Hermann Schmidt TRANSP Parts list manual

Instructions for Operating
TRANSP
Transporter

Hermann Schmidt®- Model: TRANSP
2
LIFT-O-FLEX®
20000
SERIES
TABLE OF CONTENTS
1. MODEL: TRANSP , TRANSPORTER .....................................................................................................3
1.1 WARRANTY........................................................................................................................................4
2. ASSEMBLY INSTRUCTIONS .................................................................................................................5
2.1 ASSEMBLY...........................................................................................................................................5
2.2 DISASSEMBLY ......................................................................................................................................8
3. OPERATING INSTRUCTIONS.................................................................................................................9
3.1 OPERATING .........................................................................................................................................9
3.1.1 CHARGING ........................................................................................................................................9
3.1.2 HANDLEBAR ....................................................................................................................................10
3.1.3 LIFTING ...........................................................................................................................................10
3.1.4 TRANSPORT....................................................................................................................................10
3.2 TROUBLESHOOTING............................................................................................................................11
3.3 MAINTENANCE...................................................................................................................................12
4. ENCLOSURES .......................................................................................................................................13
4.1 ELECTRICAL SCHEMATICS ..................................................................................................................... 13
4.2 LIFT MAST ........................................................................................................................................... 14
4.3 LOWER AND UPPER INTERMEDIATE SECTIONS........................................................................................ 15
4.4 LEGS-LOW PROFILE (20300 AND 20500)............................................................................................... 16
4.5 HANDLEBAR ........................................................................................................................................ 17
5.DECLARATION OF CONFORMITY ........................................................................................................ 18
6.TEST PROTOCOL ................................................................................................................................... 19

Hermann Schmidt®- Model: TRANSP
3
1. MODEL: TRANSP, Transporter
NOTE: It is important that you read and fully understand this manual before using your Transporter.
If you have any questions contact your distributor or the manufacturer.
GENERAL DATA
Type
Transporter
Total Lift Capacity
Maximum 275-lbs (includes weight of load and end-
effector)
Certification
CE Marked
Material
Intermediate Section: Aluminum –Anodized
Legs: Steel –Powder Coated or Stainless Steel
Lift Mast: Aluminum –Anodized
End-Effector: Stainless Steel (304), Aluminum, Other
Transporter Weight (excluding End-Effector)
80-lbs.
Weighted average for vibrations during
operation
Not to exceed 2.5 m/s2
Operational Sound Level
Not to exceed 70 dB (A)
Declaration of Conformity
Delivered with each Transporter
Labeling
Manufacturer
Year of Manufacture
Serial Number
GOOD WORKING ENVIRONMENT
Transporters are designed to ergonomically assist in material handling operations. By using the
Transporter, the prevention or elimination of injuries as well as the creation of safer working
conditions for personnel will occur. People that already suffer from injuries or have suffered
injuries will find that the Transporter will enhance productivity.

Hermann Schmidt®- Model: TRANSP
4
OPERATIONAL SAFETY
The ergonomic design of the Transporter is by itself an active factor of operational safety. Other
factors of security and technical features are as follows:
The movement of the load platform will stop should an object be placed in-between the lift frame
and the load platform or if other jamming occurs.
The Transporter cannot be overloaded since it will automatically stop the lifting function if loaded
with more than the maximum load limit that is factory set.
A simple and easily operated foot activated system is installed for central wheel locking of the
rear casters along with providing a directional wheel lock.
The Transporter is easy to use in confined spaces and aisle ways due to its compact outside
dimensions and large caster wheels. Both rear caster wheels have a directional lock, which makes
maneuvering the Transporter simple.
The handlebar is designed to protect the operator's hands while maneuvering the Transporter.
SERVICE
The service is easy. Modular parts, electronics and batteries are easily accessible for replacement.
This manual includes a spare parts list with drawings.
RECYCLABLE
The Transporter is made of recyclable aluminum materials. It uses gel-cell batteries, which do not leak
gas and require no maintenance and are acceptable for recycling.
1.1 Warranty
Each Transporter has a warranty that is valid for one (1) year from the date of shipment. The warranty
provides that Transporter is free from defects in material and workmanship. The batteries have a
standard manufacturer’s warranty of thirty-(30) days.
The warranty is valid providing the customer follows the instruction manual and completes the
maintenance procedures as described. Normal maintenance, calibration or regular adjustments
as specified in the operating instructions are the responsibility of the customer.
Abuse and/or careless operation will void the warranty.
This warranty is exclusive and is in lieu of all other warranties, expressed or implied, including
any implied warranty of merchantability or fitness for a particular purpose, each of which is
hereby expressly disclaimed.

