Heat Controller REG-253H Application guide

Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • [phone] • www.heatcontroller.com
REPLACEMENT
PARTS LIST
Room Air Conditioner:
REG-253H

REG-253H Parts List Room Air Conditioner Heat Controller, Inc.
EXPLODED VIEW

Heat Controller, Inc. Room Air Conditioner REG-253H Parts List
REPLACEMENT PARTS
Location Part Description Quantity Part No.
1 Front panel 1 2011221A0153
2Air lter 1 201122190038
3 Panel frame assembly 1 2011221A0156
4.1 Horizontal louver 1 2011221A0161
4.2 Vertical louver 2 2 P0000106165
4.3 Vertical louver 1 4 P0000106164
4.4 louver holder 2 201122190044
5 Installation box for Electric heater 1 201222190080
6 Foam,front scroll 1 202222190014
7 Foam,front scroll 1 202222190017
8 front cover board 1 201222190031
9 Blower wheel 1 201100120010
10 Link,ventilation door 1 2011221A0154
11 Guide sleeve, ventilation door 1 201122190017
12 Fresh air door 1 201122190012
13 Front left barrier 1 201222190004
14 Shroud 1 201122190019
15 rear cover board 1 201122190007
16 Fan blade 1 201100320005
17 Fan motor 1 202400430600
18 Rear scroll 1 202222190012
19 Front right barrier 1 201222190015
20 Drain valve 1 202301610703
21 Chassis 1 201222190093
22 Water drain pan 1 202222190000
23.1 Left shutter frame 1 201122190011
23.2 Shutter 2 201122190009
23.3 Connection bar to cabinet 2 201122190008
23.4 Right shutter frame 1 201122190010
23.5 Locking bar 2 201222190008
23.6 Left window bracket 1 201222190006
23.7 Right window bracket 1 201222190007
23.9 Remote controller 1 203355091112
24 Top shutter frame 1 201222190090
25 Cabinet 1 201222190092
Continued on next page

Location Part Description Quantity Part No.
26 Suction pipe 1 201622190190
27 Discharge pipe 1 201622190196
28 Condenser 1 201522190030
29.1 Evaporator 1 201522190029
29.2 Capillary assembly 1 201622190192
31 Compressor 1 201400601300
32 Super-cooling pipe 1 201622190197
33.1 Display board 1 201322190042
33.2 Control panel 1 2011221A0155
37.1 Capacitor clamp 1 201200100011
37.2 Capacitor 1 202401000808
37.3 Electric part box 1 201222190052
37.5 transformer 1 202300900113
37.6 Capacitor 1 202401100967
37.7 Wire joint 1 202301450117
37.8 Main control board 1 201322190037
37.11 Indoor temp sensor 1 202301300092
37.14 Power cord 1 202402290016
38 Electric heater 1 202403100021
REPLACEMENT PARTS CONTINUED
REG-253H Parts List Room Air Conditioner Heat Controller, Inc.

04/2009
02/2011
