Heinner HDU-10 User manual

DEHUMIDIFIER
Model: HDU-10
www.heinner.com
Dehumidifier
Capacity: 3L
Color: white

www.heinner.com
1
Thank you for chosing this product!
Please read this instruction manual carefully before using it and kee it for later information
This manual is conceived for ofering you all of the necessary info regarding instalation, using
and maintenance of the machine. For a correctly and safely use of the machine, please, read
this manual before instalation and using.
I. INTRODUCTION
II. PACKAGE CONTENTS
Dehimidifier
Instruction Manual
Warranty card

www.heinner.com
2
III. SAFETY PRECAUTIONS
To prevent injury to the user or other people and property damage, the following
instructions must be followed. Incorrect operation due to ignoring of instructions may
cause harm or damage.
This symbol indicates that ignoring instructions may cause death or serious
injury.
This symbol indicates that ignoring instructions may cause moderate injury
to your person, or damage to your appliance or other property.
WARNING
1. Do not exceed the rating of the power outlet or connection device.
Otherwise, it may cause electric shock or fire due to excess heat generation.
2. Do not modify power cord length or share the outlet with other appliances.
It may cause electric shock or fire due to heat generation.
3. Disconnect the power if strange sounds, smell, or smoke comes from it.
It may cause fire and electric shock.
4. Do not use the machine near flammable gas or combustibles, such as gasoline,
benzene, thinner, etc.
It may cause an explosion or fire.
5. Do not operate or stop the unit by switching on or off the power.
It may cause electric shock or fire due to heat generation.
6. Do not insert or pull out plug with wet hands.
It may cause electric shock.
7. You should never try to take apart or repair the unit by yourself.
It may cause failure of machine or electric shock.
8. Do not drink or use the water drained from the unit.
It contains contaminants and couls make you sick.
9. Do not damage or use an unspecified power cord.
It may cause electric shock.
10. Do not place the unit neat a heat source.
Plastic parts may melt and cause a fire.
11. Before cleaning, turn off the power and unplug the unit.
It may cause electrical shock or injury.
12. Do not take the water bucket out during operation.
It may cause bucket full protect of the unit and cause electric shock.

www.heinner.com
3
CAUTION
1. Do not use the unit in small spaces.
Lack of ventilation can cause overheating and fire.
2. Do not put in places where water may splash onto the unit.
Water may enter the unit and degrade the insulation. It may cause an electric
shock or fire.
3. Place the unit on a level, sturdy section of the floor.
If the unit falls over, it may cause water to spill and damage belongings, or cause
electrical shock or fire.
4. Do not cover the intake or exhaust openings with cloths or towels.
A lack of air flow can lead to overheating and fire.
5. Never insert your finger or other foreign objects into grills or openings. Take
special care to warn children of these dangers.
It may cause electric shock or failure of appliance.
6. Always insert the filters securely. Clean filter once every two weeks.
Operation without filters may cause failure.
7. Care should be taken when using the unit in a room with the following
persons:
Infants, children, elderly people, and people not senstive to humidity.
8. Do not place heavy object on the power cord and take care so that the cord is
not compressed.
There is danger of fire or electric shock.
9. If water enters the unit, turn the unit off and disconnect the power , contact a
qualified service technician.
It may cause failure of appliance or accident.
10. Do not use in areas where chemicals are handled.
This will cause the unit deterioration due to chemicals and solvents dissolved in
the air.
11. Do not climb un on or sit on the unit.
You may be injured if you fall or if the unit falls over.
12. Do not place flower vases or other water container on top of the unit.
Water may spill inside the unit, causing insulation failure and electrical shock or
fire.

www.heinner.com
4
.
IV. ELECTRICAL INFORMATION
The manufactures nameplate is located on the rear panel of the unit and contains
electrical and other technical data specific to this unit.
Be sure the unit is properly grounded. To minimize shock and fire hazards, proper
grounding is important.
The power cord is equipped with a three-prong grounding plug for protection
against shock hazards.
Your unit must be used in a properly grounded wall receptacle. If the wall
receptacle you intend to use is not adequately grounded or protected by a time
delay fuse or circuit breaker, have a qualified electrician install the proper
receptacle.
Ensure the receptacle is accessible after the unit installation.
Do not use extension cords or an adapter plugs with this unit. However, if it is
necessary to use an extension cord, use an approved Dehumidifier extension cord
only (available at most local hardware stores).
To avoid the possibility of personal injury, always disconnect the power supply to
the unit, before installing and/or servicing.

