heat-timer DiGi-SPAN Elite Series User manual

TSC DIGI-ElITE
Two-Stage Set Point Control
®
e’Œšˆ sˆ˜Œˆ™
LIMITED ONE-YEAR WARRANTY
This Heat-Timer device was thoroughly tested for defects and workmanship before leaving our factory. We do warrant the equipment to be free of defects under normal
use for a period of one year from the date of installation. Transportation charges for factory repairs must be prepaid. Damage to the Heat-Timer device or any of its
components due to misuse, abuse, improper installation, or caused by power failures, fire, flood, or lightning are not covered by this warranty. The company assumes
no liability for indirect or consequential damages of any nature. This Heat-Timer warranty applies only to the original purchaser/user, is not assignable or transferable,
and does not cover damage to the device occurring in shipment. Any service, repairs, modifications or alterations to the unit not expressly authorized by the company
will invalidate the warranty. This warranty is in lieu of all other warranties expressed or implied.
Temp -30˚F - 250˚F (-34˚C-121˚C)
Humidity 0% RH - 100% RH
Vacuum 0 Hg - 30 Hg
0mm - 760mm
Pressure 0 PSI - 30 PSI
0 PSI - 100 PS
0 PSI - 200 PSI
0 PSI - 300 PSI
Pressure 0.0 MPa - 0.250MPa
0.0 MPa - 0.600MPa
0.0 MPa - 1.000MPa
0.0 MPa - 1.600MPa
The TSC Elite is a microprocessor based Two-Stage set
point control that provides users with Digital Set Point
capability to measure and control two-stage heating,
cooling, or change-over (Heat/Cool) devices based on
a remote temperature, pressure, vacuum, or humidity
sensor Input. With built-in two Output relays, it is
capable of activating or deactivating equipment and
devices based on the two set points and differential.
Some features that are incorporated into the TSC Elite
include:
• SensorFaultOutputStatus.
• EnableDisableTerminals.
• SensorTrimtocalibratesensor.
• Independentorconsecutiveoperatingmode.
• Back-lit2-LineAlpha-NumericLCDDisplay.
• Vacuumsensorreading
• EnglishandMetricscales.
INSTALLATION AND OPERATION INSTRUCTIONS
WARNING
This Heat-Timer control is strictly an operating
control; it should never be used as a primary
limit or safety control. All equipment must have
its own certified limit and safety controls required
by local codes. The installer must verify proper
operation and correct any safety problems prior
to the installation of this Heat-Timer control.
SystemIncreaseDecrease OUTPUT2
SET
®
SYSTEM = 117oF
TARGET = 125oF/150oF
OUTPUT1
T1 T2COM T3+COM COM24VACEXT+EXT-T3- P+ P-
2 Line Alphanumeric Display
Displays sensor values and
menu settings
Output Lights indicate
output status
Display Section Locking Screws
Black (120VAC power)
Input Terminals
OUTPUT1
White N.O.
OUTPUT2
Blue N.O.

2
Mounting the Controller
• TheTSCDIGI-Eliteisdesignedtomountona1900
(4”x4”) electrical box.
• IftheTSC-Eliteistobepanelmounted,orifadditional
room is needed use the Plastic Wiring Enclosure (HT#
929135-00Switch)or(HT#929137-00withouta
Switch).
• LocatetheTSC-Eliteinaconvenientlocationnearthe
unit to be controlled.
• PartiallyunscrewtheDisplayCoverMountingscrews.
This allows for its removal.
• LiftingtheDisplaySectionawayfromthebasewill
unplugtheConnectionSocketfromtheBasesection.
• Proceedwiththepowerandoutputwiringinstructions.
• MounttheTSCawayfromexcessiveheatorcold.
Ambientoperatingtemperatureisfrom20to120°F.
• MountDisplaySectionbacktotheBaseSection.
TightentheDisplayCoverMountingScrews.
Wiring Power Input
The TSC-Elite is designed to accept ONLY A SINGLE POWER SOURCE. It can be wired to either
120VACusingthetwoBlackwiresor24VACusingtherightmosttwoterminalsontheterminalblock
on bottom of the control. Heat-Timer recommends the installation of a Surge Suppressor and a Power
SwitchbeforethePowerLineconnectionforsafetyandeaseofservice.
120VAC
• Attachlinevoltage,120VAC,tothetwoBlackwiresextendingfromthebackoftheTSC-Elite.
