HelloBaby HB50 User manual

2.4GHz Digital Wireless Video Baby Monitor
User Manual
Model: HB50
Ver: 1.1

THANK YOU FOR PURCHASING HELLOBABY BABY MONITOR.
PLEASE ACTIVE AND EXTEND YOUR WARRANTY NOW.
(Register within 7 days after receiving your product)
To register your product
Visit https://www.hellobabyfamily.com
Finished the form on the website
That is it! Your product is now active and extend warranty!
If you are unsatisfied with your product, please contact us via
before leaving a negative review.
We will definitely give you a satisfactory solution.
www.hellobabyfamily.com
[e-mail]

Follow HelloBaby on Social Media!
@hellobabybrand @hellobabyfamily @hellobabybrand
Scan QR code with your smartphone.
Stay tuned on HelloBaby new release & marketing event!

Thank you for purchasing the HB50 HelloBaby Baby Monitor. With our baby monitor, you
could see and hear your baby sleeping or playing in their room anytime.
Please retain your original dated sales receipt for your records. For warranty service of your
HelloBaby product, you will need to provide a copy of your dated sales receipt to confirm
warranty status. Registration is not required for warranty coverage.
Please make sure the following included in your package
Parent unit x 1 Camera unit x 1 Power Adapter x 2
User manual x 1 Wall-mounting kit x 1
CAUTION: Keep the device away from children.
Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of the reach of
children (more than 3ft (0.9m) away). Never use extension cords with AC Adapters. Only use
the AC Adapters provided.
Choking hazard : This product contains small parts, please be careful when unpack and
assemble the product.
Read and keep to instructions: All the safety and operating in structions should be read
before the video baby monitor is operated. This product cannot replace responsible adult
supervision.
Water and moisture: This product is designed for indoor use only. The unit should not be
exposed to rain, moisture, dripping or splashing. No objects filled with liquid should be
placed on top of, or beside the product, such as a glass or vase. This item should not be used
near water.
DO NOT: Use the appliance if the cord or plug is damaged. If your baby monitor is not
operating properly or has suffered any damage, contact “HelloBaby” service center to
request inspection and repair of the appliance in order to avoid any possible risk.
DO NOT: Do not attempt to repair or adjust any of the electrical or mechanical functions of
the unit. Otherwise, the guarantee will be made void.
Ventilation: This baby monitor should not be used on a bed, sofa, rug or similar surface that
may block the ventilation openings, or be placed in an enclosed area such as a bookcase or
drawer that may impede air flow.
Keep away from sources of heat: This unit should not be exposed to direct heat sources
such as a candle, radiator, heat register, stove or other appliance that emits heat. The unit
should not be left in direct sunlight.
Power source: This unit should only be used with the AC power adapters included in this
package (rated 5V DC 1A).
Damage requiring service: This unit should be serviced by qualified personnel only when:
. Objects have fallen or liquid has been spilled into the product;
. The units have been exposed to rain;
1
[e-mail]
1. SAFETY INSTRUCTIOINS

2
. The units do not appear to operate normally or exhibits a distinct change in performance;
. The units have been dropped or the enclosure damaged;
We offer one-year warranty from the original purchase date against defects in workmanship
and materials. If you have warranty or support issues, please contact our after-sales service
via email.
* To use your parent unit and camera unit together, you have to establish a radio
link between them, and the range will be affected by environmental conditions.
* Any large metal object, like a refrigerator, a mirror, a filling cabinet, metallic doors or
reinforced concrete between the baby and parent unit may block the radio signal.
* The signal strength may also be reduced by other solid structures, like walls, or by radio
or electrical equipment, such as T V, computers, cordless or mobile phones, fluorescent
lights or dimmer switches.
* Use of other 2.4G Hz product, such as wireless networks (Wi-Fi routers), Bluetooth
systems, or microwave ovens, may cause interference with this product, so keep the baby
monitor away at least 5ft (1.5m) from such products, or turn them off if they cause
interferences.
The camera can be placed on the desktop or mounted on the wall. Don't place baby monitor
on soft quiltsor blankets or in the corners of cupboards, shelves, etc; Keep the baby monitor
away from heat sources such as radiators, chimneys, cookers and direct sunlight; Keep the
baby unit away from TV sets, microwave oven and radios. If interference occurs, move the
camera to elsewhere;
*Place the camera within6 feet (2 meters) of the area being monitored for optimum
performance.
5.1 TURN ON THE BABY UNI T:
1. Insert the DC plug of the power adapter into the DC jack in the rear of the Baby Unit;
2. Insert the other end of the power adapter into a suitable electrical outlet;
3. Once the adapter is connected, the power L ED will light up;
.2 TURN ON THE PA RENT UN IT: 5
1. Insert the DC plug of the power adapter into the DC jack in the side of the parent Unit;
2.Insert the other end of the power adapter into a suitable electrical outlet;
[e-mail]
2. WARRANTY TERMS
3.INSTALLATION GUIDELINES
4. PLACEMENT OF THE BABY MONITOR
5. GETTING STARTED

