HETRONIC CS 434 Operating instructions

Operating instructions
Installation instructions
for the radio remote control systems
of different transmitter versions
from HETRONIC
Please enter the system number here!
Please retain for reference!
Date of publication:
HETRONIC  Adalbert – Stifter – Strasse 2  D – 84085 Langquaid
Tel.: [phone] Fax: [phone]

Congratulations on purchasing this high quality safety radio remote control system
from HETRONIC. You have selected a quality product from one of the leading
manufacturers of safety radio remote control systems and therefore can be fully
confident that it reflects state-of-the-art technology.
All rights are reserved, including those relating to photomechanical reproduction and
to recording on electronic media.
The models, illustrations and diagrams contained herein are the property of
HETRONIC and may only be used with our express permission.
Subject to change without notice
Author: J. Mairföls
Version: 30
Date: 03/2006
HETRONIC GmbH
Adalbert-Stifter-Strasse 2
D-84085 Langquaid
Tel.: [phone]
Fax: [phone]
Website: http://www.hetronic.com
e-mail: [email protected]

Table of contents
1. Safety
1.1. Safety of this radio remote control system
1.2. Safety information and tips
1.3. Sources of risk
1.4. Qualified operators
1.5. Safety precautions in the working area
1.6. Protection devices
1.7. What to do in an emergency
2. Operation
2.1. Handling non-rechargeable batteries/rechargeable battery
2.1.1. Replacing non-rechargeable/rechargeable batteries
2.1.2. Battery charger and charging the battery
2.1.3. Battery chargers
2.2. Control elements
2.3. Operation
2.3.1. Visual checks
2.3.2. Safety checks and starting the radio remote control
system
2.4. Fault troubleshooting table
2.5. Frequencies and addressing
2.5.1. Frequency allocation for CS434
2.5.2. Frequency allocation for CS458
3. Installation instructions
3.1. Connection information and start-up
3.2. Receiver dimensions
3.2.1. RX-CP housing
3.2.2. HS-1 housing
3.2.3. HS-2 housing
3.2.4. Housing, 250 x 255
3.2.5. Housing, 400 x 250
3.2.6. Housing, 400 x 400

4. Maintenance
5. Disposal
6. Technical data
6.1. General
6.2. Rechargeable batteries and battery charger
6.3. Transmitter
6.4. Receiver
6.5. Standard options
7. Appendix A

Operating instructions
1. Safety
1.1. Safety of this radio remote control system
This radio remote control system is equipped with both electronic and
mechanical protection devices.
When allocated, coding applies to one transmitter only, meaning that control
commands cannot be received from other transmitters.
This concerns your safety
In the event of incorrect operation or misuse, there is a risk of harm to
- the health of the operator or other persons, and
- the machine and other property.
All persons working with this radio remote control system
- must be both suitably qualified and have been instructed as
required by regulations
- must strictly comply with the contents of these operating
instructions.
1.2. Safety information and tips
The following symbols are used for warnings and advisory notes in these
operating instructions, with the following meanings:
This symbol is used to warn you of the risk of fatal accidents or serious
injuries. Such risks can arise whenever operating or working
instructions are not strictly followed.
This symbol is used to warn you of the risk of damage to the machine or
to other property if the operating or working instructions are either not
followed or not followed properly. Disregarding these warnings may
void your warranty.
This symbol is intended to draw your attention to particular features or
important information designed to make your work easier.

1.3. Sources of risk
The system is designed for permitting machines to be controlled by radio
remote control.
However, since the control commands also are transmitted beyond your range
of vision, and through or around obstacles in the vicinity, you should always:
- Put the transmitter down only in a safe and dry location, switch
the transmitter off and pull the key from the key switch (or if your
transmitter does not have a key switch, remove the rechargeable
battery or the battery compartment).
- Disconnect the power supply before you start any installation,
maintenance or repair work!
- Avoid removing or modifying any safety devices!
1.4. Qualified operators
(Refer to the operating instructions for the machine you intend to
operate with this control system!)
The operator is responsible for ensuring that when the transmitter is put down,
it cannot be used by unauthorized persons. This can be done either by pulling
the key from the key switch, by removing the rechargeable battery or by
storing the transmitter in a locked location.
The owner must:
- provide the operator with these operating instructions
and
- ensure that the operator has read and understood them.
1.5. Safety precautions in the working area
- Ensure that there is no risk of slipping in the work area.
- Before each use of the radio remote control system, check that
nobody is within the working area or swiveling range of your load.
- If a carrying aid is prescribed for your transmitter, this is to be
worn during use.
Either turn the key switch to the off position and pull the key, or
remove the rechargeable battery or the battery compartment from
the receptacle when putting the transmitter down. This will prevent
undesired use or misuse of the transmitter by third parties.

