Heinner HF-99F+ User manual

REFRIGERATOR
Model: HF-99F+
www.heinner.ro
•Refrigerator
•Energy class: F
•Total capacity: 99 L

www.heinner.com
1
Please read the instructions carefully and keep the manual for future information.
This manual is designed to give all necessary instructions concerning installation, use and
maintenance of the unit. In order to operate the unit correctly and safely, please read this
instruction manual carefully before installation and use.
I. INTRODUCTION
II. YOUR PACKAGE CONTAINS
➢Refrigerator
➢User manual
➢Certificate of warranty
Thank you for choosing this product!

www.heinner.com
2
III. SAFETY INFORMATION
For your safety and correct usage, before installing and first using the appliance, read this
user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and
accidents, it is important to make sure that all people using the appliance are thoroughly
familiar with its operation and safety features. Save these instructions and be sure that
they remain with the appliance if it is moved or sold, so that anyone using it throughout
its life, will be properly informed on its usage and safety notices.
For the safety of life and property, keep the precautions of these user's instructions as the
manufacturer is not responsible for damages caused by omission.
Safety for children and others who are vulnerable people
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Keep all packaging away from children as there is risk of suffocation.
If you are discarding the appliance, pull the plug out of the socket, cut the
connection cable (as close to the appliance as you can) and remove the door to
prevent children playing from suffering an electric shock or from closing
themselves inside it.
If this appliance, featuring a magnetic door seals, is to replace an older
appliance having a spring lock (latch) on the door or lid, be sure to make the
spring lock unusable before you discard the old appliance. This will prevent it
from becoming a death trap for a child.
General safety
WARNING - This appliance is intended to be used in household and similar applications
such as:
•staff kitchen areas in shops, offices and other working environments;
•farm houses and by clients in hotels, motels and other residential type
environments;
•bed and breakfast type environments;
•catering and similar non- retail applications;

www.heinner.com
3
WARNING - Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
WARNING - If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING - Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING - Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING - Do not damage the refrigerant circuit.
WARNING - Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended by
the manufacturer.
WARNING - The refrigerant and insulation blowing gas are flammable. When disposing
of the appliance, do so only at an authorized waste disposal centre. Do not expose to
flame.
WARNING –Children aged from 3 to 8 years are aloud to load and unload refirgerating
appliances.
WARNING - When positioning the appliance, ensure the supply cord is not trapped or
damaged.
WARNING - Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
Replacing the illuminating lamps
WARNING - The illuminating lamps must not be replaced by the user! If the
illuminating lamps is damaged, contact the customer helpline for assistance. This
warning is only for refrigerators that contain illuminating lamps.
Refrigerant
The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the
appliance, a natural gas with a high level of environmental compatibility, which is
nevertheless flammable.
During transportation and installation of the appliance, ensure that none of the
components of the refrigerant circuit becomes damaged.
The refrigerant (R600a) is flammable.
The symbol is a warning and indicates the refrigerant and insulation blowing gas
are flammable.
WARNING! Risk of fire
If the refrigerant circuit should be damaged:
•Avoid opening flames and sources of ignition.
•Thoroughly ventilate the room in which the appliance is situated.
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire, and/or electric shock.

www.heinner.com
4
Electrical safety
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A crushed or damaged
power plug may overheat and cause a fire.
3. Make sure that you can access the main plug of the appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
6. You must not operate the appliance without the interior lighting lamp cover.
7. The fridge is only applied with power supply of single phase alternating current of
220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the
voltage exceeds the above scope, for safety sake, be sure to apply A.C. Automatic
voltage regulator of more than 350W to the fridge. The fridge must employ a
special power socket instead of common one with other electric appliances. Its
plug must match the socket with ground wire.