3
Speaker
DC-jack
Stand
Reset Key RES ET
Charging LED
Power LED
Sound Level Indicator
Power key
5.0'' Diagonal TFT LCD
Exit/Two Way Talk
Menu/OK
Zoom / View / Scan
MIC
Right Key
Up key
Down Key
Left Key
6.2 PARENT UNIT OVERVIEW:
3. Press and hold the power key 3 seconds on the top of the parent unit;
4.Once parent unit is on, the power LED will light upand the image will display on the LCD
5.3 INFRARED NIGHT VISION (AUTOMATIC)
The infrared night vision function allows the camera to pick up images in dark or low
light conditions. In this mode, only black and white images will be displayed on the
m The onitor,the optimum image lie in where baby unit is 6ft (2m) away from object.
camera is in night vision mode, the icon will be displayed on the top of screen.
6. 1 ICONS OVERVIEW:
--------
Signal Strength
Alarm
--------
Volume
--------
Zoom
--------
Lullaby
--------
Camera
--------
Battery Level
--------
--------
Vox
Night vision
--------
12
3
6
9
Temperature
--------
2
--------
℃
--------
℉
Celsius
Fahrenheit
[e-mail]
6. PRODUCT OVERVIEW

7.1 POWER SAVE/SCREEN OFF
Short press the power key to turn on / off the screen.
7.2 VOLUME ADJUSTMENT
Press the ▲ key to increase the volume; Press the ▼ key to decrease the volume;
7.3 BRIGHTNESS ADJUSTMENT
Press the ◀ key to decrease the brightness; Press the ▶ key to increase the brightness;
7.4 CAMERA VIEW/SCAN
Press scan key to view/scan camera, during scan mode, the scan icon will be
displayed on the top of screen. Each camera’s video will be stay on the LCD around 10
seconds then change to next camera;
7.5 DIGITAL ZOOM & PAN / TILT
Press and hold the key around 2 seconds to operate Zoom in / out; At the Zoom mode,
press the ◀ key to Pan left; press ▶ key to Pan right; press ▲ key to tilt up; press ▼ key
to tilt down; During digital zoom mode, the zoom icon will be displayed on the top of
screen.
Warm reminder: If you want to adjust the volume/Brightness, you have to exit the Zoom
mode before you operate it.
7.5 TWO WAY TALK
Press and hold key to enter two way talk mode. A microphone icon will be displayed
in the corner of the LCD screen. Release the key to stop.
Note: When you are in the two-way talk mode, the parent unit speaker is muted.
8.1 PAIRING THE CAMERA AND PARENT UNITS
The baby unit is pre-registered to your parent unit. You do not need to register it again
unless the baby unit loses its link with the parent unit. To re-register your baby unit, or
6. 3 BABY UNIT OVERVIEW:
CMOS sensor
Speaker
Light sensor
MIC
Infrared LEDs
Power LED
Pair key
DC-Jack
Temperature
sensor
2
4
[e-mail]
7. KEY OPERATION
8. MENU OPERATION