1.6. Protection devices
The machine will be stopped:
- If you actuate the red EMERGENCY STOP button or the Stop button
on the control panel of the transmitter
- If the range is exceeded
- If there is receiver or transmitter interference or when the radio signal is
interrupted
- If the rechargeable battery or the battery compartment is removed
- If the rechargeable battery or non-rechargeable batteries is/are run
down
These protection devices:
- are included for the safety of both persons and property, and
- must not be modified, removed or bypassed under any circumstances
or in any way whatsoever!
Additional protection devices (depending on transmitter version):
- Guard rim, guard clip or recessed function buttons. These safety
devices protect against undesired actuation of the control elements,
which in turn prevents unintentional control commands from being
transmitted.
1.7. What to do in an emergency
In an emergency, immediately press the red EMERGENCY STOP button
or the other EMERGENCY STOP button on the transmitter control panel.
Then proceed as instructed in the operating instructions for your
machine. (Figs. 1 - 3)
EMERGENCY STOP button Red EMERGENCY STOP
button Version 1
(Fig.1) (Fig.2)
Red EMERGENCY STOP
button
Version 2
(Fig. 3)

2. Operation
Have you read and understood the operating instructions, in particular section
1 on safety and protection devices?
You may not use the device until you have done so!
2.1. Handling non-rechargeable/rechargeable
batteries
Depending on the version, HETRONIC radio remote control systems either
come with a battery compartment for two or three 1.5 V alkaline mignon
batteries
or
with a HETRONIC rechargeable battery/battery charger set (12/24 VDC or
115/230 VAC depending on the transmitter type) and two HETRONIC
interchangeable batteries
or
with a VersaPak rechargeable battery/battery charger set (115 V AC or 230 V AC)
with two interchangeable VersaPak penlite batteries rated at 3.6 V each.
If your HETRONIC radio remote control system was
delivered with a battery compartment for alkaline mignon
batteries, never attempt to charge the battery
compartment with the alkaline batteries in a battery
charger!
Alkaline batteries are not capable of recharging; only
batteries specially designed for this purpose can be
recharged!

2.1.1. Replacing rechargeable/non-rechargeable
batteries
Ensure that there is no dirt or grime in the non-rechargeable /
rechargeable battery compartment, as this can lead to breaks in contact.
Only use alkaline batteries. Zinc-carbon batteries are not suited for
powering the transmitter. The transmitter electronics continuously
monitor the battery voltage. When this has dropped below a certain
value, the operating LED on the transmitter begins to flash red, or you
hear an acoustic signal and the system switches off (handheld
transmitter versions excluded).
Proceed as follows:
- Bring the machine to a safe state within 30 seconds (transmitter
switches off after about 30seconds).
-Switch off the transmitter by turning the key switch to position 0 (if your
transmitter has a key switch).
Alkaline mignon batteries:
- Remove the battery compartment with the run down alkaline batteries
from the transmitter.
- Remove the run down alkaline batteries (two or three).
- Place two or three fully charged 1.5 V alkaline batteries in the battery
compartment as depicted on the latter.
- Insert the battery compartment in the battery receptacle of the
transmitter with the contacts first and the open side facing down, or
insert the battery compartment in the battery receptacle of the
transmitter with the narrower end first (see Figs. 4 and 6).
- Now press the battery compartment until it fully locks into place.
VersaPak rechargeable battery:
- Press the lever at the end of the rechargeable battery compartment until
the battery releases.
- Replace the run down rechargeable battery with a fully charged one.
- Press the end of the rechargeable battery until it fully locks into place
(see Fig. 5).
HETRONIC rechargeable batteries:
- Remove the run down rechargeable battery by pressing the edge lip or
battery cover forward, then pull up and out.
- Take a charged battery and insert it in the designated pockets of the
transmitter battery compartment with both contact points forward
(NOVA) or down (GL) and both guide rails down.
- Then press the rechargeable battery in the direction of the battery
receptacle until the battery fully locks into place (see Figs. 7 and 8).

