Hewlett Packard Enterprise HPE Apollo 2000 Gen10 Plus User manual

HPE Apollo 2000 Gen10 Plus Chassis User Guide
Part Number: P26200-002
Published: August 2020
Edition: 2
Abstract
This document is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett
Packard Enterprise assumes that you are qualified in the servicing of computer equipment, trained in recognizing hazards
in products with hazardous energy levels, and are familiar with the weight and stability precautions for rack installations.

©Copyright 2020 Hewlett Packard Enterprise Development LP
Notices
The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise
products and services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable
for technical or editorial errors or omissions contained herein.
Confidential computer software. Valid license from Hewlett Packard Enterprise required for possession, use, or copying.
Consistent with FAR 12211 and 12212, Commercial Computer Software, Computer Software Documentation, and
Technical Data for Commercial Items are licensed to the U.S. Government under vendor's standard commercial license.
Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no
control over and is not responsible for information outside the Hewlett Packard Enterprise website.
Acknowledgments
Linux®is the registered trademark of Linus Torvalds in the U.S. and other countries.
Microsoft®, Windows®, and Windows Server®are either registered trademarks or trademarks of Microsoft Corporation in
the United States and/or other countries.
Red Hat®Enterprise Linux®are registered trademarks of Red Hat, Inc. in the United States and other countries.
VMware ESXi™and VMware vSphere®are registered trademarks or trademarks of VMware, Inc. in the United States
and/or other jurisdictions.
All third-party marks are property of their respective owners.

Contents
HPE Apollo 2000 Gen10 Plus System............................................................................ 7
Component identification................................................................................................ 8
System components.......................................................................................................................................................................................................8
Front panel components..............................................................................................................................................................................................8
Information pull tab................................................................................................................................................................................... 10
Front panel LEDs and buttons..............................................................................................................................................................................10
Front panel LED power fault codes..................................................................................................................................................12
Chassis UID LED.......................................................................................................................................................................................... 12
UID button functionality..........................................................................................................................................................................12
Rear panel components............................................................................................................................................................................................ 13
Rear panel LEDs and buttons................................................................................................................................................................................14
Server node numbering.............................................................................................................................................................................................14
Server node orientation............................................................................................................................................................................................ 15
Drive configurations....................................................................................................................................................................................................15
Node-to-drive association....................................................................................................................................................................................... 15
Drive numbering............................................................................................................................................................................................................16
HPE Smart Carrier drive LEDs and components .......................................................................................................................................16
Fan numbering............................................................................................................................................................................................................... 18
Fan board connectors.................................................................................................................................................................................................19
Power backplane-distribution board components....................................................................................................................................19
Operations........................................................................................................................ 20
Power up the server.................................................................................................................................................................................................... 20
Power down the server..............................................................................................................................................................................................20
Power capping................................................................................................................................................................................................................20
Remove the hot-plug drive..................................................................................................................................................................................... 21
Remove the power supply.......................................................................................................................................................................................21
Remove the server blank..........................................................................................................................................................................................22
Disconnect the tube set............................................................................................................................................................................................ 23
Remove the server....................................................................................................................................................................................................... 23
Extend the chassis from the rack........................................................................................................................................................................ 24
Remove the chassis from the rack......................................................................................................................................................................25
Remove the access panel.........................................................................................................................................................................................27
Install the access panel..............................................................................................................................................................................................28
Install the chassis into the rack.............................................................................................................................................................................29
Install the server blank.............................................................................................................................................................................................. 31
Install the server............................................................................................................................................................................................................31
Connect the tube set.................................................................................................................................................................................................. 32
Setup..................................................................................................................................34
General site planning..................................................................................................................................................................................................34
Optional service.............................................................................................................................................................................................................34
Compiling the documentation...............................................................................................................................................................................34
Initial system installation..........................................................................................................................................................................................34
3

