OWNER’S MANUAL
Room Air Heat Pump
with R-410A:
RAH-183G

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
1
Comfort ZoneTM
Room Air Conditioner & Heat Pump
Use and Care Manual
Introduction
Room air conditioners cool, dehumidify, and filter air inside
your home. Heat pump and electric heat models offer both
heating and cooling. Opening sections of manual provide
general information for all room air conditioner models.
Operating Controls section describes operation of controls
for each model. After reading the opening sections, turn to
Operating Controls section and find the panel layout that
matches the model of your unit.
Read entire manual thoroughly before beginning installation
and operation of your new room air conditioner. Be sure you
have all necessary tools and materials on hand for the job.
Study illustrations to familiarize yourself with important
details of the installation process. Review manual for oper-
ating instructions.
NOTE
1. Mechanical experience is required to install air condi-
tioner.
2. Installation can take from 1 to 3 hours, depending on
installer’s knowledge and skill.
3. If you encounter problems during installation, call our
consumer information line at (86-756) 8617555.
If your problem cannot be resolved by phone, contact an
authorized GREE®brand servicer. Contact and service
will be at your expense.
SafetyInformation
Be sure electrical service is adequate for chosen model of air
conditioner. Complete electrical rating for unit is found on
serial plate located behind front grille. Electrical outlet must
be close enough to unit for power cord to reach without strain.
Air conditioner should be the only appliance on individual
circuit.
For personal safety and to avoid possible damage to appli-
ance or home, observe all safety instructions highlighted by
symbol shown below.
RECOGNIZE THIS SYMBOL AS A
SAFETY PRECAUTION.
After installing unit, reread instructions to ensure each step
is complete and that all parts are fastened in place. For best
results and to minimize installation time, perform all proce-
dures in the order shown.
To prevent heat related illness or death, do
not use this device for unattended cooling
of persons or animals unable to react to
product failure. Failure of unattended air
conditioner may result in extreme heat in
area intended for cooling, causing heat-
related illness or death of persons or
animals.
WARNING
Contents
Introduction .................................................................. 1
Safety Information ....................................................... 1
1
Normal Care and Maintenance .................................. 3
Installation Instructions ............................................... 6
Electrical Requirements .............................................. 2
General Instructions ................................................... . 5
Operating Controls .................................................... 12
Before Calling Service ..............................................
When Service Is Required ........................................
Any Questions? ..........................................................
Through-The-Wall Installation Instructions .............
15
16
16
17
If you encounter problems during installation, call our
consumer information line at [phone] and ask for
the technical service deparment. If your problem cannot
be resolved by phone, contact an authorized servicer.
Introduction............................................................. 1
Safety Information .................................................. 1
Normal Care & Maintenance .................................. 2
Electrical Requirements.......................................... 2
Installation Requirements ....................................... 3
General Operating Instructions............................... 5
Installation Instructions ........................................... 6
Vent Control.......................................................... 14
Troubleshooting.................................................... 15
When Service is Required.................................... 15
Any Questions ...................................................... 15
Room air conditioners cool, dehumidify and lter air inside
your home. Heat pump models offer both heating and cool-
ing. The opening sections of this manual provides some
general information for all room air conditioner models. The
Operating Controls section describes operation of controls
for each model. After reading the opening sections, turn to
the Operating Controls section and nd the panel layout
that matches your model.
To prevent heat related illness or death,
do not use this device unattended.
Failure of an unattended air conditioner
may result in extreme heat in area
intended for cooling, causing heat related
illness or death of persons or animals.

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
2
2
To avoid death, personal injury or property
damage due to electrical shock:
• Observe all local codes and ordinances.
•Disconnect electrical power to unit before servicing.
• Ground appliance properly.
• Check with a qualified electrician if you are not
sure this appliance is properly grounded.
• DO NOT ground to gas line.
• DO NOT ground to cold water pipe if pipe is
interrupted by plastic, non-metallic gaskets, or
other insulating (non-conducting) materials.
• DO NOT modify plug on power cord. If plug
does not fit electrical outlet, have proper outlet
installed by qualified electrician.
• DO NOT have a fuse in the neutral or ground
circuit. A fuse in the neutral or ground circuit
could result in an electrical shock.
• DO NOT use an extension cord with this appliance.
• DO NOT use an adapter plug with this appliance.
• DO NOT pinch power cord.
•DO NOT REMOVE warning tag from power cord.
WARNING
ElectricalRequirements
Grounding Instructions
This appliance is equipped with a three-prong grounding plug
for protection against possible shock hazards. If a two-prong
wall receptacle is encountered, the customer is required to
contact a qualified electrician and have the two-prong wall
receptacle replaced with a properly grounded three-prong
wall receptacle in accordance with the National Electrical
Code.
Room air conditioners are designed to operate according to
requirements on the nameplate and as shown in Table 1.
Fuse or circuit breaker ratings must be according to the fuse
instruction label and as shown in Table 1. Do not plug models
marked “Use on Single Outlet Circuit Only” into a circuit with
another appliance or light fixture.
Receptacle Wiring
Receptacle wiring must be of adequate size for unit. Refer
to unit identification plate for exact power requirements.
Minimum size of wiring, based on power requirements, is:
Units up to 20 amps: 12gauge
20–30 amp units: 10gauge
LCDI or AFCI Power Cords
Underwriters Laboratories (UL) and the National Electric
Code (NEC) now require power cords that sense current
leakage and can open the electrical circuit to the unit. In the
HIGH TEMPERATURE STRESS HAZARD
This room air conditioner is not meant to
provide unattended cooling or life support
for persons or animals that are unable to
react to failure of the product.
The failure of an unattended air conditioner
may result in extreme heat in the cond-
itioned space causing overheating or
death of persons or animals.
Precautions must be taken to ward off or
guard against such an occurrence.
WARNING
Unpacking
Unpack and visually inspect the unit. Report any damage to
the delivering carrier immediately. Remove and discard all
packing material. On some models the air conditioner front
and/or mounting kit hardware may be packed separately.
Record the model, serial and manufacturing numbers of your
unit in the space provided below. This information is found on
a nameplate visible after the front of the air conditioner has
been removed. The rated voltage, amperage and capacity for
your specific model can also be found on this nameplate.
Read the warranty packaged with the unit. Keep the warranty
and a copy of your sales receipt for future reference. You may
also want to record in the space provided the date purchased
and the selling dealer.
OWNER'S PRODUCT IDENTIFICATION
MODEL NUMBER
SERIAL NUMBER
MANUFACTURING NUMBER
Owner's Name
Address
City State Zip
/ /
Date of Purchase
Authorized Dealer
Address
City State Zip
( )
Phone Number
Unpacking
Unpack and visually inspect the unit. Report any damage to
the delivering carrier immediately. If your unit is not damaged,
remove and disgard all packing materials. On some models
the air conditioner front and/or mounting kit hardware may be
packed separately.
leakage and be able to open the electrical circuit to the unit. In the
Record the model and serial numbers of your unit in the space
provided. This information is found on a nameplate visible after
the front of the air conditioner has been removed. The rated
voltage, amperage and capacity for your specic model can
also be found on this nameplate. Read the warranty packaged
with the unit. Register your unit and keep the warranty and a
copy of your sales receipt for future reference. You may also
want to record in the space provided the date purchased and
the selling dealer.

