Heliospectra ELIXIA User manual
ELIXIA, EOS and DYNA
Quick Set Up Guide
When unpacking the luminaire make sure to have a
sturdy surface to work on. Damage to the unit can occur if
dropped.
Do not immerse the xture in water or clean the xture with
a high pressure water jet or strong detergents.
Never operate the xture with the lens directly on a at
surface (e.g. table) as this may damage the lens. A
minimum distance of 0.2m/8in should be kept to other
objects.
The product is for indoor use only.
Always allow a free ow of air around the xture. Verify that
the air inlet and outlet are not covered. A minimum distance
of 0.2m/8in should be kept to other objects. Blocked airow
may cause the lamp to dim to counteract overheating
This xture may only be serviced by a trained technician. In
the case of a suspected malfunction contact your
distributor or Heliospectra directly.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualied person.
The luminaire should be positioned so that prolonged
staring into the luminaire at a distance closer than 1 meter/
40 inches is avoided.
Do not stare into the light source. LED grow lights may
contain potentially harmful light radiation. Please use UV
blocking eyewear when working in and around the
illuminated area.
Only connect the xture to properly grounded mains that
complies with the voltage rating on the xture (see power
label).
Only operate the xture with an undamaged power cord,
power plug and electrical outlet.
Never unplug the xture by pulling on the power cord.
For proper performance of the unit the ambient air
temperature shall be no higher than 40° C.
Quand vous déballez le luminaire assurez-vous d’avoir une
surface solide sur laquelle travailler. L’appareil peut être
endommagé si on le fait tomber.
N’immergez pas l’appareil dans l’eau et n’essayez pas de le
nettoyer avec un jet d’eau à haute pression.
Ne pas mettre en marche l’appareil avec la lentille posée à
plat sur quelconque surface (par exemple : une table), cela
pourrait l’endommager.
Le produit ne s’utilise qu’en intérieur.
Assurez-vous qu’il y ait un minimum d’air autour de
l’appareil. Assurez-vous que l’espace réservé à cet effet ne
soit pas encombré. Il doit y avoir un espace minimum de
0.2m/ 8 pouces entre l’appareil et d’autres objets. Le
blocage de la circulation de l’air pourrait affaiblir l’intensité
de la lumière pour éviter toute surchauffe.
Cet appareil ne peut être entretenu que par un technicien
expérimenté. Si vous avez un soupçon sur le mauvais
fonctionnement de celui-ci, contactez votre distributeur ou
Heliospectra directement.
La source de lumière contenue dans ce luminaire ne
doit-être remplacée que par le fabricant ou ses agents de
services ou une personne similaire qualiée pour le faire.
Le luminaire doit être positionné de telle sorte que le xer
longuement à une distance d’1 mètre/ 40 pouces soit évité.
Ne pas xer la source de lumière. Les éclairages LED
pourraient potentiellement contenir des radiations
lumineuses nocives. Portez des lunettes anti-rayons UV
quand vous travaillez sous ou à proximité de l’endroit
éclairé.
Ne connectez l’appareil que sur une prise reliée à la terre et
dont le voltage correspond à celui de l’appareil.
L’appareil doit être mis en marche avec rien d’autre qu’une
prise, un cordon électrique ou une prise secteur non
endommagés.
Ne jamais déconnecter l’appareil en tirant sur le cordon
électrique.
Pour une utilisation optimale de l’appareil, la température
ambiante ne doit pas dépasser 40°C.
Precautions
Our product is an advanced and safe LED
xture. However, for proper operation and for
your safety, please read and follow the below
precautions:
Le produit est un appareil moderne et sûr.
Mais pour une bonne utilisation et pour votre
sécurité, veuillez lire les informations ci-des-
sous :
Your luminaire will have either an attached power cable, as in the rst two images, or a power socket and a
detachable cable as in the nal image. This depends on your specic variant.
Attached power cable
At the other end of the power cable you will either have a plug, or it will be open ended. This depends on what you
have purchased. If you have open ended cables, make sure that you use a licensed electrician for the installation.
Attached power cable Power socket
Luminaires must be installed with adequate surge protection according to the
IEEE 1100-2005 recommended practice or, in Europe, the IEC 62305 standard.
Ensuring you have the correct level of protection for your facility can be complex so it is strongly
recommended that you consult a certied electrical engineer.
The luminaire is delivered with pre-mounted M6 i-hook bolts.
Connect your eyelets to these bolts and then
connect them to the chosen mounting structure.
For proper operation, the luminaire must be mounted
horizontally from a support structure. The support
structure needs to be sturdy enough to support the weight of the
luminaires and any additional equipment. It must also allow for
air to ow freely into the fan.
If provided with a light plan you must install the lights
accordingly. If not, please install to best to suit your needs.
For full product manuals visit
support.heliospectra.com/portal or scan
the QR code to go straight there.
If you have purchased an ELIXIA or DYNA then you will either
need our basic System Assistant software to connect them or
our full helioCORE™ control system to control them.
For details and to download System Assistant go to
https://support.heliospectra.com or scan the QR code
to go straight there.
To purchase helioCORE™ please contact your sales account
manager and ask for more details.