2.1.2. Battery charger and charging the battery
Charging the rechargeable batteries:
- Remove the rechargeable battery as described in section 2.1.1.
- Then place the battery in the charger designed for your particular battery
(see Figs. 9 to 11).
- Ensure that the battery charger is connected to the respective power
supply (power plug, vehicle, etc.).
- Charging should take approximately 3 to 6 hours, depending on the
version. See section 6, “Technical data”, for more information.
Please make sure that you read the operating instructions
provided by the manufacturer for the battery charger prior
to use and that you follow all safety instructions contained
therein. HETRONIC will not accept liability for improper or
negligent use.
Only use genuine HETRONIC parts or parts approved by
HETRONIC. Not doing so introduces the risk of explosion!
Emitted chemicals and flying parts can cause injury.
Battery chargers from HETRONIC have a charge level
recognition feature that automatically switches the charger
to charge retention mode when the batteries are at full
capacity. Always leave one battery in the HETRONIC
battery charger so that you will have a fully recharged
battery in reserve at all times.
To prevent possible damage to VersaPak rechargeable
batteries and the battery charger: Please ensure that
VersaPak batteries do not remain in the battery charger for
more than 24 hours (only applies to VersaPak penlite
rechargeable batteries and the battery charger).
Batteries and rechargeable battery packs are to be treated
as hazardous waste!
Use a specialist disposal company for recycling and
disposal! Defective rechargeable battery packs can also be
disposed of directly through HETRONIC.

2.1.3. Battery chargers
Battery charger UCH-2-AC or UCH-DC
The battery charger contains a processor to control and regulate
the whole charging process. Depending on the version it is
designed for operating voltages of 10-30 VDC or 90-270 VAC.
After inserting the battery, a yellow LED indicates the charging
process. When the battery is fully charged a green LED lights
up. When you switched to fast charge a red LED lights up
additionally. If no LED is shining after inserting battery
on power at charger the yellow LED is flashing continuously,
the battery is bad.
Version 1, VersaPak (Fig. 9)
Version 2, HETRONIC MINI
(Fig. 10)
Version 3, HETRONIC GL
(Fig. 11)

Your HETRONIC radio remote control system is delivered with
charged rechargeable batteries (optional) or with
non-rechargeable batteries, i.e. the radio remote control system
is ready for immediate use.
Battery compartment: Rechargeable battery:
Version 1 Version 1, VersaPak rechargeable
battery
(Fig.4) (Fig.5)
Version 2 Version 2, HETRONIC MINI
(Fig.6) (Fig.7)
Version 3, HETRONIC GL
(Fig.8)

2.2. Control elements
Please refer to the transmitter and receiver diagram included with these
operating instructions for the control element arrangement of your radio remote
control system. The diagram forms an integral part of these operating
instructions.
The following is a description of those control elements that are standard on
HETRONIC radio remote control systems.
2.3. Operation
Before you use the system, you must carry out the safety checks described in
sections 2.3.1. and 2.3.2. below.
These safety checks must be carried out at least once each day before you start
using the system or before each change of shift.
A diagram of your transmitter version is included with these operating
instructions. The diagram forms part of the operating instructions. The
arrangement of the control elements and the transmitter labeling will vary
subject to customer requirements, but generally will be the same as the
labeling of the previous controls. The only essential difference, in fact, is
that you will now be able to exert control without the need for cable
connections.
Refer also to the manufacturer's operating instructions for your
machine and the diagram of your transmitter version to familiarize
yourself with the arrangement of the control elements and their
functions!
The section below deals with the radio remote control system’s control elements
and special features.
Risk to life and property!
Check the EMERGENCY STOP function each time
before use as described in the manufacturer’s
manual.

2.3.1. Visual checks
Always check the transmitter for damage each time before use!
- Are all protection devices present and intact?
- Are there any broken parts?
- Are the rubber sleeves and pushbutton caps free of cracks?
Never work with a transmitter that is damaged in any of these ways!
Ensure that such damage is dealt with immediately!
2.3.2. Safety checks and starting the radio remote
control system
- Check the charge state of your transmitter’s power supply (rechargeable
battery, non-rechargeable batteries)
- In the event that your transmitter is equipped with an EMERGENCY STOP
button, ensure that it is not activated. If the button is activated, unlock it (see
pictures 12,13 and 14).
- Now start the machine to be controlled.
- If your transmitter has a green START button, press it or start the
transmitter by turning the key switch. If your transmitter does not have a
green START button, start the machine by pressing one of the function
buttons or the rocker switch.
- Jog mode: The transmitter does not transmit a continuous signal after the
START button or one of the function buttons is pressed, but switches itself
off two seconds afterwards. Thus, keep one of the function buttons
depressed in this mode upon actuating the EMERGENCY STOP button or
the STOP button during a safety check.
Continuous transmission mode: The radio signal and the EMERGENCY
STOP relay remain active until the transmitter is switched off.
- Now press one of the function buttons of the transmitter and keep it
depressed.

