and any
combustible materials. Otherwise, 1” clearance
should be maintained between the pipe and any
combustible materials.
Framing should be constructed
of 2 X 4 lumber or heavier.
WARNING: FRAMING DIMENSIONS ASSUME
USE OF 1/2 INCH THICK WALL COVERING
MATERIALS ON EXTERIOR OF FRAMING ONLY
ANDNO SHEETROCK ONINTERIOR OFFRAMING.
!
EXHAUST
COLLAR 1”
(25.4mm)
B-Vent
1” (25.4mm)
PV-FLEX
1-1/2” (38mm)
AB
C
A = 39 3/4 (1010mm)
B = 21 5/8 (549mm) 1/2 Sheetrock
21 3/8 (543mm) 5/8 Sheetrock
C= 40 1/4 (1022mm)

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 13
Step 3. Negative Pressure
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward
Figure 3.3
Draft is the pressure difference needed to vent fireplaces
successfully. Considerations for successful draft include:
• Preventingnegative pressure
• Locationoffireplaceandchimney
Negative pressure resultsfromtheimbalanceofair avail-
able for the fireplace to operate properly. Causes for this
imbalanceinclude:
• Exhaust fans (kitchen, bath, etc.)
• Rangehoods
• Combustion air requirements for furnaces, water heat-
ersandothercombustionappliances
• Clothesdryers
• Locationofreturn-airtofurnace or air conditioning
• Imbalances of the HVAC air handling system
• Upperlevel airleaks(recessed lighting,attichatch open-
ing, duct leaks)
To minimize theeffectsofnegative air pressure, the follow-
ing must be considered:
• Install the fresh air kit. Install the intake on the side of
the house towards prevailing winds during the heating
season.
• Ensureadequateoutdoor air is suppliedforcombustion
appliancesandexhaustequipment.
• Ensurefurnaceand air conditioningreturnvents are not
located in the immediate vicinity of the fireplace.
• Avoid installing the fireplace near doors, walkways or
small isolated spaces.
• Recessedlightingshouldbeof“sealed can” design; at-
tichatchesweatherstripped or sealed;andatticmount-
ed ductwork and air handler joints and seams taped or
sealed.
• Basement installations should be avoided due to stack
effect. Stack effect creates negative pressure in lower
levels. Hearth & Home Technologies recommends the
use of direct vent fireplaces in basements.
Locationofthefireplaceandchimneywillaffectperformance.
As shown in Figure 3.3, the chimney should:
• Be installed through the warm space enclosed by the
buildingenvelope.This helps toproducemore draft, es-
peciallyduringlightinganddie-downof the fire.
• Penetrate the highest part of the roof. This minimizes
theeffectsofwindturbulence.
• Be located away from trees, adjacent structures, un-
evenrooflinesand other obstructions.
Offsetscanrestrictdraftsotheiruse should be minimized.
Consider the fireplace location relative to floor and ceiling
and attic joists.
Asphyxiation Risk.
•Negative pressure can cause spillage of
combustion fumes and soot.
• Fireplaceneedstodraftproperlyforsafety.
WARNING

Heat & Glo • Gateway • 288-900 Rev. S • 3/0614
This unit is equipped to accept outside air. It is recom-
mended that an AK-TV air kit be used with this appli-
ance. By using outside make-up air, the amount of room
airusedfor combustion willbereduced. However,in a neg-
ative pressure condition the outside air kit MUST be in-
stalled to obtain proper performance and to help prevent
spillage of combustion gases.
A 4-inch side collar/damper (found in AK-TV Kit) must be
installedonthefireplacebyattachingthesidecollartothe
outerwrapofthefireplaceattheright-handrearcornerusing
sheetmetalscrews.Attachdamperhandle(extendedhandle
foundinmanualbag)tothe damper door prior to attaching
doortoouter wrap. Thenliftthe handle intothenotch under
the fireplace. See Figure 3.5. Attach one end of a 4-inch
flexible air duct (not provided in theAK-TV Kit) to the side
collar and the other end of the duct to the make-up air
termination cap. Use plastic tie straps to secure the ends
of the flex duct to each collar.
Air Damper
Before lighting the burner, open the damper. Close the
damperwhentheburneris off.
Detailedinstallation instructions for ModelAK-TVOutside
Air kit are found in the kit.
Figure 3.4 Make-up Air
AK-TV
AIR
DAMPER
ASSEMBLY
EXHAUST
COLLAR
Figure 3.5 Make-up Air Handle
NOTE: Pullhandletoopendamper. Push handle to close
damper.
HANDLE
NOTCH
!
WARNING: WHEN TERMINATING THE VENTING
HORIZONTALLYTHE MAKE-UPAIRTERMINATION
MUST BE AT A LOWER ELEVATION THAN THE
EXHAUSTTERMINATION.
Asphyxiation Risk.
Fire Risk.
Do NOT draw outside combustion air from:
WARNING
• Wall, floor or ceiling cavity.
• Enclosed space such as an attic or garage.
• Closeproximitytoexhaustventsorchimneys.
Fumes or odor may result.