Remember to use the power line from a different source than the equipment being controlled.
24VAC
• Useadedicatedtransformerwithatleasta5VAoutput.
• Bring24VACtothetworightmostscrewsonthefrontoftheTSC-Elitemarked24VAC and COM
Wire Colors
• TheTSCElitehasatwoS.P.S.T.(single-polesingle-throwN.O.)relays.
Eachoutputisratedat6A,1/8HP.
• Theoutputsaredrycontactsonly.Theydonotsourceanypower.
• ThetwoWhitewiresrepresentOutput1relay.
• ThetwoBluewiresrepresentOutput2relay
Wiring Input Terminals
BasedupontheoptionsselectedfromtheSensorTypeinStartupmenu,
the sensor input terminals will vary. The TSC Elite will only measure
the terminals used for the specific sensor type. All other sensor terminal
inputs will be ignored. i.e., if the TSC was set to measure Temperature
250˚F,itwillonlymeasureterminalsT1,COM.See"SensorType
SettingsandTerminals"onpage6
T1 T2 T3+ COM COM T3- EXT+ EXT- P+ P- COM 24VAC
Input Terminals
Temperature Sensors
rated Up to 250˚F/121˚C {
Pressure, Vacuum, Humidity
Sensors, or 4-20mA input {
Enable/Disbale
Dry Contact Only {
{
Not Used {
24VAC power Input {
Not Used
Display Cover
Mounting Screws
Display Section
Base Section
Base Mounting Holes
Input Terminals
24VAC optional
power input
Connection
Socket
WARNING
The TSC-Elite can accept only one source of
power: 120VAC or 24VAC. If more than one power
source is applied, the unit may be damaged.
SystemIncreaseDecrease OUTPUT2
SET
®
SYSTEM = 117oF
TARGET = 125oF/150oF
OUTPUT1
Temperature Sensor Enable/Disable
Switch
White (N.O.)
Blue (N.O.)
OUTPUT1
Normally Open (N.O.)
Activated when
relay is Energized
OUTPUT2
Normally Open (N.O.)
Activated when relay
is Energized
120 VAC
Black (Power)
T1 T2COM T3+COM COM24VACEXT+EXT-T3- P+ P-
SystemIncreaseDecrease OUTPUTS
SET
®
SYSTEM = 147oF
TARGET = 150oF
120 VAC
Black (Power)
SystemIncreaseDecrease OUTPUTS
SET
®
SYSTEM = 147oF
TARGET = 150oF
24 VAC
Optional Power
COM
24VAC
T1 T2COM T3+COM
COM24VAC
EXT+EXT-T3-
P+ P-

3TSC Digi-Elite Operation Manual
Installing and Wiring Temperature Sensor Inputs
(T1, COM (-30°F-250°F)
A variety of sensor inputs can be connected to the TSC-Elite series depending on the model and
sensors provided. Each TSC-Elite comes with the sensors it is designed to work with.
• Thesensorwirescanbeextendedupto500'bysplicingwith18gaugeshieldedwire.
• Donotrunsensorwiresinconduitwithlinevoltage.
• Ifmeasuringliquidtemperature,thesensorshouldbeinsertedintoa3/8"IDwell
(HT#904011orequivalent).
• TheTSC-Elitewilloperatebasedonthetemperatureitreadsatthesensorlocation.
Therefore, select a sensor location that is representative of the entire system.
• Intemperatureapplications,polarityisnotobserved.Eitherwirefromthesensorcanbe
connected to either sensor input.
• ConnecttheShieldofeachsensoratthecontrolsidetotherespectiveCOMterminal.
Installing and Wiring a Pressure or Vacuum Sensor
(P+, P-)
• Attacha1/4”brassisolationtube(pigtail)tothesteamheader.
• ScrewthepressureorVacuumsensortothepigtail.Thesensorhas1/4”NPTtaperedthreads.
• Thesensorwirescanbeextendedupto500’bysplicingwith18gaugeshieldedwire.
• Donotrunsensorwiresinconduitwithlinevoltage.
• TheTSC-Elitewilloperatebasedonthepressureorvacuumsensorreading.Therefore,selecta
sensor location that is representative of the entire system.
• Thesensor'sBLACKwireshouldbeconnectedtotheterminalmarkedP(-).
• TheREDwirefromthesensorshouldbeconnectedtotheterminalmarkedP(+).
