HELVIA ONDA Series User manual

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall Speakers
Manuale d’uso
en-ita
Please read this manual carefully and keep it for future reference
Leggete questo manuale e conservatelo per future consultazioni
User Manual

Dear value Customer,
First, thank you for purchasing a HELVIA® product. Our mission is to oer
solutions based on the most up-to-date technologies for all systems integration
needs in the private, commercial and corporate sectors.
We hope you are satised with this product and, if you wish to participate, we
would be very pleased to receive your feedback on the operation of this product
and possible improvements for the future. You can go to “CONTACT” section of
www.frenexport.com and send an e-mail with your opinion; this would help us
make equipment that are closer to the real needs of our customers.
Finally, please read this user manual carefully before using the product; incorrect
use could cause damages to you and the product. Take care!
The HELVIA team
Gentile Cliente,
Prima di tutto, grazie per aver acquistato un prodotto HELVIA®. La nostra missio-
ne e di orire soluzioni basate sulle tecnologie più aggiornate a tutte le esigenze
di integrazione di sistemi nei settori privati, commerciali e corporate.
Speriamo che siate soddisfatti da questo prodotto e, qualora vogliate partecipare,
saremmo molto lieti di poter ricevere il vostro feedback sul funzionamento del
prodotto e su possibili miglioramenti da apportare in futuro. Potete andare sulla
sezione CONTATTACI del sito www.frenexport.com e inviare una e-mail con la vo-
stra opinione; questo ci aiuterebbe a realizzare apparecchiature sempre più vicine
alle reali esigenze dei Clienti.
Vi preghiamo, inne, di leggere attentamente questo manuale di istruzioni prima
di utilizzare il prodotto; un uso incorretto potrebbe causare danni a voi e al pro-
dotto stesso: pensateci!
Il team HELVIA

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
3
TABLE OF CONTENTS
1. IMPORTANT SAFETY INSTRUCTIONS......................................... 3
2. UNPACKING ...................................................................................... 4
3. PRODUCT OVERVIEW ..................................................................... 4
3.1. Features: .................................................................................................................................5
4. PRODUCT APPEARANCE................................................................ 5
5. INSTALLATION.................................................................................. 6
5.1. Speaker Installation.............................................................................................................7
6. UNDER-POWERING VS OVER-POWERING................................ 9
6.1. Example of Low Impedance System Conguration................................................10
7. IN-WALL/IN-CEILING SPEAKER PAINTING...............................10
8. TECHNICAL PARAMETERS ............................................................12
8.1. Frequency Response Charts...........................................................................................12
8.2. Specications ......................................................................................................................13
9. WARRANTY AND SERVICE ...........................................................14
10. WARNING.........................................................................................14
1. IMPORTANT SAFETY INSTRUCTIONS
yRead these instructions
yKeep these instructions
yHeed all warning
yFollow all instructions
Water and Moisture
The apparatus should be protected from moisture and rain and can not be used
near water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
Heat
The apparatus should be located away from heat sources such as radiators, stoves

ONDA Series Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
4
or other appliances that produce heat.
Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus
for safety.
Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzene or alcohol.
Servicing
Do not implement any servicing other than those means described in the manual.
Refer all servicing to qualied service personnel only. Only use accessories/attach-
ments or parts recommended by the manufacturer.
2. UNPACKING
Thank you for purchasing your ONDA Series in-wall/in- ceiling speakers. All units
have been rigorously tested before leaving the factory. Carefully unpack the
carton and check the contents to ensure that all parts are present and in good
conditions:
y1x ONDA series ceiling speaker
yThis User manual
If anything damaged during transport, notify the shipper immediately and keep
packing material for inspection. Again, please save its carton and all packing
materials. If the unit must be returned to the manufacturer, it is important that the
unit is returned in the original manufacturer’s packing. Please do not take any ac-
tion without rst contacting us. Our products are subject to a continuous process
of further development. Therefore modications to the technical features remain
subject to change without further notice.
3. PRODUCT OVERVIEW
ONDA in-wall speaker series is born to satisfy all those indoor installations where
sound pressure and quality higher than normal 70/100V systems are requested.
The ONDA speakers are all low-impedance (8ohm), coaxial, with Kevlar woof-
ers, silk-dome tweeters, precision crossovers; essentially true 2-way speakers for
professional applications, but ceiling/wall mount. The look of the front panel is
minimalist and captivating, and reminds recording studio monitor. The frame-less
design, with black ABS frame and white magnetic grids, makes the ONDA speak-