Hermann Schmidt®- Model: TRANSP
5
2. Assembly Instructions
2.1 Assembly
Assembly instructions for a partly assembled Transporter (Intermediate section with legs and
brake rod assembled)
1. Place the Transporter base on the floor. Items include:
1) Leg - Right Hand
1) Leg –Left Hand
1) Intermediate Section-Lower (with lift motor)
1) Intermediate Section-Upper (with mast slide)
1) Brake Rod
Note: Rear casters should be delivered with the wheels in the locked position.
2. Ease off the two nuts on the Mast Slide mounting bracket located at the rear of the Upper
Intermediate Section above the Brake Rod but do not remove them.
3. Pick up the lift mast and carefully insert the mast onto the mast slide on the Upper Intermediate
Section and slide it down over the mounting slide. (A mounting slot is provided full length on
the rear of the mast). Slide the mast into the lift motor coupling located at the bottom of the
intermediate section. (If the coupling does not seat properly, lift the mast up approximately 2”
from the Lower Intermediate Section, lift up on the end-effector mounting yoke (this will turn the
coupling on the lift mast) and push the mast into position). When properly seated, the lift mast
base should be flush with the top of the Lower Intermediate Section.
4. Tighten up the two bolts at the rear of the Upper Intermediate Section with an open-end wrench
(13 mm), but not too hard.
5. Take the Electronic Power Package and insert the mounting tabs into the top of the slot at
the rear of the Lift Mast. Next, lower it until it stops and tighten the two bolts with an open
end wrench (13 mm). Plug the motor cable into its outlet on the Electronic Power Pack.
6. Take the handle and insert the mounting tabs into the top of the slot on the backside of the lift
mast and slide it down to a comfortable position and lock it in place. Make sure that the
remote control holder is placed on the handlebar in a good position. Then place the remote
control on the remote control holder in the keyhole slot and plug in the controller to the
electronic power pack.
The Transporter is now ready to operate

Hermann Schmidt®- Model: TRANSP
6
Assembly instructions for a completely disassembled Transporter
1. Place the Transporter base components on the floor. Items include:
2) Leg - Right Hand
2) Leg –Left Hand
2) Intermediate Section-Lower (with lift motor)
2) Intermediate Section-Upper (with mast slide)
1) Brake Rod
Note: Rear casters should be delivered with the wheels in the braked position. Insure they
are in this position prior to assembly.
2. Assemble the Lower Intermediate Section and Upper Intermediate Section to one leg. The
Lower Intermediate Section should have the motor cable on the left side if you are
standing at the rear of assembled Transporter. The Upper Intermediate Member should be
assembled with the Mast Mounting bracket facing the front of the Transporter if you are standing
at the rear of the assembled Transporter. Insert and loosely tighten
(8) M8 x 50mm button head bolts as shown below. Do Not Tighten
3. Next turn the intermediate section(s) with one leg attached on its side and insert the brake rod at
a forward angle horizontal to the floor (the wheels are now in the braked position) into the
hexagon hole situated above the wheel. Take the next leg and insert the brake rod into its
hexagon hole located above the wheel and secure the leg with the screws as described above.
Check to make sure both rear casters are in the braked position prior to bolting final leg to
intermediate section.
4. After assembly, prior to installing the mast, place Transporter base on a flat surface and tighten
the button head bolts ensuring that all wheels are in contact with the floor. Do Not Over tighten.

Hermann Schmidt®- Model: TRANSP
7
5. Ease off the two nuts on the Mast Slide mounting bracket located at the rear of the Upper
Intermediate Section above the Brake Rod but do not remove them.
6. Pick up the lift mast and carefully insert the mast onto the mast slide on the Upper Intermediate
Section and slide it down over the mounting slide. (A mounting slot is provided full length on the
rear of the mast). Slide the mast into the lift motor coupling located at the bottom of the
intermediate section. (If the coupling does not seat properly, lift the mast up approximately 2”
from the Lower Intermediate Section, lift up on the end-effector mounting yoke (this will turn the
coupling on the lift mast) and push the mast into position).
When properly seated, the lift mast base should be flush with the top of the Lower Intermediate
Section.
Sliding Mast into Mounting Bracket Lift Motor Coupling
7. Tighten up the two bolts at the rear of the Upper Intermediate Section with an open-end wrench
(13 mm), but not too hard.
8. Take the Electronic Power Package and insert the mounting tabs into the top of the slot at the
rear of the Lift Mast. Next, lower it until it stops and tighten the two bolts with an open end
wrench (13 mm). Plug the motor cable into its outlet on the Electronic Power Pack.
9. Take the handle and insert the mounting tabs into the top of the slot on the backside of the lift
mast and slide it down to a comfortable position and lock it in place. Make sure that the remote
control holder is placed on the handlebar in a good position. Then place the remote control on
the remote control holder in the keyhole slot and plug in the controller to the electronic power
pack.
The Transporter is now ready to operate.