ALERT
The EXT input terminals must be shorted for TSC-Elite to operate the outputs. DO NOT
remove the factory installed EXT jumper unless it is replaced with an Enable Signal.
Connecting the Enable/Disable
(EXT+, EXT-)
• TheEXTterminalscanbeusedtoenableordisablethesystembyconnectingittoeitherathermostator
external control.
• TheEXTinputshouldbedrycontactonly.
• Polarityisnotimportant.EitherwirefromthethermostatcanbeconnectedtoeitherEXTterminals.
• IfnothermostatorcontrolisconnectedtotheEXTterminals,leavethejumpersuppliedasacontacttothe
terminals.
• NooutputswillbeactiveunlesstheEXTterminalsareclosed.
Button and Navigating Menus
The TSC Elite has three buttons.
• TheSETbuttonfunctionvaries.WhentheDefaultScreenis
displayed,pushingtheSETButtonviewstheMENU.Wheninthe
Menusandsettings,theSETButtonacceptstheselectedentryor
setting value.
• Wheninthemenus,theUpandDownbuttonswillscrollthroughthemenuoptions.Theycanbeusedtochangethesettingofa
specicfunction.i.e.changetheSetPoint,Differential,orSystemTrim.
• Attheendofeveryoperationmenuthereisa<Back>optionthatallowstheusertogobackonemenulevel.IftheSETButtonwas
helddownforthreesecondsonthe<Back>option,thedisplaywillgobacktothedefaultscreen.
Startup Options
Wheneverthecontrolisstartedforthersttimeorafteramanualreset,itwillinitiateitsoperationwiththeStartupMenu.Moreover,
the Startup menu can be accessed by selecting it from the operation menu. An option must be selected in each screen in the Startup
Menutomovetothenextlevel.
SET
SET
SET
SET
SET
SET
SystemIncreaseDecrease OUTPUT2
SET
®
SYSTEM = 117oF
TARGET = 125oF/150oF
OUTPUT1
-30°F - 250°F
Temperature Sensor
T1 T2COM T3+COM
COM24VACEXT+EXT-T3- P+ P-
SystemIncreaseDecrease OUTPUT2
SET
®
SYSTEM = 117oF
TARGET = 125oF/150oF
OUTPUT1
Cut the Green,
White, and Clear
Tube
Connect
to 1/4" pigtail
BLACK
RED
Transducer
4-20mA
T1 T2COM
T3+
COM COM24VAC
EXT+EXT-T3- P+ P-
SystemIncreaseDecrease OUTPUT2
SET
®
SYSTEM = 117oF
TARGET = 125oF/150oF
OUTPUT1
Enable/Disable
Switch
T1 T2COM
T3+
COM COM24VAC
EXT+EXT-T3- P+
P-

4
Standard
Options: English, Metric Default: English
SET
SET
SET
SET
SET
SET
: MENU/<System Startup>/Standard
Due to the large variety of inputs available to connect to the TSC Elite, this option helps in narrowing
down the sensor type options.
STANDARD:
English
Metric
• IfEnglishisselected,sensortypesin˚F(Fahrenheit),PSI(Pounds/Squareinch),Hg(Inchesof
MercuryforVacuum)willbeavailable.
• IfMetricisselected,sensortypesin˚C(Celsius),MPa(MillionPascal),mm(Millimeterof
MercuryforVacuum)willbeavailable.
• %RH(RelativeHumidity)willbeavailableinbothoptions.
SENSOR TYPE:
Temp. 250 F
Pres. 30psi
Pres. 100psi
Pres. 200psi
Pres. 300psi
Vacuum 30in
Humidity %RH
SENSOR TYPE:
Temp. 121 C
Pres. 0.250MPapsi
Pres. 0.600MPapsi
Pres. 1.000MPapsi
Pres. 1.600MPapsi
Vacuum 760mm
Humidity %RH
Sensor Type
Options: Temp.250˚F/121˚C, Pres. 30Psi/0.25MPa, Pres. 100Psi/0.60MPa, Pres. 200Psi/1.0MPa,
Pres. 300Psi/1.6MPa, Vac. 30Hg/760mm, and Humidity %RH Default: Temp.250˚F/121˚C
SET
SET
SET
SET
SET
SET
: MENU/<System Startup>/Standard/Sensor Type
The Sensor Type available options depend on the Standard Option selected from the previous menu.