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
5
ers extremely discreet. Finally, the grids can be repainted to make them even less
visible.
3.1 . Features:
y2-Way Hi-Fi Coaxial Low-Impedance Loudspeaker
yFrame-less Design with Magnetic Grilles
yQuick-Fit Mounting System with 4 Screws
yRMS Powers from 40W to 80W
yHigh Excursion Kevlar Woven Cone Woofers
yWoofers diameters from 5.25” to 8”
y0.76” Silk-Dome Tweeters
yBuilt-In Precision Passive Crossover
y+/-2dB High-Frequency Attenuation Selector
4. PRODUCT APPEARANCE
ONDA-540FTW Size
Ø232mm
88mm
Ø194mm
Ø232mm
ONDA-660FTW Size
Ø248mm
97mm
Ø208mm
Ø248mm

ONDA Series Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
6
ONDA-880FTW Size
Ø290mm
108mm
Ø252mm
Ø290mm
5. INSTALLATION
Read these instructions carefully before installing and using the product.
• When installing in-wall/in-ceiling loudspeakers, be aware of the weight of
your particular model (see “8. TECHNICAL PARAMETERS” at page 12 for
the weight) and the sturdiness of the material into which you are installing the
speaker. Also, be aware of any concealed studs, electrical wiring or plumbing
in the wall or ceiling into which you are installing the speakers.
• Do not use nails, adhesives or other unauthorized devices. Long-term use
and vibrations may cause it to fall easily.
• If you plan to install your speakers where water will directly contact them, it is
advisable to use a silicone sealant or caulk between the frame of the speaker
and the wall surface. This seal should prevent water from getting behind the
loudspeaker and possibly damaging the wall surface.
• Do not position the speaker where water can pool on the surface of the
woofer cone or tweeter dome, as this will great decrease the speaker’s useful
life (and everything will sound ”glub! glub!”, like it’s coming from under wa-
ter).
ONDA Series speakers are IP54 speakers. Please be noticed before
installing the speaker.
• Do not place the speakers on movable supports.
• Do not touch or bump the woofer. If these are damaged, the sound will be
distorted.

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
7
• Do not listen to sound at a very high level when you are changing the input
source (for example, from FM Tuner to CD player). Please be sure the power
amplier is turned o or master volume is at lower level.
• Do not attempt to clean the speakers with chemical solvents as this may
damage the paint surface. Clean with a dry cloth.
5.1. Speaker Installation
“Out of the box and into the wall”, that is how easy it is to install ONDA series
loudspeakers.
If you intend to do the installation yourself, we recommend that you possess
some skill in the proper use of hand and power tools. You should have a thor-
ough understanding of local building and re codes and a familiarity with the area
behind the wall or ceiling into which you plan to install your speakers.
The installer is responsible of installation. Please pay attention to
install speakers according to local safety regulations. If you are not
sure to install in a safe way these speakers, consult a professional
installer, your authorized dealer, or a contractor.
Things you will need:
yPencil for marking the location of installation;
yKeyhole saw, utility knife or material appropriate incising implement for cutting
drywall or other wall material
yLevel
yScrewdriver (preferably powered)
yPower drill with appropriate bit (optional, for starting wall cut)
Steps to be followed:
1. Make sure the material into which you plan to mount the speaker (plaster, dry-
wall, paneling, stone, etc.,) supports the weight of the speakers (see “7. IN-
WALL/IN-CEILING SPEAKER PAINTING” at page 10 for the weight of each
model).
2. Make sure the locations you select do not conceal studs, electrical wiring or
plumbing. Prior to installation, hold the speaker in your chosen location to make
sure it safely clears obstacles such as studs, corners, beams, lighting xtures and
door/window frames. Your cutout must be at least 1” (25mm) from adjoining
walls or ceiling, internal studs or plumbing.
3. Draw a ceiling hole on the wall or ceiling with a diameter corresponding to the