www.heinner.com
5
Control pads
When you push the button to change operation modes, the unit will make a beep sound to
indicate that it is changing modes.
1. Power Pad
Press to turn the dehumidifier on and off.
2. Mode Pad
Press to select the desired operation mode from Dehumidifying,Dryer,Continuous
dehumidifying and Smart dehumidifying.
NOTE: Dryer and Smart dehumidifying modes are optional.
3&4. Down/Up Pads
Humidity Set Control Pads
The humidity level can be set within a range of
35%RH(Relative Humidity) to 85%RH(Relative
Humidity) in 5% increments.
For drier air, press - the pad and set to a lower
percent value(%).
For damper air, press + the pad and set a higher
percent value(%).
TIMER Set Control Pads
Use the Up/Down pads to set the Auto start and
Auto stop time from 0.0 to 24.
V. CONTROL PADS ON THE DEHUMIDIFIER

www.heinner.com
6
5. Timer Pad
Press to initiate the Auto start and Auto stop feature, in conjuction with the + and -
key pads.
6. Turbo Pad
Control the fan speed. Press to select either High or Normal fan speed. Set the fan
control to High for maximum moisture removal. When the humidity has been reduced
and quiet operation is preferred, set the fan control to Normal.
7. Ion Pad(optional)
Press to activate the ionizer. Anions ar automatically generated by ionization. The anions
deactive the airborne chemical vapors and dust particles. Press it again to stop the
function.
8. Display
Shows the set % humidity level from 35% to 85% or auto start/stop time (0~24) while
setting, then shows the actual ( ± 5% accuracy) room % humidity level in a range of
RH(Relative Humidity) to 90%RH(Relative Humidity). Error Codes and Protection Codes:
AS- Humidity sensor error--Unplug the unit and plug it back in. If error repeats, call for
service. ES- Temperature sensor error-- Unplug the unit and plug it back in. If error
repeats, call for service.
P1- Unit is defrosting-- Allow the unit time to automatically defrost. The protection will
clear after the unit self defrosts.
P2- Bucket is full or bucket is not in right position—Empty the bucket and replace it in
the right position.
E3- Unit malfunction-- Unplug the unit and plug it back in. If error repeats, call for
service.
EC- Refrigerant leakage detection-- With this new technology, the display area will
appear EC when the unit detects refrigerant leakage, call for service.

www.heinner.com
7
Other features
Bucket Full Light
Glows when the bucket is ready to be emptied, or when the bucket is removed or not
replaced in the proper position.
Auto Shut Off
The dehumidifier shuts off when the bucket is full, or when the bucket is removed or
not replaced in the proper position. When the setting humidity is reached, the unit will
be shut off automatically. For some models, the fan motor will continue operating.
Auto Defrost
When frost builds up on the evaporator coils, the compressor will cycle off and the fan
will continue to run until the frost disappears. NOTE: When Auto defrosting operation,
the unit may make a voice of refrigerant flowing, it is normal.
Wait 3 minutes before resuming operation. After the unit has stopped, it can not be
restart opertation in the first 3 minutes. This is to protect the unit. Operation will
automatically start after 3 minutes.
Smart dehumidifying mode(optional)
At smart dehumidifying mode, the unit will automatically control room humidity in a
comfortable range 45%~55% according to the room temperature. The humidity setting
function will be invalid.
Auto-Restart
If the unit breaks off unexpectedly due to the power cut, it will restart with the previous
function setting automatically when the power resumes.
Setting the Timer
When the unit is on, first press the Timer button, the Timer Off indicator light
illuminates. It indicates the Auto Stop program is initiated. Press it again the
Time On indecator light illuminates. It indicates the Auto Start is initiated.
When the unit is off, first press the Timer button, the TIMER ON indicator light
illuminates. It indicates the Auto Start program is initiated. Press it again the
Time Off indecator light illuminates. It indicates the Auto Stop is initiated.
Press or hold the UP or DOWN pad to change the Auto time by 0.5 hour
increments, up to 10 hours, then at 1 hour increments up to 24 hours. The
control will count down the time remaining until start.
The selected time will register in 5 seconds and the system will automatically
revert back to display the previous humidity setting.
When the Auto start & Auto stop times are set, within the same program
sequence, TIMER ON OFF indicator lights illuminate identifying both ON and
OFF times are now programmed.
Turning the unit ON or OFF at any time or adjusting the timer setting to 0.0 will
cancel the Auto Start/Stop function.
When LED display window displays the code of P2, the Auto Start/Stop function
will also be cancelled.