Control Mode
Options: Heat-BreakOnRise, Cool-MakeOnRise, Change-over Default: Heat-BreakOnRise
SET Button: MENU/<System Startup>/Standard/Sensor Type/Control Mode
• InHeat-Break-On-Risemodeeachrelaywillenergizewhenthesensorvalueisbelowthe
corresponding set point.
• InCool-Make-On-Risemodeeachrelaywillenergizewhenthesensorvalueisabovethe
corresponding set point.
• InChange-Overmode(Heat/Cool),therstoutputrelaywillenergizewhensensorvalueisabove
SP1.However,whenthesensorvaluefallsbelowSP2,the2ndoutputrelaywillenergize.
CONTROL MODE:
Heat-BreakOnRise
Cool-MakeOnRise
Change-Over
Operating Mode
(Available in Heat and Cool Modes Only)
Options: Independent, Consecutive Default: Independent
SET
SET
SET
SET
SET
SET
: MENU/<System Startup>/..../Operating Mode
OPERATING MODE:
Independent
Consecutive
• IftheOperatingmodeissettoHeatingandConsecutive,Output2relay(Bluewires)willoperate
fromthelowestsensortemperaturetotheSP2Setting.However,Output1relay(Whitewires)will
operatefromSP2settingtotheSP1Setting.
• InConsecutivemode,amaximumofoneoutputwillbeonatanypoint.
• InConsecutivemode,norotationwillbeavailable.
• Consecutivemode,isgreatforapplicationswheretheoutputsarenotequalincapacity.
• InIndependentmode,bothoutputscouldbeonwhenbelowthelowestSetPointinHeatingor
when above the highest Set Point in Cooling.
Sensor Fault
(Not Available in Change-Over Mode)
Options: All Off, All On Default: All On
v: MENU/<System Startup>/..../Sensor Fault
• TheSensorFaultwilldeterminetheoperatingstatusoftherelaywhenasensorreadsShortor
Open. On sensor fault the Set Point will indicate FAULT TGT=ON or OFF to indicate the
condition of the output and the Sensor will read SYSTEM=OPEN or SHORT to indicate the
condition of the sensor.
SENSOR FAULT:
Output On
Output Off
SYSTEM= OPEN
FAULT TGT= ON
Manually Resetting the Control to Defaults
To Reset the TSC Elite control to its original factory defaults, power down the control. Hold down
theSETandDOWNbuttonswhilepoweringthecontrolbackupuntiltheLoadingDefaultValues
Loading Default
Values...
screen appears. The Display will direct you to the Startup menu after the defaults are loaded to program the control.
ALERT
When resetting the control to original factory defaults all control settings will be over written and will no longer exist.

5TSC Digi-Elite Operation Manual
HEAT-TIMER CORP.
V1.00 c 2006
DIGI-SPAN ELITE
TSC
Loading Default
Values...
STANDARD:
English
Metric
SENSOR TYPE:
Temp. 250 F
Pres. 30psi
Pres. 100psi
Pres. 200psi
Pres. 300psi
Vacuum 30in
Humidity %RH
CONTROL MODE:
Heat-BreakOnRise
Cool-MakeOnRise
Change-Over
SENSOR FAULT:
Output On
Output Off
SETUP COMPLETE!
PRESS SET
SENSOR TYPE:
Temp. 121 C
Pres. 0.250MPapsi
Pres. 0.600MPapsi
Pres. 1.000MPapsi
Pres. 1.600MPapsi
Vacuum 760mm
Humidity %RH
Startup Menu
SYSTEM= 68 F
TARGET= 100/70 F
------MAIN------
SP1 70 F
SP2 70 F
<Settings>
<Maintenance>
<Sys. Startup>
<Info>
<Back>
Set Point1:
70 F 140 F
----SETTINGS----
Diff. 5 F
Rotation On
<Back>
Differential:
5 F 10 F
---MAINTENANCE---
SysTrm +0 F
<Back>
System Trim:
+0 F -1 F
SYSTEM STARTUP
No
Yes
TSC V1.00
Temp.250 F
Heat-BreakOnRise
Independent
FAULT: Output On
Operating Menu
Default Screen
Menus
SET
SET
SET
SET
SET
SET
Operating Menu Options (Click SET Button)
Set Point SP1, SP2
Options: Varies based on Sensor Type. See "Sensor Type Settings and Terminals" on page 6
SET
SET
SET
SET
SET
SET
: MENU/SP1 , SP2
• EachoftheSetPoints(Target)isthetemperature,pressure,vacuum,orrelativehumiditytheTSC
will use to control the system by energizing the respective output relay. It will be displayed on the
default screen as Target= SP1/SP2.