ONDA Series Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
8
ones shown on “4. PRODUCT APPEARANCE” at page 5.
4. Carefully cut the hole with the appropriate cutting tool for your wall or ceiling
material. Start the hole by drilling a hole on the inside of the tracing (with the
drill bit touching the line). Use this hole to insert the saw or knife and begin
cutting.
5. Remove the magnetic speaker grille.
6. Once you have cut the hole, sh your previously positioned wiring out of the
hole and connect the speaker. Strip about 2” (12 mm) of insulation from each of
the two conductors of the wire to expose the bare metal and twist each of the
conductors into a single unfrayed strand (so you have two unfrayed strands).
Note that one of the two terminals on the rear of each speaker is red (+) and
the other is black(-). Make certain that you connect the wire from the red ter-
minal (+) of your amplier or receiver to the red terminal (+) of your speaker,
and the wire from the black terminal (-) of your amplier to the black termi-

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
9
nal (-) of your speaker. Most wire has some indicator (such as color-coding,
ribbing or writing) on one of the two conductors to help you maintain consis-
tency.
7. Loosen the rotating clamps by unscrewing them. Make sure that they are
ipped inwards so that your speaker ts into your cutout without nicking your
wall. Then place the speaker carefully into the cutout.
If you have a level, use it to help you correctly align the speaker. Tighten the
wall clamp screws with a screwdriver. This will rotate the wall clamps and se-
cure the speaker to the wall.
HINT: do not over-tighten the wall clamp screws!
8. Carefully reinstall the grille.
6. UNDER-POWERING VS OVER-POWERING
Most speaker damages are caused by ampliers with too little power (wattage).
Overdriven ampliers clip output waveforms and send distortion to the speakers.
Clipping is usually audible; it may vary from a harsh sound to a fuzzy or unclear
sound.
If you hear this condition at loud volume levels, turn down the amplier volume
until the distortion is no longer present. Damages caused by operating the speak-
ers at distorted volume levels are no covered by warranty.

ONDA Series Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
10
6.1. Example of Low Impedance System Configuration
2 speakers connected to each channel of the amplier
7. IN-WALL/IN-CEILING SPEAKER PAINTING
You will need:
yPaint of your choice (to make the job easier, we recommend spray-painting the
grille)
yMasking tape and/or paper
Preparing to paint:
When painting the frame of the speaker, carefully mask o the front of the
speakers to protect the drivers and baes while painting. You can do this while
the speaker is already installed in the wall (if, for instance, you are repainting the
room). Carefully mask the speaker components using paper and masking tape.
Painting the frame:
1. Apply paint to exposed (unmasked parts). Use two or more thin coats. Spray
painting is recommended.
Mask the drivers and baes, and then spray part in thin coats

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
11
2. When the paint is completely dry, remove the masking material.
Painting the grille:
3. Grilles must be spray-painted. Do not use a brush and paint. Thick, brushed
paint may clog the grille holes.
4. Before spray-painting the grille, carefully remove the grille’s fabric scrim by
peeling it away from the inside of the grille. Place this on a clean, at surface
where it will not be wrinkled.
Peel away fabric grille scrim before painting the grille
5. After removing the grille by carefully hooking it with a bent paper clip and
pulling it gently away from the frame, spray on two thin coats of nish color.
If you are using a compressor and spray gun, use the nest, most diuse
setting. Be careful not to ll the holes in the grille with paint.
Paint the grille. Use thin coats of spray paint. Do not block grille holes with paint.
6. When the grille is dry, carefully press the fabric scrim back into place on the
inside of the grille. The special fabric scrim hides the speaker’s drivers from
view, and not interfere with the sound.
7. When the paint is completely dry, carefully reinstall the grille by tting it into
its recess so that it is just resting on the frame. Starting with one corner, go
around the speaker and push the grille into the grille notch a little bit at a
time. Be gentle; the grille may be easily bent out of shape by rough handling.
You will feel a positive “snap” when it is fully in place.

ONDA Series Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
12
8. TECHNICAL PARAMETERS
8.1 . Frequency Response Charts
NOTE: All Frequency charts below show dB SPL (1W @ 1m).
ONDA-540FTW
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
-10
0
10
20
30
40
50
60
70
80
90
100
110
dB SPL
ONDA-660FTW
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
-10
0
10
20
30
40
50
60
70
80
90
100
110
dB SPL