Hermann Schmidt®- Model: TRANSP
8
Follow the instructions from 2.1 Assembly for a partly assembled Transporter.
2.2 Disassembly
To disassemble the Transporter, refer to item 2.1 above and reverse the order.
Disposal after useful life
When the Transporter has provided many years of use and is ready to be disposed of, it should be
recycled. The Transporter is manufactured with materials that are recyclable. We have also selected
recyclable gel-cell batteries over nickel-cadmium batteries for this purpose.

Hermann Schmidt®- Model: TRANSP
9
3. Operating instructions
3.1 Operating
In order to prevent and avoid work injuries it is important that the Transporter be operated in a proper
manner.
3.1.1 Charging
NOTE: DO NOT OPERATE TRANSPORTER WHEN CHARGING BATTERIES
Gel-Cell batteries cannot withstand total discharging and need to be recharged after use. The
battery charger supplied with the Transporter connects to an ordinary electrical wall outlet and allows
for recharging the batteries.
When the battery charger is connected to the Transporter and plugged into the wall outlet, both
the green and the red lights come on simultaneously. After a few seconds the red light stays on,
showing that the charging procedure is taking place. When the batteries are about fully charged
the yellow light goes on which gives the battery a “Balancing Charge” to top off the charge cycle.
Generally, the Charge State reached at the “Balancing Charge” is 80%-95% of total charge capacity
of the battery. The green light indicates that the battery is fully charged.
Note: The battery chargers will not over charge the batteries. The electronic card used on the
Transporter will not allow for total discharge of the batteries. Continuous Transporter use will not hurt
the batteries.
Red lamp = Charger is connected to power supply and charging battery.
Yellow lamp = Balancing Charge-Charging battery at 2.7 Amp.
Green lamp = Battery fully charged
The batteries will not leak and are maintenance free.
When the display on the voltmeter flashes the batteries need to be recharged. The power pack
must be switched on for two full minutes after finishing charge cycle for the display on the
voltmeter to indicate charge level.
The Transporter should be recharged every night, over weekends, holidays and after prolonged
periods without use, or the batteries will lose the capability of being recharged. This will ensure that
the batteries can achieve a maximum charge and that they will handle the lifts required during the
working day.

Hermann Schmidt®- Model: TRANSP
10
3.1.2 Handlebar
The height of the handlebar can easily be adjusted by loosening the quick disconnect handles
and sliding the handlebar to the desired position. After adjustment, tighten the quick disconnect
handles. To obtain the best working conditions it is important to adjust the handle to a
comfortable level. During movement of the Transporter, always keep hands inside the handle. This
will protect the hands if the handlebar should encounter an obstacle.
3.1.3 Lifting
Important!
The maximum lift capacity is limited to weights as noted on page 3
The Transporter is not to be used for personnel transportation.
Place your Transporter in the working area. Make sure to always apply the brake before loading or
unloading the end-effector. To apply the brakes, push the red brake bar forward to its bottom position.
Be certain that the end-effector is placed on the same level as the object being loaded. To adjust the
elevation of the end-effector, use the buttons on the remote control pendant. The remote control
pendant has arrows to show the direction of operation.
Place the load on the end-effector. The load should always be positioned centrally in order to
obtain the best stability possible. The load should be placed at the center and back of the end-
effector.
When loading different items raise/lower the end-effector to the correct elevation, making it easy to
push or pull the items on or off the end-effector.
The remote control pendant can rest on the handle or be held in the hand in the best position
to observe the movement of the end-effector. The remote control holder with keyhole slot is mounted
on the handlebar and can be easily adjusted. Turn the quick release handle loosening the holder,
adjust to the desired angle or position and retighten the quick release handle to lock it in place.
3.1.4 Transport
The end-effector should always to be lowered to the lowest possible position before
moving the Transporter. Unlock the central brake by positioning the red bar in the middle position.
All four wheels can now swivel in any direction.
Directional wheel locks
When moving a heavy load, it is both easier and safer if you use the directional wheel locks by
moving the red bar into the upper position. Both back wheels are now locked in a straightforward
position. This gives greater directional stability when moving heavy loads. Observe that it is
especially important that a heavy load be kept as low and as centered on the end-effector as
possible.

