HGLRC Racewhoop30 User manual

1
www.hglrc.com
Racewhoop30 HD
FPV Racing Drone
Manual

2
www.hglrc.com
Product Specifications.............................................................................................................................1
Interface Description...............................................................................................................................2
Check the flight control drive................................................................................................................3
Calibration accelerometer......................................................................................................................4
URAT serial port use.................................................................................................................................5
Select aircraft model.................................................................................................................................6
Choose ESC protocol..................................................................................................................................7
Voltage parameters setting.....................................................................................................................8
Setting up the receiver..............................................................................................................................9
Check receiver signal................................................................................................................................10
Select flight mode startup mode...........................................................................................................11
LED settings.................................................................................................................................................12
Troubleshooting.........................................................................................................................................13
.......................................................................................
Package IncIuded
Racwhoop30 HD FPV Racing Drone *1
Accessory Package*1

3
www.hglrc.com
1.Product Specifications
Product parameters
Model
Racwhoop30 HD
FPV Racing Drone
Frame Kit
Racewhoop30 Frame Kit
Flight Controller
Zeus35 AIO
ESC
35A 4in1
VTX
CADDX Nebula Nano
Motor
2105.5 Motor
4S KV3600
6S KV2800
Support receiver
SBUS .DSMX.i.BUS
Input Voltage
3-6S Lipo

4
www.hglrc.com
2.Interface Description

5
www.hglrc.com
3.Check the flight control drive
1. Long Press BOOT buttons.connect USB.The system automatically
install the driver
2.Driver cannot be installed, please download ImpulseRC_Driver_Fixer
3.Double-click on the run(Plug in the flight controller to automatically
install the driver)
4.open betaflight configurator ，enter DFU mode

6
www.hglrc.com
5. Click Select firmware version
6.Click Load firmware.Waiting for
completion It will be prompted upon
completion.
7.open betaflight configurator 。Controller plugged into the
computer. Betaflight Automatically assigned port，click “Connect”
Enter setup interface（Different computer COM）

7
www.hglrc.com
4.Calibration accelerometer
1. Put the aircraft horizontal and click“Reset Z axis”
Click again
5.UART serial port use
UART1 uses VTX image transmission
UART2 uses receiver telemetry

8
www.hglrc.com
6.Select aircraft model
1.Click Select model
2.Click Click “I understand the risks”
Push Master to check motor
steering“Master”Steering can be changed at BLHeliSuite

9
www.hglrc.com
7.Choose ESC protocol
1.Choose the right ESC protocol, the optional universal protocol
DSHOT600.
8.Voltage parameters setting
1.Click Setting parameters

10
www.hglrc.com
9.Setting up the receiver
1.Receiver connection diagram

11
www.hglrc.com
2.Click .have found“UART2”Open （SBUS）the receiver serial port
3.Open (i.BUS/DSMX) receiver serial port
4.Set the SBUS receiver
5.Set the i.BUS receiver
6.Set the DSMX receiver

12
www.hglrc.com
10.Check receiver signal
1.Click Check the remote control output signal

13
www.hglrc.com
11.VTX serial port use. VTX uses
OSD smart audio
1.VTX connection diagram

14
www.hglrc.com
2.VTX serial port opens. The protocol is selected according to its own VTX
protocol.
12.Select flight mode startup
mode
1. Click set up the function of remote control switch across the
channel (below are for reference only)

15
www.hglrc.com
13.LED settings
1. Click Turn on LED support
2.Click .Click set according to
need

16
www.hglrc.com
14.Troubleshooting
Warning:
Please read the cautions as follows, otherwise stability of your flight
controller cannot be ensured, your flight controller will even get damaged.
●Keep focus on the polarity. Check carefully before power supply.
●Cut off the power when you connect, plug and pull anything.
●The refresh rate of PID and Gyroscope is up to 8K/8K.
after sales question:
1. After receiving the goods, it is found that the product can not be used
normally. If the return to the factory is a quality problem, the repair
service will be provided free of charge.
2. If the product is damaged due to improper operation, the repair service
may be provided under the condition that the inspection can be repaired.
3. For domestic customers, please contact the after-sales service personnel.
For overseas customers, please contact the official website for after-sales
service.

17
www.hglrc.com
Product daily problems
1.OSD garbled:
If you find garbled characters, please open Betaflight, click “OSD” .and click “Font Manager”
clicks on “Upload Font” to update
1. When plugged in the battery, the aircraft does not pass the self-test
without "BBB" sound. There is only one sound.
Please check if the ESC agreement is correct
3.The spin of the aircraft keeps spinning
1. Please check if the propeller is correct
2. Please check if the motor direction is correct