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
3
3
NEMA No. 5-15P NEMA No. 5-15R 125V-15AMP 115V
NEMA No. 6-15P NEMA No. 6-15R 250V-15AMP 230/208V rated
at 12 amperes or
less
NEMA No. 6-20P NEMA No. 6-20R 250V-20AMP 230/208V rated
over 12 amperes,
but not more than
16 amperes
NEMA No. 6-30P NEMA No. 6-30R 250V-30AMP 208V rated over
16 amperes, but
not more than
24 amperes
Unit Plug Receptacle Circuit Rating, Voltage
Type Required Breaker, Time Rating On
Delay Fuse Nameplate
event, the unit does not operate, check the reset button
located on or near the head of the power cord as part of the
normal troubleshooting procedure.
Use copper wire only. Consumer’s responsibility is to provide
proper and adequate receptacle wiring that conforms to all
applicable codes. All wiring should be installed by qualified
electrician.
Installation
Complete step-by-step installation instructions are furnished
with your unit. These instructions will be found on a separate
page included with this manual or in the mounting kit
assembly. Follow these instructions carefully. Keep these
instructions with this manual for future reference. Your unit
will be one of the following three designs:
•Unit with a window mounting kit
These models are designed for mounting though an
opening in a wall. These units can be adapted to
windowinstallationbyusingtheoptionalwindow mount-
ing kit supplied with your unit.
•Unit without a window mounting kit
No window mounting kit is supplied with the unit.
These models are designed for mounting through an
opening in a wall. These units can be adapted to
window installation by purchasing an optional window
mounting kit. Consult your dealer to choose the kit that
is appropriate for your model and installation.
•Unit with a separate sleeve
Some Builder models are designed such that the outer
case and the chassis can be purchased separately.
Through-the-wall installation instructions are included
with the outer case. These models can be adapted to
window installation by purchasing an optional mount-
ing kit.
RoomHeatPumps
Heat pumps work by moving heat instead of creating it. In the
summer, the cool indoor coil absorbs heat from your room
and moves it outdoors, providing cooling. In the winter, heat
pumps reverse this operation. By lowering the temperature
of the outdoor coil below the outdoor temperature, the heat
pump absorbs the heat from outdoors and moves it inside
your house. This heat transferring process is very efficient.
For example, at 45°F outdoor temperature, a heat pump can
provide 2 ½ watts of heat for every watt of electricity it
consumes.
As outdoor temperatures drop, the heating capacity and
efficiency of the heat pump declines. At temperatures below
45°F, it is likely that ice will form on the outdoor coil. Heat
pump units are designed to operate as a heat pump above
approximately 40°F. Below 40°F, these units switch auto-
matically from reverse cycle heat pump to auxiliary electric
heating. No defrost is required. There is no minimum
operating temperature.
NormalCare andMaintenance
To avoid property damage, personal injury
or death due to electrical shock, turn fan
control OFF and remove plug from wall
outlet before inspecting unit or performing
maintenance.
WARNING
Annual Inspection
It is suggested that your unit be inspected by your dealer or
servicer once a year. It is advisable to have the outer case
removed and the unit thoroughly cleaned.
Note: The life of your unit may be greatly reduced if you live
in a salt air or other corrosive type environment. Under these
conditions, the unit should be removed from its case and
completely cleaned at least once a year. At that time any
scratches or blisters on the painted surfaces should be
sanded and repainted. Placing an algaecide tablet in the
outdoor side of the unit’s basepan is suggested in humid
areas where algae formation is common.
To avoid property damage, personal injury
or death due to electrical shock, turn unit
OFF and remove plug from wall outlet before
inspecting unit or performing maintenance.
Note: The life of your unit may be greatly reduced if you live in a
corrosive environment such as an oceanside location with salty
air. Under these conditions, the unit should be removed from its
case and completely cleaned at least once a year. At that time
any scratches or blisters on the painted surfaces should be
sanded and repainted. Placing an algaecide tablet in the outdoor
side of the unit’s basepan is suggested in humid areas where
algae formation is common.
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
3
3
NEMA No. 5-15P NEMA No. 5-15R 125V-15AMP 115V
NEMA No. 6-15P NEMA No. 6-15R 250V-15AMP 230/208V rated
at 12 amperes or
less
NEMA No. 6-20P NEMA No. 6-20R 250V-20AMP 230/208V rated
over 12 amperes,
but not more than
16 amperes
NEMA No. 6-30P NEMA No. 6-30R 250V-30AMP 208V rated over
16 amperes, but
not more than
24 amperes
Unit Plug Receptacle Circuit Rating, Voltage
Type Required Breaker, Time Rating On
Delay Fuse Nameplate
event, the unit does not operate, check the reset button
located on or near the head of the power cord as part of the
normal troubleshooting procedure.
Use copper wire only. Consumer’s responsibility is to provide
proper and adequate receptacle wiring that conforms to all
applicable codes. All wiring should be installed by qualified
electrician.
Installation
Complete step-by-step installation instructions are furnished
with your unit. These instructions will be found on a separate
page included with this manual or in the mounting kit
assembly. Follow these instructions carefully. Keep these
instructions with this manual for future reference. Your unit
will be one of the following three designs:
•Unit with a window mounting kit
These models are designed for mounting though an
opening in a wall. These units can be adapted to
windowinstallationbyusingtheoptionalwindow mount-
ing kit supplied with your unit.
•Unit without a window mounting kit
No window mounting kit is supplied with the unit.
These models are designed for mounting through an
opening in a wall. These units can be adapted to
window installation by purchasing an optional window
mounting kit. Consult your dealer to choose the kit that
is appropriate for your model and installation.
•Unit with a separate sleeve
Some Builder models are designed such that the outer
case and the chassis can be purchased separately.
Through-the-wall installation instructions are included
with the outer case. These models can be adapted to
window installation by purchasing an optional mount-
ing kit.
RoomHeatPumps
Heat pumps work by moving heat instead of creating it. In the
summer, the cool indoor coil absorbs heat from your room
and moves it outdoors, providing cooling. In the winter, heat
pumps reverse this operation. By lowering the temperature
of the outdoor coil below the outdoor temperature, the heat
pump absorbs the heat from outdoors and moves it inside
your house. This heat transferring process is very efficient.
For example, at 45°F outdoor temperature, a heat pump can
provide 2 ½ watts of heat for every watt of electricity it
consumes.
As outdoor temperatures drop, the heating capacity and
efficiency of the heat pump declines. At temperatures below
45°F, it is likely that ice will form on the outdoor coil. Heat
pump units are designed to operate as a heat pump above
approximately 40°F. Below 40°F, these units switch auto-
matically from reverse cycle heat pump to auxiliary electric
heating. No defrost is required. There is no minimum
operating temperature.
NormalCare andMaintenance
To avoid property damage, personal injury
or death due to electrical shock, turn fan
control OFF and remove plug from wall
outlet before inspecting unit or performing
maintenance.
WARNING
Annual Inspection
It is suggested that your unit be inspected by your dealer or
servicer once a year. It is advisable to have the outer case
removed and the unit thoroughly cleaned.
Note: The life of your unit may be greatly reduced if you live
in a salt air or other corrosive type environment. Under these
conditions, the unit should be removed from its case and
completely cleaned at least once a year. At that time any
scratches or blisters on the painted surfaces should be
sanded and repainted. Placing an algaecide tablet in the
outdoor side of the unit’s basepan is suggested in humid
areas where algae formation is common.
To avoid property damage, personal injury
or death due to electrical shock, turn unit
OFF and remove plug from wall outlet before
inspecting unit or performing maintenance.
Note: The life of your unit may be greatly reduced if you live in a
corrosive environment such as an oceanside location with salty
air. Under these conditions, the unit should be removed from its
case and completely cleaned at least once a year. At that time
any scratches or blisters on the painted surfaces should be
sanded and repainted. Placing an algaecide tablet in the outdoor
side of the unit’s basepan is suggested in humid areas where
algae formation is common.