Hermann Schmidt®- Model: TRANSP
2
3.2 Troubleshooting
The Transporter has been designed to operate safely and effectively provided that maintenance
procedures are followed according to the instruction manual. A guide for trouble-shooting is provided
as listed below should any problems arise. If the problem remains after referring to the
troubleshooting guide below - contact Hermann Schmidt Co.
Symptom
Action
1
Motor not running when remote is depressed
A
Check that lights on battery charger are on
See 3.11 Charging
B
Check if the voltmeter display on the 20001 and
20002 Power Packs indicate that the battery is
charging
C
Check that the connections to/from the battery
charger are correct during charging
D
Check battery voltage-See 3.1.1
E
Check fuses inside Power Packs
2
End-Effector doesn’t move when depressing
remote controller or control module
A
See above under Symptom 1
B
Check that the maximum load is not exceeded
C
Check that the lift mast is secure and in its lowest
position-see Assembly 2.1
3
End-Effector moves slowly up and down
A
See Symptom 1-Actions 1A and 1D
4
During lifting, mast sounds noisy or behaves
oddly
A
Go through actions under 2.1 Assembly-4
5
Rear wheel brake doesn’t hold
A
With 3mm Allen wrench tighten set screw found
on caster. Perform adjustment while brake is in
opened position. Only slight adjustments are
required

Hermann Schmidt®- Model: TRANSP
3
3.3 Maintenance
Regular maintenance is important to protect the continued use of the Transporter.
Daily maintenance
1. If the Transporter is fitted with a scale - make sure that power to the scale is off when not in use.
2. Wipe down the Transporter with a detergent suitable for powder coat surfaces, aluminum and
stainless steel. Follow the instructions on the detergent. Wipe the Transporter dry.
Do not use a high-pressure hose. It could damage both the electronics as well as the chassis.
3. The batteries are to be charged every night or when the Transporter is not being used for a long period of
time.
The Batteries cannot be "over charged".
Every 6 month maintenance
1. Electrical connections: Check all connections and have any items that show wear or damage
repaired. Replace if needed.
2. Bolts and screws: Check that all bolts and screws are tight.
3. Lift mast: Take the mast out of the base frame. Wipe it clean and lubricate it with ball bearing
grease. When the mast is out of the intermediate section the bristles in the mast are to be taken
out from the bottom of the mast and cleaned. At the same time the screw can be lubricated with
ball bearing grease. Assemble the mast, see 2.1 Assembly, and check that the end-effector is
operating properly.
4. Wheels: Check that all wheels run smoothly and lubricate the ball bearings regularly. Check
that the wheel rubber is not worn or damaged.
5. Central brake system: Check that all brake positions are operating properly:
•Rear wheels locked (brake rod is in lower (horizontal) position)
•Neutral, casters are unlocked (brake rod is in middle position)
•Directional lock engaged (brake rod is in the upper (vertical) position)
6. Quick disconnect handle for handlebar and the mounting bracket for remote control: Check
that the quick disconnect handles can be loosened and tightened properly.
7. Identification and warning signs: Check that the signs are well attached and can be read. They are
mounted for your safety.
8. If the Transporter is fitted with the optional scale, check that the scale is calibrated. If the scale does not
show the correct figures, 0.00, after zeroing "TARA" (Tare).

Hermann Schmidt®- Model: TRANSP
4
4. Enclosures
4.1 Electrical Schematics
17102
No.
Qty
Description
Part No.
No.
Qty
Description
Part No.
1
1
Charger (24VDC/110VAC)
2403SRL
6
1
Aux. Card
20001-10
2
1
Plug
17327
7
1
Motor Controller
20001-01
3
1
Battery Indicator
17102
8
1
Fuse 30A
4
2
Battery 12V
R7104
9
1
2 Button Controller
17272
5
1
Motor 12V w/Brake
20053
10
1
4 Button Controller
17273

