HGLRC Arrow3 6S User manual

1
www.hglrc.com
HGLRC Arrow3 6S FPV Racing Drone
Manual

2
www.hglrc.com
Product Specifications.............................................................................................................................1
Interface Description...............................................................................................................................2
Check the flight control drive................................................................................................................3
Calibration accelerometer......................................................................................................................4
URAT serial port use.................................................................................................................................5
Select aircraft model.................................................................................................................................6
Choose ESC protocol..................................................................................................................................7
Select ESC telemetry..................................................................................................................................8
Voltage and current parameters setting............................................................................................9
Setting up the receiver..............................................................................................................................10
VTX serial port use. VTX uses OSD smart audio..............................................................................11
GPS parameters setting...........................................................................................................................12
Check receiver signal................................................................................................................................13
Select flight mode startup mode...........................................................................................................14
OSD settings.................................................................................................................................................15
LED settings.................................................................................................................................................16
Troubleshooting.........................................................................................................................................17
.......................................................................................
Package IncIuded
HGLRC Arrow3 6S FPV Racing Drone *1
Accessory Bag*1

3
www.hglrc.com
1.Product Specifications
HGLRC Arrow3 6S FPV Racing Drone
Product parameters
FC name
Forward F4 Mini Flight Control
Usage
for 110mm-1000mm Frame Kit
MPU
MPU6000-SPI
CPU
STM32F405R6T6, 8K
Firmware:
Betaflight OMNIBUSF4V6
Black Box
No dataflash chip found
Support receiver
SBUS .i.BUS .DSMX
ESC name
Forward 45A 4in1 Mini ESC
Continuous current
45A-4S/35A-6S
CPU
STM32F051
ESC firmware
BIheIi_32
VTX
Forward VTX Mini
Output Power
PIT/25mW/100mW
200mW/350mW
Input Voltage
2-6S Lipo
Size
182*162*75mm
Weight(without battery）
166.6g

4
www.hglrc.com
2.Interface Description

5
www.hglrc.com

6
www.hglrc.com

7
www.hglrc.com
3.Check the flight control drive
1. Long Press BOOT buttons.connect USB.The system automatically
install the driver
2.Driver cannot be installed, please download ImpulseRC_Driver_Fixer
3.Double-click on the run(Plug in the flight controller to automatically
install the driver)
4.open betaflight configurator ，enter DFU mode

8
www.hglrc.com
5.Click Select firmware version
6.Click Load firmware.Waiting for
completion It will be prompted upon
completion.
7.open betaflight configurator 。Controller plugged into the
computer. Betaflight Automatically assigned port，click “Connect”
Enter setup interface（Different computer COM）

9
www.hglrc.com
4. Calibration accelerometer
1. Put the aircraft horizontal and click“Reset Z axis”
Click again

10
www.hglrc.com
5.URAT serial port use
URAT1 uses receiver telemetry
UART2 uses VTX image transmission
UART3 uses GPS
UART4 uses ESC telemetry
URAT6 uses the receiver
6.Select aircraft model
1.Click Select model

11
www.hglrc.com
2.Click Click “I understand the risks” Push Master to check motor
steering“Master”Steering can be changed at BLHeliSuite32
7.Choose ESC protocol
1.Choose the right ESC protocol, the optional universal protocol
DSHOT600.For FD445, DSHOT1200 is recommended.
8.Turn on ESC telemetry
1.Open ESC telemetry serial port.TX on the ESC needs to be connected
to the RX4 on the flight controller to use the ESC telemetry

12
www.hglrc.com
2.Use KISS/BLHeli_32 ESC telemetry as sensor.
3.View telemetry data on OSD

13
www.hglrc.com
9.Voltage and current
parameters setting
1. Click Setting parameters

14
www.hglrc.com
10. Setting up the receiver
1.Receiver connection diagram

15
www.hglrc.com
2.Click .have found“UART6”Open（SBUS）the receiver serial
port
3.Open (i.BUS/DSMX) receiver serial port
4.Set the SBUS receiver
5.Set the i.BUS receiver

16
www.hglrc.com
6.Set the DSMX receiver
7.Turn on the receiver telemetry serial port Function on

17
www.hglrc.com
11.VTX serial port use. VTX uses
OSD smart audio
1.VTX connection diagram
2.Fourth, frequency and power control methods:
1.Betalight firmware.
2.Button frequency control: Short press once to change channel number CH
(CH1-CH8) long press for 2 seconds and then short press to change
frequency group FR （A-B-E-F-R-L）
3.Button power control: Long press button for 6 seconds and then short
press button to change power level 25mw/100mw/200mw/ 350mw:

18
www.hglrc.com
3.VTX serial port opens. The protocol is selected according to its
own VTX protocol.

19
www.hglrc.com
4.Use OSD to adjust VTX
which displays information like battery voltage and mAh consumed while you fly. In addition, the
Betaflight OSD can be used to configure the quadcopter, making in-field adjustments and tuning more
convenient.
MODE2 MODE1
The graphics above show the stick command to bring up the OSD menu. The stick command is: throttle
centered, yaw left, pitch forward. The exact stick command therefore depends on which mode your
transmitter sticks are in.
In the OSD menu, use pitch up/down to move the cursor
between menu items. When a menu option has a > symbol
to the right of it, this indicates that it contains a sub-menu.
Roll-right will enter the sub-menu. For example, in the
screen to the right, moving the cursor to “Features” and
then moving the roll stick to the right will enter the
“Features” sub-menu.
If you are using a video transmitter that supports remote
configuration, enter the “Features” menu to configure the
vTX. From there, enter either “VTX SA” if you are using
SmartAudio (TBS Unify) or “VTX TR” if you are using IRC
Tramp Telemetry.
To adjust PIDs, rates, and other tuning-related parameters,
enter the “Profile” sub-menu.
In the “Scr Layout” sub-menu, you can move the OSD
elements (like battery voltage, mAh, and so forth) around on
the screen.
The “Alarms” sub-menu lets you control when the OSD will
try to alert you that battery voltage is too low or mAh
consumed is too high.

20
www.hglrc.com
When a parameter can be modified, the parameter’s current
value will be shown on the right-hand side of the screen. In
this case, roll left/right will adjust the parameter up and
down.
The screen to the right shows the current vTX settings. From
here, you can change the frequency band, channel, and
power level of the video transmitter. After making the
changes, move the cursor to “Set” and press roll-right to
confirm the settings.
12.GPS parameters setting
1. GPS connection diagram
2. Open the GPS serial port