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
4
4
Front Grille and Filter Removal
The front contains a removable grille that provides easy
access to the air filter. To clean the filter use one of the
following methods for filter removal:
METHODONE
Grasp filter handle and slide filter out of unit.
Optional Air Filter Installation
Remove air filter from plastic bag. Insert three tabs
on right side of filter into three slots on filter frame. Carefully
bow middle of filter until two tabs on filter can be inserted into
two slots on filter frame. Relax bow.
Reinstall air filter and grille by reversing removal procedure.
Front Grille and Cabinet Cleaning
Grille and cabinet may be cleaned with warm water and mild
soap or detergent. Cleaning and polishing compounds are
not recommended, as they may damage plastic surfaces.
Air Filter Cleaning
A dirty air filter reduces operating efficiency of unit. Filter
should be inspected at least once every week during opera-
tion. Clean filter with vacuum cleaner or wash in warm water
and mild detergent. Filter should be thoroughly dried before
replacing in unit. Do not operate unit without filter in place.
Fan Motor Care
The fan motor is permanently lubricated for long life. There is
no need to oil the motor.
Slide-out Chassis Removal from Outer Case
1. Remove front grille by sliding grille to left and pulling out.
2. Remove air filter by sliding to left.
3. Remove four screws holding plastic front to unit and
remove front.
4. If the unit has a screw holding the basepan clip to the
chassis, remove the screw.
To reduce the risk of personal injury be
sure to have sufficient help when moving
your unit. A room air conditioner can
weigh between 70 and 240 pounds.
CAUTION
5. Using basepan handle, pull chassis straight out, slowly
and evenly, until approximately 9-12 inches extends
To reduce the risk of personal injury, be
sure to have sufcient help when moving
your unit. A room air conditioner can be
excessivley heavy.

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
5
5
from outer case. Use both hands to grasp basepan and
pull remaining chassis from outer case.
PLASTIC FRONT
CHASSIS
BASEPAN
CLIP
NOTE: Basepan clip is shipped in plastic bag with mounting
screw and condensate drain cup. Install clip after reinserting
chassis into outer case to prevent accidental chassis removal.
GeneralOperatingInstructions
While operation of all units is similar, controls vary slightly
from model to model. Operating Controls section shows
control panel of unit purchased and gives detailed information
about operation of controls.
Initial Start-Up and Cooling
Select the highest fan speed and set temperature control to
its coldest position. When the desired temperature is
reached, slowly move the temperature control toward a
warmer setting until the compressor shuts off. The thermo-
stat will then cycle the compressor on and off to maintain this
selected temperature. Adjust the fan speed for desired air
circulation.
Changing Airflow Direction Baffles
Airflow on unit may be diverted left or right from center by
baffles. Upward and downward air discharge is provided by
tilting louvers. Adjust baffles and tilt louvers for desired
airflow pattern.
Airflow Around Unit
Check the indoor grille and outdoor louvers for obstructions to
airflow. Do not block the airflow to and from the unit. If air is
obstructed and/or deflected back into the unit, the air
conditioner’s compressor may cycle on and off rapidly. This
could damage your unit.
OUTDOOR
LOUVERS
INDOOR
GRILLE
BAFFLES
Drain Cup Installation and Use(on some models)
Your air conditioner uses a system where the water removed
from the indoor air (condensate) is channeled to the outdoor
side of the unit. The outdoor fan blade has a “slinger” ring
attached to it that dips into the water and slings the water onto
the outdoor coil surface. This is the sound of water you hear
during normal operation. The water quickly evaporates on
this warm surface and improves the efficiency of your air
conditioner. In normal conditions the unit can evaporate the
water as fast as it is removed from the indoor air.
However, in very humid conditions excess amounts of water
may drip off the unit chassis. If this proves to be a problem,
install the condensate drain cup included with the unit to
route excess water where it would not be a problem (see
illustration below).
To install, remove the unit chassis from the outer case. Insert
the condensate drain cup through the recessed ½” hole on
the right side bottom flange of the outer case. Once inserted,
place a ½” diameter hose or tube on the drain cup bottom
spout. The hose allows you to route where you want the
excess water to go. Reinsert the unit chassis into the outer
case. The unit basepan overflow hole will be positioned
directly above the drain cup and will catch any water that
might run out.
1/2" Diameter
Hose
Condensate
Drain Cup
Outer Case
Switchover Thermostat Control
Emergency heat switch overrides heat pump (compressor)
and starts auxiliary electrical heater. When switch is ON,
heat pump is locked out.
• Use emergency switch only when heat pump fails to
provide adequate heat. Cause of heat pump malfunc-
tion should be determined by authorized servicer. Cost
of operating unit will increase when emergency heat
switch is engaged.
To access and engage emergency switch:
1. Remove front grille, air filter, and plastic front, as de-
scribed in Installation Instructions.
2. Remove basepan clip.
3. Slide chassis out of case about two inches.
4. Locate access hole for emergency switch above label on
right front of control box.
5. To start emergency heat, insert flathead screwdriver into
slot and turn counterclockwise until switch-stop is reached.
6. Return chassis to case.
7. Replace basepan clip, plastic front, air filter, and front
grille.