- Check the EMERGENCY STOP function as described in the
manufacturer's manual, however, instead of pressing the EMERGENCY
STOP button on the machine, press the Emergency Stop button or the
yellow STOP button on the control panel of the transmitter.
- Now press the EMERGENCY STOP button or the yellow STOP button
on the transmitter.
Once you have pressed the EMERGENCY STOP button on the
transmitter, it should no longer be possible to exercise control over
any of the machine’s functions!
- Have you completed the checks and does the EMERGENCY STOP
system function properly?
- Now release the function button and unlock the EMERGENCY STOP
button on the transmitter again.
- After the EMERGENCY STOP button has been unlocked and the
transmitter restarted, the system is ready for operation again.
EMERGENCY STOP button, version 1
Unlock by turning clockwise.
(NOVA transmitters)
(Fig. 12)
EMERGENCY STOP button, version 2
Unlock by pulling up.
(GL, handheld, and GR and TG transmitters)
(Fig. 13)
STOP button
Inching mode only (MINI transmitters)
(Fig. 14)

2.4. Fault troubleshooting table
Your radio remote control system has been designed and manufactured using state-of-the-art
technology. Every individual device is subjected to a stringent quality control process at the
manufacturer’s factory before being released for delivery to the customer.
Please check the following points in the event of a fault:
Trouble symptom
Possible causes Remedies
Self-test routine
The transmitter is ready for operation after a 3 second self-test
routine.
On/Off function cannot be
actuated or controlled.
Rechargeable battery/non-
rechargeable batteries run down.
Insert charged rechargeable battery or check non-rechargeable
batteries. Switch on the master switch of the machine.
Interruption to receiver power supply.
Check connectors.
Measure the power supply of the receiver.
Check to see if the same effect occurs with the second
rechargeable battery or with new batteries.
Check the battery compartment and rechargeable battery
compartment and clean if required. Please contact your dealer.
Rechargeable battery or battery
compartment is defective (contact
corrosion).
Batteries are run down.
No reaction to keying the
transmitter.
A non-compatible transmitter and
receiver combination is being used.
Addresses of transmitter and receiver
do not correspond with each other.
Check the system number on the stickers of the transmitter and
receiver to see if you are using two compatible devices. The device
numbers correspond to the system address and therefore must be
identical.
Operating time is too short.
Incorrect or run down rechargeable
batteries/non-rechargeable batteries
were inserted.
Check if the power supply for the charger was switched off, or if the
connection is faulty or loose.
Only use rechargeable batteries approved by HETRONIC.
Only use alkaline batteries.
No radio link.
Check that a yellow and red LED flash on the receiver. If not,
please contact your dealer.
Check to see if there is a large metal
surface located between the
transmitter and receiver.
The range has been exceeded. Please
contact your dealer.
There is interference with the
transmission of the control
commands to the machine.
The receiver is located in a steel
cabinet or a vehicle, or is installed
inside the machine to be controlled.
The aerial is inadequate.
A radio remote control system with the
same frequency is being used within
the vicinity.
A projecting aerial must be installed outside the steel cabinet,
vehicle or the machine to be controlled. Try an alternative
frequency setting for the transmitter and receiver. Please contact
your dealer.
Break in the control lead between the
machine and the receiver.
Check that the connector plug is properly seated. Check the
connecting cable to the machine. Check the wiring and carry out
cable-based control checks of the individual functions if necessary.
Individual functions cannot be
actuated or controlled.
Output module in receiver is defective.
Check that a LED illuminates on the output modules in the receiver
in response to actuating the corresponding function. Please contact
your dealer.