register a new baby unit, follow the procedure below:
Note : Camera icon with " " means it is well registered. You should select and pair with
the camera icon without " " sign.
8.1 .1 ADD CAMERA
1. Press the MENU key then the menu will pop up;
2. Press the ◀/▶/▲/▼ key until the camera icon is selected by red box;
3. Press OK key to enter into sub-menu, then press ▲ / ▼ key to select your desired
camera;
4. Press key enter into sub-menu; Press ▲ / ▼ key to select then press key;
5. While the icon ... displayed on the LCD screen, press the PAIR button on the back of
camera;
6. Once paired, Successful pairing icon shows on the LCD screen;
7. If fails, repeat the above steps.
8.1.2 DELETE CAMERA
1. Press the MENU key and the menu will pop up;
2. Press the ◀/▶/▲/▼ key until the camera icon is selected by red box ;
3. Press OK key, to enter into sub-menu, then press ▲ / ▼ key to select the camera
you want to delete;
4. Press key enter into sub-menu; Press ▲ / ▼ key to select then press key;
5. Press ◀ / ▶ key to select for deleting the camera;
6. Press OK key to confirm the option.
8.2 TEMPERATURE UNIT SETTING
1. Press the MENU/OK key and the menu will pop up;
2. Press the◀ / ▶ / ▲ / ▼ key until the temperature icon is selected by red box;
3. Press key enter into sub-menu;
4. Press the◀ / ▶key to select the ℉ or ℃ for setting temperature unit;
5. Press the key to confirm;
6. Press the key to Exit.
Note: The temperature detection range is 0~40 ℃ .
8.2.1 TEMPERATURE ALARM SETTING
1. Press ◀ / ▶ / ▲ / ▼ key to select for turning on alarm function; press key
to confirm;
2. Press ◀ / ▶ / ▲ / ▼ key to select for off alarm function; press key turning
to confirm;
8.2.2 SET TEMPERATURE HI/LO ALERT LIMITS
1. press ◀ / ▶ to select (red）or (green）for Hi/Lo limits settings;
2. Press ▲ / ▼ keys to adjust the Hi limit when (red）is selected;
3. Press ▲ / ▼ keys to adjust the Lo limit when (green）is selected;
Note: The high temperature alarm default setting is 36 ℃, and the low temperature
alarm default setting is 8 ℃. When the temperature goes above or below the settings, the
temperature iconwill display on the screen. It will alert user by beeps. Press any key on
5
[e-mail]

6
the parent unit to stop beeping and flashing.
8.3 LULLABY SETTING
You can soothe the baby to sleep by playing a gentle lullaby from the Camera unit.
1. Press the MENU key then the menu will pop up;
2. Press the◀ / ▶ / ▲ / ▼ key until the lullaby icon is selected by red box;
3. Press key enter into sub-menu;
4. Press the◀ / ▶ / ▲ / ▼ key to select one of the 8 available lullabies, you can pick single
playback, loop (all 8 lullabies) playback or stop ;
4. Press key to confirm.
Note : The lullaby default setting is OFF.
8.4 ALARM SETTING
You can use the alarm to remind yourself to feed your baby / change diaper / sleeping, etc.
1. Press the MENU key then the menu will pop up;
2. Press the ◀ / ▶ / ▲ / ▼ key until the alarm icon is selected by red box.
3. Press key enter into sub-menu, Press the ◀ / ▶ / ▲ / ▼ key to selected the alarm
time you need;
4. Press key to confirm;
5. Press key to Exit.
Note 1: The minimum unit is 0.5 hour. The maximum setting is 5 hours (7 levels);
Note 2: Once the alarm is turned on, alarm icon will display on the screen;
Note 3: The alarm default setting is OFF;
Note 4: When the alarm is ringing, press any key on the parent unit to turn the alarm off;
Note 5: If you don’t turn off the alarm, the alarm will ring for 1 minute. After three minutes
the alarm will ring again for 1 minute. The alarm will ring for 3 times in total, after this the
alarm goes off.
8.5 VOX SETTING
This mode allows you to control the sound activation of your baby unit. If there is no sound
around the baby unit within 30 seconds, it will stop audio transmission and turn off the
screen of the parent unit. When the baby unit detects any sounds louder than the sensitivity
level, it will start transmitting the signal to the parent unit again and turn on the screen of
the parent unit. To change the VOX level, please follow the below instructions.
1. Press the MENU key then the menu will pop up;
2. Press the◀ / ▶ / ▲ / ▼ key until the VOX icon is selected by red box.
3. Press key enter into sub-menu, then press ▲ / ▼ key to select desired level;
4. Press key to confirm;
5. Press key to Exit.
Note: is Low sensitivity level; the baby have to make a lot of sound before the VOX
function will be activate;
Note: is middle sensitivity level;
Note: is High sensitivity level; the baby don't have to make a lot of sound before the
VOX function will be activate;
12
3
6
9
[e-mail]