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
6
6
BEFORE YOU BEGIN
Read thes e instructions com pletely
and carefully.
IMPORTANT — Save these
instructions for local inspector's use.
●
●
●
●
●
●
●
●
●
IMPORTANT— Observe all
governing codes and ordinances .
Note to Installer — Be sure to leave these
instructions with the Cons umer.
Note to Consumer — Keep these
instructions for future reference.
Skill level — Installation of this appliance
requires basic mechanical skills.
Completion time — Approximately 1 hour
We recommend that two people install
this product.
Proper installation is the responsibility
of the installer.
Product failure due to improper installation
is not covered under the Warranty.
Question? Consumer information line (86-756) 8617555(Customer Service Center)
Installation Air Conditioner
Ins tructions
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall
outlet you plan to use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
Some models require 230/208-volt a.c.,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for
best performance and to prevent
overloading house or apartment wiring
circuits, which could cause a possible
fire hazard from overheating wires.
ELECTRICAL REQUIREMENTS
CAUTION:
Do not, under any circumstances , cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems —consult a qualified electrician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
Flat-blade screwdriver
Power cord includes a current interrupter
device. A test and reset button is provided on
the plug case. The device should be tested on a
periodic basis by first pressing the TEST button
and then the RESET button. If the TEST button
does not trip or if the RESET button will not stay
engaged, discontinue use of the air conditioner
and contact a qualified service technician.
Adjustable wrench
517-787-2100
6
BEFORE YOU BEGIN
Read thes e instructions com pletely
and carefully.
IMPORTANT — Save these
instructions for local inspector's use.
●
●
●
●
●
●
●
●
●
IMPORTANT— Observe all
governing codes and ordinances .
Note to Installer — Be sure to leave these
instructions with the Cons umer.
Note to Consumer — Keep these
instructions for future reference.
Skill level — Installation of this appliance
requires basic mechanical skills.
Completion time — Approximately 1 hour
We recommend that two people install
this product.
Proper installation is the responsibility
of the installer.
Product failure due to improper installation
is not covered under the Warranty.
Question? Consumer information line (86-756) 8617555(Customer Service Center)
Installation Air Conditioner
Ins tructions
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall
outlet you plan to use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
Some models require 230/208-volt a.c.,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for
best performance and to prevent
overloading house or apartment wiring
circuits, which could cause a possible
fire hazard from overheating wires.
ELECTRICAL REQUIREMENTS
CAUTION:
Do not, under any circumstances , cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems —consult a qualified electrician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
Flat-blade screwdriver
Power cord includes a current interrupter
device. A test and reset button is provided on
the plug case. The device should be tested on a
periodic basis by first pressing the TEST button
and then the RESET button. If the TEST button
does not trip or if the RESET button will not stay
engaged, discontinue use of the air conditioner
and contact a qualified service technician.
Adjustable wrench
6
BEFORE YOU BEGIN
Read thes e instructions com pletely
and carefully.
IMPORTANT — Save these
instructions for local inspector's use.
●
●
●
●
●
●
●
●
●
IMPORTANT— Observe all
governing codes and ordinances .
Note to Installer — Be sure to leave these
instructions with the Cons umer.
Note to Consumer — Keep these
instructions for future reference.
Skill level — Installation of this appliance
requires basic mechanical skills.
Completion time — Approximately 1 hour
We recommend that two people install
this product.
Proper installation is the responsibility
of the installer.
Product failure due to improper installation
is not covered under the Warranty.
Question? Consumer information line (86-756) 8617555(Customer Service Center)
Installation Air Conditioner
Ins tructions
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall
outlet you plan to use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
Some models require 230/208-volt a.c.,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for
best performance and to prevent
overloading house or apartment wiring
circuits, which could cause a possible
fire hazard from overheating wires.
ELECTRICAL REQUIREMENTS
CAUTION:
Do not, under any circumstances , cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems —consult a qualified electrician.
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
Flat-blade screwdriver
Power cord includes a current interrupter
device. A test and reset button is provided on
the plug case. The device should be tested on a
periodic basis by first pressing the TEST button
and then the RESET button. If the TEST button
does not trip or if the RESET button will not stay
engaged, discontinue use of the air conditioner
and contact a qualified service technician.
Adjustable wrench
Flat-head screwdiver

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
7
Type A (6)
V-support (2)
Window locking
bracket (2)
Top
mounting
rail
Right
accordion
panel
Foam top
window gasket
Window
sash seal
Left
accordion
panel
Type B (4) Type C (7) Type E (
Bolt (2) & nuts (2)
PARTS INCLUDED
(Appearance may vary)
Installation Instructions
Type D (6)
7
Type E (4) Type F (2)

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
8
Installation Instructions
WINDOW REQUIREMENTS
●These instructions are for a standard
double-hung window. You will need to
modify them for other types of windows.
●T he air conditioner can be installed
without the accordion panels if needed
to fit in a narrow w indow. See the
window opening dim ens ions .
● All supporting parts must be secured
to firm w ood, m asonry or metal.
●T he electrical outlet m us t be within
reach of the power cord.
1
１７３／８＂min.
30" to 38.1"
(With accordion panels )
26" min.
(Without accordion panels)
STORM WINDOW REQUIREMENTS
A s torm w indow fram e will not allow the
air conditioner to tilt toward the outside,
and w ill keep it from draining properly.
To adjus t for this, attach a piece of wood
to the s tool.
WOOD PIECES-
WIDT H: 2"
LENGTH: Long enough to fit inside the
window frame.
THICKNESS : To determine the thickness,
place a piece of wood on the stool to
make it 1/2" higher than the top of the
storm window fram e.
Attach s ecurely w ith nails or s crew s
provided by the ins taller.
1/2" higher
than fram e
Storm
window
fram e
W ood
Stool
2
REMOVE THE AIR CONDITIONER
FROM THE CASE
Remove the locking screw and locking
bracket from the lower frame. Save to
reinstall later.
Remove the ground screw and save to
reinstall later.
Slide the air conditioner from the case by
gripping the base pan handle and pulling
forward while bracing the case.
B
A
3
PREPARE THE WINDOW
Cut the window sash seal to the proper
length. Peel off the backing and attach the
seal to the underside of the window sash.
4
Removethegroundscrew
andsavetoreinstalllater
8
C
26” min.
(Without accordion panels)
unit
Remove the locking screw and lock-
ing bracket from the lower frame.
Save to reinstall later.
Remove the ground screw. Save to
reinstall later.