www.heinner.com
8
Dryer mode (optional)
The unit can make the MAX dehumidification function when it is under the Dryer
mode. The fan speed is fixed at high fan speed. The humidity level is automatically
controlled according to the actual room humidity. The unit will quit dryer mode after a
maximum 10 hours' operation.
NOTE: The Dryer mode must be operated in a close room, do not open the door and
window. To make the best effective dehumidification, please first dehydrate the wet
clothes. Make sure to direct airflow at the wet clothes (See Fig.A). For thick and heavy
wet clothes may not get the best effective dehumidification.
CAUTION
Do not cover the air outlet of the unit with clothes. It may cause excessive heat, fire or
failure of unit. Do not place the wet clothes on the top of the unit and do not make
the water drop into the unit. It may cause electric shock, creepage or failure of unit.
Identification of parts
VI. INDICATION OF PARTS

www.heinner.com
9
Front
1. Control panel
2. Handle
3. Air outlet grille
4. Wtare bucket
5. Water level window
Rear
1. Drain hose outlet
2. Caster
3. Power cord and plug
4. Air intake grille
5. Air filter (behind the grill)
NOTE: All the pictures in the manual are for explanation purposes only. The actual shape of
the unit you purchased may be slightly different, but the operations and functions are the
same.

www.heinner.com
10
VII. POSITIONING THE UNIT
A dehumidifier operating in a basement will have little or no effect in drying an
adjacent enclosed storage area, such as a closet, unless there is adequate circulation
of air in and out of the area.
Do not use outdoors.
This dehumidifer is intended for indoor residential applications only. This
dehumidifier should not be used for commercial or industrial applications.
Place the dehumidifier on a smooth, level floor strong enough to support the
unit with a full bucket of water.
Allow at least 20cm of air space on all sides of the unit for good air circulation.
Place the unit in an area where the temperature will not fall below 5 C(41 F).
The coils can become covered with frost at temperatures below 5 C(41 F),
which may reduce performance.
Place the unit away from the clothes dryer, heater or radiator.
Use the unit to prevent moisture damage anywhere books or valuables are
stored.
Use the dehumidifier in a basement to help prevent moisture damage.
The dehumidifier must be operated in an enclosed area to be most effective.
Close all doors, windows and other outside openings to the room.
Casters(At four points on the bottom of unit)
Casters can move freely.
Do not force casters to move over carpet, nor move the unit with water in the bucket.
(The unit may tip over and spill water.)

www.heinner.com
11
When using the unit
When first using the dehumidifier, operate the unit continuously 24 hours.
This unit is designed to operate with a working environment between 5OC/41OF
and 35OC/95OF.
If the unit has been switched off and needs to be switched on again quickly,
allow approximately three minutes for the correct operation to resume.
Do not connect the dehumidifier to a multiple socket outlet, which is also being
used for other electrical appliances.
Select a suitable location, making sure you have easy access to an electrical
outlet.
Plug the unit into a electrical socket-outlet with earth connection.
Make sure the Water bucket is correctly fitted otherwise the unit will not
operate properly.
NOTE:When the water in the bucket reaches to a certain level,please be careful
to move the machine to avoid it falling down.

www.heinner.com
12
VIII. REMOVING THE COLLECTED WATER
There are two ways to remove collected water.
1. Use the bucket
When the unit is off,if the bucket is full, the unit will beep 8 times and the Full
indicator light will flash, the digital display shows P2.
When the unit is on,if the bucket is full, the compressor turns off and the fan
turns off after 30 seconds for drying the water of the condenser, then the unit
will beep 8 times and the Full indicator light will flash, the digital display
shows P2.
Slowly pull out the bucket. Grip the left and right handles securely, and
carefully pull out straight so water does not spill. Do not put the tank on the
floor because the bottom of the bucket is uneven. Otherwise the bucket will
fall and cause the water to spill.
Throw away the water and replace the bucket. The bucket must be in place
and securely seated for the dehumidifier to operate.
The machine will re-start when the bucket is restored in its correct position.
NOTES:
When you remove the bucket, do not touch any parts inside of the unit. Doing so may
damage the product. Be sure to push the bucket gently all the way into the unit.
Banging the bucket against anything or failing to push it in securely may cause the unit
not to operate. When you remove the bucket, if there is some water in the unit you
must dry it.
2. Continuous draining
Water can be automatically emptied into a floor drain by attaching the unit
with a water hose (not included).
Remove the rubber plug from the back drain hose outlet. Attach a drain
hose(ID=13.5mm) and lead it to the floor drain or a suitable drainage facility
(see Fig.7).
Make sure the hose is secure so there are no leaks.
Direct the hose toward the drain, making sure that there are no kinks that will
stop the warter flowing.
Place the end of the hose into the drain and make sure the end of the hose is
level or down to let the water flow smoothly. Do never let it up.
Select the desired humidity setting and fan speed on the unit for continuous
draining to start.
NOTES:
When the continuous drain feature is not being used,remove the drain hose
from the outlet.