2412MHz~2469MHz
Power Adaptor
Parent Unit: Input: 100-240VAC 50/60Hz
Output: 5V DC 1A
Camera Unit: Input: 100-240VAC 50/60Hz
Output: 5V DC 1A
Operation
environment
Up to 1000ft (300m) outdoor (line of sight)
Up to 165ft (50m) indoor
Operating Range
Display 5.0'' Diagonal TFT LCD
Battery (Parent Unit)
Battery Life
Li-ion 3.7V 2000mAh (7.4Wh)
Up to 8 hours
RelativeHumidity:15%-85%
Maximum power
<19dBm
8.6 LANGUAGE SETTING
1. Press the MENU key then the menu will pop up;
2. Press the◀ / ▶ / ▲ / ▼ key until the language icon is selected by red box.
3. Press key enter into sub-menu, then press ◀ / ▶ / ▲ / ▼ key to select the language
you need;
4. Press key to confirm;
5. Press key to Exit.
No reception on the
monitor
Interference or poor
reception
* The power adapters may not be properly connected;
* Confirm that the camera and monitor are ON;
* Camera may be far away from the monitor;
* Camera and monitor may not be properly paired; follow PAIRING instructions;
* Move the monitor close to the camera;
* The camera or monitor may be placed too close to many metal objects;
* Other electronic devices may be interfering with the signal;
* The battery power may be too low;
Operation Temperature: +32F~+104F (0℃~40℃)
Battery Charging Temperature: +50F~+104F(10℃~40℃)
7
[e-mail]
9. TECHNICAL DATA
Frequency
10. TROUBLE SHOOTING

Frozen Picture on
Screen
* Repower the baby unit (plug out the adapter, then plug it into the
socket again);
* Press the RESET key at the back of parent unit;
* Clean your baby monitor with a slightly damp or anti-static cloth.
* Never use cleaning agents or solvents.
* Do not attempt to repair or adjust any of the electrical or mechanical functions of the
unit;
* Remember to dispose of the product in an environmentally responsible way;
* For proper collection and processing of these products, take them to the collection
points designated by local authorities. You can also contact the store where you
purchased the product.
Improper or incorrect use of batteries may cause corrosion or battery leakage, which could
cause personal injury or damage to property.Use only the types of the batteries which are
indicated in this manual.
CAUTION: Risk of Fire and Burns. Do Not Open, Crush, Heat Above 45 degree C or Incinerate.
Follow Manufacturer's Instructions.
- Disposal of a battery into fire or a hot over, or mechanically crushing or cutting of a battery,
that can result in an explosion;
- Leaving a battery in an extremely high temperature surrounding environment that can
result in an explosion or the leakage of flammable liquid or gas;
- A battery subjected to extremely low air pressure that may result in an explosion or the
leakage of flammable liquid or gas.
- The battery shall not be exposed to excessive heat such as sunshine, fire or the like;
8
[e-mail]
11. MAINTENANCE
12. DISPOSAL GUIDE FOR BATTERY AND PRODUCT
Audio feedback
(high pitched noise)
* The camera and monitor may be placed too closed;
* The volume on the monitor may be set too high;

[e-mail]
Product tested against EN62471
WARNING IR emitted from this product. Do not stare at operating lamp
Risk Group 1
Made in China
9
Strangulation Hazard: Children have STRANGLED
in cords. Keep this cord out of the reach of children
(more than 3 ft (0.9 m) away). Do not remove this tag.
WARNING
DANGER D’ÉTRANGLEMENT: Des enfants se sont
ÉTRANGLÉS avec des cordons électriques. Garde
le cordonélectrique hors de la portée des enfants(à
plus de 0.9m/3 pi du lit d’enfant). Ne pas enlever
cette étiquette.
AVERTISSEMENT

THANK YOU FOR PURCHASING HELLOBABY
BABY MONITOR. PLEASE ACTIVE AND EXTEND YOUR
WARRANTY NOW.
Live Chat Support
Learn more about Hellobaby, please visit us at
www.hellobabyfamily.com
[e-mail]
www.hellobabyfamily.com
Or
Scan QR Code &
Send to us
SCAN
ME
Made in China