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
9
PREPARE THE CASE
Install the top mounting rail with 4 type B
screws from the inside of the case.
Insert the frames for the accordion panels
into the top mounting rail and the bottom
frame guides. Attach the accordion panels
to the side of the case using 3 type A screws
on each side.
Note: When attaching the accordion panels,
make sure to only screw the inner panels
to the case sides.
B
A
5
Installation Instructions
Top mounting rail
Bottom fram e guides
INSTALL THE CASE
IN THE WINDOW
Carefully slide the case into the window and
center the case. Lower the window behind
the top mounting rail. Pull the bottom of the
case forward so that the bottom mounting
rail is tight against the back of the window
stool. Mount the case to the window sill using
4 type E screws. Drill pilot holes, if necessary.
Make sure the bolts and nuts are all of the
way in both the left and right V-supports.
Position the V-supports on the case bottom
so that they will be near the outside wall.
Attach a V-support to each side of the
bottom of the case using type C screws,
3 on each side.
C
B
A
6
Bolt and nut
V-support
4 type E screws
S tool
9

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
10
Installation Instructions
INSTALL THE CASE
IN THE WINDOW (cont.)
Adjust the leveling bolts and nuts against the
outside wall so that the case has a slight tilt
to the outside. Tighten nuts with an adjustable
wrench. Use a level; about a 1/2 bubble will
be the correct case slant to the outside.
Use a wood block (obtained locally) between
the leveling bolts and the wall if the wall is
weak or if the weight of the air conditioner
falls between the studs in the wall.
Extend the left and right accordion panels
to the vertical window sashes. Drill pilot
holes and attach the top and bottom corners
with 4 type D screws.
F
E
D
6
Type D
screw Type D
screw
Type D
screw
Top mounting rail
Type D
screw
INSTALL SUPPORT BRACKETS
AND THE FOAM TOP WINDOW
GAS KET
Attach the support brackets w ith tw o
type D s crews , one on each s ide.
Cut the foam top window gas ket to the
window w idth.
Stuff the foam between the glas s and the
window to prevent air and insects from
getting into the room.
C
B
A
7
10
INSTALL SUPPORT BRACKETS
AND TOP WINDOW FOAM GASKET
Cut the top window foam gasket to the window
width.
Stuff the foam between the glass and the window
to prevent air from getting into the room.

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
11
11
INS TALL THE AIR CONDITIONER
IN THE CASE
Slide the air
conditioner into
the case. Do not
push on the
controls or the
finned coils.
Make sure the
air conditioner
is firmly seated.
Reinstall the locking bracket and screw
removed earlier.
Reconnect the ground wire to the air
conditioner using the screw removed earlier.
IMPORTANT: The ground wire must be
reinstalled to ensure a proper ground.
Remove the front grille from its box and
remove the shipping tape.
Grasp the inlet grille at the bottom corners
and pull it forward. Unhook it from its top
hinges and set it aside.
Using the tab, pull up slightly on the filter
to release it and pull it down and out.
F
E
D
C
B
A
8
Installation Instructions
INSTALL THE AIR CONDITIONER
IN THE CASE (cont.)
Pull the coiled power cord from its shipped
position in the air discharge area. Attach
the front grille frame to the case by inserting
the tabs on the grille frame into the slots
on the front top of the case. Push the grille
frame in. And install the 2 type F screws at bottom
left and right side of front panel.
Secure the front grille frame to the case
with one type C screw.
Reinstall the filter.
Reinstall the inlet grille. Connect power.
J
I
H
G
8
Guide the lever carefully
through the grille fram e
as y ou push it in.
INSTALL THE AIR CONDITIONER
IN THE CASE IN THE CASE (cont.)