2.5. Frequencies and addressing
Radio remote control systems from HETRONIC include a CS434, CS447 or
CS458 RF module synthesizer (not subject to registration), which incorporates
an RF transmitter module and an RF receiver module.
2.5.1. Frequency allocation for CS434
FREQUENCY ALLOCATION FOR CS434TXN
MANUAL
SETTING
AUTOMATIC SETTING
S1 = 0 S1 = 1
D2 = 1 = FCS (Free Channel Search TX), and SCAN-RX
D2 D3 D4 D5 D6 Frequency Channels D3 = 1 = AUTX (Automatic Channel Change TX), and SCAN-RX
0 0 0 0 0 433.1000 2
0 0 0 0 1 433.5500 20 Freq Group for FCS/AUTX/SCAN
0 0 0 1 0 434.0500 40 D4 D5 D6 Channels
0 0 0 1 1 434.0750 41 0 0 0 68, 58, 54, 52, 49, 41
0 0 1 0 0 434.1000 42 0 0 1 67, 59, 55, 53, 47, 44
0 0 1 0 1 434.1250 43 0 1 0 66, 64, 61, 57, 51, 43
0 0 1 1 0 434.1500 44 0 1 1 65, 63, 60, 56, 50, 42
0 0 1 1 1 434.1750 45 1 0 0 38, 32, 28, 18, 10, 8, 5
0 1 0 0 0 434.2000 46 1 0 1 37, 29, 25, 23, 17, 14, 4
0 1 0 0 1 434.2250 47 1 1 0 36, 34, 31, 27, 21, 13, 3
0 1 0 1 0 434.2500 48 1 1 1 35, 33, 30, 26, 20, 12, 2
0 1 0 1 1 434.2750 49
0 1 1 0 0 434.3000 50 If FCS is selected,
0 1 1 0 1 434.3250 51 the module will remember the last frequency that is set and then the
0 1 1 1 0 434.3500 52 frequency change is made by pushing the decrement switch button.
0 1 1 1 1 434.3750 53 FCS on the transmitter module will only work with decrement switch
button.
1 0 0 0 0 434.4000 54
1 0 0 0 1 434.4250 55 In AUTX mode, the TX module will remember the last frequency
1 0 0 1 0 434.4500 56 and then it will automatically decrement the channel everytime
1 0 0 1 1 434.4750 57 it is cycled On-Off-On.
1 0 1 0 0 434.5000 58
1 0 1 0 1 434.5250 59 In both, AUTX and FCS mode, the decrement switch button is
1 0 1 1 0 434.5500 60 always active.
1 0 1 1 1 434.5750 61 Thus, the user can change the frequency by pushing the button.
1 1 0 0 0 434.6000 62
1 1 0 0 1 434.6250 63
1 1 0 1 0 434.6500 64
1 1 0 1 1 434.6750 65
1 1 1 0 0 434.7000 66
1 1 1 0 1 434.7250 67
1 1 1 1 0 434.7500 68
1 1 1 1 1 434.7750 69
Maximum power is 10mW ERP, 100% duty cycle in
Europe
Maximum power is 1mW ERP, 100% duty cycle in
Europe

2.5.2. Frequency allocation for CS458
FREQUENCY ALLOCATION FOR CS458TXN
MANUAL
SETTING AUTOMATIC SETTING
S1 = 0 S1 = 1
D2 = 1 = FCS (Free Channel Search TX), and SCAN-RX
D2 D3 D4 D5 D6 Frequency CH D3 = 1 = AUTX (Automatic Channel Change TX), and SCAN-RX
0 0 0 0 0 458.5000 0
0 0 0 0 1 458.5250 1 Freq Group for FCS/AUTX/SCAN
0 0 0 1 0 458.5500 2 D4 D5 D6 Channels
0 0 0 1 1 458.5750 3 0 0 0 18, 15, 10, 3, 1
0 0 1 0 0 458.6000 4 0 0 1 17, 14, 9, 2, 0
0 0 1 0 1 458.6250 5 0 1 0 18, 12, 8, 5, 3
0 0 1 1 0 458.6500 6 0 1 1 17, 11, 7, 4, 2
0 0 1 1 1 458.6750 7 1 0 0 27, 19, 16, 14, 10, 0
0 1 0 0 0 458.7000 8 1 0 1 24, 15, 13, 9, 6, 1
0 1 0 0 1 458.7250 9 1 1 0 26, 18, 12, 8, 5, 3
0 1 0 1 0 458.7500 10 1 1 1 25, 17, 11, 7, 4, 2
0 1 0 1 1 458.7750 11
0 1 1 0 0 458.8000 12 If the FCS mode is selected, the module
0 1 1 0 1 458.8250 13 will check for free channels and transmit if a channel is free.
0 1 1 1 0 458.8500 14 The module also remembers the last channel and transmits in
0 1 1 1 1 458.8750 15 that channel the next time power is on.
1 0 0 0 0 458.9000 16 If all channels are occupied, the module will transmit at the least crowded
1 0 0 0 1 458.9250 17 channel.
1 0 0 1 0 458.9500 18
1 0 0 1 1 458.9750 19 In AUTX mode, the TX module will remember the last frequency
1 0 1 0 0 459.0000 20 and then it will automatically decrement the channel everytime
1 0 1 0 1 459.0250 21 it is cycled On-Off-On.
1 0 1 1 0 459.0500 22
1 0 1 1 1 459.0750 23 In both, AUTX and FCS mode, the decrement switch button is
1 1 0 0 0 459.1000 24 always active.
1 1 0 0 1 459.1250 25 Thus, the user can change the frequency by pushing the button.
1 1 0 1 0 459.1500 26
1 1 0 1 1 459.1750 27
1 1 1 0 0 459.2000 28
1 1 1 0 1 458.5000 0
1 1 1 1 0 458.5250 1
1 1 1 1 1 458.5500 2
UK Channels
Use of the CS 434 RF module is not subject to registration or
payment of a fee!
The transmitter must never be used without an aerial, as this could
destroy the RF module!
The frequency is preset by HETRONIC in the factory. If you should
experience difficulties with the radio link in your system, please
contact your dealer or HETRONIC’s aftersales service team. The
phone number can be found on the cover page of these operating
instructions.