ONDA Series
Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
13
ONDA-880FTW
20 50 100 200 500 1k 2k 5k 10k 20k
Frequency (Hz)
-10
0
10
20
30
40
50
60
70
80
90
100
110
dB SPL
8.2. Specifications
Model ONDA-540FTW ONDA-660FTW ONDA-880FTW
Speaker Type 2-Way Passive, Coaxial
Frequency Response
(-10dB) 65Hz-20kHz 60Hz-20kHz 45Hz-20kHz
Sensitivity (1W @ 1m) 91dB 93dB 95dB
RMS Power 40W 60W 80W
Impedance 8 ohm
Woofer 5.25” (135mm), Kevlar
Woven Cone
6.5” (165mm), Kevlar
Woven Cone
8” (203mm), Kevlar
Woven Cone
Tweeter 0.76” (20mm), Silk Dome
High-Freq. Attenuator 2-position switch (0dB/-2dB)
Housing ABS
IP rate (speaker installed) IP54
Mounting Quick mounting system with 4 screws
Grille Frameless Design, Magnetic Mount, Perforated steel with acoustic trans-
parent foam inside, paintable
Color Black Housing / White Grille
Cutout Size Ø 194 mm Ø 208 mm Ø 252 mm
Product Size (WxDxH) Ø 232 x 88 mm Ø 248 x 97 mm Ø 290 x 108 mm
Speaker Weight 1,23 kg 1,6 kg 2,3 kg
Packing Size (WxDxH) 255 x 250 x 92 mm 270 x 270 x 98 mm 340 x 315 x 115 mm
Packing Weight 1,43 kg 1,9 kg 2,7 kg
Our products are subject to change. Modications to technical features remain subject to change without notice

ONDA Series Quick-Mount Hi-Fi Coaxial In-Wall/In-Ceiling Speakers
14
9. WARRANTY AND SERVICE
All HELVIA® products are covered by warranty according to European regulations (2 years
in the case of purchase by private person - B2C; 1 year in the case of purchase by company
- B2B). The warranty is valid from the date of purchase by the end user (private individual
or company), indicated in the purchase document (receipt in the case of private person;
invoice in the case of company). The following cases / components are not covered by the
above warranty:
yAll accessories supplied with the product;
yImproper use;
yFailure due to wear and tear;
yAny unauthorized modication of the product by the user or third parties.
HELVIA must meet the warranty obligations due to any non-compliant materials or manu-
facturing defects, by remedying free of charge at HELVIA’s discretion by either repairing or
replacing specic parts or the entire equipment. Any defective parts removed by a product
in the event of a warranty claim become property of HELVIA.
During the warranty period, defective products can be returned to HELVIA retailer or
installer with proof of original purchase (receipt or invoice). To avoid damage during trans-
port, please use the original packaging, if available. For more information, visit the website:
www.frenexport.com.
10. WARNING
READ CAREFULLY - only for EU and EEA (Norway, Iceland and Liechtenstein).
This symbol indicates that the product must not be disposed of with household waste,
according to the WEEE directive (2202/96/EC and subsequent amendments) and national
legislation.
The product must be delivered to a designated waste collection center (e.g. on an autho-
rized one-for-one basis when you buy a new similar product, or to an authorized collection
site for recycling waste electrical and electronic equipment).
Improper handling of this type of waste can have a negative impact on the environment
and human health due to potentially dangerous substances that are generally associated
with electrical and electronic equipment. At the same time, your cooperation in the proper
disposal of this product will contribute to the eective use of natural resources.
For more information about where you can drop o your waste equipment for recycling,
please contact your local city oce, waste authority, approved WEEE scheme or your
household waste disposal service.

SOMMARIO
1. IMPORTANTI ISTRUZIONI DI SICUREZZA.................................17
2. CONTENUTO DELL’IMBALLO........................................................17
3. DESCRIZIONE DEL PRODOTTO....................................................18
3.1. Caratteristiche:....................................................................................................................18
4. ASPETTO DEL PRODOTTO ............................................................19
5. INSTALLAZIONE ............................................................................. 20
5.1. Installazione del Diusore.............................................................................................. 20
6. SCELTA DELL’AMPLIFICATORE..................................................... 23
6.1. Esempio di Sistema a Bassa Impedenza ................................................................... 23
7. TINTEGGIATURA DEGLI ALTOPARLANTI .................................. 24
8. PARAMETRI TECNICI..................................................................... 26
8.1. Risposta in Frequenza..................................................................................................... 26
8.2. Speciche ............................................................................................................................ 27
9. GARANZIA E ASSISTENZA ........................................................... 28
10. AVVISO ............................................................................................. 28