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
12
Controls
Mode Pad
Use to set the air conditioner to Cool,
Energy Saver,Fan Only Heat (on some
models) mode. or
controlpanelindicatetheselectedsettings.
Delay 1–24hr
Delay timer
Decrease
Mode select
Fan speed
Decrease
Temperature
set Increase
and Decrease
Remote Control
DelaytimerIncrease
Auto Fan on
Fan speed Increase
Unit power on/off
Power Pad
Turns air conditioner on and off.
Lightsnexttothetouchpadsontheairconditioner
Operating your air conditioner properly helps you toobtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■If you turn off the air conditioner, wait at least 3 minutes
before turning it back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■Do not try to operate your air conditioner in the cooling mode
when outside temperature is below 61°F (16°C). Do not try to
operate your air conditioner in the heating mode when outside
temperature is over 86°F (30°C). The inside evaporator coil
will freeze up, and the air conditioner will operate properly.
NOTE: Inthe event of a power failure, yourair conditioner will
operate at the previous settings when the power is restored.
Display
Shows the set temperature when in Heat/
Cool/Energy Saver mode. Shows time
remaining on the delay timer. Shows
the room temperature when in Fan Only
modes. The Set light will turn on while
setting.
DelayTimer Increase (+)/Decrease (Æ-)Pads
Eachtouchof theIncrease /Decrease
padsontheunitortheIncrease+/Decrease–
padsonthe remotecontrolwillsetthedelay
timewhenusingtheDelay1–24hrtimer .
The Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low,Med,High
or Autoon the unit.NOTE: On the remote
control, use the fan speed Increase+/
Decrease–pads to set the fan speeds to
Low,Med or High. Use the Auto pad to
turn Auto fan on.
TIMER Pads
TIEMR ON—When the air conditioner is off, it
can be set to automatically come on in 0.5 to 24
hours at its previous mode and fan settings.
Operating Controls(For Electronic units)
12
Set
TIMER
SWING
-
FAN
SPEED
MED
HIGH
LOW
AUTO
POWER
COOL
FAN ONLY
HEAT
MODE 1-24 HR
ENERGY SAVER
TEMP/TIMER
+
Light indicates the
delay timer is set.
Light indicates the unit
is in the temperature or
delay time Set mode.
AirConditionerControls
Swing
Light indicates
SWING is on.
SWING Pad
Turn on to provide continuous side-to-side
air circulation. For fixed side-to-side air
direction,turn on until the desired air
direction is obtained,then turn it off.
The display shows the set temperature
when in Heat/Cool/Energy Saver mode.
Shows time remaining on the delay timer.
Shows the room temperature when in
Fan Only mode
Do not try to operate your air conditioner in the cooling mode when
outside temperature is below 61°F (16°C). Do not try to operate
your air conditioner in the heating mode when outside temperature
is over 86°F (30°C). Otherwise, the inside evaporator coil will freeze
up, and the air conditioner will operate properly.
Use to set the air conditioner to COOL, ENERGY
SAVER, FAN ONLY or HEAT mode
Controls
Mode Pad
Use to set the air conditioner to Cool,
Energy Saver,Fan Only Heat (on some
models) mode. or
controlpanelindicatetheselectedsettings.
Delay 1–24hr
Delay timer
Decrease
Mode select
Fan speed
Decrease
Temperature
set Increase
and Decrease
Remote Control
DelaytimerIncrease
Auto Fan on
Fan speed Increase
Unit power on/off
Power Pad
Turns air conditioner on and off.
Lightsnexttothetouchpadsontheairconditioner
Operating your air conditioner properly helps you toobtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■If you turn off the air conditioner, wait at least 3 minutes
before turning it back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■Do not try to operate your air conditioner in the cooling mode
when outside temperature is below 61°F (16°C). Do not try to
operate your air conditioner in the heating mode when outside
temperature is over 86°F (30°C). The inside evaporator coil
will freeze up, and the air conditioner will operate properly.
NOTE: Inthe event of a power failure, yourair conditioner will
operate at the previous settings when the power is restored.
Display
Shows the set temperature when in Heat/
Cool/Energy Saver mode. Shows time
remaining on the delay timer. Shows
the room temperature when in Fan Only
modes. The Set light will turn on while
setting.
Temp Increase  /Decrease Pads
Use to set temperature when in Heat(on some
models)/Cool/EnergySavermode. The Set light
willturnonwhilesetting.
DelayTimer Increase (+)/Decrease (Æ-)Pads
Eachtouchof theIncrease /Decrease
padsontheunitortheIncrease+/Decrease–
padsonthe remotecontrolwillsetthedelay
timewhenusingtheDelay1–24hrtimer( ).
The Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low,Med,High
or Autoon the unit.NOTE: On the remote
control, use the fan speed Increase+/
Decrease–pads to set the fan speeds to
Low,Med or High. Use the Auto pad to
turn Auto fan on.
TIMER Pads
TIEMR ON—When the air conditioner is off, it
can be set to automatically come on in 0.5 to 24
hours at its previous mode and fan settings.
Operating Controls(For Electronic units)
12
Set
TIMER
SWING
-
FAN
SPEED
MED
HIGH
LOW
AUTO
POWER
COOL
FAN ONLY
HEAT
MODE 1-24 HR
ENERGY SAVER
TEMP/TIMER
+
Light indicates the
delay timer is set.
Light indicates the unit
is in the temperature or
delay time Set mode.
AirConditionerControls
Swing
SWING Pad
Turn on to provide continuous side-to-side
air circulation. For fixed side-to-side air
direction,turn on until the desired air
direction is obtained,then turn it off.
The display shows the set temperature
when in Heat/Cool/Energy Saver mode.
Shows time remaining on the delay timer.
Shows the room temperature when in
Fan Only mode
Light indicates the unit
is in the temperature or
delay time Set mode.
TIMER
.5-24 HR
Delay 0.5-24hr timer
Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
12
Controls
Mode Pad
Use to set the air conditioner to Cool,
Energy Saver,Fan Only Heat (on some
models) mode. or
control panelindicatetheselectedsettings.
Power Pad
Turns air conditioner on and off.
Lightsnext tothetouchpadsonthe airconditioner
Operating your air conditionerproperly helps you to obtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■If you turn off the air conditioner, wait at least 3 minutes
before turningit back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■Do not try to operate your air conditioner in the cooling mode
when outside temperature is below 61°F (16°C). Do not try to
operate your air conditioner in the heating mode when outside
temperature is over 86°F (30°C). The inside evaporator coil
will freeze up, and the air conditioner will operate properly.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
Display
Shows the set temperature when in Heat/
Cool/Energy Saver mode. Shows time
remaining on the delay timer. Shows
the room temperature when in Fan Only
modes. The Set light will turn on while
setting.
Temp Increase /Decrease  Pads
Use to set temperature when in Heat(on some
models)/Cool/EnergySavermode. The Set light
willturn onwhile setting.
DelayTimerIncrease (+)/Decrease (Æ-)Pads
Each touchofthe Increase /Decrease
padsontheunitortheIncrease+/Decrease–
padsonthe remote controlwillset thedelay
timewhenusing theDelay1–24hrtimer( ).
The Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low,Med,High
or Autoon the unit.NOTE: On the remote
control, use the fan speed Increase +/
Decrease–pads to set the fan speeds to
Low,Med or High. Use the Auto pad to
turn Auto fan on.
TIMER Pads
TIEMRON—When the air conditioner is off, it
can be set to automatically come on in 0.5 to 24
hours at its previous mode and fan settings.
Operating Controls(For Electronic units)
12
Set
TIMER
SWING
-
FAN
SPEED
MED
HIGH
LOW
AUTO
POWER
COOL
FAN ONLY
HEAT
MODE 1-24 HR
ENERGY SAVER
TEMP/TIMER
+
Light indicates the
delay timer is set.
Light indicates the unit
is in the temperature or
delay time Set mode.
AirConditioner Controls
Light indicates
SWING is on.
SWING Pad
Turn on to provide continuous side-to-side
air circulation. For fixed side-to-side air
direction,turn on until the desired air
direction is obtained,then turn it off.
The display shows the set temperature
when in Heat/Cool/Energy Saver mode.
Shows time remaining on the delay timer.
Shows the room temperature when in
Fan Only mode
Do not try to operate your air conditioner in the cooling mode when
outside temperature is below 61°F (16°C). Do not try to operate
your air conditioner in the heating mode when outside temperature
is over 86°F (30°C). Otherwise, the inside evaporator coil will freeze
up, and the air conditioner will operate properly.
Use to set temperature when in Heat/Cool/Energy
Saver. The SET light will turn on while setting.
Use to set the air conditioner to COOL, ENERGY
SAVER, FAN ONLY or HEAT mode
Controls
Mode Pad
Use to set the air conditioner to Cool,
Energy Saver,Fan Only Heat (on some
models) mode. or
control panelindicatetheselectedsettings.
Power Pad
Turns air conditioner on and off.
Lightsnext tothetouchpadsonthe airconditioner
Operating your air conditionerproperly helps you to obtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■If you turn off the air conditioner, wait at least 3 minutes
before turningit back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■Do not try to operate your air conditioner in the cooling mode
when outside temperature is below 61°F (16°C). Do not try to
operate your air conditioner in the heating mode when outside
temperature is over 86°F (30°C). The inside evaporator coil
will freeze up, and the air conditioner will operate properly.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
Display
Shows the set temperature when in Heat/
Cool/Energy Saver mode. Shows time
remaining on the delay timer. Shows
the room temperature when in Fan Only
modes. The Set light will turn on while
setting.
Temp Increase /Decrease  Pads
Use to set temperature when in Heat(on some
models)/Cool/EnergySavermode. The Set light
willturn onwhile setting.
DelayTimerIncrease (+)/Decrease (Æ-)Pads
Each touchofthe Increase /Decrease
padsontheunitortheIncrease+/Decrease–
padsonthe remote controlwillset thedelay
timewhenusing theDelay1–24hrtimer( ).
The Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low,Med,High
or Autoon the unit.NOTE: On the remote
control, use the fan speed Increase +/
Decrease–pads to set the fan speeds to
Low,Med or High. Use the Auto pad to
turn Auto fan on.
TIMER Pads
TIEMRON—When the air conditioner is off, it
can be set to automatically come on in 0.5 to 24
hours at its previous mode and fan settings.
Operating Controls(For Electronic units)
12
Set
TIMER
SWING
-
FAN
SPEED
MED
HIGH
LOW
AUTO
POWER
COOL
FAN ONLY
HEAT
MODE 1-24 HR
ENERGY SAVER
TEMP/TIMER
+
Light indicates the
Light indicates the unit
is in the temperature or
delay time Set mode.
Light indicates
SWING Pad
Turn on to provide continuous side-to-side
air circulation. For fixed side-to-side air
direction,turn on until the desired air
direction is obtained,then turn it off.
The display shows the set temperature
when in Heat/Cool/Energy Saver mode.
Shows time remaining on the delay timer.
Shows the room temperature when in
Fan Only mode
Controls
Mode Pad
Use to set the air conditioner to Cool,
Energy Saver,Fan Only Heat (on some
models) mode. or
control panelindicatetheselectedsettings.
Delay 1–24hr
Delay timer
Decrease
Mode select
Fan speed
Decrease
Temperature
set Increase
and Decrease
Remote Control
DelaytimerIncrease
Auto Fan on
Fan speed Increase
Unit power on/off
Power Pad
Turns air conditioner on and off.
Lightsnext tothetouchpadsonthe airconditioner
Operating your air conditionerproperly helps you to obtain the
best possible results.
This section explains proper air conditioner operation.
IMPORTANT:
■If you turn off the air conditioner, wait at least 3 minutes
before turningit back on. This prevents the air conditioner
from blowing a fuse or tripping a circuit breaker.
■Do not try to operate your air conditioner in the cooling mode
when outside temperature is below 61°F (16°C). Do not try to
operate your air conditioner in the heating mode when outside
temperature is over 86°F (30°C). The inside evaporator coil
will freeze up, and the air conditioner will operate properly.
NOTE: In the event of a power failure, your air conditioner will
operate at the previous settings when the power is restored.
Display
Shows the set temperature when in Heat/
Cool/Energy Saver mode. Shows time
remaining on the delay timer. Shows
the room temperature when in Fan Only
modes. The Set light will turn on while
setting.
Temp Increase /Decrease  Pads
Use to set temperature when in Heat(on some
models)/Cool/EnergySavermode. The Set light
willturn onwhile setting.
DelayTimerIncrease (+)/Decrease (Æ-)Pads
Each touchofthe Increase /Decrease
padsontheunitortheIncrease+/Decrease–
padsonthe remote controlwillset thedelay
timewhenusing theDelay1–24hrtimer( ).
The Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low,Med,High
or Autoon the unit.NOTE: On the remote
control, use the fan speed Increase +/
Decrease–pads to set the fan speeds to
Low,Med or High. Use the Auto pad to
turn Auto fan on.
TIMER Pads
TIEMRON—When the air conditioner is off, it
can be set to automatically come on in 0.5 to 24
hours at its previous mode and fan settings.
Operating Controls(For Electronic units)
12
Set
TIMER
SWING
-
FAN
SPEED
MED
HIGH
LOW
AUTO
POWER
COOL
FAN ONLY
HEAT
MODE 1-24 HR
ENERGY SAVER
TEMP/TIMER
+
Light indicates the
delay timer is set.
Light indicates the unit
is in the temperature or
delay time Set mode.
AirConditioner Controls
Swing
Light indicates
SWING is on.
SWING Pad
Turn on to provide continuous side-to-side
air circulation. For fixed side-to-side air
direction,turn on until the desired air
direction is obtained,then turn it off.
The display shows the set temperature
when in Heat/Cool/Energy Saver mode.
Shows time remaining on the delay timer.
Shows the room temperature when in
Fan Only mode
Light indicates the unit
is in the temperature or
delay time Set mode.
TIMER
.5-24 HR
Delay .5-24hr timer
Delay0.5–24hr
Delay timer
Decrease
Mode select
Fan speed
Decrease
Temperature
set Increase
and Decrease
RemoteControl
Delaytimer Increase
Auto Fan on
Fan speed Increase
Unit power on/off
Air Conditioner Controls
Timer/Delay
Timer/Delay Pads
Timer/Delay On—When the air conditioner is off, it
0.5
Temp Increase ▲ /Decrease ▼ Pads
Use to set temperature when in Heat
The Set light will turn on while setting.
(on some models)/Cool/Energy Saver
Press Increase(+) and Decrease (-) Pads
at the same time for 3 seconds,Temperature
display will change between ∞oÑF and oC.