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 15
!
Step 4. Installing the Vent System
A. Vent System Approvals
Model GATEWAY is approved to use Duravent 4-inch
(102mm)diameterB-typeventfor installationsthatterminate
vertically. ThePV-Flex Seriesventpipeis approved foruse
ininstallationsthatterminate horizontally.This pipeis tested
andlistedasanapproved component of the fireplace.
This model may also use single wall rigid or flexible gas
vent IF and ONLY IF the vent system is installed within
non-combustibleconstructionsuch as amasonrychimney.
The same diameter noted above for B-type vent must be
usedforsingle-wallvent(see Figure 3.6).
For B-type vent the clearance to combustibles is 1-inch.
Followvent manufacturersREQUIREDclearances.ForPV-
Flextheclearancesare 1-1/2” top and 1”sidesandbottom
whenventinghorizontally. For PV-Flextheclearancesare
1” all sides when passing vertically through combustible
materials.
Hightemperaturesiliconesealantisrequiredatallpipejoints.
NOTE:DuetothepositivepressurewithintheGateway
ventingsystem,when usingPV-FLEX usea1/2” bead
of silicone caulk on ALL pipe ends and connectors
throughoutthevent runtoensurea completelysealed
system.
Vent pipes must be installed within the conditioned house
envelope in order to avoid flue gas condensation. Vertical
termination through an unconditioned attic space is
permissible.
The flame and ember appearance may vary based on the
typeoffuelburnedand the venting configuration used.
B. System Components
ConsultLocalBuilding CodeOfficialsandCodes forproper
vent system installations.
Planandinstalltheventsystemusingtheparametersshown
in this vent system configuration chart.
Figure 3.6 Vent System Attachment
!
WARNING: THIS GAS FIREPLACE MUST NEV-
ER BE VENTED BY CONNECTING TO A CHIM-
NEYFLUESERVINGASEPARATE SOLIDFUEL
BURNING APPLIANCE.
Thefollowingfiguresareexamplesofapprovedventingcon-
ditions. Venting downward (3’ maximum) is approved, to
allowventingbelow thefloor.However,onlyonedownward
sectionisallowed for up to,butnotexceeding 3’ maximum.
NOTE:Itisalwaysbetter to first attach astraightsectionof
vent to the unit before attaching an elbow. Avoid using el-
bows in the vent system if possible.
Continuetoadd ventcomponents,until theventrun iscom-
pleted.
Using the four screws provided in the manual bag, attach
theflueoutletcollar.Connecta ventcomponent to the flue
outlet collar (see Figure 3.6).
WARNING: YOU MUST NOT EXCEED THESE
PARAMETERS.
MAXIMUM TOTAL RUN: = 50 FT.
MAXIMUMNO. of ELBOWS/BENDS: five- 90oorten-45o
No. of 90O
Elbows/
Bends
Maximum
Vertical Run Maximum HorizontalRun Maximum Total Run
0 - 40' (12.2m) 40' (12.2m)
1 50' (15.2m) - 50' (15.2m)
1 - 35' (10.7m) 35' (10.7m)
2 - 35' (10.7m) 35' (10.7m)
2 35' (10.7m) 35' (10.7m) 38' (11.6m)
3 30' (9.1m) 35' (10.7m) 35' (10.7m)
4 25' (7.6m) 32' (9.8m) 35' (10.7m)
5 25' (7.6m) 30' (9.1m) 33' (10.1m)
50 FT.
40 FT.
Î

Heat & Glo • Gateway • 288-900 Rev. S • 3/0616
Figure 3.8 Venting with One 90° Elbow and Vertical Termination
HORIZONTALVENTING
H(FT.)
40' MAX. (12.2m)
2’ MIN. (.6m)
Figure 3.7 Horizontal Venting and Horizontal Termination
V(FT.)
50' MAX. (13.8m)
VENTINGWITHONE90oELBOW
TERMINATION
CAP
H
TERMINATION
CAP
V

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 17
Figure 3.9 Venting with Two 90° Bends and Horizontal Termination
Figure 3.10
Venting with Three 90° Elbows and Horizontal Termination
VENTINGWITHTHREE 90oBENDS
3' MAX. (.91m) 35´ MAX. (10.7m)
V+H+H1+H2= 35´ MAX.(10.7m)
V (FT.) (DOWN) H + H1+ H2(FT.)
V (FT.) DOWN
3´MAX. (.91m)
VENTINGWITHTWO
90oBENDS
H+ H1(FT.)
35´MAX. (10.7m)
V+H+H1= 38´ MAX.(11.6m)
V (FT.) UP
35´MAX. (10.7m)
VENTINGWITHTWO
90oBENDS
H+ H1(FT.)
35´MAX. (10.7m)
V+H+H1= 38´ MAX.(11.6m)
Note: Only horizontal
venting allowed after
downward venting run.
Note:Only horizontal
ventingallowedafter
downwardventingrun.
H
V
H
1
3’
MAXIMUM
H
2
H
V
H
1
3 FT.
MAXIMUM
H
H1
V