Serie ONDA Diffusori Hi-Fi Coassiali da Incasso a Montaggio Rapido
16
1. IMPORTANTI ISTRUZIONI DI SICUREZZA
yLeggete queste istruzioni
yConservate queste istruzioni
yRispettate tutte le avvertenze
ySeguite tutte le istruzioni
Acqua / Umidità
L’apparecchio deve essere protetto dall’umidità e dalla pioggia, non può essere
usato in prossimità di acqua; ad esempio nei pressi di una vasca da bagno, di un
lavandino, di una piscina, etc.
Calore
L’apparecchio deve essere posto lontano da fonti di calore come radiatori, stufe o
altri apparecchi che producono calore.
Introduzione di Oggetti e Liquidi
Non introdurre oggetti o versare liquidi all’interno dell’apparato per ragioni di
sicurezza.
Pulizia
Pulite solo con un panno asciutto. Non utilizzate solventi come benzolo o alcol.
Manutenzione
Non eettuate qualsiasi altro intervento al di fuori di quelli descritti nel manuale.
Per eventuale assistenza rivolgetevi solo a personale qualicato. Utilizzate solo
accessori / componenti suggeriti dal produttore.
2. CONTENUTO DELL’IMBALLO
Grazie per aver acquistato i diusori da incasso della serie ONDA. Tutte le unità
sono state rigorosamente testate prima di lasciare la fabbrica. Disimballare con
cura la confezione e controllare il contenuto per assicurarsi che tutte le parti siano
presenti e in buone condizioni:
y1x Diusore serie ONDA
yQuesto manuale di istruzioni
In caso di danni durante il trasporto, informare immediatamente lo spedizioniere
e conservare il materiale di imballaggio per l’ispezione. Ancora una volta, si prega
di conservare la confezione e tutti i materiali di imballaggio. Se l’unità deve essere

Serie ONDA
Diffusori Hi-Fi Coassiali da Incasso a Montaggio Rapido
17
restituita al produttore, è importante che questa venga restituita nella confezio-
ne originale del produttore. Si prega di non intraprendere alcuna azione senza
prima averci contattato. I nostri prodotti sono soggetti a un processo continuo di
sviluppo. Pertanto, le modiche alle caratteristiche tecniche rimangono soggette a
modiche senza preavviso.
3. DESCRIZIONE DEL PRODOTTO
La serie di diusori a incasso ONDA nasce per soddisfare tutte quelle installa-
zioni da interno dove sono richieste pressioni sonore e qualità audio superiori
ai normali sistemi di diusione a 70/100V. I diusori ONDA sono tutti a bassa
impedenza (8ohm), coassiali, con woofer in kevlar, tweeter con cupola in seta,
crossover di precisione; in sostanza dei veri e propri diusori a 2-Vie per appli-
cazioni professionali ma in formato da incasso. Il look della supercie frontale è
minimalista e accattivante, e richiama quello dei monitor di riferimento da studio
di registrazione. Il design frame-less, con telaio in ABS nero e griglie magnetiche
bianche, rende i diusori ONDA estremamente discreti. Le griglie, inne, possono
essere riverniciate per renderle ancora meno visibili.
3.1 . Caratteristiche:
yAltoparlante coassiale Hi-Fi a bassa impedenza a 2 vie
yDesign senza telaio con griglia magnetica
ySistema di montaggio Quick-Fit con 4 viti
yPotenze RMS da 40W a 80W
yWoofer a cono in tessuto Kevlar ad alta escursione
yDiametri di woofer da 5,25 “a 8”
yTweeter a cupola da seta da 0,76 “
yCrossover passivo di precisione incorporato
ySelettore di attenuazione ad alta frequenza +/- 2 dB

Serie ONDA Diffusori Hi-Fi Coassiali da Incasso a Montaggio Rapido
18
4. ASPETTO DEL PRODOTTO
Dimensioni ONDA-540FTW
Ø232mm
88mm
Ø194mm
Ø232mm
Dimensioni ONDA-660FTW
Ø248mm
97mm
Ø208mm
Ø248mm
Dimensioni ONDA-880FTW
Ø290mm
108mm
Ø252mm
Ø290mm