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
13
 To ensure proper operation, aim the remote
control at the signal receiver on the air
conditioner.
 The remote control signal has a range of
up to 20 feet.
Remote Control
Cool Mode
Use the Coolmode at Low, Med, High orAuto Fan
Speed for cooling. Use the Temperature Increase 
/Decrease pads to set the desired temperature
between 61°F and 86°F in 1°F increments.
The compressor will cycle on and off to keep
the room at the set level of comfort.
Setthethermostatatalowernumberandthe indoor
airwillbecomecooler.Setthethermostatat ahigher
number and the indoor air will become warmer.
NOTE:If the air conditioner is off and is then turned on
while set to a Coolsetting or if turned from a fan setting
to a Cool setting, it may take approximately 3 minutes
for the compressor to start and cooling to begin.
Fan Only Mode
Energy Saver Mode
Auto Fan Speed
Inthecase ofapoweroutageorinterruption,the
unit will automatically re-start in the settings last
usedafterthe powerisrestored.Ifthe
Power Outage Recovery Feature
Controls the fan.
ON—The fan will cycle on and off with the
compressor. This results in wider variations of
room temperature and humidity. Normally used
when theroom is unoccupied. NOTE: Thefanmay
continuetorunforashorttimeafterthecompressorcyclesoff.
OFF—The fan runs all the time, while the
compressor cycles on and off.
Set to Auto fan speed for the fan speed to auto-
maticallysettothespeedneededtoprovideopti-
mum comfortsettingswiththesettemperature.
If the room needs more cooling, the fan speed
will automatically increase. If the room needs less
cooling, the fan speed will automatically decrease.
Use the Fan Only Mode at Low, Med or High fan
speed to provide air circulation and filtering
without cooling. Since fan only settings do not
provide cooling, a Set temperature cannot be
entered. The room temperature will appear
in the display.
TIMER OFF—When the air conditioner is on,
it can be set to automatically turn off in 0.5 to
24 hours.
How to set:
Press the TIMER1–24hr pad on the unit or
the pad on the remote control. Each
touch of the Increase/ Decrease  pads on the
unit or the Increase +/ Decrease –pads on
the remote control will set the timer in
0.5 hour or 1 hour intervals (the intervals is
0.5 hour as the delay timer below 10 hours;
To review the remaining time on the TIMER
1–24hrtimer, press the TIMER 1–24hr pad on the
unit or the pad on the remote control.
Use the Increase  / Decrease  pads on the unit
or the Increase+/ Decrease –pads on the
remote control to set a new time if desired.
To cancel the timer, press the TIMER1–24hr pad
until the light on the TIMER 1–24hr pad goes off.
 Make sure nothing is between the air conditioner
and the remote control that could block the
signal.
 Makesurebatteriesarefresh andinstalled
correctly as indicated on the remote control.
Cooling Descriptions
For Normal Cooling—Select the Cool mode and
High or Med fan with a middle set temperature.
For Maximum Cooling—Select the Cool mode
and High fan with a lower set temperature.
For Quieter & Nighttime Cooling—Select the
Cool mode and Low fan with a middle set
temperature.
NOTE:Auto FanSpeedcannot be usedwheninthe
Fan Only Mode.
feature was set, it will resume countdown. You may
need to set a new time if desired.
NOTE:Auto FanSpeedcannot be usedwheninthe
Fan Only Mode.
Heat Mode (On some models)
Use the Heat mode at Low, Med, High or Auto Fan
Speed for heating. Use the Temperature Increase
/Decrease pads to set the desired temperature
between 61°F and 86°F in 1°F increments.
13
the intervalsis1hourasthedelaytimerabove
10 hours).TheSetlightwill turnonwhilesetting.
This time delay is required to protect the compressor.
fresh
TIMER -24hr
-24hr timer, press the TIMER -24hr pad on the
TIMER 0.5-24hr
TIMER 0.5-24hr
Timer/Delay OFF—When the air conditioner is on,
Timer/Delay0.5-24hr
0.5
0.5 0.5
TI MER
0.5-24HR DE LAY
TI MER
0.5-24HR DE LAY