Set Point1:
70 F 140 F
SYSTEM= 68 F
TARGET= 100/70 F
Differential
Options: Varies based on Sensor Type. See "Sensor Type Settings and Terminals" on page 6
SET
SET
SET
SET
SET
SET
: MENU/<Settings>/Diff.
Differential:
5 F 10 F
• Thedifferentialcontrolshowmanydegreesthesystemcanuctuatearoundanyofthesetpoints.Itisusedtopreventshortcycling
of the unit being controlled.
• AsmallerDifferentialsettingwillnormallyresultintightercontrolofthesetpointbutwilltendtoincreasethefrequencyofuc-
tuationinthesystem.LargerDifferentialvalueswillreduceoutputshortcycling,butthesystemwillbeallowedtovaryfurther
from the set point value
• Dependingonthecontrolmodeofoperation,thedifferentialwillbeeitheraddedorsubtractedfromthesetpoint.
OPERATING MODE:
Independent
Consecutive
ROTATION:
On
Off

6
Rotation
(Not Available in Consecutive or Change-Over Modes)
Options: On, Off
SET
SET
SET
SET
SET
SET
: MENU/<Settings>/Rotation.
• IfOffwasselected,theTSCElitewillhaveaxedleadstageandnorotationwilltakeeffect.
ROTATION:
On
Off
• IfOnwasselected,theTSCElitewillrotatetheleadstageevery24hours.WhentheTSC'spoweristurnedon,therstrotation
willtakeplacein12hours.The24-hourrotationwilltakeeffectaftertherstrotation.
System Trim
Options: Varies based on Sensor Type
SET
SET
SET
SET
SET
SET
: MENU/<Maintenance>/SysTrm
TheSystemTrimvalueadjuststhesensorreadingusingpositiveornegativevalues.Itallowsyouto
calibrate the sensor by the number of units selected.
System Trim:
+0 F -1 F
Sensor Type Settings and Terminals
STANDARD SENSOR TYPE SET POINT DIFFERENTIAL TRIM (Default=0) SENSOR
TERMINALS
Range Default Range Default Range
English Temperature 250˚F -30˚F to 250˚F 70˚F 1˚F to 40˚F 5˚F -20˚F to +20˚F T1, COM
English Pressure 30 PSI 0.0 to 30.0 PSI 10.0 PSI 0.5 to 10.0 PSI 2.0 PSI -3.0 to +3.0 PSI P+, P-
English Pressure 100 PSI 0 to 100 PSI 30 PSI 1 to 30 PSI 7 PSI -10 to 10 PSI P+, P-
English Pressure 200 PSI 0 to 200 PSI 60 PSI 1 to 60 PSI 10 PSI -20 to +20 PSI P+, P-
English Pressure 300 PSI 0 to 300 PSI 80 PSI 1 to 90 PSI 20 PSI -30 to +30 PSI P+, P-
English Vacuum 30 Hg 0.0 to 30.0 Hg 10.0 Hg 0.5 to 10.0 Hg 2 Hg -3.0 to +3.0 Hg P+, P-
Metric Temperature 120˚C -34˚C to 121˚C 21˚C 1˚C to 22˚C 3˚C -11˚C to +11˚C T1, COM
Metric Pressure 0.250 MPa 0.0 to 0.25 MPa 0.10 MPa 0.001 to 0.100 MPa 0.02 MP -0.025 to +0.025 MPa P+, P-
Metric Pressure 0.600 MPa 0.0 to 0.6 MPa 0.2 MPa 0.002 to 0.200 MPa 0.03 MPa -0.06 to +0.06 MPa P+, P-
Metric Pressure 1.000 MPa 0.0 to 1.0 MPa 0.3 MPa 0.005 to 0.300 MPa 0.05 MPa -0.1 to +0.1 MPa P+, P-
Metric Pressure 1.600 MPa 0.0 to 1.6 MPa 0.5 MPa 0.005 to 0.500 MPa 0.10 MPa -0.16 to +0.16 MPa P+, P-
Metric Vacuum 760 mm 0 to 760 mm 250 mm 10 to 250 mm 50 mm -80 to +80 mm P+, P-
English /
Metric
Humidity %RH 0 to 100%RH 60 %RH 1 to 30 %RH 7 %RH +10 to -10%RH P+, P-
Heating, Cooling, and Change-Over (Heat/Cool) Operation
The TSC Elite can operate in either heating or cooling applications. Select the proper application from the Startup menu.