Serie ONDA
Diffusori Hi-Fi Coassiali da Incasso a Montaggio Rapido
19
5. INSTALLAZIONE
Leggere attentamente queste istruzioni prima di installare e utilizzare il prodotto.
• Quando si installano altoparlanti a parete / a sotto, prestare attenzione al
peso del proprio modello particolare (vedere “8. PARAMETRI TECNICI” a pagi-
na 12 per il peso) e alla robustezza del materiale su cui si sta installando l’alto-
parlante. Inoltre, prestare attenzione a eventuali perni nascosti, collegamenti
elettrici o idraulici nella parete o nel sotto in cui si installano gli altoparlanti.
• Non utilizzare chiodi, adesivi o altri dispositivi non autorizzati. L’uso a lungo
termine e le vibrazioni possono far cadere il diusore facilmente.
• Se si prevede di installare i diusori in modo che l’acqua entri in contatto di-
rettamente, è consigliabile utilizzare un sigillante siliconico o un sigillante tra
il telaio del diusore e la supercie della parete. Questo isolamento dovrebbe
impedire all’acqua di penetrare dietro l’altoparlante e danneggiare eventual-
mente la supercie della parete.
• Non posizionare l’altoparlante dove l’acqua può accumularsi sulla supercie
del cono del woofer o della cupola del tweeter, poiché ciò ridurrà notevol-
mente la vita utile dell’altoparlante (e tutto suonerà come se provenisse da
sott’acqua).
I diffusori della serie ONDA sono altoparlanti IP54. Si prega di tenere
a mente questa informazione prima dell’installazione.
• Non posizionare gli altoparlanti su supporti mobili.
• Non toccare o urtare il woofer e il tweeter. Se questi sono danneggiati, il
suono sarà distorto.
• Non ascoltare l’audio a un livello molto alto quando si cambia la sorgente di
ingresso (ad esempio, dal sintonizzatore FM al lettore CD). Assicurarsi che
l’amplicatore di potenza sia spento o che il volume principale sia al livello più
basso.
• Non tentare di pulire i diusori con solventi chimici in quanto ciò potrebbe
danneggiare la supercie della vernice. Pulire con un panno asciutto.
5.1. Installazione del Diffusore
“Direttamente dalla scatola al muro”, questo è il modo più semplice per descrivere
la facilità di installazione degli altoparlanti ONDA.

Serie ONDA Diffusori Hi-Fi Coassiali da Incasso a Montaggio Rapido
20
Se si intende eseguire l’installazione da soli, è necessario possedere alcune abilità
nell’uso corretto degli utensili manuali e elettrici. Dovresti avere una conoscenza
approfondita dei codici di colore usati negli impianti elettrici e antincendio locali,
e sapere cosa c’è dietro il muro o il sotto in cui intendi installare i diusori.
L’installatore è responsabile della corretta messa in opera dell’im-
pianto. Prestare attenzione all’installazione degli altoparlanti secon-
do le norme di sicurezza locali. Se non si è sicuri di installare questi
diffusori in modo sicuro, consultare un installatore professionista o
un rivenditore autorizzato.
Materiale Occorrente:
yMatita per segnare il luogo di installazione;
ySega da traforo, taglierino multiuso o attrezzo per incisione del materiale adatto
al taglio di pareti a secco o altro materiale per pareti.
yLivella
yCacciavite (preferibilmente avvitatore)
yTrapano elettrico con punta appropriata (opzionale, per iniziare il taglio della
parete)
Passaggi da seguire:
1. Accertarsi che il materiale su cui si prevede di montare l’altoparlante (intonaco,
muro a secco, cartongesso, pietra, ecc.) supporti il peso del diusore (vedere
XXXXXXXXXX per il peso di ciascun modello) .
2. Assicurarsi che dietro il punto selezionato non passino cavi elettrici o tubi o vi
siano altri impedimento. Prima di forare, vericare che l’altoparlante nella posi-
zione scelta non incontri ostacoli come, angoli, travi, apparecchi di illuminazio-
ne e cornici di porte/nestre.
3. Disegna un foro sul sotto sulla parete o sul sotto con un diametro corrispon-
dente a quelli mostrati su “4. ASPETTO DEL PRODOTTO” a pagina 18.
4. Realizzare con cura il foro sul muro o sul sotto con la sega da traforo. Inizia
il ritaglio praticando un foro all’interno della traccia (con la punta che tocca il