Heat & Glo • Gateway • 288-900 Rev. S • 3/0618
Figure 3.11
Venting with Four 90° Bends and Horizontal Termination
VENTINGWITHFOUR 90oBENDS
H+H1+H2+H3(FT.)
32' MAX. (9.8m)
Figure 3.12 Venting with Five 90° Bends and Horizontal Termination
VENTINGWITHFIVE 90oBENDS
H+H1+H2+H3+H4 (FT.)
30' MAX. (9.1m)
V+H+H1+H2+H3+H4 = 33´ MAX.(10.1m)
V+H+H1+H2+H3 = 35´ MAX.(10.7m)
V (FT.) DOWN
3' MAX. (.914m)
V(FT.) (DOWN)
3' MAX. (.914m)
Note: Only horizontal
venting allowed after
downward venting run.
Note: Only horizontal
venting allowed after
downward venting run.
H
V
H
1
3 FT.
MAXIMUM
H3
H2
H
V
H
1
3 FT.
MAXIMUM
H
3
H
2
H
4

Heat & Glo • Gateway • 288-900 Rev. S • 3/06 19
Figure 3.14 Firestop Wall Hole
Figure 3.15 Interior & Termination Cap Firestops
Install Support Brackets
For Horizontal Runs -The vent system must be sup-
ported every five (5) feet of horizontal run by a horizontal
pipe support for B-Vent (see Figure 3.21 for PV-Flex pipe
supportbrackets).
To install support brackets for horizontal runs:
• Place the pipe supports around the vent pipe.
• Nail the pipe supports to the framing members.
To install firestops for horizontal runs that pass through
eitherinteriororexteriorwalls:
• Cuta7in.x8in.(178mmx204mm)holethroughthewall.
• Position the firestops on both sides of the hole previ-
ously cut and secure the firestops with nails or screws.
• Continuetheventrunthrough the firestops.
Install Firestops
For Horizontal Runs - Firestops are REQUIRED on both
sidesofacombustible wall through whichtheventpasses.
ForVerticalRuns- Thevent systemmustbe supported
everyeight(8) feet (2.4m)abovethefireplace flue outletby
wall brackets.
To install support brackets for vertical runs:
• Attachwallbracketstotheventpipeandsecurethewall
bracket to the framing members with nails or screws.
8 FT.
(2.4mm)
1 INCH
MIN.
(25.4mm)
4 INCH
ELBOW
FLUE
OUTLET
4 INCH PIPE
B-VENT
WALL STUD
WALL BRACKET
TRIM HEAT SHIELD IF TOO LONG,
ADD TO SHIELD IF TOO SHORT
TERMINATION CAP
WITH BUILT-IN
EXTERIOR FIRESTOP
INTERIOR
FIRESTOP
Figure 3.13 Installing Support Brackets
NOTE: There must be NO INSULATION or other
combustibles inside the framed firestop opening.
7”
8”

Heat & Glo • Gateway • 288-900 Rev. S • 3/0620
If the area above the ceiling is NOT an attic, position and
securetheceilingfirestopontheceiling sideofthepreviously
cutandframedhole.
Figure 3.16 Hole & New Framing Members
CEILING
NEW
FRAMING
MEMBERS
EXISTING CEILING
JOISTS
CHIMNEY
HOLE
6 1/2" (165mm)
6 1/2" (165mm)
Figure 3.18 Attic Firestop
CEILING
CEILING FIRESTOP
RAFTER
NAILS (4 REQUIRED)
NOTE:For vertical terminationthetermination capmustbe
listedfortheventpipe used.
Figure 3.17 Ceiling Firestop (Ceiling Side)
Ifthearea above theceilingIS an attic, positionandsecure
thefirestopontopofthepreviouslyframed hole.
JOIST
CEILING FIRESTOP
CEILING
NAILS (4 REQUIRED)
For Vertical Runs- Oneceiling firestop is REQUIRED
at the hole in each ceiling through which the vent passes.
Toinstallfirestopsforverticalrunsthatpassthroughceilings:
• Positionaplumbbobdirectly over the center of theverti-
calventcomponent.
• Mark the ceiling to establish the centerpoint of the vent.
• Drill a hole or drive a nail through this centerpoint.
• Check the floor above for any obstructions, such as wir-
ingorplumbingruns.
• Reposition the fireplace and vent system, if necessary,
to accommodate the ceiling joists and/or obstructions.
• Cuta61/2 in. x61/2in.(165mm x 165mm)holethrough
theceiling,usingthecenterpointpreviouslymarked.
• Framethehole with framing lumberthesamesize as the
ceiling joists.
NOTE: There must be NO INSULATION or other
combustibles inside the framed firestop opening.
Figure3.18 showsan atticinstallation. Keepinsulation away
from the vent pipe at least 1 inch (25mm).
Whileitis notmandatory, itisstrongly recommendedthatan
atticinsulationshieldbeusedwheneverinsulationcancome
incontactwiththeventpipe.Followyourlocalbuildingcodes.