3. Installation instructions
3.1. Connection information and start-up
The machine may only be connected by a qualified expert familiar with the machine
to be operated (see section 4., “Maintenance”).
The following also applies:
- Before starting any work on the switch cabinet or the receiver, switch off
the power supply to the machine to be controlled.
- VDE regulations (German Association of Electrical Engineers), the
regulations of local electricity supply companies, and German UVV
(accident prevention) safety regulations must all be fulfilled.
HETRONIC will not accept liability or provide a guarantee in the
event of personal injury, damage to property and consequential
damage resulting from improper or negligent handling of this
product or from handling that does not comply with the
regulations and standards on which these operating instructions
are based.
Take steps to ensure that the receiver is located in an easily accessible place and is
not installed within the vehicle, the machine to be controlled, a switch cabinet or any
other similar equipment.
If installation in such a location is unavoidable, a projecting aerial must be mounted
with it as well. Suitable projecting aerials can be obtained from your dealer. Please
refer to section 3.3. of these operating instructions for installation information.
Switch off the power supply to the machine before connecting the power
supply unit of the receiver.
Please refer to section 3.2. on the following page for the dimensions of
the receiver and the drilling pattern.
The radio remote control system may only be connected by a
qualified expert familiar with the electrical circuitry of the machine
to be controlled.

Operation
Signal
Error
Normal
Dieser Bereich muss
von Hindernissen frei sein
insbesondere Metallflächen.
Montieren Sie den Empfänger so, dass das Diagnosefenster immer sichtbar bleibt. (Nur System BMS)
ANTENNE muss in vertikaler
Richtung nach oben zeigen
210.5 mm
246.8 mm
71.1 mm
162 mm
167.9 mm
113.5 mm
Mounting the receiver:
The receiver should be mounted on the vehicle or machine to be controlled with the
screwed glands or connections underneath. If your receiver is to be installed on a
vehicle or on a mobile machine, you should equip the receiver with four rubber
buffers. These can be obtained from your dealer or direct from the replacement parts
sales division at HETRONIC. The rubber buffers will prevent heavy vibrations being
transferred from the machine to the receiver. A diagram of your transmitter and
receiver version is included with these operating instructions.
When mounting the receiver, ensure that the aerial is positioned in such a way
that it is minimally shielded by large metallic surfaces.
The receiver has an internal aerial. If it is not possible to mount the receiver in
a favorable position, be sure to order a projecting aerial from your dealer.
Projecting aerials can be ordered with 1.5, 3.0 and 5.0 meter extension lines.
Then mount the aerial in a more favorable position.
3.2. Receiver dimensions
Please refer to the following pages for the receiver dimensions required for
mounting. All receiver types that are offered standard by HETRONIC are
listed. If your receiver type is not listed, you will find a diagram of your receiver
dimensions included with these operating instructions. The diagram forms an
integral part of the operating instructions.
AERIAL must point This area must be free of hindrances,
vertically upwards especially metal surfaces.
Mount the receiver in such a way that the diagnosos window is always visible (only for BMS system).