www.heinner.com
13

www.heinner.com
14
Turn the dehumidifier off and remove the plug from the wall outlet before cleaning.
1. Clean the Grille and Case
Use water and a mild detergent. Do not use bleach or abrasives.
Do not splash water directly onto the main unit. Doing so may cause an
electrical shock, cause the insulation to deteriorate, or cause the unit to rust.
The air intake and outlet grilles get soiled easily, so use a vacuum attachment
or brush to clean.
2. Clean the bucket
Every few weeks, clean the bucket to prevent growth of mold, mildew and
bacteria. Partially fill the bucket with clean water and add a little mild
detergent. Swish it around in the bucket, empty and rinse.
NOTE: Do not use a dishwasher to clean the bucket. After clean, the bucket
must be in place and securely seated for the dehumidifier to operate.
3. Clean the air filter
The air filter behind the front grille should be checked and cleaned at least
every 30 days or more often if necessary.
NOTE: DO NOT RINSE OR PUT THE FILTER IN AN AUTOMATIC DISHWASHER.
To remove:
Grip the tab on the filter and pull it upward, then pull it out as shown in Fig.8.
Clean the filter with warm, soapy water. Rinse and let the filter dry before
replacing it. Do not clean the filter in a dishwasher.
To attach:
Insert the air filter into the unit from underside to upside. See Fig.10.
CAUTION:
DO NOT operate the dehumidifier without a filter because dirt and lint will
clog it and reduce performance.
4. When not using the unit for long time periods
After turning off the unit, wait one day before emptying the bucket.
Clean the main unit, water bucket and air filter.
Cover the unit with a plastic bag.
Store the unit upright in a dry, well-ventilated place.
IX. CARE AND CLEANING OF THE DEHUMIDIFIER

www.heinner.com
15

www.heinner.com
16
Before installing for service, review the chart below first yourself
Problem
What to check
Unit does not start
Make sure the dehumidifier s plug is pushed completely into
the outlet.
Check the house fuse/circuit breaker box.
Dehumidifier has reached its preset level or bucket is full.
Water bucket is not in the proper position.
Dehumidifier does not dry the
air as it should
Did not allow enough time to remove the moisture.
Make sure there are no curtains, blinds or furniture blocking
the front or back of the dehumidifier.
The humidity control may not be set low enough.
Check that all doors, windows and other openings are
securely closed.
Room temperature is too low, below 5OC(41OF).
There is a kerosene heater or something giving off water
vapor in the room.
The unit makes a loud noise
when operating
The air filter is clogged.
The unit is tilted instead of upright as it should be.
The floor surface is not level.
Frost appears on the coils
This is normal. The dehumidifier has Auto defrost feature
Water on floor
Hose to connector or hose connection may be loose.
Intend to use the bucket to collect water, but the back
drain plug is removed.
ES, AS P1 or P2 appear in the
display
These are error codes and protection codes. See the
CONTROL PADS ON THE DEHUMIDIFIER section.
X. TROUBLESHOOTING TIPS

www.heinner.com
17
HDU-10
Power
285 W
Voltage
220-240V, 50Hz
Moisture Removal
10L/24H
Capacity
3 L
Color
White
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distibution. All rights reserved.
www.heinner.com, http://www.nod.ro
http://www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community
Importer: Network One Distribution
Marcel Iancu Street, no 3-5, Bucharest, Romania
Tel: [phone], www.heinner.com , www.nod.ro
XI. TECHNICAL DATA

www.heinner.com
18
DEZUMIDIFICATOR
Model: HDU-10
www.heinner.com
Dezumidificator
Capacitate: 3 L
Culoare: alb

www.heinner.com
19
Vă mulțumim pentru alegerea acestui produs!
Înainte de a utiliza acest aparat, citiți cu atenție manualul de instrucțiuni și păstrați-l
pentru consultări ulterioare.
Acest manual este conceput pentru a vă oferi toate instrucțiunile necesare referitoare la
instalarea, utilizarea și întreținerea aparatului. Pentru utilizarea corectă și în siguranță a
aparatului, vă rugam să citiți cu atenție acest manual de instrucțiuni, înainte de instalare și
utilizare.
I. INTRODUCERE
II. CONȚINUTUL PACHETULUI DUMNEAVOASTRĂ
Dezumidificator
Manual de instrucțiuni
Certificat de garanție