www.heinner.com
5
IV. DAILY USE
Do not store flammable gass or liquids in the appliance, There is a risk of an explosion.
Do not operate any electrical appliances in the appliance (e.g. electric ice cream
makers,mixers etc.).
When unplugging always pull the plug from the mains socket, do not pull on the cable.
Do not place hot items near the plastic components of this appliance.
Store pre-packed frozen food in accordance with the frozen food manufacture's
instructions.
The appliances manufactures storage recommendations should be strictly adhered
to.Refer to relrelevant instructions for storage.
Do not place carbonated or fizzy drinks in the freeze compartment as it creates pressure
on the container, which may cause it to explode,resulting in damage to the appliance.
Frozen food can cause frost burns if consumed straight from the freezer compartment.
Do not place the appliance in direct sunlight.
Keep buring candles, lamps and other items with naked flames away from the appliance
so that do not set the appliance on fire.
The appliance is intended for keeping food stuff and/or beverages in normal household
as explained in this instruction booklet.
The appliance is heavy. Care should be taken when moving it.
Do not remove nor touch items from the freezer comartment if your hands are
damp/wet, as this could cause skin abrasions or frost/freezer burns.
Never use the base, drawers, doors etc. to stand on or as supports.
Frozen food must not be refrozen once it has been thawed out.
Do not consume ice popsicles or ice cubes straight from the freezer as this can cause
freezer burn to the mouth and lips.
To avoid items falling and causing injury or damage to the appliance, do not overload the
door racks or put too much food in the crisper drawers.
This refrigerating appliance is not intended to be used as a a built-in appliance.
This refrigerating appliance is not suitable for freezing foodstuffs
V. CLEANING AND MAINTENANCE
Before maintenance, switch off the appliance and disconnect the mains plug from the mains
socket.
Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic solvents or
abrasive cleansers.
Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.

www.heinner.com
6
VI. INSTALLATION
Important!
For electrical connection carefully, follow the instructions given in this manual.
Unpack the appliance and check if there are damages on it. Do not connect the
appliance if it is damaged. Report possible damages immediately to the place
you bought it. In this case retain packing.
It is advisable to wait at least four hours before connecting the appliance to
allow the oil to flow back in the compressor.
Adequate air circulation should be around the appliance, lacking this leads to
overheating. To achieve sufficient ventilation, follow the instructions relevant to
installation.
Wherever possible the back of the product should not be too close to a wall to avoid
touching or catching warm parts (compressor, condenser) to prevent the risk of a fire, follow
the instructions relevant to installation.
The appliance must not be located close to radiators or cookers.
Make sure that the mains plug is accessible after the installation of the appliance.
Any electrical work required to do the servicing of the appliance should be carried out by
qualified electrician or competent person.
This product must be serviced by an authorized Service Center, and only genuine spare parts
must be used.
If the appliance is Frost Free.
If the appliance contains freezer compartment.
Energy Saving tips
Do not place warm foods into the appliance. Allow warm foods to cool first. Do not install
the appliance near cookers, radiators or other sources of warmth. High ambient
temperatures cause longer, more frequent operation of the compressor.
In order to make the cooling system work efficiently, please make sure the side plates and
back plate of the product are with some distance from the wall. It is strongly recommended
that its back is 75mm away from the wall, its sides at least have a space of 100mm
separately and the height from over its top is not less than 100mm.
When the product works, please do not open the door too often or leave the door open any
longer than necessary.
Do not set temperature any colder than necessary.
The direct cooling refrigerator (with a freezer) needs to be defrosted when necessary. This
will improve the cold transfer and reduce energy consumption.
Store food logically. Do not exceed the storage period specified.
VII. SERVICE AND ENERGY SAVING

www.heinner.com
7
VIII.PRODUCT DESCRIPTION
1.Freezer compartment door
2.Ice cube tray
3.Freezer compartment
4.Drip tray
5.Removable shelves
6.Glass panel
7.Crisper
8.Levelling legs
9.Bottle racks
10.Temperature control knob
11.Recessed handle
Note:
•Due to unceasing modification of our products, your refrigerator may be slightly
different from this instruction manual, but its functions and using methods remain
the same.
•To get the best energy efficiency of this product, please place all shelves, drawers
and baskets on their original position as the illustration above.

www.heinner.com
8
Fig. 4
IX. REVERSE DOOR
Warning - When changing the side at which the door opens, the appliance must not be
connected to the mains. Remove plug from the mains beforehand.
The side at which the door opens can be changed from the right side (as supplied) to the left
side, if the installation site requires.
Before you start, lay the refrigerator on it’s back in order to gain access to the base, you
should rest it on soft foam packaging or similar material to avoid damaging the cooling pipes
at the rear of the refrigerator.
1. Remove the upper hinge cap (7)
2. Remove the two screws blot (6) that connect the upper hinge (5) on the right side of
the cabinet top
3. Carefully lift the door and place it on a padded surface to prevent scratching.
4. Remove the plug (9) and transfer it to the uncovered hole on the right side of the
unit. Be sure to pres the button firmly into the hole.
5. Remove the two screws (7) that hold the lower hinge (2) on the right side of the
unit.
6. Remove the screw-type leveling front leg (4) and transfer it to the right side as
shown in the adjacent figure.
7. Set the door into its new place making sure the pin enters the bushing at the lower
frame section (hole).
8. Secure the upper hinge (5) previously removed in step 3 on the left side of the unit.
Make sure the pin enters the bushing on the upper frame section (hole).
9. Loosely secure the lower left hinge (2) and do not tighten the bolts until the door is
in the closed position and leveled.
10. Insert the plug (9) on the uncovered holes (right side).
11. Replace the upper hinge cap (7).