HPE Installation Service.......................................................................................................................................................................... 35
Setting up the system...............................................................................................................................................................................35
Operational requirements........................................................................................................................................................................................37
Site requirements........................................................................................................................................................................................37
Space and airflow requirements.........................................................................................................................................................37
Temperature requirements................................................................................................................................................................... 37
Power requirements.................................................................................................................................................................................. 38
Grounding requirements.........................................................................................................................................................................38
Device bay thermal requirements..................................................................................................................................................... 38
Rack warnings and cautions...................................................................................................................................................................................39
Server warnings and cautions............................................................................................................................................................................... 40
Electrostatic discharge.............................................................................................................................................................................................. 41
Hardware options installation...................................................................................... 42
Hardware option installation guidelines......................................................................................................................................................... 42
Rack rail option.............................................................................................................................................................................................................. 42
Drive options................................................................................................................................................................................................................... 42
Drive support information......................................................................................................................................................................42
Drive guidelines............................................................................................................................................................................................42
PCIe riser requirement for drive installation............................................................................................................................... 43
Installing a hot-plug drive...................................................................................................................................................................... 43
Redundant fan option................................................................................................................................................................................................ 45
Fan behavior...................................................................................................................................................................................................45
Installing the redundant fans............................................................................................................................................................... 45
Energy pack option......................................................................................................................................................................................................47
HPE Smart Storage Battery.................................................................................................................................................................. 47
Installing an energy pack........................................................................................................................................................................48
Power supply options.................................................................................................................................................................................................50
Power supply warnings and cautions..............................................................................................................................................50
Installing an AC power supply............................................................................................................................................................. 50
Power interface board options ............................................................................................................................................................................ 52
Installing the PIB assembly....................................................................................................................................................................53
RCM module option.....................................................................................................................................................................................................56
RCM module operational requirements......................................................................................................................................... 56
Installing the RCM module.....................................................................................................................................................................56
Enabling the iLO ports on the RCM module................................................................................................................................61
RCM module network cabling.............................................................................................................................................................. 61
Cabling.............................................................................................................................. 63
Cabling guidelines........................................................................................................................................................................................................ 63
Front I/O cabling........................................................................................................................................................................................................... 64
Drive backplane cabling............................................................................................................................................................................................65
n26008 SFF U.3 drive backplane cabling................................................................................................................................... 65
n260024 SFF basic drive backplane cabling............................................................................................................................ 66
Energy pack cabling....................................................................................................................................................................................................67
APM module cabling...................................................................................................................................................................................................67
RCM sideband cabling............................................................................................................................................................................................... 68
Software and configuration utilities............................................................................69
Server mode.....................................................................................................................................................................................................................69
Product QuickSpecs.................................................................................................................................................................................................... 69
Active Health System Viewer................................................................................................................................................................................ 69
4

Active Health System............................................................................................................................................................................... 69
HPE iLO 5..........................................................................................................................................................................................................................70
iLO Federation.............................................................................................................................................................................................. 70
iLO Service Port........................................................................................................................................................................................... 71
iLO RESTful API........................................................................................................................................................................................... 72
RESTful Interface Tool.............................................................................................................................................................................72
iLO Amplifier Pack......................................................................................................................................................................................72
Integrated Management Log.................................................................................................................................................................................72
Intelligent Provisioning..............................................................................................................................................................................................72
Management security.................................................................................................................................................................................................73
Scripting Toolkit for Windows and Linux....................................................................................................................................................... 73
HPE Message Passing Interface...........................................................................................................................................................................73
HPE Performance Cluster Manager...................................................................................................................................................................74
HPE Cray Programming Environment..............................................................................................................................................................74
UEFI System Utilities.................................................................................................................................................................................................. 74
Selecting the boot mode ........................................................................................................................................................................74
Secure Boot.....................................................................................................................................................................................................75
Launching the Embedded UEFI Shell .............................................................................................................................................76
HPE Smart Storage Administrator..................................................................................................................................................................... 76
HPE InfoSight for servers ....................................................................................................................................................................................... 77
USB support.....................................................................................................................................................................................................................77
External USB functionality.....................................................................................................................................................................77
Redundant ROM support......................................................................................................................................................................................... 77
Safety and security benefits................................................................................................................................................................. 77
Keeping the system current................................................................................................................................................................................... 78
Updating firmware or system ROM.................................................................................................................................................. 78
Drivers................................................................................................................................................................................................................80
Software and firmware.............................................................................................................................................................................80
Operating system version support................................................................................................................................................... 81
HPE Pointnext Portfolio..........................................................................................................................................................................81
Proactive notifications..............................................................................................................................................................................81
Troubleshooting..............................................................................................................82
NMI functionality...........................................................................................................................................................................................................82
Troubleshooting resources..................................................................................................................................................................................... 82
Safety, warranty, and regulatory information.......................................................... 83
Regulatory information............................................................................................................................................................................................. 83
Notices for Eurasian Economic Union............................................................................................................................................. 83
Turkey RoHS material content declaration................................................................................................................................. 84
Ukraine RoHS material content declaration................................................................................................................................84
Warranty information................................................................................................................................................................................................. 84
Specifications...................................................................................................................85
Environmental specifications.................................................................................................................................................................................85
Mechanical specifications.........................................................................................................................................................................................85
Power supply specifications................................................................................................................................................................................... 86
HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen Power Supply.................................................................... 86
HPE 1800 W–2200 W Flex Slot Platinum Hot-plug Power Supply .............................................................................87
HPE 3000 W 200–277 VAC Platinum Hot-plug Power Supply......................................................................................87
5