More Information
Electrical Installation
Mounting
Connectivity and Control
ELIXIA LX50 ELIXIA LX60 EOS E50 EOS E60 DYNA RX30
Typical power
consumption
10.5W to 500W 10.5W to 600W 500W 600W 10.5W to 420W
Input voltage 312-528VAC, 47/63Hz 85-528 VAC, 50/60Hz 312 - 528VAC, 47/63Hz 85 - 305VAC, 50/60Hz 85 - 305VAC, 50/60Hz
Maximum
Current
1.44 A @ 347 VAC
1.25 A @ 400 VAC
1.04 A @ 480 VAC
5.00 A @ 120 VAC
2.50 A @ 240 VAC
2.17 A @ 277 VAC
1.73 A @ 347 VAC
1.50 A @ 400 VAC
1.25 A @ 480 VAC
1.44 A @ 347 VAC
1.25 A @ 400 VAC
1.04 A @ 480 VAC
4.67 A @ 120 VAC
2.33 A @ 240 VAC
2.02 A @ 277 VAC
3.50 A @ 120 VAC
1.75 A @ 240 VAC
1.52 A @ 277 VAC
Control Built in WiFi and/or
Ethernet
RJ 45, 10/100Mbit IPv4
Ethernet
DHCP for IP address
management
32 bit microprocessor
(80MHz)
Built in WiFi and/or Ethernet
RJ 45, 10/100Mbit IPv4
Ethernet
DHCP for IP address manage-
ment
32 bit microprocessor
(80MHz)
- -
Built in WiFi and/or
Ethernet
RJ 45, 10/100Mbit IPv4
Ethernet
DHCP for IP address
management
32 bit microprocessor
(80MHz)
Dimming Dimming 1-100% Dimming 1-100% - - Dimming 1-100%
Housing Durable ABS plastic and
powder
coated aluminium
Durable ABS plastic and
powder
coated aluminium
Durable ABS plastic and
powder
coated aluminium
Durable ABS plastic and
powder
coated aluminium
Durable ABS plastic and
powder
coated aluminium
Weight 8kg (17.6lbs) 8kg (17.6lbs) 8kg (17.6lbs) 8kg (17.6lbs) 8kg (17.6lbs)
Dimensions 199 x 219 x 425 mm
(7.83 x 8.62 x 16.73 in)
199 x 219 x 425 mm (7.83 x
8.62 x 16.73 in)
199 x 219 x 425 mm (7.83
x 8.62 x 16.73 in)
199 x 219 x 425 mm
(7.83 x 8.62 x 16.73 in)
199 x 219 x 425 mm
(7.83 x 8.62 x 16.73 in)
Temperature Operating: -10-40 °C (14-
104 °F)
Storage: -20-70°C (-4-
158°F)
Operating:-10-40°C(14-104°F)
-10-35 °C (14-95 F) for 347 -
480 VAC
Storage: -20-70°C (-4-158°F)
Operating: -10-40 °C (14-
104 °F)
Storage: -20-70°C (-4-
158°F)
Operating: -10-40 °C (14-
104 °F)
Storage: -20-70°C (-4-
158°F)
Operating: -10-40 °C (14-
104 °F)
Storage: -20-70°C (-4-
158°F)
Humidity Operating: 90 %(max.)
relative humidity,
non-condensing
Storage: 95 %(max.)
relative humidity,
non-condensing
Operating: 90 %(max.) relative
humidity, non-condensing
Storage: 95 %(max.) relative
humidity, non-condensing
Operating: 90 %(max.)
relative humidity,
non-condensing
Storage: 95 %(max.) rela-
tive humidity,
non-condensing
Operating: 90 %(max.)
relative humidity,
non-condensing
Storage: 95 %(max.)
relative humidity,
non-condensing
Operating: 90 %(max.)
relative humidity,
non-condensing
Storage: 95 %(max.)
relative humidity,
non-condensing
Warranty 3 years 3 years 3 years 3 years 3 years
Cooling Active, variable speed
cooling fan
Active, variable speed cooling
fan
Active, variable speed
cooling fan
Active, variable speed
cooling fan
Active, variable speed
cooling fan
Compliance CE, cETLus,RoHS CE, cETLus,RoHS CE, cETLus,RoHS CE, cETLus,RoHS CE, cETLus,RoHS
Lifetime 50 000 hrs (rated life to
90% of initial photon ux)
50 000 hrs (rated life to 90%
of initial photon ux)
50 000 hrs (rated life to
90% of initial photon ux)
50 000 hrs (rated life to
90% of initial photon ux)
50 000 hrs (rated life to
90% of initial photon ux)
IP rating IP24 rated IP24 rated IP24 rated IP24 rated IP24 rated
Compatible with
helioCORE™ Yes Yes - - Yes
Network
requirements
DHCP service and 100
Mbit/s switch or access
point for WiFi. For details
refer to the full manuals
DHCP service and 100 Mbit/s
switch or access point for
WiFi. For details refer to the
full manuals
- - DHCP service and 100
Mbit/s switch or access
point for WiFi. For details
refer to the full manuals
Website
www.heliospectra.com
Telephone
+46 31 40 67 10 (SWE) +1 (888) 942 GROW (US)
+1 (437) 922 6677(CAN)
Email
Heliospectra AB
Fiskhamnsgatan 2
SE-414 58 Göteborg
Sweden
If you have any questions or queries regarding your luminaire please visit our
support portal at support.heliospectra.com.
Alternatively contact us at support@heliospectra.com.