www.heinner.com
9
1. Screw
2. Low hinge
3. Adjustable low foot
4. Adjustable high foot
5. Upper hinge
6. Screw bolt
7. Upper hinge cap
8. Shaft sleeve
9. Plug

www.heinner.com
10
Remove transport packaging
The appliance and the interior fittings are protected are protected for transportation. Pull
of the adhesive tape on the left and right side of the door. You can remove any remnants of
adhesive using white spirit. Remove all adhesive tape and packing pieces from the interior
of the appliance.
Positioning
Position the appliance away from sources of heat such as stoves, radiators, direct sunlight
etc. Maximum performance and safety are guaranteed by maintaining the correct indoor
temperature for the class of unit concerned, as specified on the rating plate. This
application performs well from N to ST. The Appliance may not work properly if it is left for
a longer period at a temperature above or below the indicated range.
IMPORTANT - There is a need of good ventilation around the fridge for easy dissipation of
heat, high efficiency of refrigeration and low power consumption. For this purpose,
sufficient clear space should be available around the fridge. It is advisable for there to be
50-70 mm separating the back of the fridge to the wall, at least 100 mm of space at its two
sides, height of over 100 mm from its top and a clear space upfront to allow the doors to
open 160°.
Climate classification
Ambient temperature
SN
10-32 °C
N
16-32 °C
ST
16-38 °C
T
16-43 °C
Appliances must not be exposed to rain. Sufficient air must be allowd to circulate in the
lower rear section of appliances, as poor air circulation can affect performance. Built-in
appliances should be positioned away from heat sources such as heaters and direct
sunlight.

www.heinner.com
11
XI. TEMPERATURE SETTING
Starting up and temperature regulation
The first time you turn the unit on, set the temperature control to "8" position.
The settings of the temperature control are "0,1,2,3,4,5,6,7,8". After 20 minutes, adjust the
temperature control setting to "4". The setting of "4" should be correct for home or office
use.
To turn the refrigerator off, turn the temperature control to "0".
Turning the temperature control to "0" position stops the cooling cycle, but does not shut
off the power to the refrigerator.
If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the refrigerator will not
start.
You should put your appliance in the coolest place in your room, which can save energy
consumption of your appliance. If the environment temperature is too high, the
temperature in the refrigerator may not get the target temperature.
Important!
Normally we advise you select setting of 2 or 3 or 4, if you want the temperature warmer
or colder please turn the knob to lower or higher setting accordingly. When you turn the
knob to lower which can lead to the more energy efficiency. Otherwise, it would result the
energy-consuming.
Important!
High ambient temperatures (e.g. on hot summer days) and a cold setting on the
temperature regulator (position 6 to 8) can cause the compressor to run contin- uously or
even non-stop!
Reason: when the ambient temperature is high, the compressor must run continuously to
maintain the low temperature in the appliance.
Interior accessories
Storage shelves/wire tray
Various glass or plastic storage shelves or wire trays are included with your appliance -
different models have different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of
guides, above the fruit and vegetable containers, and keep it in this position.

www.heinner.com
12
The height of the storage shelves can be adjusted:
To do this, pull the storage shelf forward until it can be swiveled upwards or downwards and
removed.
Please do the same in reverse to insert the shelf at a different height.
IMPORTANT - In order to make the most of the volume of the fresh food storage
compartment and frozen-food storage compartment, the user can remove one or more
shelves, drawers, out of the appliance, according to your daily use.
IMPORTANT - In order to take full advantage of the storage volume, the user can store
waterproof foodstuffs on the Drip Tray, such as packed food with heat sealing, etc.
But during the process of manual defrosting, the user had better take the foodstuffs away
from the drip tray.
Tips:
Food in the refrigerator should always be covered or packaged, to prevent drying and tainting
of other food.
The following are suited for packaging:
•Polyethylene airtight bags and wraps
•Plastic containers with lids
•Special plastic covers with elastic
•Aluminium foil