Websites............................................................................................................................89
Support and other resources........................................................................................ 90
Accessing Hewlett Packard Enterprise Support.........................................................................................................................................90
Accessing updates....................................................................................................................................................................................................... 90
Remote support.............................................................................................................................................................................................................91
Documentation feedback......................................................................................................................................................................................... 91
6

HPE Apollo 2000 Gen10 Plus System
The HPE Apollo 2000 Gen10 Plus System is a dense, multiserver platform that packs incredible performance and
workload flexibility into a small data center space. The system oers a density-optimized, shared infrastructure with a
flexible scale-out architecture. The system supports a variety of workloads from remote site systems to large HPC clusters
and everything in between.
Chassis
The HPE Apollo n2000 Gen10 Plus series chassis occupies 2U space in the rack.
• HPE Apollo n2400 Gen10 Plus Chassis—This model has no drives, drive backplanes, and system interconnect
assemblies. This model provides optimum power and cooling eiciencies ideal for high-power processor
configurations.
• HPE Apollo n2600 Gen10 Plus Chassis
◦This model supports the following storage configurations:
– 8 SFF SAS/SATA/NVMe drive configuration
– 24 SFF SAS/SATA drive configuration
◦Drives are allocated equally across all server nodes.
Server node
HPE ProLiant XL225n Gen10 Plus Server—1U, dual-processor AMD server node
A 42U rack fits up to 20 Apollo n2000 Gen10 Plus series chassis. Each chassis can accommodate up to four 1U servers for
a total of 801U servers per rack.
For more information about product features, specifications, options, configurations, and compatibility, see the product
QuickSpecs on the Hewlett Packard Enterprise website (https://www.hpe.com/info/qs).
HPE Apollo 2000 Gen10 Plus System 7

Component identification
System components
Item Description
1 Fan board
2 System interconnect assemblies
3 Fan
4 Access panel
5 Power backplane-distribution board assembly
6 PDB cover
7 Rack consolidation management (RCM) module (optional)
8 Server blank
9 1U server node
10 Chassis
Front panel components
HPE Apollo n2400 Gen10 Plus Chassis
Component identification 8

Item Description
1 Nonremovable bezel blanks
2Chassis information pull tab
HPE Apollo n2600 Gen10 Plus Chassis with 8 SFF drives
Item Description
1 SFF hot-plug drives
2Chassis information pull tab
3 Nonremovable bezel blanks
HPE Apollo n2600 Gen10 Plus Chassis with 24 SFF drives
Item Description
1 SFF hot-plug drives
2Chassis information pull tab
Component identification 9

Information pull tab
Item Description
1 QR code label
2 Chassis serial number/product ID label
Use a mobile device to scan the QR code label to display the chassis mobile product page (https://www.hpe.com/qref/
apollo2000gen10plus). This page contains links to chassis setup information, spare part numbers, QuickSpecs,
troubleshooting resources, and other useful product links.
Front panel LEDs and buttons
Item Description Status Definition
1 Node 2 UID button/LED1Solid blue Activated
Flashing blue • 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
Table Continued
Component identification 10