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
14
Fan Control
OFF – Completely shuts off the unit. To prevent blowing
fuses, wait two minutes after turning the unit off before
turning it on again.
LOW COOL – Filters and circulates room air with the fan
running continuously on low speed. Also cools and dehu-
midifies while the compressor is running. Select this setting
for quiet cooling operation.
HIGH COOL – Filters and circulates room air with the fan
running continuously on high speed. Also cools and dehu-
midifies while the compressor is running. Select this setting
for maximum air circulation and cooling effect.
LOW HEAT – Filters and circulates room air with the fan
running continuously on low speed. Also heats while the
compressor or electric heat is running. Select this setting for
quiet heating operation.
HIGH HEAT – Filters and circulates room air with the fan
running continuously on high speed. Also heats while the
compressor or electric heater is running. Select this setting
for maximum air circulation and heating effect.
FAN ONLY– Select this setting for circulating or exhausting
room air without cooling.
Temperature Control
Slide this control to the left for a warmer room temperature,
to the right for a cooler room temperature.
Vent Control
Choose one of the following two settings by sliding the vent
control under the appropriate marking:
– Exhausts room air to the outdoors. Also
circulates and filters room air. This position can be used to
exhaust stale or smoky air. To conserve energy, it is advised
that the Fan Control be in the Fan Only setting when using
this feature.
– Exhaust damper is closed. Unit circulates and
filters room air. This position should be used for normal
cooling operation.
COMFORT ZONETM AND HEAT PUMP MODELS
14
Operating Controls(For Mechanical units)
CLOSE
OPEN

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
15
17
BeforeCallingService
To reduce the risk of electric shock, personal injury, or death, turn the fan control to the
off position and remove the unit plug from the wall outlet before doing any inspection or
maintenance work.
WARNING
The following is a list of problems that are sometimes encountered when using a room air conditioner. Possible cause and
suggested remedies are given for each problem.
If the problem cannot be fixed using the suggested remedies, see WHEN SERVICE IS REQUIRED section.
PROBLEM POSSIBLE CAUSE SUGGESTED REMEDY
UNIT WILL NOT RUN No power to unit Push reset button on power cord.
Set Fan Control to position other than OFF.
Make sure plug is firmly seated in outlet.
Check for blown fuses, tripped circuit breakers.
LITTLE OR NO COOLING
LITTLE OR NO HEATING
(fan and compressor run)
Fresh air/exhaust damper open
Obstructed indoor or outdoor airflow
Dirty air filters
Unit undersized for application
Set vent to CLOSED.
Remove obstruction from indoor grille or outdoor louvers.
Dirty air filter. Clean or replace, as needed.
Check with dealer to determine proper capacity unit for application.
LITTLE OR NO COOLING
LITTLE OR NO HEATING
(only fan runs)
Temperature Control not set properly For cooling, turn Temperature Control to cooler setting.
For heating, turn Temperature Control to warmer setting.
NOISY UNIT Loose front on mounting assembly
Weak building construction
Water hitting fan blade
Unit oversized for application:
compressor cycles on and off frequently
Tighten any loose parts.
Provide additional support for unit.
Normal in high humidity. Stop noise by removing drain plug or
adding condensate drain cup.
Check with dealer to determine proper capacity unit for application.
MOUNTING SUPPORT NOT
INSTALLED
Storm window frame installed in window Some models require removal of storm window frame before
installation.
FROST ON INDOOR COIL Dirty air filter
Normal for low outdoor temperatures
Clean air filter by vacuuming or washing with water and mild soap.
Turning Temperature Control to warmer setting reduces occurrence
and duration of frost.
FROST ON OUTDOOR COIL
(heat pump models only)
Normal for outdoor temperatures at or
below 45°F
Call for service only if unit does not heat room and you have
checked all problems and remedies listed under LITTLE OR NO
HEATING.
ODORS IN COOLING Mold, mildew, or algae formation on wet
surfaces
To reduce algae growth, use algaecide tablet in base pan; remove
drain plug; add condensate drain cup and hose. Thoroughly clean
unit.
ODORS IN HEATING Normal for first time electric heater is
used each season
Caused by dust accumulation during unused months.
Odor dissipates quickly with heater use.
When Service Is Required
Your room air conditioner dealer can give you the name of
your nearest Authorized Service Center. Help them give
you prompt service by providing:
•An accurate description of problem.
•Complete model, serial, and manufacturing (P) num-
bers from serial plate.
•Proof of purchase (sales receipt) upon request.
Repair by unauthorized servicer that results in subsequent
failure of unit voids warranty. Warranty details are con-
tained in warranty certificate enclosed with unit.
Keep accurate records of service calls, including what was
done, servicer’s name, and date of service.
AnyQuestions?
Most questions can be answered by your local dealer. If you
have other matters that cannot be resolved locally, or you
need additional information regarding other heating and
cooling products offered by us - please call:
CONSUMER INFORMA
Tel: [phone] (Customer Service Center)
TION LINE
Web Site: http://www.gree.com.cn
Troubleshooting
Set Fan Control to any position other than OFF.
Front panel may be loose
Heat Controller, Inc.
Customer or Technical Service Department
517-787-2100
Call 866-557-1865 for service and warranty. Help them
give you prompt service by providing:
Complete model and serial number from
serial plate

Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc.
16
THIS PAGE WAS LEFT INTENTIONALLY BLANK

Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual
17
THIS PAGE WAS LEFT INTENTIONALLY BLANK

04/2009
07/2010 66129905195