Hermann Schmidt®- Model: TRANSP
5
4.2 Lift Mast
No.
Qty
Description
Part No.
No.
Qty
Description
Part No.
1
1
Wedge 3x3 L=18
17531
20
1
Spacer L=15
17568
2
1
Connector-Slide
17567
21
1
Spacer L=5
17569
3
1
Sleeve
17529
22
1
Washer
17580
4
1
Bearing 7201 BE
17520
23
1
Spring
17581
5
1
Bearing Holder
17521
24
Brush Strip L=1497
6
1
Lift Screw Nut
17523
25
Brush Strip L=1747
7
1
Coupling
15101
26
Brush Strip L=1997
8
4
Stub Axle
17515
26
Brush Strip L=2197
9
4
Wheel
17516
28
Brush Strip L=2497
10
1
Screw
sk6SS m6X8
29
Ball Screw L= 1485
17522
11
1
End Cover
17000-82
30
Ball Screw L= 1735
20045
12
4
Screw
mc6S m5x1.6 8.8
31
Ball Screw L= 1985
17539
13
10
Cup Spring
34x12x1.5
32
Ball Screw L= 2185
17506
14
5
Cup Spring
28x10.2x1.5
33
Ball Screw L= 2485
17565
15
1
Spacer
20052
34
Mast Profile L= 1487
20040-01
16
1
Screw
t6ss msx6
35
Mast Profile L= 1737
20041-01
17
1
Slide
20049-02
36
Mast Profile L= 1987
20042-01
18
1
Nut
895 m10
37
Mast Profile L= 2187
20043-01
19
1
Connector
17566
38
Mast Profile L= 2487
20044-01

Hermann Schmidt®- Model: TRANSP
6
4.3 Lower and Upper Intermediate Sections
No.
Qty
Description
Part No.
No.
Qty
Description
Part No.
1
1
Lower Intermediate
20030-01
9
1
Upper Intermediate
20030-03
2
1
Motor 404.311
17344
10
1
Mast Bracket
20030-04
3
1
Motor Bracket
16014
11
1
Locking Plate
19134
4
1
Cable Fitting
20016
12
2
Lock Washer
8.4 hb 200
5
3
Screw
Mc6s m6x20
13
2
Nut
M8 mk
6
5
Screw
Mk6s m6x20
14
2
Bar
17205
7
1
Motor Cover
20030-02
15
1
Brake Rod
17111
8
1
Electrical Schematic
16
4
Screw
K6s m8x20

Hermann Schmidt®- Model: TRANSP
7
4.4Legs-Low Profile
No.
Qty
Description
Part No.
1
2
Legs
20020
2
2
End cover
13004
3
2
Front Wheel 56mm
20011-01
4
2
Rear Wheel 100mm
17557
5
4
Washer
8.4
6
4
Screw
K6s m8x12 10.9
7
2
Screw
Mc6s m10x20 8.8
8
2
Washer
10.5

Hermann Schmidt®- Model: TRANSP
8
4.5Handlebar
No.
Qty
Description
Part No.
1
1
Handle
17280-03
2
1
Remote Bracket
17201A
3
1
Bar
19228
4
2
Locking Knob
19166
5
2
Washer
8.4 hb 200
6
2
End Cover
19169-03

Hermann Schmidt®- Model: TRANSP
9
5. Declaration of Conformity
Referring to Directive for machines 89/392/EEC with addendum -
appendix 2A
Supplier: Hermann Schmidt Co, 26 Sea Pave Road, South Windsor, CT 06074
Address
Description: Model: TRANSP Transporter
Regulations:AFS 1993:10 (89/392/EEG) AND (91/368/EEG)
Regulations that the Transporter complies to:
Standards: EN 292-1, EN 292-2, EN 294, EN 60204-1, EN 349
(when applicable) Applicable harmonized standards
IKH 4.30.01 utg 3, SMS 2986
Applicable national standards and specifications
The item above hereby is assured to be in compliance of the fundamental requirements as stated in the Directive for
machines
89/392/EEC with addendum, respectively be in compliance with the machine that has gone through
Common market control by
an institution as above.

Hermann Schmidt®- Model: TRANSP
10
6. TEST PROTOCOL

Proof Loaded –the overload protection operates.

The slide stops correctly when it goes to the top end position with and without load.

The break function in the slide works at the lower end position, and if the load platform
is hold and is moving downward.

The wheels, rolls - brakes - the directional lock -works with as well as without load.

The maneuvering handle is adjustable and is in fixed position when locked.

Surface Condition

Machine plate –signs –language.

The wheels can rotate free from the load platform.

The sound level from motor and stand is normal.

Accessories –check order / requisition.

Manuals , including; Declaration of Conformity - Instructions for recharging - Assembly
instructions.

The battery charger operates together with the lift trolley. Overnight Charged.