Item Description Status Definition
O Deactivated
2 Node 1 UID button/LED1Solid blue Activated
Flashing blue • 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
O Deactivated
3 Node 2 Health LED1, 2 Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded2
Flashing red System critical2
4 Node 1 Health LED1, 2 Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded2
Flashing red System critical2
5 Node 4 Health LED1, 2 Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded2
Flashing red System critical2
6 Node 3 Health LED1, 2 Solid green Normal
Flashing green iLO rebooting
Flashing amber System degraded2
Flashing red System critical2
7 Node 4 UID button/LED1Solid blue Activated
Flashing blue • 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
O Deactivated
8 Node 3 UID button/LED1Solid blue Activated
Table Continued
Component identification 11

Item Description Status Definition
Flashing blue • 1 flash per second = Remote management
or firmware upgrade in progress
• 4 flashes per second = iLO manual soft
reboot sequence initiated
• 8 flashes per second = iLO manual hard
reboot sequence in progress
O Deactivated
1 When the LEDs described in this table flash simultaneously, a power fault has occurred. For more information, see Front panel LED
power fault codes.
2 If the Health LED indicates a degraded or critical state, review the system IML or use iLO to review the system health status.
Front panel LED power fault codes
The following table provides a list of power fault codes, and the subsystems that are aected. Not all power faults are
used by all servers.
Subsystem LED behavior
System board 1 flash
Processor 2 flashes
Memory 3 flashes
Riser board PCIe slots 4 flashes
FlexibleLOM 5 flashes
Storage controllers 6 flashes
System board PCIe slots 7 flashes
Power backplane or storage backplane 8 flashes
Power supply 9 flashes
Chassis UID LED
The chassis UID LED is used to locate a particular chassis when it is deployed in a dense rack with other equipment. When
the UID LED of any of the servers installed in the chassis is activated, the chassis UID LED also flashes blue. Activating the
UID LED allows an onsite technician to quickly identify a chassis for maintenance tasks.
UID button functionality
The UID button can be used to display the Server Health Summary when the server will not power on. For more
information, see the latest HPE iLO 5 User Guide on the Hewlett Packard Enterprise website.
Component identification 12

Rear panel components
Item Description
1 Power supply 2
2 Power supply 1
3 Apollo Platform Manager (APM) 20 port in the APM module1, 2
4 APM 20 port in the RCM module1
5 iLO ports
1 The RCM and APM modules are both chassis options.
2 To enable the APM 20 port, in the System Utilities screen, select System Configuration > iLO 5 Configuration Utility > Network
Options > Network Interface Adapter > ON. For more information, see the UEFI System Utilities user guide on the HPE website
(https://www.hpe.com/info/UEFI/docs).
Component identification 13

Rear panel LEDs and buttons
Item Description Status Definition
1 Power supply LED Solid green The power supply is operating normally.
O One or more of the following conditions exists:
• Power is unavailable
• Power supply failure
• Power supply is in standby mode
• Power supply error
2 iLO link LED1Solid green Linked to network
O No network connection
3 iLO activity LED1Solid green Linked to network
Flashing green Network active
O No network activity
1 These iLO LEDs are located on the optional RCM module.
Server node numbering
1U system: Server node numbering
Component identification 14

Server node orientation
The server node cover facilitates smooth node entry and ejection from the bay. When installing the server into the bay,
observe the correct node orientation.
• Left side—The node cover must be facing down with the release lever on the top side of the bay.
• Right side—The node cover must be facing up with the release lever on the bottom side of the bay.
The following image is shown from the perspective of a user facing the chassis rear panel. The release lever is shown in
amber color.
Drive configurations
The HPE Apollo n2000 Gen10 Plus series chassis occupies 2U space in the rack and supports the following drive
configurations:
• HPE Apollo n2400 Gen10 Plus Chassis—This model has no drives, drive backplanes, and system interconnect
assemblies. This model provides optimum power and cooling eiciencies ideal for high-power processor
configurations.
• HPE Apollo n2600 Gen10 Plus Chassis
◦This model supports the following storage configurations:
– 8 SFF SAS/SATA/NVMe drive configuration
– 24 SFF SAS/SATA drive configuration
◦Drives are allocated equally across all server nodes.
Node-to-drive association
The drive cage is structured into four drive boxes. Each drive box is assigned to a specific node number. Install drives only
in the drive box that has the associated server node installed.
Component identification 15