• Inheatingapplications,theTSCElitecontrolwillusetheSetPointlesstheDifferentialasastartingpointwhensensorreadingis
dropping. Then, it will keep the relay energized as long as the sensor is below the Set Point (Target).
• Whenthesystemvalueincreasesinheatingapplications,therelaywillremainenergizeduntiltheSetPoint(Target)isreached.
Then, it will de-energize.
SP1 = 60
SP2 = 80
DIF = 5
Output 1
ON
Output 2 ON
85
65
80
60
Output 1
ON
Output 2 ON
TSC Independent
Cooling
Diff
Diff
SP1
SP2
Both
Outputs
are ON
Off
Off
SP1 = 60
SP2 = 50
DIF = 5
Output 1 ON
Output 2 ON
65
50
60
45
Output 1 ON
Output 2 ON
TSC Change-Over
Heating/Cooling
Diff
Diff
SP1
SP2
Dead
Band
Off
Off
SP1 = 120
SP2 = 100
DIF = 5
Output 1 ON Output 2 ON
120
100
115
95
Output 1 ON Output 2 ON
TSC Independent
Heating
Diff
Diff
SP1
SP2
Both Outputs
are ON
Off
Off
Output 1 ON
Output 1 ON
Off
Off
SP1 = 120
SP2 = 100
DIF = 5
Output 2 ON
120
100
115
95
Output 1 ON
Output 2 ON
TSC Consecutive
Heating
Diff
Diff
SP1
SP2
Only Output 2
is ON
Off
Off
Off
Output 1 ON
Off
Off
SP1 = 60
SP2 = 80
DIF = 5
Output 2 ON
85
65
80
60
Output 2 ON
TSC Consecutive
Cooling
Diff
Diff
SP1
SP2
Only Output 2
is ON
Off
Off
Off
Output 1
ON
Output 1
ON
Temp Rising
Temp Dropping
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
SP1 = 60
SP2 = 80
DIF = 5
Output 1
ON
Output 2 ON
85
65
80
60
Output 1
ON
Output 2 ON
TSC Independent
Cooling
Diff
Diff
SP1
SP2
Both
Outputs
are ON
Off
Off
SP1 = 60
SP2 = 50
DIF = 5
Output 1 ON
Output 2 ON
65
50
60
45
Output 1 ON
Output 2 ON
TSC Change-Over
Heating/Cooling
Diff
Diff
SP1
SP2
Dead
Band
Off
Off
SP1 = 120
SP2 = 100
DIF = 5
Output 1 ON Output 2 ON
120
100
115
95
Output 1 ON Output 2 ON
TSC Independent
Heating
Diff
Diff
SP1
SP2
Both Outputs
are ON
Off
Off
Output 1 ON
Output 1 ON
Off
Off
SP1 = 120
SP2 = 100
DIF = 5
Output 2 ON
120
100
115
95
Output 1 ON
Output 2 ON
TSC Consecutive
Heating
Diff
Diff
SP1
SP2
Only Output 2
is ON
Off
Off
Off
Output 1 ON
Off
Off
SP1 = 60
SP2 = 80
DIF = 5
Output 2 ON
85
65
80
60
Output 2 ON
TSC Consecutive
Cooling
Diff
Diff
SP1
SP2
Only Output 2
is ON
Off
Off
Off
Output 1
ON
Output 1
ON
Temp Rising
Temp Dropping
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising

7TSC Digi-Elite Operation Manual
• Incoolingapplications,theTSCElitecontrolwillusetheSetPointplustheDifferentialasastarting
point when sensor reading is increasing. It will energize the output relay as long as the sensor is
above the Set Point (Target).
• Whenthesystemvaluefallsincoolingapplications,therelaywillremainenergizeduntiltheSet
Point (Target) is reached. Then, it will de-energize.
• TheChange-OveroptionwillallowOutput1relaytofollowSP1.Output1relaywillenergize
wheneverthesensorvalveisaboveSP1plusthedifferential.Therelaywillde-energizewhen
thesensorvaluedropstotheSP1value.TheOutput2relaywillfollowSP2.Output2relaywill
energizewheneverthesensorvalveisbelowSP2minusthedifferential.Therelaywillde-energize
whenthesensorvalueincreasestotheSP2value.