www.heinner.com
13
Order
Compartments TYPE
Target storage temp. [ ℃ ]
Appropriate food
1
Fridge
+2≤+6
Eggs, cooked food, packaged food, fruits and vegetables,
dairy products, cakes, drinks and other foods are not suitable
for freezing.
2
(***)*-Freezer
≤-18
Seafood (fish, shrimp, shellfish), freshwater aquatic
products and meat products (recommended for 3 months,
the longer the storage time, the worse the taste and
nutrition), suitable for frozen fresh food.
3
***-Freezer
≤-18
Seafood (fish, shrimp, shellfish), freshwater aquatic products
and meat products (recommended for 3 months, the longer
the storage time, the worse the taste and nutrition), are not
suitable for frozen fresh food.
4
**-Freezer
≤-12
Seafood (fish, shrimp, shellfish), freshwater aquatic products and
meat products (recommended for 2 months, the longer the
storage time, the worse the taste and nutrition), are not suitable
for frozen fresh food.
XIII. STORING THE FOOD
To avoid contamination of food, please respect the following instructions:
•Opening the door for long periods can cause a significant increase of the temperature
in the compartments of the appliance.
•Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
•Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
•Two-star frozen-food compartments are suitable for storing pre-frozen food, storing
or making ice cream and making ice cubes.
•One-, two- and three-star compartments are not suitable for the freezing of fresh
food.
Note: Please store different foods according to the compartments or target storage
temperature of your purchased products.
If the appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the
door open to prevent mould developing within the appliance.
WARNING! Food needs to be packed in bags before putting into the refrigerator, and liquids
need to be packed in bottles or capped containers to avoid the problem that the product
design structure is not easy to clean.

www.heinner.com
14
5
*-Freezer
≤-6
Seafood (fish, shrimp, shellfish), freshwater aquatic products and
meat products (recommended for 1 months, the longer the
storage time, the worse the taste and nutrition), are not suitable
for frozen fresh food.
6
0-star
-6≤0
Fresh pork, beef, fish, chicken, some packaged processed foods,
etc. (Recommended to eat within the same day, preferably no
more than 3 days). Partially encapsulated processed foods
(non-freezable foods)
7
Chill
-2≤+3
Fresh/frozen pork, beef, chicken, freshwater aquatic products,
etc. (7 days below 0 ℃and above 0 ℃is recommended for
consumption within that day, preferably no more than 2 days).
Seafood (less than 0 for 15 days, it is not recommended to store
above 0 ℃)
8
Fresh Food
0≤+4
Fresh pork, beef, fish, chicken, cooked food, etc.
(Recommended to eat within the same day, preferably no
more than 3 days)
9
Wine
+5≤+20
Red wine, white wine, sparkling wine etc.

www.heinner.com
15
XIII. CLEANING AND DEFROSTING THE FREEZER
Cleaning and Care
For hygienic reasons the appliance interior, including interior accessories, should be
cleaned regularly.
Warning!
The appliance may not be connected to the mains during cleaning. Danger of
electrical shock! Before cleaning switch the appliance off and remove the plug from
the mains, or switch off or turn out the circuit breaker or fuse.
Never clean the appliance with a steam cleaner. Moisture could accumulate in
electrical components, danger of electrical shock! Hot vapors can lead to the damage
of plastic parts.
The appliance must be dry before it is placed back into service.
Important!
Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice
from orange peel, butyric acid, cleanser that contain acetic acid.
Do not allow such substances to come into contact with appliance parts. Do not use
any abrasive cleansers.
Remove the food from the refrigerator. Store it in a cool place, well covered.
Switch the appliance off and remove the plug from the mains, or switch off or turn
out the circuit breaker or fuse.
Clean the appliance and the interior accessories with a cloth and lukewarm water.
Commercially available dish washing detergents may also be used.
After cleaning wipe with fresh water and rub dry.
Accumulation of dust at the condenser increases energy consumption.
For this reason carefully clean the condenser at the back of the appliance once a year
with a soft brush or a vacuum cleaner .
Check the water drain hole on the rear wall of the refrigerator compartment.
Clear a blocked drain hole with the aid of something like soft green peg, be careful
not to make any damage to the cabinet by sharp things.
After everything is dry place appliance back into service.
Defrosting
Why defrosting
Water contained in food or getting into air inside the fridge be opening doors may
form a layer pf frost inside. It will weaken the refrigeration when the frost is thick.
While it is more than 10 mm thick, you should defrost.
Defrosting in frozen-food storage compartment
Defrosting in freezer chamber is operated manually. Before defrosting, take the food
out; take the ice tray and drawers out or put them into the fresh food compartment
temporarily, then set the knob of temperature regulator to position “0” (where the
compressor will stop working) and leave the door of the refrigerator open until ice
and frost dissolve thoroughly and accumulation at the bottom of the freezer chamber.