1U system
• Node 1 > Drive box 1
• Node 2 > Drive box 2
• Node 3 > Drive box 3
• Node 4 > Drive box 4
Drive numbering
Apollo n2600 Gen10 Plus Chassis with 8 SFF drives
Apollo n2600 Gen10 Plus Chassis with 24 SFF drives
HPE Smart Carrier drive LEDs and components
This HPE Smart Carrier supports SAS, SATA, and NVMe drives.
Component identification 16

HPE Smart Carrier drive LEDs
Item Description Status
1 Locate • Solid blue = The drive is being identified by a host
application.
• Flashing blue = The drive carrier firmware is being updated
or requires an update.
2 Activity ring • Rotating green = Drive activity.
•O = No drive activity.
3 Do not remove • Solid white = Do not remove the drive. Removing the drive
causes one or more of the logical drives to fail.
•O = Removing the drive does not cause a logical drive to
fail.
4 Drive status • Solid green = The drive is a member of one or more logical
drives.
• Flashing green = The drive is doing one of the following:
◦Rebuilding or performing a RAID migration
◦Performing a strip size migration
◦Performing a capacity expansion
◦Performing a logical drive extension
◦Erasing
• Flashing amber/green = The drive is a member of one or
more logical drives and predicts the drive will fail.
• Flashing amber = The drive is not configured and predicts
the drive will fail.
• Solid amber = The drive has failed, is unsupported, or is
invalid.
•O = The drive is not configured by a RAID controller or a
spare drive.
Component identification 17

HPE Smart Carrier components
Item Description Definition
1 Drive handle • Pull the open handle to remove a drive.
• Close the handle to fully seat and lock a drive into place.
2 Handle release button Releases the drive handle for removal and insertion.
Fan numbering
The system supports up to seven non-hot-plug, dual-rotor fans.
• Fans 1, 2, 4, 6, and 7 are default fans for basic cooling.
• Fans 3 and 5 are optional fans for high performance cooling.
Redundant fan is supported in both basic and high performance cooling setups.
Component identification 18

Fan board connectors
Item Description
1 Drive backplane power cable connectors
2 Right front I/O cable connector
3 SAS expander sideband cable connector
4 Fan connectors
5 Left front I/O cable connector
Power backplane-distribution board components
Item Description
1 Power backplane
2 Power backplane connector
3 Fan board connector
4 Energy pack connector
5 Power interface board (PIB) connectors
6 Power distribution board (PDB)
7 RCM cable connector
Component identification 19

Operations
Power up the server
The Apollo n2000 Gen10 Plus series chassis firmware initiates an automatic power-up sequence when the servers are
installed. If the default setting is changed, use one of the following methods to power up each server:
• Use a virtual power button selection through iLO 5.
• Press and release the Power On/Standby button.
When the server goes from standby mode to full power mode, the server power LED changes from amber to green.
Power down the server
Before powering down the server for any upgrade or maintenance procedures, perform a backup of critical server data
and programs.
IMPORTANT: When the server is in standby mode, auxiliary power is still being provided to the system.
To power down the server, use one of the following methods:
• Press and release the Power On/Standby button.
This method initiates a controlled shutdown of applications and the OS before the server enters standby mode.
• Press and hold the Power On/Standby button for more than 4 seconds to force the server to enter standby mode.
This method forces the server to enter standby mode without properly exiting applications and the OS. If an
application stops responding, you can use this method to force a shutdown.
• Use a virtual power button selection through iLO 5.
This method initiates a controlled remote shutdown of applications and the OS before the server enters standby
mode.
Before proceeding, verify that the server is in standby mode by observing that the system power LED is amber.
Power capping
Server power capping is useful when you want to hold the actual used system power to a specific amount. This amount
might be lower than what the system configuration might maximally use. The power capping feature in the HPE Apollo
n2000 Gen10 Plus series chassis operates at the server enclosure (chassis) level.
To configure power capping, use one of the following:
• HPE Apollo Platform Manager (HPE APM)
APM is a rack-level device that can control power caps for all enclosures in the rack. A global power cap can be applied
to all enclosures with one APM command. Also, dierent caps can be applied to user-defined groups using flexible
zones within the same rack. Hewlett Packard Enterprise recommends configuring the APM such that it controls only
one rack. For more information, see the HPE Apollo Platform Manager User Guide (https://www.hpe.com/support/
APM_UG_en).
• iLO RESTful API
Operations 20