Output Light
The TSC Elite has three lights, however, only the left two output
lights are used. They follow the relay operation. Whenever,
theleftOutputLightisON,Output1isactiveandtherelayis
energized.ThemiddlelightwillrepresentOutput2status.
Enable/Disable Input
TheTSCElitewilloperateinheatingorcoolingmodesonlyiftheEXT-andEXT+terminals
are shorted. If no external equipment or switch is connected to these terminals, leave the factory
installedjumper.WhentheterminalsareOPEN,theTargetwilldisplayTSTATOPEN.
ALERT
On a sensor fault while the Enable/Disable terminals are open, the
control will follow the Enable /Disable state. However, the System
Sensor will display the fault condition weather Short or Open.
SYSTEM= 55 F
TSTAT OPEN
SYSTEM= SHORT
TSTAT OPEN
Troubleshoot
No Display:
 Turnthepoweroffandbackon.MakesuretheDisplaysection
is mounted securely to the base.
OPEN or SHORT Display:
 First,makesurethattheSensorTypeselectedmatchesthe
sensor used. Also, make sure that the sensor is connected to
therespectiveinputterminals.IfcontrolreadsOPEN,the
TSC-Elite either does not see a sensor connected or the sensor
reading is below the sensor operating range. Check the sensor
wires are connected from the sensor to the TSC-Elite controller.
If SHORT, the TSC-Elite either sees a short across the input
terminals or the sensor reading is above its operating range.
Remove the sensor wires from the TSC-Elite terminals, the
displayshouldreadOPEN.Ifthedisplaydoesnotchangeto
OPEN,theTSC-Elitemaybedamaged.Otherwise,followsteps
for Incorrect Temperature Display for temperature sensors or
IncorrectpressureorVacuumDisplayforalltransducers.
Incorrect Temperature Display:
 RemovethewiresfromtheSENSORscrews.Thedisplay
shouldchangetoreadOPEN.Ifitdoesn’t,theTSC-Elitemay
bedamaged.Fortemperature,takeanohmreadingacrossthe
detached sensor wires. The ohm reading should correspond
tothechartontheright.Iftheohmreadingissignicantly
different, the sensor may be damaged.
SP1 = 60
SP2 = 80
DIF = 5
Output 1
ON
Output 2 ON
85
65
80
60
Output 1
ON
Output 2 ON
TSC Independent
Cooling
Diff
Diff
SP1
SP2
Both
Outputs
are ON
Off
Off
SP1 = 60
SP2 = 50
DIF = 5
Output 1 ON
Output 2 ON
65
50
60
45
Output 1 ON
Output 2 ON
TSC Change-Over
Heating/Cooling
Diff
Diff
SP1
SP2
Dead
Band
Off
Off
SP1 = 120
SP2 = 100
DIF = 5
Output 1 ON Output 2 ON
120
100
115
95
Output 1 ON Output 2 ON
TSC Independent
Heating
Diff
Diff
SP1
SP2
Both Outputs
are ON
Off
Off
Output 1 ON
Output 1 ON
Off
Off
SP1 = 120
SP2 = 100
DIF = 5
Output 2 ON
120
100
115
95
Output 1 ON
Output 2 ON
TSC Consecutive
Heating
Diff
Diff
SP1
SP2
Only Output 2
is ON
Off
Off
Off
Output 1 ON
Off
Off
SP1 = 60
SP2 = 80
DIF = 5
Output 2 ON
85
65
80
60
Output 2 ON
TSC Consecutive
Cooling
Diff
Diff
SP1
SP2
Only Output 2
is ON
Off
Off
Off
Output 1
ON
Output 1
ON
Temp Rising
Temp Dropping
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
Temp Dropping
Temp Rising
SystemIncreaseDecrease OUTPUT2
SET
®
SYSTEM = 117oF
TARGET = 125oF/150oF
OUTPUT1
250°F/120°C Temperature
Sensor Chart
TEMPERATURE Value
(in Ohms)
°F°C
OPEN 150000
-30 -34 117720
-20 -29 82823
-10 -23 59076
0 -18 42683
10 -12 31215
20 -7 23089
25 -4 19939
30 -1 17264
35 2 14985
40 4 13040
45 7 11374
50 10 9944
55 13 8714
60 16 7653
70 21 5941
80 27 4649
90 32 3667
TEMPERATURE Value
(in Ohms)
°F°C
100 38 2914
110 43 2332
120 49 1879
130 54 1524
140 60 1243
150 66 1021
160 71 842
170 77 699
180 82 583
190 88 489
200 93 412
210 99 349
220 104 297
230 110 253
240 116 217
250 121 187
SHORT 100

8
Incorrect Pressure or Vacuum Display:
 Makesurethatthepressuresettingselectedmatchesthepressure
transducer connected to the TSC-Elite control. If it does, then use a
current multi-meter and set it to read mA and put it in series with the
sensor.Matchtheohmreadingtothepressuretablebelow.Ifcurrent
does not match the actual pressure, use the System Trim from the
MaintenanceMenutocorrectit.Ifthedifferenceislargerthanthe
System Trim range, then the pressure or vacuum transducer is damaged.