www.heinner.com
16
Wipe off the water with soft cloth. In the case of speeding up the process of
defrosting, you may put a bowl of warm water (about 50ć) into the freezer chamber,
and scrape away the ice and rost with a defrosting spatula. After doing so, be sure to
set the knob of the temperature regulator to the original position.
It is not advisable to heat the freezer chamber directly with hot water or hair dryer
while defrosting to avoid deformation of the inner case.
It is also not advisable to scrape off ice and frost or separate food from the containers
which have been congealed together with the food with sharp tools or wooden bars,
so as not to damage the inner casing or the surface of the evaporator.
Warning!
Switching off the appliance.
To sitch off the appliance, turn the temperature regulator to position “0”.
Important!
The fridge should be defrosted at least everyone month. During the using process, if
the door was opened frequently or using the appliance in the extreme humidity, we
advise the user to defrost every two weeks.
Troubleshooting/Correcting malfunctions/Spare parts
The following spare parts can be ordered from your local Service Force Center. You
can fit these yourself without any special skill or training, e.g.:
•butter/cheese compartment
•egg holders
•door racks
•fruit and vegetable drawers
•storage racks
A malfunction may be caused by only a minor fault that you can rectify yourself using
the following instructions. Do not perform any other work on the appliance if the
following information does not provide assistance in your specific case.
Important!
Repairs to refrigerators/freezers may only be performed by competent service
engineers. Improper repairs can give rise to significant hazards for the user. If your
appliance needs repairing, please contact your specialist dealer or your local Service
Force Center.

www.heinner.com
17
Symptom
Possible cause
Remedy
Appliance does
not work
Appliance is not switched on
Switch on the appliance
Mains plug is not plugged in or is loose
Insert mains plug
Fuse has blown or is defective
Check fuse, replace if necessary
Socket is defective
Mains malfunctions are to be
corrected by an electrician
Appliance cools
too much
Temperature is set too cold
Turn the temparature regulator to a
warmer setting temporarily
The food is too
warm
Temperature is not properly adjusted
Please look in the "Initial start up"
section
Door was open for an extended period
Open the door only as short as
necessary
A large quantity of warm food was placed
in the appliance within the last 24 hours
Turn the temperature regulation to a
colder setting temporarily
The appliance is near a heat source
Please look in the "installation
location" section
Interior lighting
does not work
Light bulb is defective
Please look in the "changing the
lightbulb" section
Heavy build-up
or frost, possibly
also on the door
seal
Door seal is not air-tight (possibly after
reversing the door)
Carefuly warm the leaking sections
of the door seal with a hair dryer (on
a cool setting). At the same time
shape the warmed door seal by
hand such that it sits correctly
Unusual noises
Appliance is not level
Readjust the feet
The appliance is touching the wall or other
objects
Move the appliance slightly
A component, e.g. a pipe, on the rear of
the appliance is touching another part of
the appliance or the wall
If necessary, carefully bend the
component out of the way
The compressor
does not start
immediately
after changing
the temperature
setting
This is normal, no error has occurred
The compressor starts after a period
of time

www.heinner.com
18
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data
available: Model and Serial Number.
The information can be found on the rating plate. Subject to change without notice.
TECHNICAL DATA
The technical information is situated in the rating plate on the internal side of the appliance
and on the energy label.
The QR code on the energy label supplied with the appliance provides a web link to the
information related to the performance of the appliance in the EU EPREL database.
Keep the energy label for reference together with the user manual and all other documents
provided with this appliance.
It is also possible to find the same information in EPREL using the link https://
eprel.ec.europa.eu and the model name and product number that you find on the rating
plate of the appliance.
To access information about your product in the EPREL portal, you can scan the codes below:
HF-99F+
Thank you for purchasing this product. If you need support with your product, visit our
website using the links below.
Get User manuals: https://www.heinner.ro
Get Service information: https://www.heinner.ro

www.heinner.com
19
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distribution. All rights reserved.
www.heinner.com, http://www.nod.ro
http://www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community.
Importer: Network One Distribution
Marcel Iancu, 3-5, Bucharest, Romania
Tel: [phone], www.heinner.com , www.nod.ro