RememberthatPressureandVacuumtransducersaresusceptibletostatic
electricity. Thus, reduce excessive manual handling prior to transducer
installation.
Output Red Light does not come on at the desired temperature:
Check the set points and differential values. In a heating application,
the Red light will not come on until the sensor value drops below the
set point minus the differential. In a cooling application, the Red light
will not turn off until the sensor value rises above the set point plus the
differential.
TSC-Elite does not activate the output:
 FirstremoveallconnectionstotheWhiteandBlueoutputwires.Ifboth
Outputs'RedLightsareon,therelaysshouldbeenergized.Boththe
WhitewiresandtheBluewiresshouldbeclosed.IfbothOutputs'Red
Lightsareoff,therelaysshouldbede-energized.BoththeWhitewires
andtheBluewiresshouldbeopen.Iftheabovetwoconditionsaremet,
the TSC-Elite is working normally. Check the unit the TSC-Elite is
controlling.
Specications
Voltage Input: . . . . . . . 120 VAC 60 Hz(2 Black wires) /24VAC 60 Hz (24VAC terminals) (Only One Power Source)
Power Consumption: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 VA Max
Operating Temperature: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20°F/-7°C to 120°F/49°C
Operating Humidity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20% to 80%
Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4"W x 4"H x 2½"
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 pound
Outputs: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 S.P.S.T (White = Output1.), (Blue = Output2.)
Output Relay Ratings: . . . . . . . . . . . . . . . . . . . . . 1 Amp Inductive duty, 6 Amp resistive at 120 VAC 60 Hz
Control Modes: . . . . . . . . . . . . . . . . .Heat (Break on Rise), Cool (Make on Rise), Change-Over (Heat/Cool)
Operating Modes: . . . . . . . . . . . . . Independent, Consecutive (a max of a Single Stage can be on at one time)
Rotation Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . On (Every 24 Hours)l, Off
Sensor Fault Operating Options: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Output On or Output Off
Temperature Ranges: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . from -30˚F (-34˚C) to 250˚F (121˚C)
Pressure Ranges: . . . . PSI (0-30PSI, 0-100 PSI, 0-200PSI, 0-300PSI) or MPa (0.25MPa, 0.60MPa, 1MPa, 1.6MPa)
Vacuum Ranges: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Hg or 760mm
Humidity Ranges: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0% to 100% RH
Display: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Lite Alphanumeric (2 rows x 16 char. each)
LED: . . . . . . . . . . . . . . . . . . . . . . . . . 2 representing the Output relays (Left=Output1, Middle=Output2)
Buttons: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 (Set, Up, Down)
Enable/Disable: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Terminals EXT+, EXT-
20 New Dutch Lane, Faireld, NJ 07004 973-575-4004 • Fax [phone] • http://www.heat-timer.com
HT #059058-00 C
Pressure, Vacuum, and Humidity Sensor Chart
Input
(in mA)
0 - 30 PSI
0 - 30 Vac
Range
0 - 100
PSI
0 - 100%
Humidity
Range
0 - 200
PSI
Pressure
Range
0 - 300
PSI
Pressure
Range
2 OPEN
4 0 0 0 0
4.08 1
4.16 1 2
4.53 1 10
5.07 2 20
5.6 3 10 20 30
7.2 6 20 40 60
8.8 9 30 60 90
10.4 12 40 80 120
12 15 50 100 150
13.6 18 60 120 180
15.2 21 70 140 210
16.8 24 80 160 240
18.4 27 90 180 270
20 30 100 200 300
22 SHORT
